Rails Frontend: 2016 edition.

Slides from talk about enhancements in Rails Frontend.

Transcript

1. View Slide

2. RAILS FRONTEND: 2016
   and That Sprockets Talk


   View Slide

3. Vipul A M
   @vipulnsward


   View Slide

4. View Slide

5. timezones
   1.Mumbai TimeZone (UTC+05:30)
   2.Taiwan TimeZone (UTC+08:00)
   3.Pacific Time Zone (UTC-08:00)
   4.Singapore Time Zone (UTC+08:00)


   View Slide

6. timezones



   View Slide

7. timezones



   View Slide

8. timezones
   +


   View Slide

9. timezones
   +=


   View Slide

10. View Slide

11. View Slide

12. View Slide

13. View Slide

14. View Slide

15. View Slide

16. View Slide

17. Rails 5


    View Slide

18. http://blog.bigbinary.com/categories/Rails-5
    Rails 5 Blog Series (55+ and counting)


    View Slide

19. Sprockets: *Spotlight


    View Slide

20. Sprockets
    https://speakerdeck.com/rafaelfranca/how-sprockets-works


    View Slide

21. Sprockets
    1. sprockets
    2. sprockets-rails
    3. sass-rails
    4. execjs
    5. coffee-rails


    View Slide

22. manifest.js
    # In Rails configuration

    config.assets.precompile += [“payment.css”,
    “advertising.css"]
    <%= stylesheet_link_tag "advertising" %>




    View Slide

23. manifest.js
    config.assets.precompile = [“manifest.js”]
    // app/assets/config/manifest.js
    //= link_tree ../images

    //= link_directory ../stylesheets .css
    //= link application.css

    //= link advertising.css

    //= link payment.css

    //= link application.js



    View Slide

24. manifest.js
    <%= stylesheet_link_tag "advertising" %>
    .logo {

    background: url(<%= asset_url("logo.png") %>)

    }


    View Slide

25. folders as modules
    foo/index.js
    <%= asset_path("foo/index.js") %>

    <%= asset_path("foo.js") %>


    View Slide

26. folders as modules
    //= require_tree .
    foo/jquery-ui.js and foo/jquery.min.js
    Now:
    //= require foo.js
    # foo/index.js
    //= require foo.min.js

    //= require foo-ui.js



    View Slide

27. sourcemaps.js


    View Slide

28. sourcemaps.js


    View Slide

29. sourcemaps.js
    //# sourceMappingURL=
    File: public/assets/application.js
    Map: public/assets/application.js.map
    //# sourceMappingURL=/assets/application.js.map
    /*# sourceMappingURL=application.css.map */


    View Slide

30. sourcemaps.js


    View Slide

31. sourcemaps.js


    View Slide

32. ES2016!


    View Slide

33. ES2016!
    1. Arrows and Lexical This
    2. Classes
    3. Enhanced Object Literals
    4. Template Strings
    5. Destructuring
    6. Default + Rest + Spread
    7. Let + Const
    8. Iterators + For..Of
    9. Symbols, etc


    View Slide

34. ES2016!


    View Slide

35. ES2016!


    View Slide

36. ES2016!


    View Slide

37. 12x
    @schneems
    https://engineering.heroku.com/blogs/2016-02-18-
    speeding-up-sprockets/


    View Slide

38. 1.raw asset
    2.processed asset
    3.bundled
    4.compressed
    5.asset fingerprint
    6.minified
    7.etc
    12x


    View Slide

39. # https://github.com/rails/sprockets/blob/543a5a27190c26de8f3a1b03e18aed8da0367c63/lib/sprockets/base.rb#L46-L57



    def file_digest(path)

    if stat = File.stat(path)

    cache.fetch("file_digest:#{path}:#{stat.mtime.to_i}")
    do

    Digest::SHA256.file(path.to_s).digest

    end

    end

    end
    12x


    View Slide

40. “file_digest:/Users/schneems/my_project/app/assets/javascripts/application.js:
    123456”
    "file_digest:/+Other/path/+my_project/app/assets/javascripts/application.js:
    123456"
    12x


    View Slide

41. # https://github.com/rails/sprockets/blob/9ca80fe00971d45ccfacb6414c73d5ffad96275f/lib/sprockets/loader.rb#L55-L58
    digest =
    DigestUtils.digest(resolve_dependencies(paths))

    if uri_from_cache =
    cache.get(unloaded.digest_key(digest), true)

    asset_from_cache(UnloadedAsset.new(uri_from_cache,
    self).asset_key)

    end
    12x!


