'Materializing' Wunderlist for Android

'Materializing' Wunderlist for Android

Our approach to Material Design guidelines. Should we follow the guidelines? Or should we adapt them to our needs? In this talk, we will cover how Wunderlist for Android it is being 'materialised'.

Antonio J. Consuegra

January 31, 2015
Tweet

More Decks by Antonio J. Consuegra

Other Decks in Technology

Transcript

  1. bbbb ‘Materializing’ Wunderlist for Android Material Fest @ Cádiz -

    01/02/15 Antonio J. Consuegra @aconsuegra 6Wunderkinder GmbH
  2. ‘Materializing’ Wunderlist for Android • Finally, design guidelines from Google.

    • Tasty candy for designers. • Wunderlist has a strong design character. • Redesign everything? Or keep our own style? • Let’s see :)
  3. Tasks View - Toolbar • Generalization of ActionBar. • 48dip

    vs 56dip. • Default elevation 4dip. • More flexible, but more work needed.
  4. Tasks View - Toolbar • Generalization of ActionBar. • 48dip

    vs 56dip. • Default elevation 4dip. • More flexible, but more work needed.
  5. Tasks View - Toolbar • Generalization of ActionBar. • 48dip

    vs 56dip. • Default elevation 4dip. • More flexible, but more work needed.
  6. Tasks View - Toolbar <android.support.v7.widget.Toolbar
 app:theme="@style/ThemeOverlay.AppCompat.Dark.ActionBar"
 android:id="@+id/toolbar"
 android:background="?attr/colorPrimary"
 android:elevation="4dip">



    <ProgressBar
 android:id="@+id/progress_circular"
 android:layout_gravity="right"
 android:indeterminate="true"
 android:visibility="gone"/>
 </android.support.v7.widget.Toolbar> <LinearLayout>
 <include layout="@layout/toolbar"/>
 </LinearLayout> Toolbar toolbar = (Toolbar) findViewById(R.id.toolbar);
 setSupportActionBar(toolbar);
  7. Tasks View - Toolbar <android.support.v7.widget.Toolbar
 app:theme="@style/ThemeOverlay.AppCompat.Dark.ActionBar"
 android:id="@+id/toolbar"
 android:background="?attr/colorPrimary"
 android:elevation="4dip">



    <ProgressBar
 android:id="@+id/progress_circular"
 android:layout_gravity="right"
 android:indeterminate="true"
 android:visibility="gone"/>
 </android.support.v7.widget.Toolbar> <LinearLayout>
 <include layout="@layout/toolbar"/>
 </LinearLayout> Toolbar toolbar = (Toolbar) findViewById(R.id.toolbar);
 setSupportActionBar(toolbar);
  8. Tasks View - Toolbar <android.support.v7.widget.Toolbar
 app:theme="@style/ThemeOverlay.AppCompat.Dark.ActionBar"
 android:id="@+id/toolbar"
 android:background="?attr/colorPrimary"
 android:elevation="4dip">



    <ProgressBar
 android:id="@+id/progress_circular"
 android:layout_gravity="right"
 android:indeterminate="true"
 android:visibility="gone"/>
 </android.support.v7.widget.Toolbar> <LinearLayout>
 <include layout="@layout/toolbar"/>
 </LinearLayout> Toolbar toolbar = (Toolbar) findViewById(R.id.toolbar);
 setSupportActionBar(toolbar);
  9. Tasks View - Palette • Not part of SDK, in

    support library. • Extract colours from an image. • Personalize UI components. • It tries to generate 6 swatches.
  10. Tasks View - Palette compile 'com.android.support:palette-v7:21.0.3' Palette.generateAsync(bitmap, new PaletteAsyncListener() {



 @Override
 public void onGenerated(Palette palette) {
 if (palette != null) {

 ColorDrawable color = new ColorDrawable(
 palette.getMutedColor(defaultColor)
 );
 color.setAlpha(200);
 getSupportActionBar().setBackgroundDrawable(color);

 }
 }
 });
  11. Tasks View - Palette compile 'com.android.support:palette-v7:21.0.3' Palette.generateAsync(bitmap, new PaletteAsyncListener() {



 @Override
 public void onGenerated(Palette palette) {
 if (palette != null) {

 ColorDrawable color = new ColorDrawable(
 palette.getMutedColor(defaultColor)
 );
 color.setAlpha(200);
 getSupportActionBar().setBackgroundDrawable(color);

