Apache Hadoop Shell Rewrite

This is a slightly updated draft of a talk I was planning on giving at Hadoop Summit in 2015. However the abstract was rejected. Rather than toss it, I'm going to share it with all of you on the (almost) 1 year anniversary of the first big commit of this feature!

Keep in mind that this is (currently) locked away in trunk. If you ever want to see this see the light of day, bug your vendors....

(FYI: This is my first attempt at using Speaker Deck. All of my other talks are over at http://slideshare.net/allenwittenauer )

Transcript

1. Shell Script Rewrite Overview Allen Wittenauer
2. Twitter: @_a__w_ (1 a 2 w 1)
   Email: aw @ apache.org!
3. 3 What is the shell code?! ! ! bin/*! ! etc/hadoop/*sh! ! libexec/*! ! sbin/*! !
5. CUTTING, DOUG 1710 554 6239 2005 APACHE SOFTWARE FOUNDATION
6. 6 https://www.flickr.com/photos/new_and_used_tires/6549497793/
8. 8 https://www.flickr.com/photos/hkuchera/5084213883
11. 11 https://www.flickr.com/photos/83633410@N07/7658225516/
12. “[The scripts] finally got to you, didn’t they?”
13. 13 Primary Goals! Consistency! Code and Config Simplification! De-clash Parameters! Documentation! ! Secondary Goals! Backward Compatibility! “Lost” Ideas and Fixes!
14. 14 https://www.flickr.com/photos/k6mmc/2176537668/
15. 15 ! ! Tuesday, August 19, 2014 majority committed into trunk:! ! ! ! ! ! ... followed by many fixes & enhancements from the community
16. 16 https://www.flickr.com/photos/ifindkarma/9304374538/   https://www.flickr.com/photos/liveandrock/2650732780/
17. 17 Old:! ! hadoop -> hadoop-config.sh -> hadoop-env.sh! ! yarn -> yarn-config.sh -> yarn-env.sh! ! hdfs-> hdfs-config.sh -> hadoop-env.sh ! ! New:! ! hadoop -> hadoop-config.sh! -> hadoop-functions.sh! ! ! ! ! ! ! ! -> hadoop-env.sh! ! yarn -> yarn-config.sh! -> hadoop-config.sh -> (above)! ! ! ! ! ! ! -> yarn-env.sh! ! hdfs -> hdfs-config.sh! -> hadoop-config.sh -> (above)!
18. 18 Old:! ! yarn-env.sh:!       JAVA_HOME=xyz   ! hadoop-env.sh:!     JAVA_HOME=xyz   ! mapred-env.sh:!     JAVA_HOME=xyz     New:! ! hadoop-env.sh!     JAVA_HOME=xyz   ! OS X:!     JAVA_HOME=$(/usr/libexec/java_home)
19. 19 Old:! ! xyz_OPT=“-­‐Xmx4g”  hdfs  namenode       java  …  -­‐Xmx1000  …  -­‐Xmx4g  …     ! ! Command line size: ~2500 bytes! New:! ! xyz_OPT=“-­‐Xmx4g”  hdfs  namenode       java  …  -­‐Xmx4g  …   ! ! Command line size: ~1750 bytes
20. 20 ! $  TOOL_PATH=blah:blah:blah  hadoop  distcp  /old  /new     Error:  could  not  find  or  load  main  class   org.apache.hadoop.tools.DistCp! ! Old:! ! $  bash  -­‐x  hadoop  distcp  /old  /new   +  this=/home/aw/HADOOP/hadoop-­‐3.0.0-­‐SNAPSHOT/bin/hadoop   +++  dirname  -­‐-­‐  /home/aw/HADOOP/hadoop-­‐3.0.0-­‐SNAPSHOT/bin/hadoop   ++  cd  -­‐P  -­‐-­‐  /home/aw/HADOOP/hadoop-­‐3.0.0-­‐SNAPSHOT/bin   ++  pwd  -­‐P   +  bin=/home/aw/HADOOP/hadoop-­‐3.0.0-­‐SNAPSHOT/bin   +  DEFAULT_LIBEXEC_DIR=/home/aw/HADOOP/hadoop-­‐3.0.0-­‐SNAPSHOT/bin/../libexec   +  HADOOP_LIBEXEC_DIR=/home/aw/HADOOP/hadoop-­‐3.0.0-­‐SNAPSHOT/bin/../libexec   +  [[  -­‐f  /home/aw/HADOOP/hadoop-­‐3.0.0-­‐SNAPSHOT/bin/../libexec/hadoop-­‐ config.sh  ]]   …   !
21. 21 New:! ! $  TOOL_PATH=blah:blah:blah  hadoop  -­‐-­‐debug   distcp  /tmp/  /1     DEBUG:  HADOOP_CONF_DIR=/home/aw/HADOOP/conf     DEBUG:  Initial  CLASSPATH=/home/aw/HADOOP/conf             …     DEBUG:  Append  CLASSPATH:  /home/aw/HADOOP/ hadoop-­‐3.0.0-­‐SNAPSHOT/share/hadoop/mapreduce/*     DEBUG:  Injecting  TOOL_PATH  into  CLASSPATH     DEBUG:  Rejected  CLASSPATH:  blah:blah:blah  (does   not  exist)             …   !
