Yugabyte & Databricks Spark workshop at Distrib...

Amey Banarse
September 22, 2021

Yugabyte & Databricks Spark workshop at Distributed SQL Summit(DSS) 2021

Session Youtube video link:https://www.youtube.com/watch?v=2NpwlFyMhtE

session blog: https://www.yugabyte.com/blog/tutorial-building-applications-with-yugabytedb-and-spark/

At Distributed SQL Summit 2021, I presented a workshop on how to build an application using the YugabyteDB Spark Connector and Databricks Spark to deliver business outcomes for our customers.

The YugabyteDB Spark Connector combines the best-of-breed technologies of Databricks Spark — an industry-leading, distributed computing engine — with YugabyteDB, a modern, cloud-native distributed SQL database. This connector allows customers to seamlessly and natively read from, perform complex ETL, and write to YugabyteDB.

Amey Banarse

September 22, 2021

Transcript

23 slides
  1. © 2021 - All Rights Reserved 1 Building Applications with

    YugabyteDB and Databricks Spark Amey Banarse Wei Wang
  2. © 2021 - All Rights Reserved Who we are Wei

    Wang VP of Field Engineering, Yugabyte, Inc. Pivotal • FINRA • NYSE University of Pennsylvania (UPenn) @ameybanarse about.me/amey Amey Banarse Principal Pre Sales Architect Rackspace • Accenture • HP Enterprise University of Oklahoma @wwang0825 2
  3. © 2021 - All Rights Reserved Workshop Agenda 3 •

    Overview of Yugabyte Architecture • Yugabyte’s YCQL API • YugabyteDB Spark Connector • Hands-on Workshop with Databricks Spark
  4. © 2021 - All Rights Reserved Transactional, distributed SQL database

    designed for resilience and scale 100% open source, PostgreSQL compatible, enterprise-grade RDBMS …..built to run across all your cloud environments 4
  5. © 2021 - All Rights Reserved Designed for cloud native

    microservices. 5 Sharding & Load Balancing Raft Consensus Replication Distributed Transaction Manager & MVCC Document Storage Layer Custom RocksDB Storage Engine DocDB Distributed Document Store Yugabyte Query Layer YSQL YCQL PostgreSQL Google Spanner YugabyteDB SQL Ecosystem ✓ Massively adopted ✘ New SQL flavor ✓ Reuse PostgreSQL RDBMS Features ✓ Advanced Complex ✘ Basic cloud-native ✓ Advanced Complex and cloud-native Highly Available ✘ ✓ ✓ Horizontal Scale ✘ ✓ ✓ Distributed Txns ✘ ✓ ✓ Data Replication Async Sync Sync + Async
  6. © 2021 - All Rights Reserved 6 ◦ Strongly-consistent secondary

    indexes ◦ Native JSON support ◦ Geographic location hints to optimize cost and latency ◦ Distributed ACID transactions ◦ Geo-distributed ◦ Supports Cassandra CQL 3.9.x and 4.x Features Cassandra YCQL Clustering and sharding ✓ ✓ Keyspaces and tables ✓ ✓ Indexes & unique constraints ✓ ✓ Transactions ✓ ✓ Strongly consistent secondary indexes 𐄂 ✓ Native JSON 𐄂 ✓ Geographic location hints 𐄂 ✓ In addition to Cassandra CQL API support, YCQL adds the following enhancements: Yugabyte Query Layer - YCQL
  7. © 2021 - All Rights Reserved 7 Secondary Indexes -

    YCQL CREATE TABLE product_rankings ( asin text, category text, sales_rank int, ... PRIMARY KEY (asin, category) ); CREATE INDEX top_products_in_category ON product_rankings (category, sales_rank, asin); Partition by product ID for efficient lookups Secondary index to list top products in a category
  8. © 2021 - All Rights Reserved 8 Secondary Indexes -

    YCQL SELECT * FROM product_rankings WHERE asin = '0684841363'; SELECT * FROM product_rankings WHERE category = 'Books' LIMIT 10 OFFSET 20; Query by ID for product summary data Query by index to list top products in a category by sales rank (best sellers)
  9. © 2021 - All Rights Reserved Global Transactions Multi-Row/Multi-Shard Operations

    At Scale 9 CREATE TABLE orders ( order_id text PRIMARY KEY, user_id uuid, order_details jsonb, ... ) WITH transactions = {'enabled': 'true'}; Update inventory and orders tables atomically. Simple to enable global transactions on any table Use JSON type for flexible schema objects.
  10. © 2021 - All Rights Reserved 10 Global Transactions Multi-Row/Multi-Shard

    Operations At Scale BEGIN TRANSACTION UPDATE product_inventory SET quantity = quantity - 2 WHERE asin = '0684841363'; INSERT INTO orders (order_id, user_id, order_details, … ) VALUES ('<order-id>', '<user-id>', '{id: "0684841363", quantity: 2, … }', … ); END TRANSACTION; Decrease inventory count for products fulfilled. Query and index by JSON attributes if needed! Add to orders table for products purchased.
  11. © 2021 - All Rights Reserved 12 YugabyteDB Spark Connector

