Essential architectural thinking

Essential architectural thinking

Based on what I see there are tons of advice, opinions and recommendations how to do architectural work. Unfortunately, many of them contradict each other. I think one of the core reasons for this unfortunate situation is that we forgot to ask "Why": Why are we doing architectural work in the first place? What are the goals of architectural work (besides having it done because "it is important")?

Thus, I start this slide deck with the "Why" question and try to answer this question. Based on that answer, I move on to the "What", i.e., what work we need to do in order to satisfy the "Why". Following the "What"-question, I come up with a 4E-model, describing the four pillars of architectural work as I understand it. I complement the 4 pillars with some tools and ideas that I found helpful in my career so far.

Finally, I move on to the "How", or to be more precise to "When to do what and how much of it". There is a widespread tendency to follow only one approach, being more waterfall-like in the past, being more "Agile" today. And these approaches are usually defended with religious zeal.

Unlike the aforementioned tendencies I recommend a different approach: Based on the uncertainty of the project, I prefer different approaches that meet the given situation best.

Therefore, I first explain the effects of uncertainty and how the typical "Agile" implementations fit in there. Then, I derive a range of software development approaches based on the given uncertainty. Finally, I map the architectural work activities on the different development approaches.

Of course, I do not claim that the ideas shared in this slide deck are the ultimate truth (or even close). Instead, you should take it as a, well, "idea", a point of view that you can use, augment or reject as you like.

However, I hope the slides are of some use for you, even if - as always - the voice track is missing.

Uwe Friedrichsen

October 08, 2019
Tweet

More Decks by Uwe Friedrichsen

Other Decks in Technology

Transcript

  1. Essential architectural thinking
    Why, what, when, how and how much?
    Uwe Friedrichsen – codecentric AG – 2006-2019

    View full-size slide

  2. Uwe Friedrichsen
    CTO @ codecentric
    https://twitter.com/ufried
    https://www.speakerdeck.com/ufried
    https://medium.com/@ufried

    View full-size slide

  3. Why we need architectural work

    View full-size slide

  4. Architectural work without asking “why” …

    View full-size slide

  5. BDUF architecture
    Big Design Upfront
    Stack-overflow architecture
    closely related to
    Conference-driven architecture
    Google-driven architecture
    “Agile” architecture
    a.k.a.
    “Emergent” architecture
    often in conjunction with
    “Death to all architects!”
    Developer-centric architecture
    “Strategic” architecture
    often found in conjunction with
    the “Powerpoint architect”
    “Architect” – step
    on the company
    career ladder
    working as fire accelerant

    and many more anti-patterns

    View full-size slide

  6. … results in a mess

    View full-size slide

  7. And how do we try to address the problem?

    View full-size slide

  8. We tend to discuss what architecture is
    instead of asking us why we need it
    or how to work on architecture

    View full-size slide

  9. … which results in even worse archetypes

    View full-size slide

  10. Hype-driven architecture

    View full-size slide

  11. Tunnel-vision architecture

    View full-size slide

  12. Blast-from-the-past architecture

    View full-size slide

  13. One-size-fits-all architecture

    View full-size slide

  14. Accidental architecture

    View full-size slide

  15. We need to ask why to focus our work
    Without asking why the value of our work will be accidental

    View full-size slide

  16. Let’s (re-)establish focus

    View full-size slide

  17. Why do we need architecture?
    • We need architecture to address
    • an optimization problem over time
    • with changing constraints

    View full-size slide

  18. Architecture attempts to satisfy quality attributes

    View full-size slide

  19. see, e.g., ISO 25010, ISO 9126 or SEI for comprehensive collections of quality attributes
    Maintainability
    Changeability
    Availability
    Performance
    Scalability
    Functionality
    Security

    Understandability
    Accessibility
    Reliability
    Usability
    Portability
    Operability

    View full-size slide

  20. Quality attributes can be segmented in two general classes
    1. Development (incl. build & test) related attributes
    2. Runtime (usage and operations) related attributes

    View full-size slide

  21. Development related attributes
    • Describe the desired behavior of a system
    from a development perspective
    • Influence how efficiently the system can be modified
    • Target “cost of change”
    • Effectiveness can usually only be measured in hindsight
    • “Arcane guesswork” – subject of many (heated) debates
    à Optimization problem over time

    View full-size slide

  22. Runtime related attributes
    • Describe the desired behavior of a system
    from a usage and operations perspective
    • Target “correctness”
    • Constrain the solution options
    • Support evaluation of solution options
    • May change over time
    à Changing constraints

    View full-size slide

  23. Correctness of behavior
    Runtime (usage and operations) related attributes
    Cost of change
    Development related attributes
    Maintainability
    Changeability
    Availability
    Performance
    Scalability
    Functionality
    Security

