Vertical & Oblique Transmission under Fluctuating Selection

Yoav Ram
October 31, 2017

Vertical & Oblique Transmission under Fluctuating Selection

Oblique transmission occurs when a trait is passed to offspring from non-parental members of the parental generation. This can occur, for example, via social learning, mobile genetic elements, epigenetics, and the microbiome. We (i.e. Drs Ram, Uri Liberman, and Marcus Feldman) developed a model in which both vertical (i.e. from parent to offspring) and oblique transmission occur in a population evolving under fluctuating selection. Our analytical and numerical results highlight scenarios in which oblique or vertical transmission are likely to evolve; surprisingly, in some cases, oblique transmission does not evolve, even though it increases population mean fitness. We also examine the effect of the transmission mode on maintenance of diversity in the population.

Yoav Ram

October 31, 2017
Tweet

More Decks by Yoav Ram

Other Decks in Science

Transcript

  1. Vertical & Oblique Transmission
    under Fluctuating Selection
    :
    Yoav Ram
    October 31, 2017
    :
    Work with Marc Feldman & Uri Liberman
    Photo by Kelly Sikkema on Unsplash

    View Slide

  2. Who I am
    » Yoav Ram (www.yoavram.com)
    » Postdoc at Feldman lab, Stanford University
    » PhD in mathematical biology at Hadany lab, Tel-
    Aviv University
    » Evolution of the mutation and recombination rate
    » Estimating fitness in microbes
    » Also: Python training for engineers & data
    scientists (python.yoavram.com)
    2/45

    View Slide

  3. The Modern Synthesis
    Genetic inheritance as the transmission mode of
    traits between generations.
    > Genetic changes that improve the fitness of
    individuals will tend to increase in frequency over
    time.
    -- Evolution, Bergstrom and Dugatkin 2012, ch. 1.1
    Considered to be vertical: parent to offspring
    3/45

    View Slide

  4. Non-genetic
    inheritance
    » Cultural evolution:
    Imitation, learning...
    » Epigenetics
    » Microbiome: symbionts,
    parasites, pathogens
    » Prions: infectious proteins
    such as [Het-s],[PSI+],
    [URE3], spongiform
    Often non-vertical
    4/45

    View Slide

  5. Non-vertical genetic inheritance
    » Horizontal gene transfer: transformation,
    transduction, conjugation (plasmids & transposable
    elements), integrons
    » Host-parasite gene transfer
    » Cross-species gene transfer
    » Chimerism?
    5/45

    View Slide

  6. Vertical vs. non-
    vertical
    transmission
    Differences in
    » persistence
    » reversibility
    » speed
    » timing
    » direction
    » regulation
    Photo by William Bout on Unsplash 6/45

    View Slide

  7. Oblique transmission
    Offspring inherit traits from
    non-parental adults.
    *Oblique = Diagonal
    Photo by Samuel Zeller on Unsplash 7/45

    View Slide

  8. Focus: mixed vertical & oblique transmission
    Offspring inherit traits either from parent or from
    non-parental adults.
    Examples:
    » Social learning in humans, birds, dolphins...
    » Microbiome
    » Genetic inheritance + horizontal gene transfer
    8/45

    View Slide

  9. Model
    Phenotypes
    Two phenotypes that affect
    fitness:
    phenotype A B
    freq.
    fitness
    9/45

    View Slide

  10. Model
    Transmission
    Offspring inherit phenotype from:
    » parent with probability
    » random non-parental adult with probability
    where is the vertical transmission rate.
    10/45

    View Slide

  11. Model
    Recurrence equation
    The frequency of phenotype in the next generation:
    Mean fitness:
    11/45

    View Slide

  12. 12/45

    View Slide

  13. Constant
    environment
    Result 1. If is favored by
    natural selection over and
    *, fixation of phenotype
    is globally stable.
    * With perfect oblique transmission ( ) or neutral
    evolution ( ) the recursion is and there is no
    change in frequency.
    Photo by Amy Humphries on Unsplash 13/45

    View Slide

  14. 14/45

    View Slide

  15. Periodic environment
    15/45

    View Slide

  16. Periodic environment
    Consider environments that favor for
    generations and for generations:
    -
    -
    -
    » Fitness of the favored phenotype (whatever it is
    at a given time) is
    » Fitness of the unfavored phenotype is
    16/45

    View Slide

  17. Periodic environment
    Result 2. If then
    fixation of either phenotype
    is unstable and a protected
    polymorphism exists.
    Photo by Scott Webb on Unsplash 17/45

    View Slide

  18. Periodic environment
    Result 3. For general and , a protected
    polymorphism exists if
    otherwise fixation of one phenotype is stable.
    18/45

    View Slide

  19. 19/45

    View Slide

  20. Periodic environment
    A1B1
    We saw that when there is a protected
    polymorphism.
    We can find it for .
    Result 4. For A1B1 there is a unique stable
    polymorphismx
    x is the frequency of at the end of even generations
    20/45

