Docker Networking

Docker Networking

At #dockerffm, 13.01.15. Introduction to docker networking, pipework, weave, flannel, socketplane, wire.

F28d4f1634bce85c90b76b197b1413d4?s=128

Andreas Schmidt

January 13, 2015
Tweet

Transcript

  1. Docker Networking #dockerffm, 13.01.15 @aschmidt75

  2. Host   Container   ~$ apt-get install

  3. Host     Container   eth0 ~$ ip addr show

    eth0
  4. Host     Container   eth0 vethY vethX Network Namespaces

    Veth   Pair   „namespaced“   interfaces   ethZ
  5. Host       Container   eth0 docker0 Connecting to

    the host network Linux  Bridge,   created  by   dockerd   172.17.42.1/16   172.17.42.5/16   „IPAM“   by  dockerd
  6. Host       Container   eth0 docker0 Connecting to

    the outside world Address  TranslaJon   RouJng   Masquerading       # /sbin/iptables
 -L -n -t nat
  7. Host       Container   eth0 docker0 Containers talk

    on docker0, secured by iptables     Container
  8. Host       Container   eth0 docker0 Across hosts

    via host ips + exposed port forwardings     Container   Host       Container   eth0 docker0     Container
  9. Host       Container   eth0 Multiple tenants, i.e.

    with tagged interfaces     Container   Host       Container   eth0     Container   eth4 eth4 eth5 eth5 Take   tagging   down  to     container   level?
  10. Multiple Hosts/DCs Host   Container   Container   Container

    Container   DC   DC   Host   Container   Container   Container   Container   Host   Container   Container   Container   Container   Host   Container   Container   Container   Container
  11. Pluggable network architecture & multi-host networking

  12. How to ? •  .. integrate containers into an existing

    system infrastructure, •  .. connect to existing networks, •  .. support vlans or vxlans etc.
  13. pipework @jpetazzo github.com/jpetazzo/pipework à Not part of docker! 1

  14. pipework 1 •  creates new linux bridges & works on

    existing Open vSwitch bridges •  injects a new interface into a container •  connects interfaces to bridges •  dhcp, vlan, ovs, ... supported •  independent of docker
  15. Weave weave.works github.com/zettio/weave •  Overlay network •  Router / Switch

    functionality, ships as container •  Encryption •  wraps docker 2 Demos Docs
  16. Flannel github.com/coreos/flannel •  Overlay network •  UDP-based (optional VxLAN-style) • 

    Uses etcd to store cluster/ip infos •  Does not wrap dockerd, but docker0! 3
  17. (*)  hSps://github.com/coreos/flannel/raw/master/packet-­‐01.png   Docker-bridge, modified Flannel-bridge Overlay TEP/Router 3

  18. Socketplane 4 socketplane.io github.com/socketplane/socketplane •  Open vSwitch-based Overlay •  Discovery

    w/ Multicast DNS •  Uses consul to store cluster info •  wraps docker •  ships as container + shell scripts hSps://www.youtube.com/watch?v=ukITRl58ntg   hSps://www.youtube.com/watch?v=5uzUSk3NjD0
  19. socketplane in a picture (*) Host       Container

      eth0 docker0-ovs (*)  according  to  demo  Vagranaile  setup  on  github     eth1 docker0 vxlan  VTEP   port   vlan-­‐tagged   port   Host   4 eth0 eth1 docker0-ovs Privileged   socketplane   Container
  20. Overview Pipework •  Swiss army knife of container/namespace networking! • 

    Low-level, but high degree of freedom when integrating existing network infrastructure (i.e vlans) Weave •  cross-host overlay network magic, encrypted (!) •  Stays parallel to existing network infrastructure Flannel •  Good fit to CoreOS (O RLY?), etcd/systemd/.. •  Integration with VxLAN networks Socketplane •  Open vSwitch-based, integration with ovs-capable network infrastructure in the future •  Working close to Feature Proposals
  21. Test-driven infrastructure & Repeatibility Green Field vs. Brown-Field

  22. Commands are ad-hoc # pipework br1 28096eac487b 192.168.77.10/24 # weave

    launch # weave run 10.0.1.1/24 -t -i ubuntu # socketplane network create web 10.2.0.0/16 # socketplane run -n web -itd ubuntu
  23. ... in contrast to model-based approaches •  Packer -> pckr.json

    •  Vagrant -> Vagrantfile •  Fig -> fig.yaml •  ... ⇒ packer validate ⇒ vagrant destroy ⇒ fig up && fig ps
  24. ~# wire up https://github.com/de-wiring/wire

  25. How it works Model files ~# wire

  26. How it works Model files ~# wire validate Check consistency

    of model
  27. How it works Model files ~# wire validate Check consistency

    of model up ovs à Bridges, dnsmasq à DHCP, fig à containers, then wiring, etc.
  28. How it works Model files ~# wire validate Check consistency

    of model up ovs à Bridges, dnsmasq à DHCP, fig à containers, then wiring, etc. verify Check eveything using linux commands
  29. How it works Model files ~# wire validate Check consistency

    of model up ovs à Bridges, dnsmasq à DHCP, fig à containers, then wiring, etc. verify Check eveything using linux commands spec Generate a #serverspec and run it
  30. How it works Model files ~# wire validate Check consistency

    of model up ovs à Bridges, dnsmasq à DHCP, fig à containers, then wiring, etc. verify Check eveything using linux commands spec Generate a #serverspec and run it down Take it down in reverse order (detach, stop containers, remove dhcp, bridges)
  31. Model Zones •  Separate Components •  i.e. „DMZ is untrusted“

    •  Policy in mind „DMZ à Application, Application à Backend, but not DMZ à Backend“ DMZ   Applica8on   Backend
  32. Model Networks •  Equals Open vSwitch bridge •  Have names

    network ranges •  Host may have an ip on that network •  May be attached to host interfaces •  May serve dhcp using dnsmasq DMZ   Applica8on   Backend   dmz-ext 10.0.1.0/24 dmz-int 10.0.2.0/24 App-int 10.1.0.0/16 be-int 10.37.15.0/24 (dhcp 10.37.15.[20..29]) 10.1.1.15 10.37.15.1
  33. Model Application Groups •  That‘s where containers are in. • 

    Containers are attached to networks of zone. •  Currently managed using fig (1 fig file per app group) DMZ   Applica8on   Backend   Web  group   App  #1   App  #2   DB   NoSQL
  34. Demo

  35. Demo

  36. Demo

  37. Demo

  38. Demo

  39. Goals •  System & Network Architecture specification. •  Manage a

    working application environment, identically between dev, stage and prod. •  Connect multiple docker hosts: using VLANs, VxLANs •  Be pluggable, integrate what‘s coming
  40. Test Driven Infrastructure? github.com/
 de-wiring/containerspec

  41. Thanks! @aschmidt75 github.com/de-wiring andreas@de-wiring.net dustin@de-wiring.net Pipework  is  (C)  @jpetazzo,  .

     Licensed  under  the  Apache  License,  Version  2.0     Weave  is  (C)  2014  Zego  Ltd.  Licensed  under  the  Apache  License,  Version  2.0     Socketplane  is  (C)  2014  SocketPlane,  Inc.  Licensed  under  the  Apache  License,  Version  2.0     Flannel  is  (C)  CoreOS,  Licensed  under  the  Apache  License,  Version  2.0     Wire:  The  MIT  License  (MIT)  Copyright  (c)  2014  Andreas  Schmidt,  DusJn  Huptas
