Kubic - openSUSEs Container Starship

Richard Brown
February 21, 2018

Kubic - openSUSEs Container Starship

Containers, Containers, Containers - The world seems to be going container crazy. openSUSE has a strong heritage with containers, being one of the first distributions to support lxc, but as time has moved on it's become more apparent that traditional, general purpose, operating systems provide as many problems for running containers as they solve.

Container admins need an operating system platform that can provide their container runtime (Docker, Cri-O, etc) and their container orchestration tooling (Kubernetes, etc), and then generally get out of their way, so they can focus on the containers and their contents.

Requirements include absolutely fully automatic updates,while updating far more often than a traditional enterprise distribution (to get the latest from this fast moving ecosystem), all the while never breaking, or at least automatically rolling back to a working state if it does.

Impossible? Some say so, CoreOS and Red Hat have taken the route of re-inventing wheels with their Container Linux & Red Hat Atomic systems.

openSUSE takes a different route. This talk introduces Kubic, details how it is the perfect operating system for running container workloads, explore how it leverages our existing expertise in rolling releases, btrfs, snapshots, and rollbacks, and explains how it forms the base of SUSE's commercial Container as a Service Platform.

Richard Brown

February 21, 2018
Tweet

More Decks by Richard Brown

Other Decks in Programming

Transcript

  1. Richard Brown
    openSUSE Chairman
    [email protected]
    Kubic Project
    openSUSE’s Container Starship, going where no
    distribution has gone before

    View full-size slide

  2. Topics

    What is the Kubic Project?

    The Problem with Traditional Distributions

    Transactional Updates In Detail

    MicroOS – *SUSE enters the Atomic-Era

    Cool Things you can do with MicroOS Today

    Just the Beginning – Kubic as a Container Service Platform

    View full-size slide

  3. Kubic Project

    Founded in May 2017

    Sub-Project of the openSUSE Project

    Focused on Container Technologies incl:
    – MicroOS, Tumbleweed-based Cluster Host OS
    – Velum, Kubernetes Cluster Bootstrapper & MicroOS Cluster
    Dashboard

    Upstream of SUSE Container as a Service Platform (CaaSP)

    View full-size slide

  4. Why?

    Application delivery is changing
    – Containers
    – Flatpak/snaps/AppImage

    View full-size slide

  5. Why?

    Micro-Services are fun
    – Why bother with complex installations when
    someone else's solution is a docker pull away?
    – VMs are comparably resource and management
    heavy
    – Lots of positive momentum behind containers,
    but tools are lacking

    View full-size slide

  6. Why?

    Containers are disruptive
    – Diferent requirements from the OS
    – Faster delivery expectations
    – Portability increases support demands
    – Containerized clusters want to run at scale

    View full-size slide

  7. Why?

    Setting up a container host should be easy
    – No point saving time with containers just to
    waste it administering a machine
    – Containers should take care of themselves, why
    can’t the host system?

    View full-size slide

  8. The Problem with
    Traditional Distributions

    View full-size slide

  9. “I NEVER want to touch a running system”
    - Every SysAdmin, ever

    View full-size slide

  10. Upgrading a Running System Is DANGEROUS

    Services are running

    Users are doing things

    Sofware changes things (sometimes on purpose!)

    Not all packages are packaged properly (sorry)

    View full-size slide

  11. Reality does not make things easy
    Rolling Releases bring larger challenges

    Intrusive Updates (SysV init → systemd)

    Major version updates of complex stacks (GNOME, KDE)

    What should I do if the update breaks my system?

    View full-size slide

  12. Reality does not make things easy
    Critical Mission Systems are even worse

    Update should not interrupt services
    Service interruption more expensive than regular reboots

    Updates need to be fully applied perfectly, or no changes made
    System state should never be undefined/questionable
    RPM post-installation scripting can lead to an undefined state

    View full-size slide

  13. Traditional Snapshots – An Imperfect Solution
    curr.
    root ro
    ro ro ro

    View full-size slide

  14. Traditional Snapshots – An Imperfect Solution
    curr.
    root ro
    ro ro ro ro
    ro-Clone 1

    View full-size slide

  15. Traditional Snapshots – An Imperfect Solution
    curr.
    root ro
    ro ro ro ro
    ro-Clone 1
    zypper up
    2

    View full-size slide

  16. Transactional Updates

    View full-size slide

  17. What is a Transactional Update?
    An Update that:

    Is Atomic
    – Either fully applied, or not at all
    – Update does not influence the running system

    Can be rolled back
    – A failed or incompatible update can be quickly discarded to
    restore the previous system conditions

    View full-size slide

  18. Other Solutions

    Several Diferent Partitions
    – Waste of Disk Space

    Special package formats (rpm-ostree, snap, etc)
    – Need to learn something new
    – Can’t re-use existing packages
    → And you need to redesign systems, tools & company
    policies

    View full-size slide

  19. All you need

    btrfs root filesystem with snapshots/rollback enabled

    snapper

    zypper (or package manager of your choice)

    btrfsprogs

    View full-size slide

  20. Traditional Snapshots
    curr.
    root ro
    ro ro ro

    View full-size slide

  21. Transactional Updates
    ro
    ro ro ro
    curr.
    root

    View full-size slide

  22. ro
    Transactional Updates
    ro
    ro ro ro
    curr.
    root
    1
    ro-Clone

    View full-size slide

  23. Transactional Updates
    ro
    ro ro ro
    curr.
    root rw
    1
    ro-Clone
    2
    Change rw

    View full-size slide

  24. Transactional Updates
    ro
    ro ro ro
    curr.
    root rw
    1
    ro-Clone
    2
    Change rw
    3
    zypper up