 }
 }
 });
  12. Details View - Pickers • Old-fashioned. • Slow to select

    date/time. • Almost “for free”. • Use colorAccent.
  13. Details View - Pickers • Old-fashioned. • Slow to select

    date/time. • Almost “for free”. • Use colorAccent.
  14. Details View - Pickers • Old-fashioned. • Slow to select

    date/time. • Almost “for free”. • Use colorAccent.
  15. Details View - Ripple • One of key features of

    Material Design. • Tangible surfaces. • selectableItemBackground (Borderless). • RippleDrawable.
  16. Details View - Ripple <style name="WunderlistTheme.Details">
 <item name=“colorControlHighlight”>@color/gray</item>
 </style> <FrameLayout


    android:background=“@color/yellow“
 android:foreground="?attr/selectableItemBackground"/> <ripple android:color="?attr/colorControlHighlight">
 <item android:drawable=“@color/yellow“ />
 </ripple> <FrameLayout
 android:background="@drawable/ripple"/>
  17. Details View - Ripple <style name="WunderlistTheme.Details">
 <item name=“colorControlHighlight”>@color/gray</item>
 </style> <FrameLayout


    android:background=“@color/yellow“
 android:foreground="?attr/selectableItemBackground"/> <ripple android:color="?attr/colorControlHighlight">
 <item android:drawable=“@color/yellow“ />
 </ripple> <FrameLayout
 android:background="@drawable/ripple"/>
  18. Details View - Note transition • Meaningful motion. • Share

    views between activities. • API 21+ only. <style name="WunderlistTheme" parent=“WunderlistTheme.Base">
 <item name="android:windowContentTransitions">true</item>
 <item name="android:windowSharedElementEnterTransition">
 @android:transition/move
 </item>
 </style>
  19. Details View - Note transition • Meaningful motion. • Share

    views between activities. • API 21+ only. <style name="WunderlistTheme" parent=“WunderlistTheme.Base">
 <item name="android:windowContentTransitions">true</item>
 <item name="android:windowSharedElementEnterTransition">
 @android:transition/move
 </item>
 </style>
  20. Details View - Note transition <EditText
 android:transitionName="Note transition"/> Intent intent

    = new Intent(context, NoteActivity.class);
 intent.putExtra(EXTRA_TASK_NOTE, note); ActivityOptionsCompat options =
 ActivityOptionsCompat.makeSceneTransitionAnimation(
 context,
 noteTextView,
 "Note transition"
 ); ActivityCompat.startActivityForResult(context, intent, REQUEST_CODE, options.toBundle());
  21. Details View - Note transition <EditText
 android:transitionName="Note transition"/> Intent intent

    = new Intent(context, NoteActivity.class);
 intent.putExtra(EXTRA_TASK_NOTE, note); ActivityOptionsCompat options =
 ActivityOptionsCompat.makeSceneTransitionAnimation(
 context,
 noteTextView,
 "Note transition"
 ); ActivityCompat.startActivityForResult(context, intent, REQUEST_CODE, options.toBundle());
  22. Details View - Note transition <EditText
 android:transitionName="Note transition"/> Intent intent

    = new Intent(context, NoteActivity.class);
 intent.putExtra(EXTRA_TASK_NOTE, note); ActivityOptionsCompat options =
 ActivityOptionsCompat.makeSceneTransitionAnimation(
 context,
 noteTextView,
 "Note transition"
 ); ActivityCompat.startActivityForResult(context, intent, REQUEST_CODE, options.toBundle());
  23. Details View - Note transition <EditText
 android:transitionName="Note transition"/> Intent intent

