Travis and Fastlane

Travis and Fastlane

A brief introduction of travis and fastlane setup for iOS project in Cocoaheads Taipei

Steven Shen

July 10, 2015
Tweet

More Decks by Steven Shen

Other Decks in Technology

Transcript

  1. TRAVIS CI

    View Slide

  2. % git add
    % git commit
    % git push
    Service hook
    Mac VM
    Xcode
    • Build
    • Test
    • Deploy
    • Notify

    View Slide

  3. Setup
    Availability
    Speed
    Easy Manual
    Cloud Private network
    Depends
    Medium
    Trouble shooting Hard Easy
    Cost
    Free for open source
    …..
    $129/month for private
    repo

    View Slide

  4. Setup
    % gem install travis
    % vim .travis.yml
    language: objective-c
    script:
    - make
    notifications:
    email: false

    View Slide

  5. all:
    xcodebuild -arch "i386" -configuration
    "Debug" -sdk "iphonesimulator" build |
    xcpretty

    View Slide

  6. Code Sign
    • Encrypt your keys, certificates, and provisioning
    profiles.
    • Commit encrypted files to github
    • Decrypt and install before build

    View Slide

  7. % openssl aes-256-cbc -k "foo" -in certs/dist.cer -out certs/dist.cer.enc -a
    % openssl aes-256-cbc -k "foo" -in certs/dist.p12 -out certs/dist.p12.enc -a
    % openssl aes-256-cbc -k "foo" -in certs/dev.cer -out certs/dev.cer.enc -a
    % openssl aes-256-cbc -k "foo" -in certs/dev.p12 -out certs/dev.p12.enc -a
    % openssl aes-256-cbc -k “foo” -in certs/AppStore.mobileprovision -out certs/AppStore.mobileprovision.enc -a
    % openssl aes-256-cbc -k “foo” -in certs/AdHoc.mobileprovision -out certs/AdHoc.mobileprovision.enc -a
    before_script:
    - openssl aes-256-cbc -k "$SECRET" -in certs/AdHoc.mobileprovision.enc -d -a -out certs/AdHoc.mobileprovision
    - openssl aes-256-cbc -k "$SECRET" -in certs/AppStore.mobileprovision.enc -d -a -out certs/AppStore.mobileprovision
    - openssl aes-256-cbc -k "$SECRET" -in certs/dist.cer.enc -d -a -out certs/dist.cer
    - openssl aes-256-cbc -k "$SECRET" -in certs/dist.p12.enc -d -a -out certs/dist.p12
    - openssl aes-256-cbc -k "$SECRET" -in certs/dist.cer.enc -d -a -out certs/dist.cer
    - openssl aes-256-cbc -k "$SECRET" -in certs/dist.p12.enc -d -a -out certs/dist.p12
    Encrypt
    Decrypt
    Export

    View Slide

  8. % travis encrypt “SECRET=foo” --add
    env:
    global:
    - secure: eLo92Sw8KejuadMDTgY
    +bMAPow3D4zqkhBqXm8oUDctZn3qOJ5iJgMrNxfhSUx+AX/
    jiT07+U0vicHWRjGtkIGBeZJ8FVJL7NZQbIbqa80g0+MT4CNk4bumUphY0
    w+OOzsY8V4OKR90mUmzz3bVN8/ROFBZygeYBdiLnmhoQ93E=
    - secure: fGoTHN29GtCiux/
    aGJ2wm3NYtbyIRh0vnfoJafYdzWC6lj0PWrv0KVF31rHA56f7wPVLFnLrx
    2UhNzZHfMaavD9QSGVYNOcE2AVXuaRWnMrKmCjAkCW/7qnePwxcgcQTV
    +zQJTV523G4nDbWQMoQ9wugzTsxhj+Ob+ZF0cGEXUA=
    Use command line

    View Slide

  9. #!/bin/sh
    # create keychain
    security create-keychain -p travis ios-build.keychain
    security default-keychain -s ios-build.keychain
    security unlock-keychain -p travis ios-build.keychain
    security set-keychain-settings -t 3600 -l ~/Library/Keychains/ios-
    build.keychain
    # Certificate & Private key
    security import ./certs/cert.cer -k ~/Library/Keychains/ios-
    build.keychain -T /usr/bin/codesign
    security import ./certs/key.p12 -k ~/Library/Keychains/ios-
    build.keychain -P "$KEY_PASSWORD" -T /usr/bin/codesign
    # Provisioning profiles
    mkdir -p ~/Library/MobileDevice/Provisioning\ Profiles
    cp "./certs/AppStore.mobileprovision" ~/Library/MobileDevice/
    Provisioning\ Profiles/
    cp "./certs/AdHoc.mobileprovision" ~/Library/MobileDevice/
    Provisioning\ Profiles/