    Understandability
    Accessibility
    Reliability
    Usability
    Portability
    Operability

    View full-size slide

  24. Note that cost of change is not sufficient as an optimization goal
    as it neglects all other relevant types of costs.
    Thus, the optimization goal for architectural work
    needs to target the cumulative costs instead.
    (unfortunately, usually not covered by quality attributes)

    View full-size slide

  25. Why do we need architecture?
    • With architecture we attempt
    • to minimize the cumulative costs of a system over its lifetime
    • while ensuring the correctness of behavior at runtime
    • On a side note: What is architecture?
    • Architecture is whatever is needed to implement
    the required quality attributes (i.e., achieve the why)

    View full-size slide

  26. What the essential activities are

    View full-size slide

  27. 1ST LAW OF ARCHITECTURAL WORK
    EVERY DECISION HAS ITS PRICE
    NO DECISION IS FOR FREE
    (NO DECISION ONLY HAS UPSIDES. EVERY DECISION ALSO HAS DOWNSIDES)

    View full-size slide

  28. 2ND LAW OF ARCHITECTURAL WORK
    A DECISION CAN ONLY BE EVALUATED
    WITH RESPECT TO ITS CONTEXT
    (DECISIONS ARE NOT INVARIABLY “GOOD” OR “BAD”, BUT ONLY IN A GIVEN CONTEXT)

    View full-size slide

  29. The 4E model of architectural work

    View full-size slide

  30. The 4E model of architectural work
    Explore

    View full-size slide

  31. Explore
    Find solution options

    View full-size slide

  32. Explore
    • About designing solution options
    • Designing structures and behavior
    • Combining frameworks, tools, technologies, …
    • Important activity
    • Always done, either explicitly or implicitly
    • Architectural work often reduced to Explore activities
    • Unclear if and how solution delivers to the Why

    View full-size slide

  33. The 4E model of architectural work
    Explore
    Execute

    View full-size slide

  34. Execute
    Help stakeholders to make the best possible decisions

    View full-size slide

  35. Execute
    • About making decisions
    • Often not made by architect, but by other stakeholders
    • Communication, collaboration, convincing, …
    • Very important activity
    • Need to collaborate with all stakeholder groups
    • Learn their needs, points of view, language, …
    • Do not forget dev’s and ops as important stakeholder groups

    View full-size slide

  36. The 4E model of architectural work
    Explore
    Evaluate
    Execute

    View full-size slide

  37. Evaluate
    Identify the trade-offs

    View full-size slide

  38. Evaluate
    • About trade-offs
    • Comparing solution options
    • How well NFRs are satisfied
    • Essential activity
    • Delivers to Why and 1st law of architectural work
    • Needed for Execute
    • Keep different perspectives in mind

    View full-size slide

  39. The 4E model of architectural work
    Examine Explore
    Evaluate
    Execute

    View full-size slide

  40. Examine
    Understand the problem

    View full-size slide

  41. Examine
    • About understanding the problem and context
    • Examine problem space holistically
    • Functionality, NFRs, time, costs, risks, constraints, …
    • The basis of all other activities
    • Provides focus and context
    • Delivers to Why and 2nd law of architectural work
    • Needed for Explore and Evaluate

    View full-size slide

  42. Examine Explore
    Evaluate
    Execute

    View full-size slide

  43. Examine (1/3)
    • Understand the degree of uncertainty
    • What is the business model context?
    • How good does the customer understand the problem?
    • How often do they change their mind?
    • Have you done something similar before?
    • Do you have a specification/backlog? How specific is it?
    • Do you already have an IT solution for the problem?
    • Are success criteria defined? How do you measure them?
    • …

    View full-size slide

  44. Examine (2/3)
    • Understand the business problem
    • Hypothesis collection and confidence check
    • Event storming
    • Actors and use cases
    • Dissect requirements document
    • Analyze existing IT solution
    • Interview key users
    • …

    View full-size slide

  45. Examine (3/3)
    • Understand architectural context
    • Context view (incl. all actors, external systems and interfaces)
    • Quality tree with prioritized quality attributes
    • Collect key figures
    • Gather known constraints (financial, organizational, legal, …)
    • Assess external system interfaces
    • …
    • One or more workshops with required stakeholders

    View full-size slide

  46. Explore (1/3)
    • The creative part of the work
    • Lots of material available
    • Yet, little advice regarding the actual task
    • Usually just lots of basics and (unfortunately) opinions
    • Designing good options is hard
    • Requires broad knowledge and experience
    • Few recommendations here that worked well for me …

