Implementing Software Packer@VXCON

Software developers wish to prevent their applications from cracking, analyzing by others, even looking for vulnerabilities. Generally, developers protect their applications by software packer, e.g. reducing the size of software by UPX Packer, using VMProtect Packer to obfuscate the execution logic, or using Themida Packer to deal with more complicated issues.

* What's PE structure?
* How compilers build a PE like executable file
* The logic of creating processes in PE Loader
* Case Study- RunPE — Malware Injection like a Loader
* Build your packer in C

Transcript

1. Implementing Software Packer
   aaaddress1@chroot.org


   View Slide

2. •Core member of CHROOT Security Group and
   TDOHacker security community in Taiwan.

   •Ten years of experience in reverse engineering
   and machine language, also mastered the intel
   8086. Expert in Windows vulnerability, reverse
   engineering.
   •Many papers presented in security conferences
   such as BSidesLV, ICNC, MC2015 and CISC.

   •Speaker at BlackHat Asia Arsenal, HITCON
   (Hackers In Taiwan Conference), SITCON (Students
   In Taiwan Conference), iThome#Chatbot.
   ./bio


   View Slide

3. Today...
   We're talking about How to
   Build A Software Packer


   View Slide

4. Today...
   We're talking about How to
   Build A Software Packer
   Nope, Is Application Loader


   View Slide

5. Exe File?
   The Portable Executable (PE) format is a file format for executables, object
   code, DLLs, FON Font files, and others used in 32-bit and 64-bit versions of
   Windows operating systems.

   The PE format is a data structure that encapsulates the information
   necessary for the Windows OS loader to manage the wrapped executable
   code. This includes dynamic library references for linking, API export and
   import tables, resource management data and thread-local storage (TLS)
   data.

   On NT operating systems, the PE format is used for EXE, DLL, SYS (device
   driver), and other file types.
   https://en.wikipedia.org/wiki/Portable_Executable


   View Slide

6. A Easy Beginning!
   #include
   int main()
   {
   MessageBoxA(
   0, "hi there.", "info", 0
   );
   return 0;
   }


   View Slide

7. Compile Source to Exe File
   via Visual Studio C++ 2017 Community


   View Slide

8. General Compiler
   Source.cpp Object Files Main.exe
   Compiler
   Assembly Codes
   Assembler
   Linker


   View Slide

9. Source Code
   #include
   int main()
   {
   MessageBoxA(
   0, "hi there.", "info", 0
   );
   return 0;
   }


   View Slide

10. Source Code → Assembly Codes
    #include
    int main() {
    MessageBoxA(
    0,
    "hi there.",
    "info", 0
    );
    return 0;
    }
    push 0
    push "info"
    push "hi there."
    push 0
    call MessageBoxA
    xor eax, eax
    ret


    View Slide

11. based on
    x86 Calling Convention
    #include
    int main() {
    MessageBoxA(
    0,
    "hi there.",
    "info", 0
    );
    return 0;
    }
    push 0
    push "info"
    push "hi there."
    push 0
    call MessageBoxA
    xor eax, eax
    ret


    View Slide

12. xor eax, eax
    ret
    push 0
    push "info"
    push "hi there."
    push 0
    call MessageBoxA
    0xdead: "info"
    0xbeef: "hi there."
    .rdata section
    0xcafe: 0x7630EA99
    .idata section

    (Import Address Table)
    How Compiler Works


    View Slide

13. xor eax, eax
    ret
    push 0
    push offset "info"
    push offset "hi there."
    push 0
    call MessageBoxA
    0xdead: "info"
    0xbeef: "hi there."
    .rdata section
    0xcafe: 0x7630EA99
    How Linker Works
    .idata section

    (Import Address Table)


    View Slide

14. xor eax, eax
    ret
    push 0
    push 0xdead
    push 0xbeef
    push 0
    call ds:0xcafe
    0xdead: "info"
    0xbeef: "hi there."
    .rdata section
    0xcafe: 0x7630EA99
    How Linker Works
    .idata section

    (Import Address Table)


    View Slide

15. Assembler Works
    push 0 ; 6A 00
    push 0xdead ; 68 AD DE 00 00
    push 0xbeef ; 68 EF BE 00 00
    push 0 ; 6A 00
    call ds:0xcafe ; FF 15 FE CA 00 00
    xor eax, eax ; 33 C0
    ret ; C3


    View Slide

16. Main.exe
    .text Section
    6A 00
    68 AD DE 00 00
    68 EF BE 00 00
    6A 00
    FF 15 FE CA 00 00
    33 C0
    C3
    0xdead: "info"
    0xbeef: "hi there."
    0xcafe: 0x7630EA99
    .rdata Section
    .idata Section


    View Slide

17. There's 3 issues We need to Deal with:
    • Where The Exe File Data Should be Placed
    • How to Place Each Section in Memory
    • Fix The Import Address Table (IAT)
    So...

