Playing Malware Injection with Exploit thoughts

In the past, when hackers did malicious program code injection, they used to adopt RunPE, AtomBombing, cross-process creation threads, and other approaches. They could forge their own execution program as any critical system service. However with increasing process of anti-virus techniques, these sensitive approaches have been gradually proactively killed. Therefore, hackers began to aim at another place, namely memory-level weakness, due to the breakages of critical system service itself.

This agenda will simply introduce a new memory injection technique that emerged after 2013, PowerLoadEx. Based on this concept, three new injection methods will be disclosed as well. These makes good use of the memory vulnerability in Windows to inject malicious behavior into system critical services. The content will cover Windows reverse analysis, memory weakness analysis, how to use and utilize, and so on. The relevant PoC will be released at the end of the agenda.

Transcript

1. Playing Malware Injection
   with Exploit thoughts
   aaaddress1@chroot.org


   View Slide

2. • Master degree at CSIE, NTUST
   • Security Researcher - chrO.ot, TDOHacker
   • Speaker - BlackHat, VXCON, HITCON
   >_cat ./Bio


   View Slide

3. • Introduction
   • Challenge When we meet Anti-Virus
   • Interesting Case - PowerLoader since 2013
   • New Vulnerability - 3 idea inspired by PowerLoader
   • Summary
   >_ls ./agenda


   View Slide

4. aaaddress1@chroot.org
   Quickly Review:
   What's Malware Injection?


   View Slide

5. >_man inject
   (｀_´)ゞ Used for bypassing whitelist checking, byassing
   anti-virus, privilege escalation, etc.
   e.g.
   • DLL Side-Loading + Digital Signature = Bypassing anti-virus
   • Remote Inject + whitelisted process = Bypassing whitelist
   • Inject explorer + DLL Side-Loading + Self-elevate Service

   = Bypassing Windows UAC (User Account Control) *Vista ~ Win8*


   View Slide

6. >_man inject
   There're serval well-known techniques
   • Shellcode Inject or DLL Inject - OpenProcess, VirtualAllocExRWX,
   WriteProcessMemory, CreateRemoteThread

   • Process Hollowing (aka RunPE) - OpenProcess, CreateProcessASuspended,
   Mapping PE FileVirtualAllocEx + WriteProcessMemory, GetThreadContext, and
   ResumeThread to Execute exe file from memory

   • Thread Hijack or AtomBombing - QueueUserAPC, Inline Hook, or IAT
   Hijack

   • Memory Exploit (PowerLoaderEX) - SetWindowLong, SendNotifyMessage


   View Slide

7. (ꐦ`•ω•´)!!!
   Here are the 4 primary challenges that
   you'll encounter during injection.
   >_man inject


   View Slide

8. There are 4 primary challenges in injection:
   1. What's target - choose a target to inject, and it should be
   meaningful. e.g. explorer, svchost

   2. Where to place - find memory for us to place RWX memory or
   ROPChain payload. e.g. VirtualAllocEx

   3. How to inject payload - any way for us to write payload into
   remote process memory

   4. How to execute - create a new thread to execute or hijack
   current thread of that process?
   >_man inject


   View Slide

9. aaaddress1@chroot.org
   Interesting Case:
   Powerloader since 2013


   View Slide

10. Powerloader,
    aka Extra Window Vulnerability


    View Slide

11. >_Shell_TrayWnd?


    View Slide

12. >_Shell_TrayWnd?
    Window event callback function


    View Slide

13. >_s_WndProc?


    View Slide

14. >_s_WndProc?


    View Slide

15. >_how it works
    Explorer Process Memory
    Low Address ➔
    High Address ➔
    Shell_TrayWnd
    Window Class Structure
    +0 - 0xcafe (vtable)
    +4 - window hwnd
    ...


    View Slide

16. Explorer Process Memory
    Shell_TrayWnd
    +0 - 0xcafe (vtable)
    +4 - window hwnd
    ...
    vtable @ 0xcafe
    +0 - Interlocked (inc)
    +4 - message callback
    +8 - Interlocked (inc)
    >_how it works


    View Slide

17. Explorer Process Memory
    Shell_TrayWnd
    +0 - 0xcafe (vtable)
    +4 - window hwnd
    ...
    vtable @ 0xcafe
    +0 - Interlocked (inc)
    +4 - message callback
    +8 - Interlocked (inc)
    Operating System
    1) Send Window Message
    2) Send Window Message
    3) Invoke s_wndProc function
    4) Invoke several
    function from vtable
    >_how it works


    View Slide

18. Explorer Process Memory
    Shell_TrayWnd
    +0 - 0xcafe (vtable)
    +4 - window hwnd
    ...
    vtable @ 0xcafe
    +0 - Interlocked (inc)
    +4 - message callback
    +8 - Interlocked (inc)
    >_issue?
    GetWindowLong()


    View Slide

19. Explorer Process Memory
    Shell_TrayWnd
    +0 - 0xbeef 0xcafe
    +4 - window hwnd
    ...
    >_issue?
    GetWindowLong()
    vtable @ 0xcafe
    +0 - Interlocked (inc)
    +4 - message callback
    +8 - Interlocked (inc)
    fake vtable @ 0xbeef
    +0 - shellcode addr
    +4 - shellcode
    ...
    SetWindowLong()


    View Slide

20. Explorer Process Memory
    malicious
    Shell_TrayWnd
    >_issue?
    GetWindowLong()
    payload
    SetWindowLong()
    +0 - fake vtable ($+4)
    fake vtable
    +4 - shellcode addr ($+8)
    +8 - shellcode
    pwn!