22. 22 Old:! ! hdfs help!
23. 23 https://www.flickr.com/photos/joshuamckenty/2297179486/
24. 24 New:! ! hdfs help!
25. 25 Old:! !   hadoop  thisisnotacommand   ! ! == stack trace! New:!   hadoop  thisisnotacommand   ! ! == hadoop help
26. 26 Old:! ! sbin/hadoop-­‐daemon.sh  start  namenode       sbin/yarn-­‐daemon.sh  start  resourcemanager   ! New:! ! bin/hdfs  -­‐-­‐daemon  start  namenode       bin/yarn  -­‐-­‐daemon  start  resourcemanager   ! ! + common daemon start/stop/status routines
27. 27 hdfs  namenode vs hadoop-­‐daemon.sh  namenode   ! Old:!! ! - effectively different code paths! ! - no pid vs pid! ! ! - wait for socket for failure! New:! ! - same code path ! ! - hadoop-­‐daemon.sh  cmd => hdfs  -­‐-­‐daemon  cmd ! ! ! - both generate pid! ! - hdfs  -­‐-­‐daemon  status  namenode
28. 28 Old:! ! “mkdir:  cannot  create  <dir>”! ! “chown:  cannot  change  permission  of  <dir>”! ! ! New:! ! “WARNING:  <dir>  does  not  exist.  Creating.”! ! “ERROR:  Unable  to  create  <dir>.  Aborting.”! ! “ERROR:  Cannot  write  to  <dir>.”
29. 29 Old:! ! (foo)  >  (foo).out     rm  (foo).out       = Open file handle! ! New:!   (foo)  >>  (foo).out     rm  (foo).out   ! ! = Closed file handle! ! ! = rotatable .out files!
30. 30 Old:! ! sbin/*-­‐daemons.sh  -­‐>  slaves.sh  blah! ! (several hundred ssh processes later)! ! *crash*! ! ! New:! ! sbin/*-­‐daemons.sh -> hadoop-­‐functions.sh   ! slaves.sh -> hadoop-­‐functions.sh   ! pdsh or (if enabled) xargs  -­‐P! ! *real work gets done*
31. 31 Old:!   egrep  -­‐c  ‘^#’  hadoop-­‐branch-­‐2/…/*-­‐env.sh   ! ! ! hadoop-env.sh: 59! ! ! ! mapred-env.sh: 21! ! ! ! yarn-env.sh: 60! New:! ! egrep  -­‐c  ‘^#’  hadoop-­‐trunk/…/*-­‐env.sh   ! ! ! hadoop-env.sh: 333! ! ! ! mapred-env.sh: 40! ! ! ! yarn-env.sh: 112! ! ! ! + hadoop-layout.sh.example : 77! ! ! ! + hadoop-user-functions.sh.example: 109
32. But wait! There’s more!
33. 33 ! ! HADOOP_namenode_USER=hdfs ! ! ! hdfs  namenode only works as hdfs! ! ! Fun: HADOOP_fs_USER=aw! ! ! ! hadoop  fs only works as aw! ! ! hadoop  -­‐-­‐loglevel  WARN ! ! ! ! => WARN,whatever! ! hadoop  -­‐-­‐loglevel  DEBUG  -­‐-­‐daemon  start         => start daemon in DEBUG mode!
34. 34 ! Old:! ! HADOOP_HEAPSIZE=15234          <-­‐-­‐-­‐  M  only     JAVA_HEAP_MAX="hahahah  you  set  something  in   HADOOP_HEAPSIZE"   ! New:! ! HADOOP_HEAPSIZE_MAX=15g     HADOOP_HEAPSIZE_MIN=10g        <-­‐-­‐-­‐  units!     JAVA_HEAP_MAX  removed  =>       no  Xmx  settings  ==  Java  default
35. 35 ! Old:! ! Lots of different yet same variables for settings   ! New:! ! Deprecated  ~60  variables     ${HDFS|YARN|KMS|HTTPFS|*}_{foo}  =>         HADOOP_{foo}
36. 36 ! Old:! ! "I wonder what's in HADOOP_CLIENT_OPTS?"! ! "I want to override just this one thing in *-env.sh."! ! New:! ! ${HOME}/.hadooprc
37. 37 ! shellprofile.d! ! ! bash snippets to easily inject:! ! ! classpath! ! ! JNI! ! ! Java command line options! ! ! ... and more!
38. 38 https://www.flickr.com/photos/83633410@N07/7658230838/
39. Power Users Rejoice:! Function Overrides