    View full-size slide

  25. Transactional Updates
    ro
    ro ro ro
    curr.
    root ro
    1
    ro-Clone
    2
    Change rw
    3
    zypper up
    Change ro 4

    View full-size slide

  26. Transactional Updates
    ro
    ro ro ro
    curr.
    root
    New
    root
    1
    ro-Clone
    2
    Change rw
    3
    zypper up
    Change ro
    5
    “Rollforward” btrfs subvol set-default
    4

    View full-size slide

  27. Transactional Updates – Afer Reboot
    ro
    ro ro ro
    curr.
    root
    ro

    View full-size slide

  28. Transactional Updates – without Reboot
    ro
    ro ro ro
    curr.
    root
    ro ro
    New
    root

    View full-size slide

  29. How to do transactional updates

    transactional-update [up|dup|patch]

    transactional-update pkg [install|remove|update] $PKG1..$PKGN
    – Install anything you’d like

    BONUS: transactional-update shell

    View full-size slide

  30. Transactional Updates – Rollback
    ro
    ro ro ro
    curr.
    root
    New
    root
    1
    Rollback btrfs subvol set-default

    View full-size slide

  31. Advantages

    btrfs:
    – Snapshots with CoW are space eficient
    – Deduplication possible
    – btrfs send/receive – update with golden images

    rpm:
    – Existing packages can be used
    – No need to learn new tools, policies remain valid

    View full-size slide

  32. Advantages, cont.

    Normal boot time

    Very quick rollback

    View full-size slide

  33. Disadvantages

    Currently limited to btrfs only

    Special requirements of RPMs
    – Care needs to be made that files are in the right place
    – User data & configuration should be converted on use, not
    during package install

    Reboot needed to activate changes

    View full-size slide

  34. Dealing with Configuration Files

    rootfs snapshots always contain package-provided files for /etc

    overlayfs used to transparently store/overlay user-provided
    files for /etc

    View full-size slide

  35. openSUSE MicroOS

    openSUSE Tumbleweed-derivative utilising transactional-
    updates & read-only rootfs

    Docker installed and enabled by default (for now)

    Download/Install from
    https://sofware.opensuse.org/distributions/tumbleweed

    View full-size slide

  36. Diferences from Tumbleweed

    Update using transactional-update dup

    Install/Remove packages using transactional-update pkg
    install|remove

    View full-size slide

  37. MicroOS Today

    View full-size slide

  38. MicroOS Example Use Cases

    Containers
    – docker
    – runc
    – lxc
    – cri-o

    View full-size slide

  39. MicroOS Example Use Cases

    View full-size slide

  40. MicroOS Example Use Cases

    Rolling Server – Use the latest of everything with no risk
    – Web (esp. NodeJS, Ruby, etc)
    – Virtualisation host
    – Media Server

    View full-size slide

  41. MicroOS on Raspberry Pi3

    View full-size slide

  42. Kubic Desktop

    View full-size slide

  43. Kubic Desktop
    https://rootco.de/2017-11-16-hackweek-2017-conclusion/

    View full-size slide

  44. Kubic Container Service
    Platform

    View full-size slide

  45. Why?

    Setting up a container host should be easy
    – No point saving time with containers just to
    waste it administering a machine
    – Containers should take care of themselves, why
    can’t the host system?

    View full-size slide

  46. What’s Next?

    Setting up a container cluster should be easy
    – No point saving time with containers just to
    waste it administering a cluster of machines
    – Containers should take care of themselves, why
    can’t the cluster?
    – Cluster admins should be able to seemlessly
    bootstrap, monitor and upgrade whole clusters
    at once

    View full-size slide

  47. Kubic Container Service Architecture
    Cluster Nodes
    (etcd + Kubernetes Master)
    Log Server
    Administration Node

    View full-size slide

  48. Current Status

    “Unconfigured Cluster Node” - fully supported system-role in
    Kubic

    Can be used to setup a Kubernetes Cluster Manually

    https://kubernetes.io/docs/getting-started-guides/scratch/
    #bootstrapping-the-cluster

    View full-size slide

  49. Current Status

    Velum & related “Container-as-a-Service Platform” containers are not
    working yet

    Contributions welcome

    https://github.com/kubic-project/container-images

    Alternatives being investigated
    – OpenShif
    – kubeadm

    View full-size slide

  50. Join Us at www.opensuse.org

    View full-size slide

  51. License
    This slide deck is licensed under the Creative Commons Attribution-ShareAlike 4.0 International license.
    It can be shared and adapted for any purpose (even commercially) as long as Attribution is given and any
    derivative work is distributed under the same license.
    Details can be found at https://creativecommons.org/licenses/by-sa/4.0/
    General Disclaimer
    This document is not to be construed as a promise by any participating organisation to develop, deliver, or
    market a product. It is not a commitment to deliver any material, code, or functionality, and should not be
    relied upon in making purchasing decisions. openSUSE makes no representations or warranties with respect
    to the contents of this document, and specifically disclaims any express or implied warranties of
    merchantability or fitness for any particular purpose. The development, release, and timing of features or
    functionality described for openSUSE products remains at the sole discretion of openSUSE. Further,
    openSUSE reserves the right to revise this document and to make changes to its content, at any time,
    without obligation to notify any person or entity of such revisions or changes. All openSUSE marks
    referenced in this presentation are trademarks or registered trademarks of SUSE LLC, in the United States
    and other countries. All third-party trademarks are the property of their respective owners.