    Source Tables Derived Tables Enrichment / pre-aggregation Batch Aggregates Key features: • Native JSONB support - ex. Column pruning • Performance optimizations with predicate pushdowns • Cluster, topology and partition awareness
  12. © 2021 - All Rights Reserved What we will be

    building in this workshop? Integrating Apache Spark with Yugabyte Cloud A Scala Application Yugabyte Cloud Read From Write To YugabyteDB Spark Connector 3.0-yb-8 - Compatible with Spark 3.0 and Scala 2.12 - Compatible with Yugabyte YCQL 3.7+ - Exposes YCQL tables as Spark RDDs and Datasets/DataFrames - Saves RDDs /DataFrames back to Cassandra by implicit saveToCassandra call - Allows for execution of arbitrary CQL statements Yugabyte Cloud - Data source and target for Spark application - Namespace: test - Table: Employees_json Spark application: Native support of JSON - Read from and write to Yugabyte cloud - Perform sample ETL operation: Window function - Process JSON data type Apache Spark 3.x YugabyteDB Spark Connector Spark APIs Perform ETL 13
  13. 19 Yugabyte Confidential © 2019 All rights reserved. YCQL Example

    CREATE KEYSPACE example WITH REPLICATION = {'class': 'SimpleStrategy', 'replication_factor': '3'};; CREATE TABLE user_actions(user_id INT, ts TIMESTAMP, action TEXT, PRIMARY KEY((user_id), ts)) WITH CLUSTERING ORDER BY (ts DESC); INSERT INTO user_actions(user_id, ts, action) VALUES (1, '2000-12-2 12:30:15', 'log in'); INSERT INTO user_actions(user_id, ts, action) VALUES (1, '2000-12-2 12:30:25', 'change password'); INSERT INTO user_actions(user_id, ts, action) VALUES (1, '2000-12-2 12:30:35', 'log out');
  14. 20 Yugabyte Confidential © 2019 All rights reserved. Databricks Scala

    Notebook (ycql) import org.apache.spark.SparkConf import org.apache.spark.SparkContext import com.datastax.spark.connector._ import com.datastax.spark.connector.cql._ val keyspace = "example" val table = "user_actions" val tableDf = spark.read .format("org.apache.spark.sql.cassandra") .options(Map( "table" -> table, "keyspace" -> keyspace)) .load() tableDf.show() +-------+-------------------+---------------+ |user_id| ts| action| +-------+-------------------+---------------+ | 1|2000-12-02 12:30:35| log out| | 1|2000-12-02 12:30:25|change password| | 1|2000-12-02 12:30:15| log in| +-------+-------------------+---------------+
  15. 21 Yugabyte Confidential © 2019 All rights reserved. YSQL Example

    CREATE SCHEMA cycling; DROP TABLE IF EXISTS cycling.cyclist_name; CREATE TABLE cycling.cyclist_name ( id bigint PRIMARY KEY, lastname character varying (50), firstname character varying (50) ); INSERT INTO cycling.cyclist_name (id, lastname, firstname) VALUES (1, 'VOS','Marianne'); INSERT INTO cycling.cyclist_name (id, lastname, firstname) VALUES (2, 'VAN DER BREGGEN','Anna'); INSERT INTO cycling.cyclist_name (id, lastname, firstname) VALUES (3, 'FRAME','Alex'); INSERT INTO cycling.cyclist_name (id, lastname, firstname) VALUES (4, 'TIRALONGO','Paolo'); INSERT INTO cycling.cyclist_name (id, lastname, firstname) VALUES (5, 'KRUIKSWIJK','Steven'); INSERT INTO cycling.cyclist_name (id, lastname, firstname) VALUES (6, 'MATTHEWS', 'Michael');
  16. 22 Yugabyte Confidential © 2019 All rights reserved. Databricks Scala

    Notebook (ysql) val jdbcDF = spark.read .format("jdbc") .option("url", "jdbc:postgresql://xxx.xxx.xxx.xxx:5433/test") .option("dbtable", "cycling.cyclist_name") .option("user", "yugabyte") .option("password", "<password>") .load() jdbcDF.show() +---+---------------+---------+ | id| lastname|firstname| +---+---------------+---------+ | 3| FRAME| Alex| | 5| KRUIKSWIJK| Steven| | 4| TIRALONGO| Paolo| | 2|VAN DER BREGGEN| Anna| | 6| MATTHEWS| Michael| | 1| VOS| Marianne| +---+---------------+---------+
  17. © 2021 - All Rights Reserved Thank You Join us

    on Slack: yugabyte.com/slack Star us on Github: github.com/yugabyte/yugabyte-db