    View Slide

42. <%= javascript_include_tag :application,
    integrity: true %>


    src="/assets/application.js"
    integrity=“sha256-
    TvVUHzSfftWg1rcfL6TIJ0XKEGrgLyEq6lEpcmrG9qs=">

    SRI


    View Slide

43. *Headers


    View Slide

44. *Header


    View Slide

45. ETag


    View Slide

46. class ItemsController < ApplicationController

    def show

    @item = Item.find(params[:id])

    fresh_when @item

    end

    end
    Etag


    View Slide

47. $ curl -i http://localhost:3000/items/1



    HTTP/1.1 200 OK

    X-Frame-Options: SAMEORIGIN

    X-Xss-Protection: 1; mode=block

    X-Content-Type-Options: nosniff

    Etag: "618bbc92e2d35ea1945008b42799b0e7"

    Last-Modified: Sat, 30 Jan 2016 08:02:12 GMT

    Content-Type: text/html; charset=utf-8

    Cache-Control: max-age=0, private, must-revalidate

    X-Request-Id: 98359119-14ae-4e4e-8174-708abbc3fd4b

    X-Runtime: 0.412232

    Server: WEBrick/1.3.1 (Ruby/2.2.2/2015-04-13)

    Date: Fri, 04 Mar 2016 10:50:38 GMT

    Content-Length: 1014

    Connection: Keep-Alive
    Etag


    View Slide

48. $ curl -i -H 'If-None-Match: "618bbc92e2d35ea1945008b42799b0e7"' http://
    localhost:3000/items/1



    HTTP/1.1 304 Not Modified

    X-Frame-Options: SAMEORIGIN

    X-Xss-Protection: 1; mode=block

    X-Content-Type-Options: nosniff

    Etag: "618bbc92e2d35ea1945008b42799b0e7"

    Last-Modified: Sat, 30 Jan 2016 08:02:12 GMT

    Cache-Control: max-age=0, private, must-revalidate

    X-Request-Id: e4447f82-b96c-4482-a5ff-4f5003910c18

    X-Runtime: 0.012878

    Server: WEBrick/1.3.1 (Ruby/2.2.2/2015-04-13)

    Date: Fri, 04 Mar 2016 10:51:22 GMT

    Connection: Keep-Alive
    Etag


    View Slide

49. Strong Etag: ”543b39c23d8d34c232b457297d38ad99"
    Weak ETag: W/“543b39c23d8d34c232b457297d38ad99"
    Etag


    View Slide

50. # app/controllers/home_controller.rb

    class HomeController < ApplicationController

    def index

    render

    end

    end



    # app/views/home/index.html.erb

    Welcome
    http_cache_forever


    View Slide

51. Processing by HomeController#index as HTML

    Rendered home/index.html.erb within layouts/
    application (1.3ms)

    Completed 200 OK in 224ms (Views: 212.4ms |
    ActiveRecord: 0.0ms)



    And so on for every request for this action.

    http_cache_forever


    View Slide

52. # app/controllers/home_controller.rb

    class HomeController < ApplicationController

    def index

    http_cache_forever(public: true) {}

    end

    end



    # OR

    class HomeController < ApplicationController

    def index

    http_cache_forever(public: true) do

    render

    end

    end

    end





    # app/views/home/index.html.erb

    Welcome
    http_cache_forever


    View Slide

53. # When request is made for the first time.



    Processing by HomeController#index as HTML

    Rendered home/index.html.erb within layouts/
    application (1.3ms)

    Completed 200 OK in 224ms (Views: 212.4ms |
    ActiveRecord: 0.0ms)



    # For consecutive requests for the same page



    Processing by HomeController#index as HTML

    Completed 304 Not Modified in 2ms (ActiveRecord:
    0.0ms)
    http_cache_forever


    View Slide

54. ⛔
    Cache-Control: max-age=3155760000
    http_cache_forever


    View Slide

55. Asset Headers


    View Slide

56. response.headers['X-Tracking-ID'] = '123456'
    Headers in Simple Responses


    View Slide

57. # open config/environments/production.rb and add following line

    config.static_cache_control = 'public, max-age=1000'
    Asset Headers


    View Slide

58. PageSpeed Warnings


    View Slide

59. Missing Expires header


    View Slide

60. # production.rb



    config.public_file_server.headers = {

    'Cache-Control' => 'public, s-maxage=31536000,
    maxage=15552000',

    'Expires' =>
    "#{1.year.from_now.to_formatted_s(:rfc822)}"