    Let's Take a Look at PE Structure :)


    View Slide

18. PE File 101 DOS Program
    NT Header
    ⋯⋯
    File Header
    Optional Header
    DOS Header


    View Slide

19. PE File 101 DOS Program
    NT Header
    ⋯⋯
    File Header
    Optional Header
    DOS Header
    1.DOSHeader starts with 'MZ'

    2.DOSHeader->e_lfanew point to NT
    Header


    View Slide

20. BYTE* getNtHdrs(BYTE *pe_buffer) {
    if (pe_buffer == NULL) return NULL;
    IMAGE_DOS_HEADER *idh;= (IMAGE_DOS_HEADER *)pe_buffer;
    if (idh->e_magic != IMAGE_DOS_SIGNATURE)
    return NULL;
    IMAGE_NT_HEADERS32 *inh;
    inh = (IMAGE_NT_HEADERS32 *)(
    (BYTE*)pe_buffer + pe_offset
    );
    if (inh->Signature != IMAGE_NT_SIGNATURE)
    return NULL;
    return (BYTE*)inh;
    }


    View Slide

21. Exe File (PE)
    DOS Program
    OptionalHeader
    NtHeader
    ...
    .ImageBase (0x400000)
    .SizeOfHeaders
    File Header
    .NumberOfSections
    .AddressOfEntryPoint
    SizeOfHeaders
    Section
    Header 1
    (.text)
    ...
    sizeof(Section Header) =
    IMAGE_SIZEOF_SECTION_HEADER = 40(fixed)
    .SizeOfImage
    Section
    Header 2
    Section
    Header 3
    Section
    Data 1
    (.text)
    .DataDirectory


    View Slide

22. Exe File (PE)
    DOS Program NtHeader
    ...
    Section
    Header 1
    (.text)
    ...
    Section
    Header 2
    Section
    Header 3
    Section
    Data 1
    (.text)
    SectionHeader[i] = PIMAGE_SECTION_HEADER(
    NtHeader +
    sizeof(IMAGE_NT_HEADERS) +
    IMAGE_SIZEOF_SECTION_HEADER * index
    );
    IMAGE SECTION HEADER
    .VirtualAddress .SizeOfRawData
    .PointerToRawData


    View Slide

23. IMAGE_NT_HEADERS32 *ntHeader;
    ntHeader = (IMAGE_NT_HEADERS32 *)getNtHdrs(data);
    memcpy(pImageBase, data, ntHeader->OptionalHeader.SizeOfHeaders);
    int maxNum = ntHeader->FileHeader.NumberOfSections;
    IMAGE_SECTION_HEADER * SectionHeader;
    for (DWORD count = 0; count < maxNum; count++) {
    SectionHeader = (IMAGE_SECTION_HEADER *)(
    DWORD(ntHeader) + sizeof(IMAGE_NT_HEADERS) +
    IMAGE_SIZEOF_SECTION_HEADER * count
    );
    memcpy(
    LPVOID(DWORD(pImageBase) + SectionHeader->VirtualAddress),
    LPVOID(DWORD(data) + SectionHeader->PointerToRawData),
    SectionHeader->SizeOfRawData
    );
    }


    View Slide

24. Example:
    Process Hollowing (aka RunPE)


    View Slide

25. ntdll!LdrVerifyImageMatchesChecksum


    View Slide

26. ntdll!LdrVerifyImageMatchesChecksumEx


    View Slide

27. View Slide

28. View Slide

29. Ntdll.dll
    ...
    Process
    Kernel32.dll
    User32.dll
    ...
    ...
    Process
    Chrome
    Memory
    Allocated
    VirtualAllocEx()
    (Length = SizeOfImage)
    0x400000
    Malware.exe
    Allocate memory at ImageBase(0x400000)


    View Slide

30. Ntdll.dll
    ...
    Process
    Kernel32.dll
    User32.dll
    ...
    ...
    Process
    Chrome
    WriteProcessMemory() at
    ImageBase + 0x00
    Copy SizeOfHeaders bytes from
    (malware.exe + 0x00)
    Image Header
    Malware.exe