40. 40 Default *.out log rotation:! ! function  hadoop_rotate_log   {      local  log=$1;      local  num=${2:-­‐5};   !    if  [[  -­‐f  "${log}"  ]];  then  #  rotate  logs          while  [[  ${num}  -­‐gt  1  ]];  do            let  prev=${num}-­‐1              if  [[  -­‐f  "${log}.${prev}"  ]];  then                  mv  "${log}.${prev}"  "${log}.${num}"              fi              num=${prev}          done          mv  "${log}"  "${log}.${num}"      fi   } namenode.out.1  -­‐>  namenode.out.2   namenode.out  -­‐>  namenode.out.1
41. 41 Put a replacement rotate function w/gzip support in hadoop-user-functions.sh!! ! function  hadoop_rotate_log   {      local  log=$1;      local  num=${2:-­‐5};   !    if  [[  -­‐f  "${log}"  ]];  then          while  [[  ${num}  -­‐gt  1  ]];  do              let  prev=${num}-­‐1              if  [[  -­‐f  "${log}.${prev}.gz"  ]];  then                  mv  "${log}.${prev}.gz"  "${log}.${num}.gz"              fi              num=${prev}          done          mv  "${log}"  "${log}.${num}"          gzip  -­‐9  "${log}.${num}"      fi   } namenode.out.1.gz  -­‐>  namenode.out.2.gz   namenode.out  -­‐>  namenode.out.1   gzip  -­‐9  namenode.out.1  -­‐>  namenode.out.1.gz
42. What if we wanted to log every daemon start in syslog?
43. 43 Default daemon starter:! ! function  hadoop_start_daemon   {      local  command=$1      local  class=$2      shift  2   !    hadoop_debug  "Final  CLASSPATH:  ${CLASSPATH}"      hadoop_debug  "Final  HADOOP_OPTS:  ${HADOOP_OPTS}"   !    export  CLASSPATH      exec  "${JAVA}"  "-­‐Dproc_${command}"  ${HADOOP_OPTS}  "$ {class}"  "$@"   }
44. 44 Put a replacement start function in hadoop-user-functions.sh!! ! function  hadoop_start_daemon   {      local  command=$1      local  class=$2      shift  2   !    hadoop_debug  "Final  CLASSPATH:  ${CLASSPATH}"      hadoop_debug  "Final  HADOOP_OPTS:  ${HADOOP_OPTS}"   !    export  CLASSPATH      logger  -­‐i  -­‐p  local0.notice  -­‐t  hadoop  "Started  ${COMMAND}"      exec  "${JAVA}"  "-­‐Dproc_${command}"  ${HADOOP_OPTS}  "$ {class}"  "$@"   }
45. Secure Daemons
46. What if we could start them as non-root?
47. 47 Setup:! ! sudoers (either /etc/sudoers or in LDAP):! ! hdfs   ALL=(root:root)   NOPASSWD:  /usr/bin/jsvc! ! hadoop-env.sh:! ! HADOOP_SECURE_COMMAND=/usr/sbin/sudo
48. 48 # hadoop-user-functions.sh: (partial code below)! function  hadoop_start_secure_daemon   {                  …      jsvc="${JSVC_HOME}/jsvc"   !    if  [[  “${USER}”  -­‐ne  "${HADOOP_SECURE_USER}"  ]];  then            hadoop_error  "You  must  be  ${HADOOP_SECURE_USER}  in  order  to  start  a   secure  ${daemonname}"          exit  1      fi                     …      exec  /usr/sbin/sudo  "${jsvc}"  "-­‐Dproc_${daemonname}"  \      -­‐outfile  "${daemonoutfile}"  -­‐errfile  "${daemonerrfile}"  \      -­‐pidfile  "${daemonpidfile}"  -­‐nodetach  -­‐home  "${JAVA_HOME}"  \      —user  "${HADOOP_SECURE_USER}"  \      -­‐cp  "${CLASSPATH}"  ${HADOOP_OPTS}  "${class}"  "$@"   }
49. 49 $ hdfs  datanode! sudo launches jsvc as root! jsvc launches secure datanode! ! ! In order to get -­‐-­‐daemon  start to work, one other function needs to get replaced*, but that’s a SMOP, now that you know how!! ! ! * - hadoop_start_secure_daemon_wrapper  assumes it is running as root!
50. 50 Lots more, but out of time... e.g.:! ! ! Internals for contributors! ! Unit tests! ! API documentation! ! Other projects in the works! ! ...! ! ! Reminder: This is in trunk. Ask vendors their plans!
51. 51 https://www.flickr.com/photos/nateone/3768979925
52. Altiscale copyright 2015. All rights reserved. 52
