1. The System Security for green hand on Linux OS 2017/02/12, Hsinchu, DigitalOcean Hsinchu Presenter: Samina
2. ◎ National Chiao Tung University, Taiwan ◦ Wireless Internet Laboratory ◦ Department of Computer Science ◦ Information Technology Service Center Network & System Engineer ◎ Familiar with python, mysql, git, linux ◎ You can find me at: https://www.worldplay.com.tw Twitter & GitHub (@sufuf3) Monisan 2
4. How to Protecte host 4
5. How to Protecte host 5
6. What is the brute-force attack? ◎ A brute force attack uses a large volume of requests/responses to break into a system. ◎ The attacker try many method to guess the response to a challenge or a request. 6
7. How to Protect 7
8. Outline ◎ Introduction ◎ Install ◎ Configure ◎ Individual Jail Settings ◎ Testing the Banning Policies ◎ How to Unblock IP 8
9. Outline ◎ Introduction ◎ Install ◎ Configure ◎ Individual Jail Settings ◎ Testing the Banning Policies ◎ How to Unblock IP 9
10. Introduction ◎ Scans log files and bans IPs that show the malicious signs -- too many password failures, seeking for exploits, etc. ◎ Generally Fail2Ban is used to update firewall rules to reject the IP addresses for a specified amount of time. ◎ Able to reduce the rate of incorrect authentications attempts. 10
11. Outline ◎ Introduction ◎ Install ◎ Configure ◎ Individual Jail Settings ◎ Testing the Banning Policies ◎ How to Unblock IP 11
12. Install (1) ◎ Ubuntu: ◦ apt-get install fail2ban ◎ CentOS: ◦ yum install fail2ban 12
13. Install (2) 13 $ sudo service fail2ban status * Status of authentication failure monitor * fail2ban is running $ sudo fail2ban-client status Status |- Number of jail: 1 `- Jail list: ssh
14. Outline ◎ Introduction ◎ Install ◎ Configure ◎ Individual Jail Settings ◎ Testing the Banning Policies ◎ How to Unblock IP 14
15. Configure (1) ◎ the configuration files directory ◦ /etc/fail2ban 15 $ ls -al total 56 drwxr-xr-x 6 root root 4096 Feb 11 18:15 . drwxr-xr-x 99 root root 4096 Feb 7 08:35 .. drwxr-xr-x 2 root root 4096 Feb 7 08:35 action.d -rw-r--r-- 1 root root 1525 Nov 13 2013 fail2ban.conf drwxr-xr-x 2 root root 4096 Nov 18 2013 fail2ban.d drwxr-xr-x 2 root root 4096 Feb 11 18:08 filter.d -rw-r--r-- 1 root root 11937 Feb 10 20:32 jail.conf drwxr-xr-x 2 root root 4096 Nov 18 2013 jail.d
16. Configure (2) - fail2ban.conf ◎ fail2ban.conf 16
17. Configure (3) - jail.conf (1) ◎ Cause the file would modified by package upgrades, we need copy it so that we can make our changes safely. 17 jail.conf jail.local default options wish to override Copy
18. Configure (4) - jail.conf (2) ◎ jail.conf ◦ Typing the following: 18 awk '{ printf "# "; print; }' /etc/fail2ban/jail.conf | sudo tee /etc/fail2ban/jail.local
19. Configure (5) - jail.conf (3) • sudo vim /etc/fail2ban/jail.conf • [DEFAULT] ◦ ignoreip ▪ add additional addresses that fail2ban ignores, separated by a space. ◦ bantime ▪ sets length of time that a client will be banned when they have failed to authenticate correctly. (second) 19
20. Configure (6) - jail.conf (4) • sudo vim /etc/fail2ban/jail.conf • the client can tries how many times in findtime. • [DEFAULT] ◦ findtime - how long that a client has to authenticate within a window. (second) ◦ maxretry - the client can tries how many times 20
21. Configure (7) - jail.conf (5) • sudo vim /etc/fail2ban/jail.conf • [DEFAULT] • if you want to receive the alerts by email. ◦ destemail - the email of recipient who should receive ban messages. ◦ sendername - the value of the "From" field in the email ◦ mta - mail service ◦ action - there are three choice: 21 action_ ban action_mw ban & send an e-mail with whois report action_mwl ban & send an e-mail with whois report and relevant log lines
22. Outline ◎ Introduction ◎ Install ◎ Configure ◎ Individual Jail Settings ◎ Testing the Banning Policies ◎ How to Unblock IP 22
23. Individual Jail Settings (1) ◎ if you want to enable ◦ uncommenting the header of the section ◦ changing the enabled line to be "true" 23
24. Individual Jail Settings (2) ◎ you can see what kind of filters are available by looking the directory: ◦ /etc/fail2ban/filter.d 24 $ ls /etc/fail2ban/filter.d/
25. Remember if you modify any configoration, you need to restart the fail2ban service. 25 $ sudo service fail2ban restart