    View Slide

21. >_abuse vtable


    View Slide

22. >_abuse vtable


    View Slide

23. aaaddress1@chroot.org
    Demo


    View Slide

24. aaaddress1@chroot.org
    3 more vulnerability:
    From Exploit to Inject


    View Slide

25. Actually,
    Many old-design services in Windows
    don't have vtable mitigation (° ꈊ °)✧˖


    View Slide

26. aaaddress1@chroot.org
    #1
    Ole32 DropEnter Event


    View Slide

27. >_cat ./ole32_init


    View Slide

28. >_cat ./reg_dropevent


    View Slide

29. >_man LPDROPTARGET
    IDropTarget actually is a virtual method table :)


    View Slide

30. >_issue?
    vtable addr is determined by GetProp()
    so... it's really easy for us to
    hijack vtable just by SetProp()
    This callback function is used to deal
    with dropping file to Start Button of
    Explorer.exe


    View Slide

31. >_how it works
    explorer Process Memory
    Low Address ➔
    High Address ➔
    DropTarget @ 0xc0fee
    DropTarget Structure
    +4 - function 1
    ...
    +8 - function 2
    +0C- dropfile func
    Prop Name Value
    OleDropTargetInterface 0xc0fee
    write DropTarget structure address (0xc0fee) via
    SetPropW() in function explorer!RegisterDragDrop
    +0 - 0xc0fee (this)


    View Slide

32. >_how it works
    explorer Process Memory
    DropTarget @ 0xc0fee
    Prop Name Value
    OleDropTargetInterface 0xbeef
    payload @ 0xbeef
    +0 - 0xbeef (this)
    +4 - don't care
    ...
    +8 - don't care
    +0C- shellcode addr
    it's easy for us to change the return value of
    GetPropW("OleDropTargetInterface") from 0xc0fee
    to 0xbeef (malicious payload).


    View Slide

33. explorer Process Memory
    Operating System
    1) Send Window Message (Drag & Drop)
    2)
    GetPropW("OleDropTargetInterface")
    3) Invoke drop file function from vtable,
    invoke shellcode addr = *(beef+0c)
    >_how it works
    DropTarget @ 0xc0fee
    payload @ 0xbeef
    +0 - 0xbeef (this)
    +4 - don't care
    ...
    +8 - don't care
    +0C- shellcode addr
    Prop Name Value
    OleDropTargetInterface 0xbeef


    View Slide

34. >_abuse vtable


    View Slide

35. >_abuse vtable


    View Slide

36. aaaddress1@chroot.org
    Demo


    View Slide

37. aaaddress1@chroot.org
    #2
    Comctl32 SubClass Event


    View Slide

38. >_cat FastGetSubclsHdr


    View Slide

39. >_cat MstSubclsProc


    View Slide

40. >_cat EnterSubclsFram


    View Slide

41. >_cat CallNxtSubclsProc


    View Slide

42. >_cat EntrSubclsCallbk


    View Slide

43. >_abuse vtable


    View Slide

44. >_abuse vtable


    View Slide

45. >_abuse vtable


    View Slide

46. aaaddress1@chroot.org
    Demo


    View Slide

47. aaaddress1@chroot.org
    #3
    Thread Hijacking (win10+)


    View Slide

48. 3) create first thread of this process,
    point register eax to AddressOfEntry,
    point ebx+8 (TIB base + 8) to image base,
    and point eip to ntdll!LdrInitializeThunk
    Process
    >_Process?
    Kernel (ring0)
    Application (ring3)
    1) create process
    via CreateProcess()
    2) mapping file into memory
    iexplorer.exe
    .data section
    .text section
    AddressOfEntry
    ntdll.dll
    kernel32.dll
    ...


    View Slide

49. >_Process?
    Process
    iexplorer.exe
    ntdll.dll
    kernel32.dll
    ...
    Call Stack
    --------------
    _LdrpSnapModule
    _LdrpMapAndSnapDependency
    _LdrpMapDllWithSectionHandle
    _LdrpLoadKnownDll
    _LdrpFindOrPrepareLoadingModule
    _LdrpLoadDllInternal
    _LdrpLoadDll
    _LdrLoadDll
    _LdrpInitializeProcess
    __LdrpInitialize
    _LdrInitializeThunk
    fix import address table,
    fix export directory,
    apply relocation, etc
    .text section ntdll!LdrInitializeThunk


    View Slide

50. >_Process?
    ntdll!LdrInitializeThunk
    AddressOfEntry@.text
    Process
    iexplorer.exe
    .text section
    ntdll.dll
    kernel32.dll
    ...
    ntdll!RtlUserThreadStart
    RtlUserThreadStart is entry-point of every thread.
    We can hijack thread via write shellcode address into
    global variable ‘LdrDelegatedRtlUserThreadStart'.


    View Slide

51. 3) point 'LdrDelegatedRtlUserThreadStart'
    to shellcode address
    Process
    >_Abuse
    Malware
    1) get privilege of target process
    via OpenProcess()
    2) mapping shellcode into target process
    chrome.exe
    .data section
    .text section
    shellcode
    ...
    ntdll.dll
    LdrDelegatedRtlUserThreadStart
    4) every new thread of target process
    can be hijack to invoke shellcode


    View Slide

52. aaaddress1@chroot.org
    Demo


    View Slide

53. Thanks for listening
    aaaddress1@chroot.org
    Slide
    Github @aaaddress1
    Facebook


    View Slide