    View full-size slide

  47. Explore (2/3)
    • Explore variability axes to identify options, e.g.
    • Cloud vs. on-premise
    • Make vs. buy (OSS vs. managed service)
    • Architectural styles, communication styles, integration styles
    • …
    • About creating a high-level design
    • Understand required functionality and the business domain
    • The magic lies in the behavior, not the static structure!
    • Prefer architectural styles over blueprints

    View full-size slide

  48. Explore (3/3)
    • About creating a set of options (max. 3 options)
    • Use constraints and key figures to reduce options
    • Take your environment into account
    • Document rationale (why you selected an option)
    • Use spikes and prototypes as exploration tools
    • Have evolvability in mind
    • But balance flexibility and understandability

    View full-size slide

  49. Evaluate (1/2)
    • Understand scenario based analysis
    • E.g., ATAM (and how to strip it down)
    • Consider evaluation matrix for summary overview
    • Use SWOT as an augmenting risk evaluation tool
    • Helps to balance short-term and long-term consequences
    • Take the financial consequences of choices into account
    • Consider all dimensions: development, testing, deployment,
    operations, maintenance, licenses, infrastructure, usage,
    administration, revenue (e.g., windows of opportunity), …
    • Do not forget the long-term financial consequences!

    View full-size slide

  50. Evaluate (2/2)
    • Take additional constraints into account
    • E.g., market situation, required deadlines, available skills
    • Evaluate with focus on all stakeholders
    • Especially do not forget consequences for operations
    • Have a “cheat sheet” for popular options
    • General usage scenarios, costs, risks and trade-offs
    • Use spikes and prototypes to leverage risk
    • Automated evaluation as an outlook *
    * https://www.thoughtworks.com/insights/blog/fitness-function-driven-development

    View full-size slide

  51. Execute (1/2)
    • Know how to create a recommendation
    • Be familiar with decision templates and how to tweak them
    • Learn to present and discuss a recommendation
    • Try to understand biases and concerns upfront
    • Adjust language and arguments to your stakeholder group
    • Communicate all perspectives – value, risks and trade-offs
    • “Give 'em all the info and then let 'em decide”

    View full-size slide

  52. Execute (2/2)
    • Accept that it (usually) is neither your risk nor your money
    • Thus accept the decisions of the risk takers and sponsors
    • If people decide against your recommendations
    • Stay supportive and sympathetic
    • Be authentic
    • Use time as an ally
    • Using code as design documentation
    • Great for developers, shitty for everyone else …

    View full-size slide

  53. When to do what and how much

    View full-size slide

  54. Understanding uncertainty

    View full-size slide

  55. Uncertainty breaks the linear relation
    between effort and value

    View full-size slide

  56. Internally controlled Externally controlled
    Effort spent
    Units produced / Output
    Certainty-driven value prediction model
    (a.k.a. industrial value prediction model)
    Value created
    Units sold / Outcome
    Linear relation due to certainty
    We are looking for this
    Due to the linear relation it
    is sufficient to plan effort
    in order to predict value

    View full-size slide

  57. Internally controlled Externally controlled
    Effort spent
    Units produced / Output
    The effect of uncertainty
    Value created
    Units sold / Outcome
    We are still looking for this
    Influencing factors outside our control
    We cannot predict it reliably upfront
    We can only observe it after the fact
    No longer suitable
    to predict value
    Breaks linear relation
    Uncertainty ?

    View full-size slide

  58. Internally controlled Externally controlled
    Effort spent
    Units produced / Output
    The effect of uncertainty
    Under uncertainty we cannot predict
    upfront which kind of performance
    we are going to produce
    Support
    performance
    Idle performance No value
    Value-adding
    performance
    Creates value
    Value-reducing
    performance
    Destroys value

    View full-size slide

  59. Uncertainty means that you cannot predict
    the value that will result from your effort

    View full-size slide

  60. Acting under uncertainty
    1. Create a hypothesis regarding the effect of an effort
    2. Do smallest action suitable to measure an effect
    3. Measure effect and evaluate hypothesis
    a. Further develop hypothesis if expectations met
    b. Drop hypothesis otherwise (optionally pivot)
    4. Repeat

    View full-size slide

  61. Under uncertainty
    you do not maximize value
    by optimizing efficiency of efforts
    (a.k.a. cost efficiency),
    but by detecting and cutting
    idle and value-reducing performances
    as soon as possible

    View full-size slide

  62. Uncertainty
    Certainty
    • Extensive effort planning
    • Maximize efficiency
    • Detailed controlling
    • Hypotheses validation
    • Small steps
    • Quick feedback cycles
    Value maximization approaches