    View Slide

31. DOS Program
    ...
    malware.exe
    ...
    Process
    Chrome
    NtHeader
    Section Header 1
    Section Data 1
    ...
    .VirtualAddress = 0xbeef
    Space@beef
    .PointerToRawData
    .SizeOfRawData
    copy SizeOfRaowData bytes from
    PointerToRawData
    via WriteProcessMemory()
    Image Header


    View Slide

32. Space@beef
    Section Header 1
    ...
    malware.exe
    ...
    Process
    Chrome
    NtHeader
    Section Header2
    Section Data 2
    ...
    .VirtualAddress = 0xcafe
    Space@cafe
    .PointerToRawData
    .SizeOfRawData
    copy SizeOfRaowData bytes from
    PointerToRawData
    via WriteProcessMemory()
    Image Header
    DOS Program


    View Slide

33. .text
    ...
    Process
    Chrome
    Section 2
    Section 3
    ...
    Ntdll.dll
    Process
    User32.dll
    SetThreadContext() &
    ResumeThread()
    eax = AddressOfEntryPoint
    ...
    Malware.exe Image Header
    Kernel32.dll


    View Slide

34. BYTE* MapFileToMemory(LPCSTR filename, LONGLONG &filelen){
    FILE *fileptr;
    BYTE *buffer;
    fileptr = fopen(filename, "rb");
    fseek(fileptr, 0, SEEK_END);
    filelen = ftell(fileptr);
    rewind(fileptr);
    buffer = (BYTE *)malloc((filelen + 1) * sizeof(char));
    fread(buffer, filelen, 1, fileptr);
    fclose(fileptr);
    return buffer;
    }


    View Slide

35. DOSHeader = PIMAGE_DOS_HEADER(Image);
    NtHeader = PIMAGE_NT_HEADERS(
    DWORD(Image) + DOSHeader->e_lfanew
    );
    // process in suspended state, for the new image.
    if (CreateProcessA(
    path, 0, 0, 0, 0, CREATE_SUSPENDED, 0, 0, &SI, &PI)) {
    if (GetThreadContext(PI.hThread, LPCONTEXT(CTX))) {
    //if context is in thread
    ...


    View Slide

36. pImageBase = VirtualAllocEx(
    PI.hProcess,
    LPVOID(NtHeader->OptionalHeader.ImageBase),
    NtHeader->OptionalHeader.SizeOfImage,
    MEM_COMMIT | MEM_RESERVE,
    PAGE_EXECUTE_READWRITE);
    WriteProcessMemory(
    PI.hProcess,
    pImageBase,
    Image,
    NtHeader->OptionalHeader.SizeOfHeaders, NULL);


    View Slide

37. int maxNum = NtHeader->FileHeader.NumberOfSections;
    for (int count = 0; count < maxNum; count++) {
    SectionHeader = PIMAGE_SECTION_HEADER(
    DWORD(NtHeader) + sizeof(IMAGE_NT_HEADERS) +
    IMAGE_SIZEOF_SECTION_HEADER * count
    );
    WriteProcessMemory(
    PI.hProcess,
    LPVOID(DWORD(pImageBase) + SectionHeader->VirtualAddress),
    LPVOID(DWORD(Image) + SectionHeader->PointerToRawData),
    SectionHeader->SizeOfRawData, 0
    );
    }


    View Slide

38. WriteProcessMemory(
    PI.hProcess,
    LPVOID(CTX->Ebx + 8),
    LPVOID(&pImageBase),
    sizeof(DWORD), 0
    );
    CTX->Eax = DWORD(pImageBase) +
    NtHeader->OptionalHeader.AddressOfEntryPoint;
    SetThreadContext(PI.hThread, LPCONTEXT(CTX));
    //Start the process/call main()
    ResumeThread(PI.hThread);


    View Slide

39. Code & Demo
    github.com/aaaddress1/RunPE-In-Memory/blob/master/runPE/runPE/runPE.cpp


    View Slide

40. But...
    We Want to Build a Software Packer.
    We need to fix IAT by myself :/


    View Slide

41. Exe File (PE)
    DOS Program
    OptionalHeader
    NtHeader
    ...
    .ImageBase (0x400000)
    .SizeOfHeaders
    File Header
    .NumberOfSections
    .AddressOfEntryPoint
    SizeOfHeaders
    Section
    Header 1
    (.text)
    ...
    sizeof(Section Header) =
    IMAGE_SIZEOF_SECTION_HEADER = 40(fixed)
    .SizeOfImage
    Section
    Header 2
    Section
    Header 3
    Section
    Data 1
    (.text)
    .DataDirectory