    }
    Public Asset Header


    View Slide

61. Result


    View Slide

62. Caching


    View Slide

63. 1.Page Caching
    2.Action Caching
    3.Fragment Caching
    4.Russian Doll Caching
    5.Low-Level Caching
    6.SQL Caching
    http://edgeguides.rubyonrails.org/
    caching_with_rails.html
    Caching


    View Slide

64. # index.html.erb

    <%= render partial: 'todo', collection: @todos %>



    # _todo.html.erb

    <% cache todo do %>

    <%= todo.name %>

    <% end %>

    Partial rendering from cache


    View Slide

65. # index.html.erb

    <%= render partial: 'todo', collection: @todos,
    cached: true %>



    # _todo.html.erb

    <% cache todo do %>

    <%= todo.name %>

    <% end %>
    multi_fetch_fragments


    View Slide

66. cached: true => read_multi
    Rendered collection of todos/_todo.html.erb [100 /
    100 cache hits] (339.5ms)
    multi_fetch_fragments


    View Slide

67. 72%
    read_multi


    View Slide

68. config.action_mailer.perform_caching = true
    ActionMailer Fragment Caching


    View Slide

69.



    <% cache 'signup-text' do %>

    Welcome to <%= @company.name %>

    You have successfully signed up to <%=
    @company.name %>, Your username is:

    <% end %>



    <%= @user.login %>.








    <%= render :partial => 'footer' %>




    ActionMailer Fragment Caching


    View Slide

70. Cache digest for app/views/user_mailer/_footer.erb:
    7313427d26cc1f701b1e0212498cee38

    Cache digest for app/views/user_mailer/welcome_email.html.erb:
    30efff0173fd5f29a88ffe79a9eab617

    Rendered user_mailer/_footer.erb (0.3ms)

    Rendered user_mailer/welcome_email.html.erb (26.1ms)

    Cache digest for app/views/user_mailer/welcome_email.text.erb:
    77f41fe6159c5736ab2026a44bc8de55

    Rendered user_mailer/welcome_email.text.erb (0.2ms)

    UserMailer#welcome_email: processed outbound mail in 190.3ms
    ActionMailer Fragment Caching


    View Slide

71. ActiveRecord::Relation#cache_key
    Caching result sets and collection


    View Slide

72. @users = User.where(city: 'miami')
    1.The query statement doesn’t change. If we change
    city name from “Miami” to “Boston” then result might
    change.
    2.No record is deleted.
    3.No record is added.
    Caching result sets and collection


    View Slide

73. @users = User.where(city: 'Miami')

    @users.cache_key

    => "users/query-67ed32b36805c4b1ec1948b4eef8d58f-3-20160116111659084027"
    # users.html.erb
    cache @users do

    #content here

    end
    Caching result sets and collection


    View Slide

74. *Layouts and Tags.


    View Slide

75. async-defer
    www.growingwiththeweb.com/2014/02/async-vs-defer-attributes.html


    View Slide

76. simple <br/>

    View Slide

77. <br/>

    View Slide

78. <br/>

    View Slide

79. Defaults


    View Slide

80. Pagespeed


    View Slide

81. 1.Placement of JS/CSS imports
    2.Font imports
    3.Analytics tags
    4.Proper viewports
    5.responsive
    6.Inlining resources, css/js, etc
    PageSpeed


    View Slide

82.





    …


    <%= @page_title || default_page_title %> | BigBinary



    <%= stylesheet_link_tag "application.css", 'data-turbolinks-
    track' => true %>

    …

    <%= csrf_meta_tags %>





    <%= yield %>



    try{Typekit.load({ async: true });}catch(e){}



    <%= javascript_include_tag "application.js", media: 'all',
    'data-turbolinks-track' => true, async: true, defer: true %>









    View Slide

83. View Slide

84. Fin.


    View Slide

85. Fin.


    View Slide

86. Images: flickr.com/search/?
    text=singapore&license=2%2C3%2C4%2C5%2C6%2C9
    http://blog.bigbinary.com/categories/Rails%205
    https://www.packtpub.com/web-development/reactjs-example-building-
    modern-web-applications-react
    http://www.growingwiththeweb.com/2014/02/async-vs-defer-
    attributes.html
    https://speakerdeck.com/rafaelfranca/how-sprockets-works
    https://thenounproject.com/search/?q=sprocket&i=283880
    References


    View Slide