    View Slide

  21. A1B1
    If vertical transmission rate
    increases
    then stable frequency
    decreases
    21/45

    View Slide

  22. A1B1
    So, with vertical
    transmission, the frequency
    of decreases just before
    it is favored again.
    That is not good.
    22/45

    View Slide

  23. A1B1
    Indeed, the stable mean
    fitness decreases with the
    vertical transmission rate:
    23/45

    View Slide

  24. Evolution of the transmission mode
    Can the transmission mode itself evolve?
    Photo by Matthew Henry on Unsplash 24/45

    View Slide

  25. Modifier model
    We model competition between
    two modifier alleles:
    » with vertical
    transmission rate ,
    » with vertical
    transmission rate .
    Photo by Cloudvisual on Unsplash 25/45

    View Slide

  26. Modifier model
    Pheno-
    genotype
    frequency
    fitness
    rate
    26/45

    View Slide

  27. Modifier model
    Recurrence equation
    27/45

    View Slide

  28. Modifier model
    Recurrence equation
    28/45

    View Slide

  29. Stability analysis
    Photo by Austin Neill on Unsplash 29/45

    View Slide

  30. Modifier model
    » Initial population:
    » only with modifier allele
    » at equilibrium between phenotypes and ( )
    » Now, allele is introduced at a low frequency
    Can increase in frequency and invade the
    population, or is stable to invasion?
    30/45

    View Slide

  31. Periodic environment: A1B1
    Result 7. A modifier allele with vertical
    transmission rate is:
    » stable to invasion of allele with rate if ,
    » unstable if .
    The evolutionary stable rate in therefore and
    oblique transmission is likely to evolve.
    31/45

    View Slide

  32. Periodic environment: A1B1
    » and switch between
    and every generation.
    » Initial resident modifier:
    .
    » Invaders reduce rate by
    .
    32/45

    View Slide

  33. Reduction principle
    Photo by Brendan Church on Unsplash 33/45

    View Slide

  34. Reduction principle for vertical transmission
    In the selection regime, evolution tends to
    reduce vertical transmission and increase oblique
    transmission.
    34/45

    View Slide

  35. The plot thickens...
    Photo by Cindy Tang on Unsplash 35/45

    View Slide

  36. Periodic
    environment: AkBk
    More generally, there is no
    reduction of the vertical
    transmission rate.
    With environmental periods
    the stable vertical
    transmission rate is high
    (>0.4).
    36/45

    View Slide

  37. Periodic
    environment: AkBk
    Moreover, the stable
    transmission rate does not
    maximize the geometric mean
    fitnessg.
    g Geometric average of the population mean fitness over
    generations.
    37/45

    View Slide

  38. Periodic
    environment: AkBk
    Moreover, the stable
    transmission rate does not
    maximize the geometric mean
    fitnessg.
    Reminder: these modifiers are
    not neutral as they reduce
    effect of selection.
    g Geometric average of the population mean fitness over
    generations.
    38/45

    View Slide

  39. Polymorphism
    Photo by Tatiana Lapina on Unsplash 39/45

    View Slide

  40. Polymorphism
    » Constant environment:
    polymorphism lasts longer
    with oblique transmission.
    Photo by Tatiana Lapina on Unsplash 39/45

    View Slide

  41. Polymorphism
    » Constant environment:
    polymorphism lasts longer
    with oblique transmission.
    » Periodic environment:
    polymorphism is maintained
    in shorter periods with
    oblique transmission
    Photo by Tatiana Lapina on Unsplash 39/45

    View Slide

  42. Evolution of oblique
    transmission
    » Rapidly changing
    environments favor oblique
    transmission.
    » Slow and constant
    environments favor vertical
    transmission.
    Photo by Ray Hennessy on Unsplash 40/45

    View Slide

  43. Phenotype switching
    Several studiesξ assumed
    - periodically changing environment
    - vertical transmission of phenotype
    - phenotype switch by transmission fidelity
    - fidelity determined by a genetic modifier
    ξ Leigh 1970, Ishii et al. 1989, Jablonka 1996, Kussel & Leibler 2005, King & Masel 2007, Liberman et al.
    2011
    41/45

    View Slide

  44. Phenotype switching
    » Switching rate evolves
    toward where is the
    period lengthμ.
    » Environmental statistics
    encoded by the modifier.
    μ Doesn't work if is large or if selection not
    symmetric.
    42/45

    View Slide

  45. Phenotype switching
    With oblique transmission:
    » Phenotype switch caused by oblique transmission
    rather then transmission errors.
    » Environmental statistics encoded by the stable
    population phenotype distribution if environmental
    changes are frequent and selection is weak.
    43/45

    View Slide

  46. Acknowledgments
    Funding: Stanford Center for Evolution and Human
    Genomics
    44/45

    View Slide

  47. Thank you!
    Yoav Ram / Feldman Lab
    [email protected]
    @yoavram
    45/45