    View Slide

42. IMAGE_DATA_DIRECTORY* getPeDir(PVOID pe_buffer, DWORD dir_id)
    {
    if (dir_id >= IMAGE_NUMBEROF_DIRECTORY_ENTRIES) return NULL;
    IMAGE_NT_HEADERS32* nt_header;
    nt_header = (IMAGE_NT_HEADERS32*)getNtHdrs((BYTE *)pe_buffer);
    if (nt_header == NULL) return NULL;
    IMAGE_DATA_DIRECTORY* peDir = NULL;
    peDir = &(nt_header->OptionalHeader.DataDirectory[dir_id]);
    if (peDir->VirtualAddress == NULL)
    return NULL;
    return peDir;
    }


    View Slide

43. Exe File (PE)
    DOS Program
    OptionalHeader
    NtHeader
    ...
    DataDirectory
    Export Directory
    index
    0
    Import Directory
    1
    Exception Directory
    2
    Security Directory
    Base Relocation Table
    Resource Directory
    Import Address Table
    3
    4
    5
    ...
    12
    ...
    IMAGE_DATA_DIRECTORY[16]
    typedef struct _IMAGE_DATA_DIRECTORY {
    DWORD VirtualAddress;
    DWORD Size;
    } IMAGE_DATA_DIRECTORY, *PIMAGE_DATA_DIRECTORY;


    View Slide

44. Exe File (PE)
    DOS Program
    OptionalHeader
    NtHeader
    ...
    DataDirectory
    index
    Import Address Table
    ...
    12
    ...
    typedef struct _IMAGE_DATA_DIRECTORY {
    DWORD VirtualAddress;
    DWORD Size;
    } IMAGE_DATA_DIRECTORY, *PIMAGE_DATA_DIRECTORY;
    .VirtualAddress .Size


    View Slide

45. Exe File (PE)
    DOS Program
    OptionalHeader
    NtHeader
    ...
    DataDirectory
    index
    Import Address Table
    ...
    12
    ...
    .VirtualAddress
    .Size
    IMAGE_IMPORT_DESCRIPTOR


    View Slide

46. IMAGE_IMPORT_DESCRIPTOR Array
    IMAGE_IMPORT_DESCRIPTOR 1
    IMAGE_IMPORT_DESCRIPTOR 2
    IMAGE_IMPORT_DESCRIPTOR 3
    ...
    \x00\x00\x00\x00\x00\x00\x00
    Fixed Size
    Fixed Size
    Fixed Size
    Exe File (PE) OptionalHeader DataDirectory
    index
    Import Address Table
    12
    .VirtualAddress
    .Size
    sizeof(IMAGE_IMPORT_DESCRIPTOR)
    NT Header
    sizeof(Descriptor Array)


    View Slide

47. bool fixIAT(PVOID modulePtr) {
    printf("[+] Fix Import Address Table\n");
    IMAGE_DATA_DIRECTORY *importsDir = getPeDir(
    modulePtr, IMAGE_DIRECTORY_ENTRY_IMPORT
    );
    if (importsDir == NULL) return false;
    DWORD maxSize = importsDir->Size;
    DWORD impAddr = importsDir->VirtualAddress;
    IMAGE_IMPORT_DESCRIPTOR* lib_desc = NULL;
    DWORD parsedSize = 0;
    while (parsedSize < maxSize) {
    lib_desc = (IMAGE_IMPORT_DESCRIPTOR*)(
    impAddr + parsedSize + (ULONG_PTR)modulePtr
    );
    ...
    parsedSize += sizeof(IMAGE_IMPORT_DESCRIPTOR);
    }