    = new Intent(context, NoteActivity.class);
 intent.putExtra(EXTRA_TASK_NOTE, note); ActivityOptionsCompat options =
 ActivityOptionsCompat.makeSceneTransitionAnimation(
 context,
 noteTextView,
 "Note transition"
 ); ActivityCompat.startActivityForResult(context, intent, REQUEST_CODE, options.toBundle());
  24. Home View - FAB and Nav. drawer? • Circular button

    made of paper. • Lifts and emits ink reactions on press. • Used for promoted actions, not mandatory. • Never use it for destructive actions.
  25. Home View - FAB and Nav. drawer? • Circular button

    made of paper. • Lifts and emits ink reactions on press. • Used for promoted actions, not mandatory. • Never use it for destructive actions.
  26. Home View - FAB and Nav. drawer? • Circular button

    made of paper. • Lifts and emits ink reactions on press. • Used for promoted actions, not mandatory. • Never use it for destructive actions.
  27. Home View - FAB <ripple android:color="?attr/colorControlHighlight">
 <item android:drawable="@drawable/shape_fab_list_button"/>
 </ripple> <ImageButton


    android:layout_width="?attr/actionBarSize"
 android:layout_height="?attr/actionBarSize"
 android:layout_marginBottom="16dip"
 android:background="@drawable/fab_list_background"
 android:src="@drawable/ic_add"
 android:tint="@android:color/white"
 android:elevation="4dip"
 android:stateListAnimator="@drawable/z_selector"/> <item android:state_pressed="true">
 <set>
 <objectAnimator android:propertyName="translationZ"
 android:duration="200"
 android:valueTo="8dip"
 android:valueType="floatType"/>
 </set>
 </item>
  28. Home View - FAB <ripple android:color="?attr/colorControlHighlight">
 <item android:drawable="@drawable/shape_fab_list_button"/>
 </ripple> <ImageButton


    android:layout_width="?attr/actionBarSize"
 android:layout_height="?attr/actionBarSize"
 android:layout_marginBottom="16dip"
 android:background="@drawable/fab_list_background"
 android:src="@drawable/ic_add"
 android:tint="@android:color/white"
 android:elevation="4dip"
 android:stateListAnimator="@drawable/z_selector"/> <item android:state_pressed="true">
 <set>
 <objectAnimator android:propertyName="translationZ"
 android:duration="200"
 android:valueTo="8dip"
 android:valueType="floatType"/>
 </set>
 </item>
  29. Home View - FAB <ripple android:color="?attr/colorControlHighlight">
 <item android:drawable="@drawable/shape_fab_list_button"/>
 </ripple> <ImageButton


    android:layout_width="?attr/actionBarSize"
 android:layout_height="?attr/actionBarSize"
 android:layout_marginBottom="16dip"
 android:background="@drawable/fab_list_background"
 android:src="@drawable/ic_add"
 android:tint="@android:color/white"
 android:elevation="4dip"
 android:stateListAnimator="@drawable/z_selector"/> <item android:state_pressed="true">
 <set>
 <objectAnimator android:propertyName="translationZ"
 android:duration="200"
 android:valueTo="8dip"
 android:valueType="floatType"/>
 </set>
 </item>
  30. New List - Extended Toolbar • Extended Toolbar to emphasise

    input field. • Removed blocks, keep focus. • FloatLabelLayout from Chris Banes. • And yes, rounded avatars.
  31. New List - Extended Toolbar • Extended Toolbar to emphasise

    input field. • Removed blocks, keep focus. • FloatLabelLayout from Chris Banes. • And yes, rounded avatars.
  32. New List - Extended Toolbar • Extended Toolbar to emphasise

    input field. • Removed blocks, keep focus. • FloatLabelLayout from Chris Banes. • And yes, rounded avatars.
  33. New List - Extended Toolbar <android.support.v7.widget.Toolbar
 app:theme="@style/ThemeOverlay.AppCompat.Dark.ActionBar"
 android:elevation="4dip"
 android:minHeight=“?attr/actionBarSize" android:layout_height=“wrap_content”>



 <FloatLabelLayout
 app:floatLabelTextAppearance=“ @style/TextAppearance.ToolBar.FloatLabel"
 app:floatLabelHint="List name"
 app:floatLabelPaddingLeft="6dip">

 <EditText
 android:hint="List name"
 android:textSize="22sp"
 android:textColor="@color/white"/>
 </FloatLabelLayout>
 </android.support.v7.widget.Toolbar>
  34. New List - Transition • We wanted to use a

    meaningful transition. • We tested 4 different variants, all with
 pros/cons. • Concerns about performance in low end
 devices. • FAB animation, activity transition and circular reveal.
  35. New List - Transition • We wanted to use a

    meaningful transition. • We tested 4 different variants, all with
 pros/cons. • Concerns about performance in low end
 devices. • FAB animation, activity transition and
 circular reveal.
  36. New List - Transition ViewCompat.animate(FAB).scaleX(0.01f).scaleY(0.01f)
 .alpha(0f).withEndAction(openActivity(FAB)); <style name="WunderlistTheme.NewList">
 <item name=“android:windowEnterTransition">