    View Slide

  10. language: objective-c
    osx_image: xcode6.4
    before_install:
    - gem install fastlane
    before_script:
    - openssl aes-256-cbc -k "$SECRET" -in certs/EMQAppStore.mobileprovision.enc -d -a -out certs/
    EMQAppStore.mobileprovision
    - openssl aes-256-cbc -k "$SECRET" -in certs/EMQDev.mobileprovision.enc -d -a -out certs/
    EMQDev.mobileprovision
    - openssl aes-256-cbc -k "$SECRET" -in certs/cert.cer.enc -d -a -out certs/cert.cer
    - openssl aes-256-cbc -k "$SECRET" -in certs/dev-cert.cer.enc -d -a -out certs/dev-cert.cer
    - openssl aes-256-cbc -k "$SECRET" -in certs/key.p12.enc -d -a -out certs/key.p12
    - openssl aes-256-cbc -k "$SECRET" -in certs/dev-key.p12.enc -d -a -out certs/dev-key.p12
    - sh ./certs/install-keys.sh
    script:
    - make
    podfile: iOSApp/Podfile
    notifications:
    email: false
    slack: emq-inc:kPgGUXItHsgRsNtc77Fz3f3P
    env:
    global:
    - secure: OqyOY/I8QoucKb4uWY9xu9pkXgFoTahqiRl3BLOCJEbgKMKoUyDnk7N/ALktHp2S/NuB4zj5PNA50Lhb/
    zAnI7cTgZT0qEDJv2yDIM/j0wQFEHbKQafEHDWj2vAnook8OBpXiiykqWIb1dKgXCjzcEDjxhSo5V6V5IsdFHVAAew=
    - secure: gAw0juDvfHolj0zg93f2qnCFBxetvFIBTsMCgHMzStk0DyKrsh4IV
    +1x2CCqSFWo5q4EbXmsKKeyQKqfreIbbQTmZkAmXjIiVg70LDVgsqk5COWUTRgn21pUGWUFosxAkSZZghEf0o3Z62jA6FgeJkCkP
    cSLszuE0Qlbiq0SFSw=
    - secure: eLo92Sw8KejuadMDTgY+bMAPow3D4zqkhBqXm8oUDctZn3qOJ5iJgMrNxfhSUx+AX/
    jiT07+U0vicHWRjGtkIGBeZJ8FVJL7NZQbIbqa80g0+MT4CNk4bumUphY0w+OOzsY8V4OKR90mUmzz3bVN8/
    ROFBZygeYBdiLnmhoQ93E=
    - secure: fGoTHN29GtCiux/
    aGJ2wm3NYtbyIRh0vnfoJafYdzWC6lj0PWrv0KVF31rHA56f7wPVLFnLrx2UhNzZHfMaavD9QSGVYNOcE2AVXuaRWnMrKmCjAkCW
    /7qnePwxcgcQTV+zQJTV523G4nDbWQMoQ9wugzTsxhj+Ob+ZF0cGEXUA=

    View Slide

  11. View Slide

  12. View Slide

  13. xcodebuild -arch "i386" -configuration "Debug" -
    sdk "iphonesimulator" build | xcpretty
    fastlane build

    View Slide

  14. Setup
    % sudo gem install fastlane
    % fastlane init
    % vim fastlane/Appfile
    % vim fastlane/Fastfile

    View Slide

  15. def unit_test
    xctest(
    workspace: 'EMQ.xcworkspace',
    scheme: 'EMQ-Demo',
    configuration: 'Demo',
    sdk: "iphonesimulator",
    arch: "i386",
    reports:[{
    report: 'html',
    output: './test-report.html'
    }]
    )
    slack(
    message: 'EMQ iOS App Unit Test',
    channel: '#dev-ios',
    default_payloads: [:test_result, :git_branch, :git_author, :last_git_commit],
    )
    end
    before_all do
    ENV["SLACK_URL"] = "https://hooks.slack.com/services/ABCDEFG/ABCDEFG/ABCDEFG"
    clean_build_artifacts
    cocoapods
    end

    View Slide

  16. lane :deliver_demo do
    #increment_build_number
    sigh
    xcodebuild(
    workspace: 'EMQ.xcworkspace',
    configuration: 'Demo',
    scheme: 'EMQ-Demo',
    identity: 'iPhone Distribution: EMQ Limited (28HUT34N52)',
    clean: true
    )
    unit_test
    xcarchive(
    workspace: 'EMQ.xcworkspace',
    configuration: 'Demo',
    scheme: 'EMQ-Demo',
    embed: '../certs/EMQAppStore.mobileprovision',
    identity: 'iPhone Distribution: EMQ Limited (28HUT34N52)'
    )
    xcexport
    resign(
    ipa: 'EMQ-Demo.ipa',
    signing_identity: 'iPhone Distribution: EMQ Limited (28HUT34N52)',
    provisioning_profile: '../certs/EMQAppStore.mobileprovision',
    )
    testflight(skip_deploy: true)
    end

    View Slide

  17. View Slide

  18. all:
    ifeq ($(TRAVIS_PULL_REQUEST), false)
    fastlane test
    else
    agvtool new-version -all $(TRAVIS_BUILD_NUMBER)
    fastlane deliver_demo
    endif

    View Slide

  19. xcodebuild -arch "i386" -configuration
    "Debug" -sdk "iphonesimulator" build |
    xcpretty
    fastlane build
    Trouble shooting

    View Slide

  20. View Slide

  21. • Easy setup
    • No maintenance
    • Github integration
    • Bad for trouble shooting
    • Automate your flows
    • Flexible, customizable
    • Life saver
    • Great for CI

    View Slide