    View Slide

48. IMAGE_IMPORT_DESCRIPTOR
    typedef struct _IMAGE_IMPORT_DESCRIPTOR {
    union {
    DWORD Characteristics;// 0 for terminating null import descriptor
    DWORD OriginalFirstThunk;// RVA to original unbound IAT (PIMAGE_THUNK_DATA)
    } DUMMYUNIONNAME;
    DWORD TimeDateStamp;// 0 if not bound,
    // -1 if bound, and real date\time stamp
    // in IMAGE_DIRECTORY_ENTRY_BOUND_IMPORT (new BIND)
    // O.W. date/time stamp of DLL bound to (Old BIND)
    DWORD ForwarderChain; // -1 if no forwarders
    DWORD Name;
    DWORD FirstThunk; // RVA to IAT (if bound this IAT has actual addresses)
    } IMAGE_IMPORT_DESCRIPTOR;
    typedef IMAGE_IMPORT_DESCRIPTOR UNALIGNED *PIMAGE_IMPORT_DESCRIPTOR;


    View Slide

49. IMAGE_IMPORT_DESCRIPTOR 1
    Exe File (PE) OptionalHeader DataDirectory
    index
    Import Address Table
    12
    .VirtualAddress
    .Size
    NT Header
    .OriginalFirstThunk
    .FirstThunk
    .Name (User32.dll)
    IMAGE_IMPORT_BY_NAME: MessageBoxA
    typedef struct _IMAGE_IMPORT_BY_NAME {
    WORD Hint;
    CHAR Name[1];
    } IMAGE_IMPORT_BY_NAME;


    View Slide

50. while (parsedSize < maxSize) {
    lib_desc = (IMAGE_IMPORT_DESCRIPTOR*)(
    impAddr + parsedSize + (ULONG_PTR)modulePtr
    );
    if (lib_desc->OriginalFirstThunk == NULL &&
    lib_desc->FirstThunk == NULL) break;
    LPSTR lib_name = (LPSTR)((DWORD)modulePtr + lib_desc->Name);
    printf(" [+] Import DLL: %s\n", lib_name);
    DWORD call_via = lib_desc->FirstThunk;
    DWORD thunk_addr = lib_desc->OriginalFirstThunk;
    if (thunk_addr == NULL) thunk_addr = lib_desc->FirstThunk;
    ...
    parsedSize += sizeof(IMAGE_IMPORT_DESCRIPTOR);
    }


    View Slide

51. xor eax, eax
    ret
    push 0
    push 0xdead
    push 0xbeef
    push 0
    call ds:0xcafe
    IMAGE_IMPORT_DESCRIPTOR 1
    Exe File (PE) OptionalHeader DataDirectory
    index
    Import Address Table
    12
    .VirtualAddress
    .Size
    NT Header
    .OriginalFirstThunk
    .FirstThunk = 0xcafe
    .Name (User32.dll)
    IMAGE_IMPORT_BY_NAME: MessageBoxA


    View Slide

52. IMAGE_IMPORT_DESCRIPTOR 1
    Exe File (PE) OptionalHeader DataDirectory
    index
    Import Address Table
    12
    .VirtualAddress
    .Size
    NT Header
    .FirstThunk = 0xcafe
    .FirstThunk
    .Name (User32.dll)
    IMAGE_IMPORT_BY_NAME: MessageBoxA
    HANDLE mod = LoadLibrary("User32.dll");
    GetProcAddress(mod, "MessageBoxA") = 0x7547EA99
    0x7547EA99


    View Slide

53. Thunk Array
    IMAGE_IMPORT_DESCRIPTOR 1
    Exe File (PE) OptionalHeader DataDirectory
    index
    Import Address Table
    12
    .VirtualAddress
    .Size
    NT Header
    MessageBoxA: *(uint32_t *)0xcafe = 0x7547EA99
    .FirstThunk = 0xcafe
    .Thunk = 0xcaff
    .Thunk = 0xcb00
    .Thunk = 0xcb02
    .Name (User32.dll)
    LoadStringA: *(uint32_t *)0xcaff = 0x75130D4D
    KillTimer: *(uint32_t *)0xcb01 = 0x754364C7
    Lastest Thunk: *(uint32_t *)0xcb02 = NULL


    View Slide

54. DWORD offsetField = 0;
    DWORD offsetThunk = 0;
    while (true) {
    IMAGE_THUNK_DATA32* fieldThunk = (IMAGE_THUNK_DATA32*)(
    DWORD(modulePtr) + offsetField + call_via
    );
    IMAGE_THUNK_DATA32* orginThunk = (IMAGE_THUNK_DATA32*)(
    DWORD(modulePtr) + offsetThunk + thunk_addr
    );
    if (fieldThunk->u1.Function == NULL) break;
    ...
    offsetField += sizeof(IMAGE_THUNK_DATA32);
    offsetThunk += sizeof(IMAGE_THUNK_DATA32);
    }