26. Outline ◎ Introduction ◎ Install ◎ Configure ◎ Individual Jail Settings ◎ Testing the Banning Policies ◎ How to Unblock IP 26
27. Testing the Banning Policies ◎ SSH ◎ mysqld-auth 27
28. SSH (1) 28 Server Attacker
29. SSH (2) 29 Server Attacker $ ssh username@server_IP The authenticity of host 'server_IP (server_IP)' can't be established. ECDSA key fingerprint is SHA256:DpIDl7AZU........yUMzXq+0lvPGHo2GA. Are you sure you want to continue connecting (yes/no)? yes Warning: Permanently added 'server_IP' (ECDSA) to the list of known hosts. username@server_IP's password: Permission denied, please try again. username@server_IP's password: Permission denied, please try again. username@server_IP's password: Permission denied (publickey,password). $ ssh username@server_IP username@server_IP's password: Permission denied, please try again. username@server_IP's password:
30. SSH (3) 30 Server Attacker $ sudo tail -f /var/log/fail2ban.log 2017-02-10 20:03:11,437 fail2ban.server : INFO Exiting Fail2ban 2017-02-10 20:03:12,166 fail2ban.server : INFO Changed logging target to /var/log/fail2ban.log for Fail2ban v0.8.11 2017-02-10 20:03:12,167 fail2ban.jail : INFO Creating new jail 'ssh' 2017-02-10 20:03:12,203 fail2ban.jail : INFO Jail 'ssh' uses pyinotify 2017-02-10 20:03:12,239 fail2ban.jail : INFO Initiated 'pyinotify' backend 2017-02-10 20:03:12,241 fail2ban.filter : INFO Added logfile = /var/log/auth.log 2017-02-10 20:03:12,243 fail2ban.filter : INFO Set maxRetry = 6 2017-02-10 20:03:12,245 fail2ban.filter : INFO Set findtime = 600 2017-02-10 20:03:12,246 fail2ban.actions: INFO Set banTime = 600 2017-02-10 20:03:12,319 fail2ban.jail : INFO Jail 'ssh' started 2017-02-10 20:06:28,496 fail2ban.actions: WARNING [ssh] Ban attacker_IP
31. SSH (4) 31 Server Attacker $ sudo fail2ban-client status ssh Status for the jail: ssh |- filter | |- File list: /var/log/auth.log | |- Currently failed: 1 | `- Total failed: 16 `- action |- Currently banned: 2 | `- IP list: 14.189.180.193 attacker_IP `- Total banned: 2
32. SSH (5) 32 Server Attacker
33. mysqld-auth (1) 33 Server Attacker
34. mysqld-auth (2) 34 Server Attacker $ mysql -u root -h server_IP -p Enter password: ERROR 1045 (28000): Access denied for user 'root'@'attacker_IP' (using password: NO) $ mysql -u root -h server_IP -p Enter password: ERROR 1045 (28000): Access denied for user 'root'@'attacker_IP' (using password: NO) $ mysql -u root -h server_IP -p Enter password: ERROR 1045 (28000): Access denied for user 'root'@'attacker_IP' (using password: NO) ... $ mysql -u root -h server_IP -p Enter password: ERROR 1045 (28000): Access denied for user 'root'@'attacker_IP' (using password: NO) $ mysql -u root -h server_IP -p Enter password: ERROR 2003 (HY000): Can't connect to MySQL server on 'server_IP' (111)
35. mysqld-auth (3) 35 Server Attacker $ sudo tail -f /var/log/fail2ban.log 2017-02-11 18:07:17,257 fail2ban.actions: WARNING [mysqld-auth] Ban attacker_IP $ sudo tail -f /var/log/mysql/error.log 170211 18:07:14 [Warning] Access denied for user 'root'@'attacker_IP' (using password: YES) ... 170211 18:07:16 [Warning] Access denied for user 'root'@'attacker_IP' (using password: YES)
36. mysqld-auth (4) 36 Server Attacker $ sudo fail2ban-client status mysqld-auth Status for the jail: mysqld-auth |- filter | |- File list: /var/log/mysql/error.log | |- Currently failed: 0 | `- Total failed: 43 `- action |- Currently banned: 1 | `- IP list: attacker_IP `- Total banned: 2
37. mysqld-auth (5) 37 Server Attacker
38. Outline ◎ Introduction ◎ Install ◎ Configure ◎ Individual Jail Settings ◎ Testing the Banning Policies ◎ How to Unblock IP 38
39. How to Unblock IP 39 $ sudo fail2ban-client set ssh unbanip attacker_IP
40. Thank You Q & A 40
41. References (1) ◎ Fail2ban ◦ http://www.fail2ban.org/wiki/index.php/Main_Page ◎ How To Protect SSH with Fail2Ban on Ubuntu 14.04 ◦ https://www.digitalocean.com/community/tutorials/how- to-protect-ssh-with-fail2ban-on-ubuntu-14-04 41
42. References (2) ◎ 《分享》Ubuntu安裝fail2ban ◦ http://www.shunze.info/forum/thread.php?threadid=188 9&boardid=3&sid=e1e02be23bf8adf2ba4bf92be652791 b ◎ CentOS安裝fail2ban記事 ◦ http://blog.pulipuli.info/2011/07/centosfail2ban.html 42
