flex-box X140Yu @ Zhihu 2018-01-02
Table of content • basic flex-box concepts • flex-box in
ComponentKit • other layout Components
What is flex-box? • a layout mode • flex "->
flexible • In CK’s world, boxes are components • Defines the relationship between boxes
What can flex-box do • A Live Demo
container & item container item ❌ container item no relationship
direction • vertical • horizontal .direction = .horizontal main axis(主轴)
cross axis (交叉轴)
container struct CKStackLayoutComponentStyle { }; CKStackLayoutDirection direction; CKStackLayoutAlignItems alignItems; CKStackLayoutJustifyContent
justifyContent; CGFloat spacing;
CKStackLayoutDirection direction; typedef NS_ENUM(NSUInteger, CKStackLayoutDirection) { CKStackLayoutDirectionVertical, CKStackLayoutDirectionHorizontal, }; .vertical
.horizontal
container struct CKStackLayoutComponentStyle { }; CKStackLayoutDirection direction; CKStackLayoutAlignItems alignItems; CKStackLayoutJustifyContent
justifyContent; CGFloat spacing;
CGFloat spacing; spacing spacing
container struct CKStackLayoutComponentStyle { }; CKStackLayoutDirection direction; CKStackLayoutAlignItems alignItems; CKStackLayoutJustifyContent
justifyContent; CGFloat spacing;
CKStackLayoutAlignItems alignItems; CKStackLayoutJustifyContent justifyContent; main axis cross axis .direction =
.horizontal justifyContent alignItems
CKStackLayoutJustifyContent justifyContent; typedef NS_ENUM(NSUInteger, CKStackLayoutJustifyContent) { CKStackLayoutJustifyContentStart, CKStackLayoutJustifyContentCenter, CKStackLayoutJustifyContentEnd, };
.start .end .center main axis .direction = .vertical
CKStackLayoutAlignItems alignItems; typedef NS_ENUM(NSUInteger, CKStackLayoutAlignItems) { CKStackLayoutAlignItemsStart, CKStackLayoutAlignItemsEnd, CKStackLayoutAlignItemsCenter, CKStackLayoutAlignItemsStretch,
}; .start .center .end .stretch .direction = .vertical cross axis
<code>
1 2 3 1 2 3 1 2 3 1
2 3
item a.k.a child struct CKStackLayoutComponentChild { CKComponent *component; CGFloat spacingBefore;
CGFloat spacingAfter; BOOL flexGrow; BOOL flexShrink; CKRelativeDimension flexBasis; CKStackLayoutAlignSelf alignSelf; };
1 2 3 struct CKStackLayoutComponentChild { CKComponent *component; CGFloat spacingBefore;
CGFloat spacingAfter; BOOL flexGrow; BOOL flexShrink; CKRelativeDimension flexBasis; CKStackLayoutAlignSelf alignSelf; }; .direction = .vertical
flexShrink 400 200 100 300 600 100 100 200 .flexShrink
= true (length - currentLength) / shrinkCount = shrinkLenght per component (400 - 600) / 2 = -100
flexGrow 175 50 175 .flexGrow = true 400 50 250
100 100 (length - currentLength) / growCount = growLenght per component (400 - 250) / 2 = 75
flexBasis • main-axis only • override height/width • flex(Grow|Shrink) >
flexBasis > (width|height)
alignSelf • same as alignItems but for single item •
cross-axis • default is `auto` • override container’s alignItems property 1 2 3
layout components • CKInsetComponent • CKBackgroundLayoutComponent • CKOverlayLayoutComponent • CKCenterLayoutComponent
• CKRatioLayoutComponent • CKStaticLayoutComponent
CKInsetComponent [CKInsetComponent newWithView:{ [UIView class], {{@selector(setBackgroundColor:), color},} } insets:{20, 30,
20, 30} component:component];
CKOverlayLayoutComponent [CKOverlayLayoutComponent newWithComponent:swiftComponent overlay:maskOverlayComponent]; + "// This component lays out
a single component and then overlays a component on top of it streched to its size
CKBackgroundLayoutComponent [CKBackgroundLayoutComponent newWithComponent:labelComponent background:backgroundComponent]; + Swift Swift "// Lays out
a single child component, then lays out a background component behind it stretched to its size.
CKRatioLayoutComponent [CKRatioLayoutComponent newWithRatio:0.5 size:{} component:imageComponent]; "// ratio = height /
width 100 200
CKStaticLayoutComponent "// A component that positions children at fixed positions.
[CKStaticLayoutComponent newWithChildren:{ { .component = yellowComponent, .position = {100, 200}, }, }]; 100 200
Thanks for watching!