    View full-size slide

  63. Uncertainty drivers in IT
    • Complexity of context and tasks
    • Post-industrial (& startup) markets
    • Digital transformation (a.k.a. digitization, digitalization)
    • Disruptive technologies
    • …

    View full-size slide

  64. Types of uncertainty
    • Due to homework not done
    • Accidental, complicated, avoidable
    • Lack of diligence
    • Due to missing internal feedback
    • Semi-accidental, complex, harder to avoid
    • Rooted in company culture deficiencies
    • Due to missing external feedback
    • Essential, complex, not avoidable
    • Cannot be solved internally

    View full-size slide

  65. Uncertainty and “Agile”
    • Due to homework not done
    • Accidental, complicated, avoidable
    • Lack of diligence
    • Due to missing internal feedback
    • Semi-accidental, complex, harder to avoid
    • Rooted in company culture deficiencies
    • Due to missing external feedback
    • Essential, complex, not avoidable
    • Cannot be solved internally
    This is what Agile
    originally tried
    to address
    This is what
    Enterprise Agile *
    usually addresses
    This is what
    Enterprise Agile *
    often causes
    * Enterprise Agile: Typical “Agile” implementation in most companies

    View full-size slide

  66. Agile as implemented in most companies
    does not address essential uncertainty

    View full-size slide

  67. Uncertainty
    Certainty
    Invent potential new
    business offerings
    Grow a successfully
    launched new
    business offering
    Explore a
    potential new
    business offering
    Extend/improve
    an established
    business offering
    Create a new digital
    interaction point for an
    established business
    offering
    Implement
    new legal
    regulation
    Replace system
    that technologically
    reached EOL
    Typical tasks with varying uncertainty

    View full-size slide

  68. Uncertainty
    Certainty
    Task examples with varying uncertainty
    “Create a better world
    for our children” (vision)
    Evolution of new
    Living 360 offering
    (insurance)
    Fruits4U (startup)
    Release of new Warp
    wireless plans
    (telecommunications)
    Subcontractor
    self-service app
    OTID (logistics)
    Implement the
    new customer
    documentation
    law (banking)
    Replacement of
    AS/400 based ERP
    AMS/400 (retailer)

    View full-size slide

  69. Uncertainty
    Certainty
    Software development approaches
    Focus on cost
    (Waterfall, V-model, SAFe, …)
    Enterprise “Agile”
    (SCRUM, LeSS, …)
    Focus on flow
    (DevOps, Lean, …)
    Focus on feedback
    (Developer anarchy, …)
    Focus on innovation
    (No software development)

    View full-size slide

  70. Uncertainty
    Certainty
    Software development approaches
    Cost “Agile” Flow Feedback Innovation
    BDUF
    Big Design
    UpFront
    All 4 activities
    completely
    upfront
    Rare
    reassessments
    Decent DUF &
    occasional
    updates
    All 4 activities
    largely upfront,
    missing details
    added along the
    way
    Rare
    reassessments
    Just enough DUF &
    continuous evolution
    Quick pass through all
    4 activities upfront
    Then discuss, complement
    and re-evaluate continuously
    along the way
    „Whatever works“
    (Minimal
    agreement)
    Just enough
    agreement to get
    things done fast
    (90%+ of all written
    code will be deleted
    anyway)
    Note: Approach not
    suitable for systems
    in maintenance
    “Too early for IT”
    ---

    View full-size slide

  71. Uncertainty
    Certainty
    Software development approaches
    Cost “Agile” Flow Feedback Innovation
    “Create a better world
    for our children” (vision)
    Evolution of new
    Living 360 offering
    (insurance)
    Fruits4U (startup)
    Release of new Warp
    wireless plans
    (telecommunications)
    Subcontractor
    self-service app
    OTID (logistics)
    Implement the
    new customer
    documentation
    law (banking)
    Replacement of
    AS/400 based ERP
    AMS/400 (retailer)

    View full-size slide

  72. Additional influencing factors
    • Time and budget constraints
    • Availability of people (who and when)
    • Available skills and knowledge
    • Risk of resulting system (e.g., can harm human lives)
    • …

    View full-size slide

  73. Wrap-up
    • Why architectural work
    • To minimize cumulative costs without violating correctness
    • How to do architectural work
    • 4E model: Examine, Explore, Evaluate, Execute
    • When to do architectural work and how much
    • Align your activities with uncertainty
    • There is no one-size-fits-all
    • Do what is needed, not what is fashionable

    View full-size slide

  74. Uwe Friedrichsen
    CTO @ codecentric
    https://twitter.com/ufried
    https://www.speakerdeck.com/ufried
    https://medium.com/@ufried

    View full-size slide
