Transcript

  1. .PUP*TIJ[BXB
    ,BONV *OD
    4IBSJOHUFTUDBTFTPGJOUFSOFUQSPUPDPMT
    XJUI(PBOE0$*"SUJGBDUT

    View full-size slide

  2. Moto Ishizawa
    Software Engineer, Kanmu, Inc.

    View full-size slide

  3. We are hiring!
    https://kanmu.co.jp/jobs/

    View full-size slide

  4. Problems in implementing HTTP/2 server
    • Writing tests requires a deep understanding of the HTTP/2 speci
    fi
    cation

    • Many implementors are writing similar tests for their own implementations

    • Di
    ff
    erent programming languages make it di
    ffi
    cult to share tests between
    implementations

    View full-size slide

  5. h2spec
    • A conformance testing tool for HTTP/2 server

    • Written in Go as a command line tool

    • Used by many HTTP/2 server implementors :)

    View full-size slide

  6. What is conformance testing tool?
    • Send data to the server according to the speci
    fi
    cation

    • Check the response from the server to make sure it complies with the
    speci
    fi
    cation

    • In HTTP/2, it is mainly tested by sending frames
    􀧘
    􀏜
    HTTP/2 Server
    h2spec
    Send frames
    Check response

    View full-size slide

  7. Why Go?
    • Easy to implement command-line tools that work on multiple OS

    • Single binary!

    • O
    ffi
    cial HTTP/2 package was available early

    View full-size slide

  8. Challenges in h2spec
    • Knowledge of Go is required to add or change test cases

    • Even if you want to change a part of the test, you need to rebuild it

    • Di
    ffi
    cult to cover all implementation di
    ff
    erences…

    • Want to test other protocols as well (QUIC, TLS v1.3, etc…)

    View full-size slide

  9. protospec
    • A general-purpose conformance testing tool implemented in Go

    • Easy to write test cases in YAML format

    • Test cases can be easily shared as OCI Artifacts

    • https://github.com/summerwind/protospec

    View full-size slide

  10. Writing conformance test case with YAML (1/8)
    A client MUST send the connection preface (Section 3.5)
    and then MAY immediately send HTTP/2 frames to such a server;
    servers can identify these connections by the presence of the
    connection preface.
    RFC7540 - Hypertext Transfer Protocol Version 2 (HTTP/2)

    View full-size slide

  11. Writing conformance test case with YAML (2/8)
    Multiple tests can be de
    fi
    ned in a single

    YAML
    fi
    le

    View full-size slide

  12. Writing conformance test case with YAML (3/8)
    De
    fi
    ne title and description of test

    View full-size slide

  13. Writing conformance test case with YAML (4/8)
    A single test consists of multiple steps

    View full-size slide

  14. Writing conformance test case with YAML (5/8)
    Send connection preface

    View full-size slide

  15. Writing conformance test case with YAML (6/8)
    Send SETTINGS frame

    View full-size slide

  16. Writing conformance test case with YAML (7/8)
    Wait for receiving of SETTINGS frame

    View full-size slide

  17. Writing conformance test case with YAML (8/8)

    View full-size slide

  18. Sharing test cases as container images
    • Test cases can be shared like docker containers

    • pushes the test cases to the registry, pulls
    them from the registry

    • Thanks to OCI Artifacts!
    protospec push protospec pull

    View full-size slide

  19. What is OCI Artifacts?
    • A mechanism for storing arbitrary
    fi
    les in a container image

    • One of the ways to use OCI Distribution and OCI Image, not a speci
    fi
    cation

    • Many container registries (ECR, GitHub, etc…) are supported

    • Used by Helm and Open Policy Agent to manage their con
    fi
    guration
    fi
    les

    • https://github.com/opencontainers/artifacts

    View full-size slide

  20. Using OCI Artifacts in your code
    • ORAS makes it easy to support OCI Artifacts in your code

    • ORAS is a command line tool, but can also be used as a package

    • https://github.com/deislabs/oras

    View full-size slide

  21. Pushing artifacts to the registry (1/4)
    Importing the ORAS package

    View full-size slide

  22. Pushing artifacts to the registry (2/4)
    Creating a docker client
    Resolver will be used to resolve the name of the container image

    View full-size slide

  23. Pushing artifacts to the registry (3/4)
    Adding a
    fi
    le to the memory store

    View full-size slide

  24. Pushing artifacts to the registry (4/4)
    Pushing the contents of the memory store to the container registry
    Name of container image to push

    View full-size slide

  25. Pulling artifacts from the registry (1/2)
    Create a
    fi
    le store and map it to ‘spec’ directory

    View full-size slide

  26. Pulling artifacts from the registry (2/2)
    Pulling the container image and extract it to the
    fi
    le store
    Name of container image to pull

    View full-size slide

  27. Conclusion
    • protospec enables sharing of test cases for conformance testing

    • Go is a good language for implementing command line tools!

    • ORAS makes it possible to use OCI Artifacts in your Go code