    View Slide

55. if (fieldThunk->u1.Function == orginThunk->u1.Function) {
    PIMAGE_IMPORT_BY_NAME by_name = (PIMAGE_IMPORT_BY_NAME)(
    DWORD(modulePtr) + orginThunk->u1.AddressOfData
    );
    LPSTR func_name = (LPSTR)by_name->Name;
    DWORD addr = (DWORD)GetProcAddress(
    LoadLibraryA(lib_name), func_name
    );
    printf(" [V] API %s at %x\n", func_name, addr);
    fieldThunk->u1.Function = addr;
    }


    View Slide

56. And What's Relocation?


    View Slide

57. Process
    Main.exe
    .text
    Address
    0x400000
    0x401000
    ...
    .idata
    0x40D000
    .rdata
    0x40D110


    View Slide

58. Process
    Main.exe
    .text
    Address
    0x400000
    0x401000
    ...
    .idata
    0x40D000
    .rdata
    0x40D110


    View Slide

59. Address space layout randomization
    (ASLR)
    Address space layout randomization (ASLR) is a computer security
    technique involved in preventing exploitation of memory corruption
    vulnerabilities.

    In order to prevent an attacker from reliably jumping to, for example,
    a particular exploited function in memory, ASLR randomly arranges
    the address space positions of key data areas of a process,
    including the base of the executable and the positions of the stack,
    heap and libraries.
    https://en.wikipedia.org/wiki/Address_space_layout_randomization


    View Slide

60. Process
    Main.exe
    .text
    Address
    0x400000
    0x401000
    ...
    .idata
    0x40D000
    .rdata
    0x40D110


    View Slide

61. Process
    Main.exe
    .text
    Address
    0x500000
    0x501000
    ...
    .idata
    0x50D000
    .rdata
    0x50D110


    View Slide

62. Process
    Main.exe
    .text
    Address
    0x600000
    0x601000
    ...
    .idata
    0x60D000
    .rdata
    0x60D110


    View Slide

63. Process
    Main.exe
    .text
    Address
    0x600000
    0x601000
    ...
    .idata
    0x60D000
    .rdata
    0x60D110
    Access violation


    View Slide

64. Exe File (PE)
    DOS Program
    OptionalHeader
    NtHeader
    ...
    Export Directory
    index
    0
    Import Directory
    1
    Exception Directory
    2
    Security Directory
    Base Relocation Table
    Resource Directory
    Import Address Table
    3
    4
    5
    ...
    12
    ...
    IMAGE_DATA_DIRECTORY[16]
    typedef struct _IMAGE_DATA_DIRECTORY {
    DWORD VirtualAddress;
    DWORD Size;
    } IMAGE_DATA_DIRECTORY, *PIMAGE_DATA_DIRECTORY;
    DataDirectory


    View Slide

65. Exe File (PE)
    DOS Program
    OptionalHeader
    NtHeader
    ...
    Export Directory
    index
    0
    Import Directory
    1
    Exception Directory
    2
    Security Directory
    Base Relocation Table
    Resource Directory
    Import Address Table
    3
    4
    5
    ...
    12
    ...
    IMAGE_DATA_DIRECTORY[16]
    typedef struct _IMAGE_DATA_DIRECTORY {
    DWORD VirtualAddress;
    DWORD Size;
    } IMAGE_DATA_DIRECTORY, *PIMAGE_DATA_DIRECTORY;
    DataDirectory


    View Slide

66. Exe File (PE)
    DOS Program
    OptionalHeader
    NtHeader
    ...
    index ...
    ...
    .VirtualAddress
    .Size
    IMAGE_BASE_RELOCATION
    typedef struct _IMAGE_BASE_RELOCATION {
    DWORD VirtualAddress;
    DWORD SizeOfBlock;
    } IMAGE_BASE_RELOCATION;
    Base Relocation Table
    5
    DataDirectory


    View Slide

67. IMAGE_DATA_DIRECTORY* relocDir = getPeDir(
    modulePtr, IMAGE_DIRECTORY_ENTRY_BASERELOC
    );
    /* Cannot relocate - application have no relocation table */
    if (relocDir == NULL) return false;
    DWORD maxSize = relocDir->Size;
    DWORD relocAddr = relocDir->VirtualAddress;
    IMAGE_BASE_RELOCATION* reloc = NULL;
    DWORD parsedSize = 0;
    while (parsedSize < maxSize) {
    reloc = (IMAGE_BASE_RELOCATION*)(
    relocAddr + parsedSize + DWORD(modulePtr));
    if (reloc->VirtualAddress == NULL || reloc->SizeOfBlock == 0)
    break;
    ...
    parsedSize += reloc->SizeOfBlock;
    }


