Modeling data and best practices for the Azure Cosmos DB.

Azure Cosmos DB is Microsoft's globally distributed, multi-model database service. In this session we are going to cover ,modeling of data using NOSQL cosmos database and how it's helpful for distributed application to maintain high availability ,scaling in multiple region and throughput.

Transcript

1. Modeling data and best practices for the Azure Cosmos DB Mohammad Asif Waquar @asifwaquar
2. 2 about me Senior Software Engineer at ABN AMRO https://www.linkedin.com/in/mohammad-asif-6a6153111/
3. SQL PASS Chapter Team @arrnagaraj @Sachit_Keshari @SanjivVenkatram @sarbjitgill @aaroh_bits @Pioisms
4. Agenda Intro Cosmos DB Resource Model Data Modelling Strategy & Partitioning Demo SQL API
5. Turnkey global distribution Elastic scale out of storage & throughput Comprehensive SLAs Guaranteed low latency at the 99th percentile Five well-defined consistency models Azure Cosmos DB A globally distributed, massively scalable, multi-model database service
6. Turnkey global distribution Elastic scale out of storage & throughput Comprehensive SLAs Guaranteed low latency at the 99th percentile Five well-defined consistency models Azure Cosmos DB A globally distributed, massively scalable, multi-model database service Column-family Document Graph Key-value
7. Column-family Document Graph Turnkey global distribution Elastic scale out of storage & throughput Comprehensive SLAs Guaranteed low latency at the 99th percentile Five well-defined consistency models TableAPI Key-value Cosmos DB’s API for MongoDB Azure Cosmos DB A globally distributed, massively scalable, multi-model database service
8. Features • Multi-model data paradigm: key-value, document, graph, family of columns; • Low latency for 99% of queries: less than 10 ms for read operations and less than 15 ms for (indexed) write operations; • Designed for high throughput; • Ensures availability, consistency of data, delay at SLA level of 99.999%; • Configurable throughput; • Automatic replication (master-slave); • Automatic data indexing; • Configurable levels of consistency of data. Five different levels (Strong, Bounded Staleness, Session, Consistent Prefix, Eventual);
9. HOW’S THE THROUGHPUT ?
10. Resource Model
11. CONTAINERS Logical resources “surfaced” to APIs as tables, collections or graphs, which are made up of one or more physical partitions or servers. Containers Resource Partitions Collections Tables Graphs Tenants Follower Follower Leader Forwarder Replica Set RESOURCE PARTITIONS • Consistent, highly available, and resource-governed coordination primitives • Consist of replica sets, with each replica hosting an instance of the database engine To remote resource partition(s) Resource Hierarchy
12. Account Database Database Database Database Database Container Database Database Item Account URI and Credentials ********.azure.com pass…
13. Account Database Database Database Database Database Container Database Database Item Creating Account
14. Account Database Database Database Database Database Container Database Database Item Database Representations
15. Account Database Database Database Database Database Container Database Database Item = Collection Graph Table Container Representations
16. Account Database Database Database Database Database Container Database Database Item Document Vertices/Edges Row Collection Graph Table Item Representations
17. Account Database Database Database Database Database Container Database Database Item Conflict Stored procedure Trigger UDF Container-Level Resources
18. Data Modelling Strategy & Partitioning
19. Ways to Model Your Data Normalize everything Embed as 1 piece
20. Data Modelling: Relational vs. Document UserID Name Dob 1 John Smith 8/30/1964 StockID UserID Qty Symbol 1 1 100 MSFT 2 1 75 WMT Document { "id": 1, "name": "John Smith", "dob": "1964-30-08", "holdings": [ { "qty": 100, "symbol": "MSFT" }, { "qty": 75, "symbol": "WMT" } ] } User Table Holdings Table Relational Store Document Store Rows Documents Columns Properties Strongly-typed schemas Schema-free Highly normalized Typically denormalized
21. Modelling challenges • How to de-normalize ? • How to normalize ? • To embed or reference ? • Can I apply joins ? • Should I put data types in same collection ,or different ?
22. Modelling challenges: To embed or reference ? Document "id": 1, "name": "John Smith", "dob": "1964-30-08", "holdings": [ { "qty": 100, "symbol": "MSFT" }, { "qty": 75, "symbol": "WMT" } ] Document { "postid": "1", "title": "My blog post", "body": "Post content…", "comments": [ "comment #1", "comment #2", "comment #3", "comment #4“, : "comment #1598873", : Embed Reference Document { "postid": "1", "title": "My blog post", "body": "Post content…“ } Document Document { Document { } } { "postid": "1", "comment": "comment #3“ }
