1. Mach-O Mach-O
   03.6.19 Tommaso Piazza - @tmpz https://github.com/blender 1
   From code to binary


   View Slide

2. Wait… but why?
   • Apps are Mach-O binaries
   • Binary frameworks
   • Carthage/Cocoapods errors
   • Get out of problems when things go south
   03.6.19 Tommaso Piazza - @tmpz https://github.com/blender 2
   Undefined symbols for architecture x86_64:
   "_thisWillTotallyBeThere", referenced from:
   _main in trust-me-c9e7ba.o
   ld: symbol(s) not found for architecture x86_64
   clang: error: linker command failed with exit code 1 (use -v to see
   invocation)
   dyld: Library not loaded:
   @rpath/Alamofire.framework/Alamofire
   Referenced from:
   /private/var/mobile/Containers/Bundle/Application/...
   Reason: image not found


   View Slide

3. What is Mach-O
   used for?
   03.6.19
   • Executables (/bin/ls)
   • Relocatable object files ( .o)
   • Static libraries (.a)
   • Dynamic Libraries (.dylib)
   • Desymbolication files (.dSYM)
   • Bundles (.bundles)
   • Core dumps (stack traces)
   Tom m aso Piazza - @ tm pz https://github.com /blender 3


   View Slide

4. 03.6.19 Tommaso Piazza - @tmpz https://github.com/blender 4


   View Slide

5. What about
   .framework(s)?
   03.6.19
   • Directory trees with special structure
   • Pack additional resources
   • Info.plist
   • Asset bundles
   • Fonts
   • ….
   • Can be static or dynamic
   Tom m aso Piazza - @ tm pz https://github.com /blender 5


   View Slide

6. How are Mach-O
   files produced?
   03.6.19 Tom m aso Piazza - @ tm pz https://github.com /blender
   14


   View Slide

7. Compiling
   03.6.19 Tommaso Piazza - @tmpz https://github.com/blender 7
   Mach-O
   Image: The Big Nerd Ranch


   View Slide

8. Compiling (2)
   Tom m aso Piazza - @ tm pz https://github.com /blender 03.6.19 8
   • The compiler checks your code
   against .h files
   • Name, arguments, return type
   • References to external
   symbols (functions, variables,
   constant from libraries) left
   undefined
   • Mismatch?


   View Slide

9. Linking
   03.6.19 Tommaso Piazza - @tmpz https://github.com/blender 9
   Image: The Big Nerd Ranch


   View Slide

10. Static Linking
    Tom m aso Piazza - @ tm pz https://github.com /blender 10
    man ld
    • The binary fromthe linked library is copied into the final product
    • No binary share
    • Relatively simple process
    You may knowld for messages like...
    Undefined symbols for architecture x86_64:
    "_thisWillTotallyBeThere", referenced from:
    _main in trust-me-c9e7ba.o
    ld: symbol(s) not found for architecture x86_64
    clang: error: linker command failed with exit code 1 (use -v to see invocation)
    03.6.19


    View Slide

11. Dynamic Linking
    Tom m aso Piazza - @ tm pz https://github.com /blender 11
    man dyld
    • The binary from the linked library is not copied into the final product
    • Binary share
    • Address of symbols resolved at load time
    • Runtime penalty, DYLD_PRINT_STATISTICS_DETAILS=1
    You may know dyld for messages like...
    dyld: Library not loaded: @rpath/Alamofire.framework/Alamofire
    Referenced from: /private/var/mobile/Containers/Bundle/Application/...
    Reason: image not found
    03.6.19


    View Slide

12. Demo
    03.6.19
    Tom m aso Piazza - @ tm pz https://github.com /blender 12


    View Slide

13. From Code to Binary
    Tom m aso Piazza - @ tm pz https://github.com /blender 03.6.19 3


    View Slide

14. Compile & Link Recap
    Tom m aso Piazza - @ tm pz https://github.com /blender 03.6.19 14
    swiftc -c Greeter.swift Colorizer.swift -module-name "Greet"
    swiftc -emit-module Greeter.swift Colorizer.swift -module-name "Greet"
    libtool -static Greeter.o Colorizer.o -o libGreeter.a
    swiftc -c main.swift -L`pwd` -I`pwd` -l`pwd`
    ld main.o -lGreeter -L`pwd` -lswiftCore \
    -L/usr/lib/swift \
    -o hello


    View Slide

15. Mach-O Format
    03.6.19
    Tom m aso Piazza - @ tm pz https://github.com /blender 15
    Single Architecture
    Multiple Architecture


    View Slide

16. Mach-O Header
    • file:///Library/Developer/CommandLineTools/SDKs/MacOSX.sdk/usr/include/mach-o/loader.h
    • How to identify a Mach-O file?
    Tom m aso Piazza - @ tm pz https://github.com /blender 03.6.19
    16


    View Slide

17. Mach-O Header
    • Mach Magic number
    • MH_MAGIC, MH_CIGAM, MH_MAGIC_64, MH_CIGAM_64
    • 0xfeedface , 0xcefaedfe, 0xfeedfacf , 0xcffaedfe
    • Indicator of Endianness and 32 of 64 bit Arch
    • CPU Type
    file:///Library/Developer/CommandLineTools/SDKs/MacOSX.sdk/usr/include/mach/machine.h
    • FileType
    • MH_EXECUTE, MH_DYLIB, MH_DSYM, MH_OBJECT …
    • Read with otool –h (or objdump -macho -private-header)
    Tom m aso Piazza - @ tm pz https://github.com /blender 03.6.19
    17


    View Slide

18. Load Commands
    Tom m aso Piazza - @ tm pz https://github.com /blender 03.6.19
    Contains
    • Information about the Data part of the file
    • Segments LC_SEGMENT_64
    • Sections in each segment
    • Read with
    • otool -l
    Answers
    • Where is the symbol table? LC_SYMTAB,
    • What is the minimum version of the OS?
    LC_VERSION_MIN_IPHONEOS
    • Where is main? LC_MAIN
    • What libraries should be loaded?
    LC_LOAD_DYLIB
    • Where is the code signature?
    LC_CODE_SIGNATURE
    18


    View Slide

19. Symbols
    • LC_SYMTAB (own symbol table)
    • Exported symbols
    • Read with: dsymutil –symtab if you have dsymor nm –Am if not stripped
    • LC_DYSYMTAB (dynamic symbol table, AKA symbols from other files)
    • Can include debug symbol
    • strip –SxXNT
    Tom m aso Piazza - @ tm pz https://github.com /blender 03.6.19
    19


    View Slide

20. FAT header
    03.6.19
    • Multiple architectures packed in one
    file
    • x86_64
    • armv6s
    • armv7
    • otool –f
    • objdump -macho -universal-headers
    Tom m aso Piazza - @ tm pz https://github.com /blender
    file:///Library/Developer/CommandLineTools/SDKs/MacOSX.sdk/usr/include/mach-o/fat.h
    See yourself at:
    20


    View Slide

21. Slimming down FAT files
    • lipo -thin -output
    Tom m aso Piazza - @ tm pz https://github.com /blender 03.6.19
    21


    View Slide

22. Party Trick
    nm –a | grep –w “SO”
    Tom m aso Piazza - @ tm pz https://github.com /blender 03.6.19 222


    View Slide

23. Thanks!
    03.6.19
    Tom m aso Piazza - @ tm pz https://github.com /blender 23