    @transition/new_list_transition</item>
 </style> <transitionSet android:ordering="together">
 <explode/>
 <fade/>
 </transitionSet> int cx = (mToolbar.getLeft() + mToolbar.getRight()) / 2;
 int cy = (mToolbar.getBottom() + mToolbar.getBottom()) /2;
 int finalRadius = Math.max(mToolbar.getWidth(), mToolbar.getHeight());
 Animator anim =
 ViewAnimationUtils.createCircularReveal(mToolbar, cx, cy,
 0, finalRadius);
 anim.start();
  37. New List - Transition ViewCompat.animate(FAB).scaleX(0.01f).scaleY(0.01f)
 .alpha(0f).withEndAction(openActivity(FAB)); <style name="WunderlistTheme.NewList">
 <item name=“android:windowEnterTransition">

    @transition/new_list_transition</item>
 </style> <transitionSet android:ordering="together">
 <explode/>
 <fade/>
 </transitionSet> int cx = (mToolbar.getLeft() + mToolbar.getRight()) / 2;
 int cy = (mToolbar.getBottom() + mToolbar.getBottom()) /2;
 int finalRadius = Math.max(mToolbar.getWidth(), mToolbar.getHeight());
 Animator anim =
 ViewAnimationUtils.createCircularReveal(mToolbar, cx, cy,
 0, finalRadius);
 anim.start();
  38. New List - Transition ViewCompat.animate(FAB).scaleX(0.01f).scaleY(0.01f)
 .alpha(0f).withEndAction(openActivity(FAB)); <style name="WunderlistTheme.NewList">
 <item name=“android:windowEnterTransition">

    @transition/new_list_transition</item>
 </style> <transitionSet android:ordering="together">
 <explode/>
 <fade/>
 </transitionSet> int cx = (mToolbar.getLeft() + mToolbar.getRight()) / 2;
 int cy = (mToolbar.getBottom() + mToolbar.getBottom()) /2;
 int finalRadius = Math.max(mToolbar.getWidth(), mToolbar.getHeight());
 Animator anim =
 ViewAnimationUtils.createCircularReveal(mToolbar, cx, cy,
 0, finalRadius);
 anim.start();
  39. New List - Transition ViewCompat.animate(FAB).scaleX(0.01f).scaleY(0.01f)
 .alpha(0f).withEndAction(openActivity(FAB)); <style name="WunderlistTheme.NewList">
 <item name=“android:windowEnterTransition">

    @transition/new_list_transition</item>
 </style> <transitionSet android:ordering="together">
 <explode/>
 <fade/>
 </transitionSet> int cx = (mToolbar.getLeft() + mToolbar.getRight()) / 2;
 int cy = (mToolbar.getBottom() + mToolbar.getBottom()) /2;
 int finalRadius = Math.max(mToolbar.getWidth(), mToolbar.getHeight());
 Animator anim =
 ViewAnimationUtils.createCircularReveal(mToolbar, cx, cy,
 0, finalRadius);
 anim.start();
  40. Settings • Hard to navigate. Lots of scroll needed. •

    Extended ToolBar, style from HomeView. • ViewPager for better navigation. • Fake headers and scroll listeners. • Sub-sections are simply PreferenceFragment.
  41. Settings • Hard to navigate. Lots of scroll needed. •

    Extended ToolBar, style from HomeView. • ViewPager for better navigation. • Fake headers and scroll listeners. • Sub-sections are simply PreferenceFragment.
  42. Settings • Hard to navigate. Lots of scroll needed. •

    Extended ToolBar, style from HomeView. • ViewPager for better navigation. • Fake headers and scroll listeners. • Sub-sections are simply PreferenceFragment.
  43. What is next? • Android Wear app. • Lists hierarchy.

    • Location Based Reminders. • Integrations. • And more!
  44. bb Thanks!! Q & A Material Fest @ Cádiz -

    01/02/15 Antonio J. Consuegra @aconsuegra 6Wunderkinder GmbH