    View Slide

68. OptionalHeader index ...
    ...
    .VirtualAddress .Size
    Base Relocation Table
    5
    IMAGE_BASE_RELOCATION 1
    VirtualAddress
    Exe File (PE)
    NT Header
    SizeOfBlock
    IMAGE_BASE_RELOCATION 2
    VirtualAddress
    SizeOfBlock
    IMAGE_BASE_RELOCATION 3
    ...
    Relocation
    Table
    DataDirectory


    View Slide

69. typedef struct _BASE_RELOCATION_ENTRY {
    WORD Offset : 12;
    WORD Type : 4;
    } BASE_RELOCATION_ENTRY;
    OptionalHeader index ...
    ...
    .VirtualAddress
    .Size
    Base Relocation Table
    5
    IMAGE_BASE_RELOCATION 1
    VirtualAddress
    Exe File (PE)
    NT Header
    _BASE_RELOCATION_ENTRY 1
    _BASE_RELOCATION_ENTRY 2
    _BASE_RELOCATION_ENTRY 3
    ...
    SizeOfBlock
    We can get the count of RELOCATION_ENTRY by:
    (SizeOfBlock - sizeof(IMAGE_BASE_RELOCATION))
    / sizeof(RELOCATION_ENTRY) =
    (SizeOfBlock - 2 * sizeof(DWORD)) / 2;
    DataDirectory


    View Slide

70. OptionalHeader index ...
    ...
    .VirtualAddress
    .Size
    Base Relocation Table
    5
    IMAGE_BASE_RELOCATION 1
    VirtualAddress
    Exe File (PE)
    NT Header
    _BASE_RELOCATION_ENTRY 1
    SizeOfBlock
    0x1000
    Offset: 0x003
    Type: 03
    ...
    00601000 - 6A 00 - push 00

    00601002 - 68 E8194100 - push 004119E8

    00601007 - 68 F0194100 - push 004119F0

    0060100C - 6A 00 - push 00

    0060100E - FF 15 08D14000 - call dword ptr [0040D108]

    ...
    typedef struct _BASE_RELOCATION_ENTRY {
    WORD Offset : 12;
    WORD Type : 4;
    } BASE_RELOCATION_ENTRY;
    #define RELOC_32BIT_FIELD 3
    #define RELOC_64BIT_FIELD 0xA
    DataDirectory


    View Slide

71. OptionalHeader index ...
    ...
    .VirtualAddress
    .Size
    Base Relocation Table
    5
    IMAGE_BASE_RELOCATION 1
    VirtualAddress
    Exe File (PE)
    NT Header
    _BASE_RELOCATION_ENTRY 1
    SizeOfBlock
    0x1000
    Offset: 0x003
    Type: 03
    ...
    00601000 - 6A 00 - push 00

    00601002 - 68 E8196100 - push 006119E8

    00601007 - 68 F0194100 - push 004119F0

    0060100C - 6A 00 - push 00

    0060100E - FF 15 08D14000 - call dword ptr [0040D108]

    ...
    typedef struct _BASE_RELOCATION_ENTRY {
    WORD Offset : 12;
    WORD Type : 4;
    } BASE_RELOCATION_ENTRY;
    #define RELOC_32BIT_FIELD 3
    #define RELOC_64BIT_FIELD 0xA
    DataDirectory


    View Slide

72. OptionalHeader index ...
    ...
    .VirtualAddress
    .Size
    Base Relocation Table
    5
    IMAGE_BASE_RELOCATION 1
    VirtualAddress
    Exe File (PE)
    NT Header
    _BASE_RELOCATION_ENTRY 2
    SizeOfBlock
    0x1000
    Offset: 0x008
    Type: 03
    ...
    00601000 - 6A 00 - push 00

    00601002 - 68 E8196100 - push 006119E8

    00601007 - 68 F0194100 - push 004119F0

    0060100C - 6A 00 - push 00

    0060100E - FF 15 08D14000 - call dword ptr [0040D108]