23. When to embed ? o Data that is queried together, should live together. o Child data is dependent on parent. o 1:1 relationship eg. All customer have email, phone, nric number for 1:1 relationship. o Data doesn’t change that frequently eg. Email ,address don’t change too often. o Usually embedding provides better read performance but trade-off for write performance, So if we aren’t doing more write this approach will be good.
24. When to reference ? o 1 : many (unbounded relationship) o many : many relationships o Data changes at different rates o What is referenced, is heavily referenced by many others o Typically provides better write performance o But may require more network calls for reads
25. Why is choice of partition key so important? o Enables your data in Cosmos DB to scale o Large impact on performance of system What can go wrong? o Hot partitions o Choice forces many cross-partition queries for workload Partitioning
26. Logical partition: Stores all data associated with the same partition key value Physical partition: Fixed amount of reserved SSD-backed storage + compute. Cosmos DB distributes logical partitions among a smaller number of physical partitions. From your perspective: define 1 partition key per container Partitioning
27. Partition Key: User Id Logical Partitioning Abstraction Behind the Scenes: Physical Partition Sets hash(User Id) Psuedo-random distribution of data over range of possible hashed values Cosmos DB Container (e.g. Collection)
28. hash(User Id) …. Melvin karen … Physical Partition 1 Physical Partition 2 Physical Partition n John Dharma Shireesh Nilesh Sukhi Bob Milton … Frugal # of Partitions based on actual storage and throughput needs (yielding scalability with low total cost of ownership) Range 1 Range 2 Range n Physical Partition Sets
29. hash(User Id) …. Melvin Karen … Physical Partition 1 Physical Partition 2 Physical Partition n John Dharma Shireesh Nilesh Sukhi Bob Milton … What happens when partitions need to grow? Range 1 Range 2 Range n Physical Partition Sets
30. hash(User Id) Partition X Dharma Shireesh Nilesh Sukhi Bob Milton … + Dharma Shireesh … Partition X1 Nilesh Sukhi … Partition X2 Partition Ranges can be dynamically sub-divided To seamlessly grow database as the application grows While sedulously maintaining high availability Range 1 Range 2 Range X1 Range X2 Range X Physical Partition Sets
31. hash(User Id) Partition Ranges can be dynamically sub-divided To seamlessly grow database as the application grows While sedulously maintaining high availability Best of All: Partition management is completely taken care of by the system You don’t have to lift a finger… the database takes care of you. Partition X Dharma Shireesh Nilesh Sukhi Bob Milton … + Dharma Shireesh … Partition X1 Nilesh Sukhi … Partition X2 Range 1 Range 2 Range X1 Range X2 Physical Partition Sets
32. Replication and Consistency
33. How do you ensure consistent reads across replicas? - Define a consistency level Replication within aregion - Data moves extremely fast (typically, within1ms) between neighboring racks Global replication - Ittakeshundreds of milliseconds to move data across continents Strongerconsistency Higherlatency Loweravailability Weakerconsistency Lower latency Higher availability Replication and Consistency
34. Consistency Level Guarantees Strong Linearizability (once operation is complete, it will be visible to all), No dirty reads Bounded Staleness Consistent Prefix. Reads lag behind writes by at most k prefixes or t interval (Dirty reads possible Bounded by time and updates.) Similar properties to strong consistency (except within staleness window), while preserving 99.99% availability and low latency. Session Consistent Prefix. Within a session: Predictable consistency for a session, high read throughput + low latency No dirty reads for writers (read your own writes),Dirty reads possible for other users Consistent Prefix Reads will never see out of order writes (no gaps). Eventual Potential for out of order reads. Lowest cost for reads of all consistency levels. Well-Defined Consistency Models
35. Let’s see in action
36. Application uses
37. Important Links https://azure.microsoft.com/en-us/pricing/calculator/?service=cosmos-db#cosmos-db7aed2059-b457-48cc- a0e9-6744ce81096b Pricing Calculator https://docs.microsoft.com/en-us/azure/cosmos-db/sql-query-getting-started Azure Cosmos Emulator https://docs.microsoft.com/en-us/azure/cosmos-db/local-emulator#controlling-the-emulator SQL API Query http://www.microsoft.com/en-us/download/details.aspx?id=46436 Data Migration Tool
38. Questions?
39. Thank you
