Secure Boot on Arm Systems

Secure Boot on Arm Systems

Secure boot on x86_64 is mostly taken for granted, as it is a mature feature in UEFI. When it comes to Arm, the Secure Boot implementation can differ on each platform as there's no standardization.

In this session, we will learn the general approach used by vendors to implement a complete chain of trust and how you could use it in openSUSE for your next embedded project.

https://www.youtube.com/watch?v=3g-WURfbhKI

Alexandre Vicenzi

June 27, 2024
Tweet

More Decks by Alexandre Vicenzi

Other Decks in Technology

Transcript

  1. About me • Software Engineer @ SUSE ◦ Container ecosystem

    ◦ Previously automotive • openSUSE ◦ Package maintainer ◦ Community moderator (Portuguese language) ◦ Mirror administrator (South America)
  2. Agenda • What • Why • How • UEFI Secure

    Boot • TF-A Trusted Board Boot
  3. What is secure boot? • Standard developed by PC industry

    • Authenticity ◦ Ensure that the image is from a trusted source • Integrity ◦ Ensure that the image has not been tampered with • Each component of the boot process is digitally signed • Each component of the boot process gets verified ◦ Verification failure aborts the boot process • Secure boot? Trusted boot? Chain of Trust?
  4. Why we need it? • Security ◦ Boot verified and

    trusted images only ◦ Image has not been tampered with • Compliance ◦ Cyber Resilience Act (EU)
  5. How it works? • Images are signed ◦ Firmware ◦

    Bootloader • Each image is verified before execution • Keys for validation and verification are stored safely ◦ On the SoC or NV-RAM • Process often varies by architecture and manufacturer ◦ UEFI Secure Boot ▪ Standard for x86 ▪ Often found on Arm hardware for data centers ◦ Trusted Firmware-A Trusted Boot ▪ For embedded applications
  6. UEFI Secure Boot • Verification mechanism from UEFI ◦ Each

    program loaded is validated and trusted • shim is an EFI application ◦ First stage bootloader ◦ Used by most distros • shim opens, verify and execute another application ◦ e.g., GRUB • shim is signed by Microsoft UEFI CA • GRUB is signed with your key ◦ The shim validates GRUB signature
  7. UEFI Secure Boot Sequence • SB verification sequence ◦ UEFI

    loads and verifies shim ◦ shim loads and verifies GRUB • System panics if the verification fails • shim allows user managed keys ◦ Also known as Machine Owner Key (MOK) ◦ Keys can be added or removed by the user ◦ Separate from the distro CA key UEFI SHIM GRUB Kernel
  8. Trusted Firmware-A Trusted Board Boot • Based on Arm Trusted

    Board Boot Requirements (TBBR) ◦ ARM DEN0006D • Establishes a Chain of Trust ◦ Using Public-Key-Cryptography Standards • Each component trusts the next • Authenticates all firmware images up to a regular bootloader • The process vary across platforms and manufactures • CoT requires ◦ BL1 residing in the ROM ◦ Self-signed certificates ◦ Signing of firmware images ◦ Key provisioning ▪ Burning the keys ▪ Locking the keys ▪ Enforcing secure boot
  9. TF-A Trusted Board Boot Sequence • Chain of Trust verification

    sequence ◦ BL1 loads and verifies BL2 ◦ BL2 loads and verifies BL3x • System panics if the verification fails BL1 Trusted ROM BL2 Trusted Boot BL31 Runtime BL32 Secure Payload (OP-TEE) BL33 Bootloader (U-Boot) Kernel ARM Trusted Firmware
  10. Hardware support • Platforms compliant with Arm SystemReady ◦ e.g.,

    Ampere, NVIDIA, NXP, Xilinx ◦ UEFI Secure Boot • NXP i.MX 6/7/8/9 ◦ High Assurance Boot (HABv4) • NXP Layerscape ◦ QorIQ Trust Architecture • Marvell Armada • STM32 • and more
  11. Creating an image • Generate key pair for signature •

    Prepare binaries ◦ Vendor firmware ◦ Kernel, Initramfs, Device Tree (dtb) ◦ Trusted Firmware-A, U-Boot • Signing binaries ◦ TF-A handles it during build time ◦ On some platforms it requires proprietary tools to sign • Bundle everything
  12. Preparing TF-A • Build requires a few dependencies ◦ U-Boot

    ◦ OP-TEE (Optional) ◦ Signing keys ◦ In some cases ▪ Proprietary initialization firmware ▪ Proprietary signing tools • Enabling extra build arguments ◦ TRUSTED_BOARD_BOOT=1 ◦ GENERATE_COT=1 • Signature is embedded into each image ◦ BL2, BL31, BL32, BL33
  13. Building TF-A $ make PLAT=lx2160ardb \ TRUSTED_BOARD_BOOT=1 \ CST_DIR=/cst \

    BOOT_MODE=sd \ RCW=/rcw/rcw_2200_750_3200_19_5_2.bin \ BL33=/boot/u-boot.bin \ all fip pbl Compile FIP and PBL
  14. Bundling all together • Create a rootfs ◦ Kernel, Initramfs,

    DTBs, Bootloader ◦ User-space applications • Write firmware files to their respective offsets ◦ Offset can vary by platform and storage type
  15. Open Build Service • KIWI can be used to build

    images • User defined scripts can perform many actions ◦ Most Arm images already use user scripts ▪ To write U-Boot ▪ To perform partition changes • pre_disk_sync.sh is used to change the root tree contents ◦ Copy files to their proper location ◦ Firmware, bootloaders, device tree, etc • editbootinstall.sh is used to write binaries into disk offsets ◦ Each firmware file has its own offset ◦ Offset varies by board and media storage (eMMC, SD, etc) • The private key used to sign needs to be stored in OBS ◦ Can't be hosted on public instances
  16. References • TF-A Trusted Board Boot • openSUSE UEFI •

    NXP Layerscape Software Development Kit User Guide • NXP Code Signing Tool