    ...
    typedef struct _BASE_RELOCATION_ENTRY {
    WORD Offset : 12;
    WORD Type : 4;
    } BASE_RELOCATION_ENTRY;
    #define RELOC_32BIT_FIELD 3
    #define RELOC_64BIT_FIELD 0xA
    DataDirectory


    View Slide

73. OptionalHeader index ...
    ...
    .VirtualAddress
    .Size
    Base Relocation Table
    5
    IMAGE_BASE_RELOCATION 1
    VirtualAddress
    Exe File (PE)
    NT Header
    _BASE_RELOCATION_ENTRY 2
    SizeOfBlock
    0x1000
    Offset: 0x008
    Type: 03
    ...
    00601000 - 6A 00 - push 00

    00601002 - 68 E8196100 - push 006119E8

    00601007 - 68 F0196100 - push 006119F0

    0060100C - 6A 00 - push 00

    0060100E - FF 15 08D14000 - call dword ptr [0040D108]

    ...
    typedef struct _BASE_RELOCATION_ENTRY {
    WORD Offset : 12;
    WORD Type : 4;
    } BASE_RELOCATION_ENTRY;
    #define RELOC_32BIT_FIELD 3
    #define RELOC_64BIT_FIELD 0xA
    DataDirectory


    View Slide

74. OptionalHeader index ...
    ...
    .VirtualAddress
    .Size
    Base Relocation Table
    5
    IMAGE_BASE_RELOCATION 1
    VirtualAddress
    Exe File (PE)
    NT Header
    _BASE_RELOCATION_ENTRY 3
    SizeOfBlock
    0x1000
    Offset: 0x010
    Type: 03
    ...
    00601000 - 6A 00 - push 00

    00601002 - 68 E8196100 - push 006119E8

    00601007 - 68 F0196100 - push 006119F0

    0060100C - 6A 00 - push 00

    0060100E - FF 15 08D14000 - call dword ptr [0040D108]

    ...
    typedef struct _BASE_RELOCATION_ENTRY {
    WORD Offset : 12;
    WORD Type : 4;
    } BASE_RELOCATION_ENTRY;
    #define RELOC_32BIT_FIELD 3
    #define RELOC_64BIT_FIELD 0xA
    DataDirectory


    View Slide

75. OptionalHeader index ...
    ...
    .VirtualAddress
    .Size
    Base Relocation Table
    5
    IMAGE_BASE_RELOCATION 1
    VirtualAddress
    Exe File (PE)
    NT Header
    _BASE_RELOCATION_ENTRY 3
    SizeOfBlock
    0x1000
    Offset: 0x010
    Type: 03
    ...
    00601000 - 6A 00 - push 00

    00601002 - 68 E8196100 - push 006119E8

    00601007 - 68 F0196100 - push 006119F0

    0060100C - 6A 00 - push 00

    0060100E - FF 15 08D16000 - call dword ptr [0060D108]

    ...
    typedef struct _BASE_RELOCATION_ENTRY {
    WORD Offset : 12;
    WORD Type : 4;
    } BASE_RELOCATION_ENTRY;
    #define RELOC_32BIT_FIELD 3
    #define RELOC_64BIT_FIELD 0xA
    DataDirectory


    View Slide

76. DWORD entriesNum = (
    reloc->SizeOfBlock - sizeof(IMAGE_BASE_RELOCATION)
    ) / sizeof(BASE_RELOCATION_ENTRY);
    DWORD page = reloc->VirtualAddress;
    BASE_RELOCATION_ENTRY* entry = (BASE_RELOCATION_ENTRY*)(
    DWORD(reloc) + sizeof(IMAGE_BASE_RELOCATION)
    );


    View Slide

77. for (DWORD i = 0; i < entriesNum; i++) {
    DWORD offset = entry->Offset;
    DWORD type = entry->Type;
    DWORD reloc_field = page + offset;
    if (entry == NULL || type == 0)
    break;
    DWORD* relocateAddr = (DWORD*)(DWORD(modulePtr) + reloc_field);
    (*relocateAddr) = ((*relocateAddr) - oldBase + newBase);
    printf(" [V] Apply Reloc Field at %x\n", relocateAddr);
    entry = (BASE_RELOCATION_ENTRY*)(
    DWORD(entry) + sizeof(BASE_RELOCATION_ENTRY)
    );
    }


    View Slide

78. Code & Demo
    github.com/aaaddress1/RunPE-In-Memory


    View Slide

79. Thanks for listening :)
    aaaddress1@chroot.org
    Slides
    Github Project


    View Slide
