Building Blockchain Application with Corda

Asif Waquar
September 19, 2019

Building Blockchain Application with Corda

In this session we covered ,Corda overview ,architecture and use-cases .We have discussed how States,transaction are maintained in Corda and Corda nodes can be deployed on network in consortium.

Asif Waquar

September 19, 2019
Tweet

More Decks by Asif Waquar

Other Decks in Technology

Transcript

  1. 2 Mohammad Asif Waquar Senior Software Engineer atABNAMRO Bank @asifwaquar

    Mohammad Asif Waquar Senior Software Engineer atABNAMRO Bank @asifwaquar BUILDING BLOCKCHAIN APPLICATION WITH CORDA ENTERPRISE
  2. RoadMap o Part-1 -Blockchain Introduction & Architecture on Azure. o

    Part-2 -Fabric Architecture & Installation on Azure o Part-3 - Block chain Hyper ledger deployment on Azure. o Part-4 – Building Blockchain with Corda Enterprise on Azure. o Part-5 - Corda workflow & Swift paymentintegration. o Part-6 - Blockchain with Ethereum & Quorum and deploying in DAPPS Azure. o Part-7 - Handling Media & Documents in BlockChain o Part-8 - Security in Blockchain. o Part-9 - Block chain with IOT . o Part-10 - Hands on Workshop on Blockchain.
  3. Hyperledger Fabric Architecture Orderer • Consensus verification • CreatesBlocks C

    A • Registration ofidentities • Manage C ertificates Peer • EndorsesT x • SimulatesTx • CommitsT x 3ComponentsofFabric L edger Blockchain & WorldState • createCar • queryAllCars • queryCarProperties • changeCarColor • changeCarOwner • EndorsementPolicies • Assets :Anythingthat’s valuablefor theOrganization • T ransactions(State changes of Assets) • GossipProtocol: Theglue that keepsthe peers in healthystate. Allthesecomponentscanbeclusteredfor scalabilityandto avoidSinglePointofFailure Channels SmartContract OtherConcepts • Private subnetfor a set of parties based on Smartcontract • Ledger/Channel • Peerscanhave multipleChannels • PrivateData 1 2
  4. Consortium Network Example of consortium network of 3 organisations Org

    1 and Org 3 run peers Org 2 provide ordering service only.
  5. Corda features 11 • No blockchains, no mining; instead a

    permissioned network • No broadcast: all communication is point-to-point • We reject the notion that data should be broadcast to all participants – or to cumbersome, predefined groups • Message senders need to know the identity of recipients • Data is shared on a need-to-know basis and peers only see what they need to see • Not sending is preferable to sending and encrypting • Unspent Transaction Output (UTXO) for recording states (likeBitcoin) • Platform is JVM-based, written in Kotlin (can use Java, Clojure, etc) • Supports industry-standard protocols: AMQP, JDBC, PKIX, etc • No cryptocurrency but can represent digital cash
  6. The Corda Ledger ALICE BOB ED CARL DEMI 1 7

    5 9 4 3 2 6 8 ALICE = { } 1 7 BOB = { 1 7 6 5 } CARL = { 9 4 6 5 2 3 } } ED= { 9 4 3 8 } DEMI= { 2 3 8 12 The ledger from each peer’s point of view is the union of all intersections with other network peers (some of which may be the empty set) Numbered circles represent unique shared facts
  7. Anatomy of a bilateral ledger ALICE BOB 1 7 •

    There is no “central ledger” • Each network peer maintains a separate vault of facts (akin to rows in a DB table) • All peers to a shared fact store identical copies • Not all on-ledger facts have to be shared with other peers • The black square “11” is an example of a on-ledger fact not shared with any peers • Immutable: easy to do analysis on a static snapshot of the data and reason about the contents • No accounts: easy to apply transactions in parallel • Transaction ordering: impossible to mis-order transactions due to reliance on hash functions to identify previous states • Consensus: conflict is the double spend problem • Auditability: full history of all activity is recorded 6 5 Id Fact 1 “Much consensus” 7 “So bilateral” 11 “Wow ledger” Id Fact 1 “Much consensus” 6 “Very fact” 7 “So bilateral” 5 “amaze network” 11 13
  8. Flows Flows are light-weight processes used to coordinate interactions required

    for peers toreach consensus about shared facts. State Object States are immutable objects that represent (shared) facts such as a financial agreement or contract at a specificpoint in time Transaction Transactions consume input states and create output states. The newly created output states replace the input states which are marked as historic. Consensus Parties reach consensus on the evolution of a shared fact. This is done by testing the validity (by way of contract code) and uniqueness (by way of the notary) of the transaction. Corda: Key Concepts IOU CONTRACT REF IOU STATE PROPERTIES From: Alice To: Bob Amount: £10 Due: 01/03/2017 Paid: £5 Penalty: 20% PARTICIPANTS Alic e Bob OUTPUT STATE INPUT STATE ALICE BOB NOTARY 14
  9. 1 3 5 4 2 2 • • Doorman: Enforces

    rules regarding the information nodes must provide before being admitted to the network. If satisfied, node’s identity is certified with a root-authority-signed TLS certificate. Nodes: JVM run-time with a unique network identity running Corda with two interfaces: network layer (interacting with other nodes) and RPC (interacting with node’s owner) • Network Map Service: Publishes IP addresses throughwhich all nodes can be reached along with certificates and services provided by node • Notary: Attest uniqueness, and possibility the validity, of ledger updates. • Oracles: Well-known service that signs transactions if they state a fact and that fact is considered to be trust Corda Network: Detailed Overview A Corda Network includes a 1) doorman (“permissioning service”), 2) two or more Corda Nodes, 3) a network map service, 4) one or more notary nodes and 5) zero or more oracles 17 1 3 2 4 5
  10. • A Corda network is a fully connected graph •

    No global broadcast or gossip network • Communication occurs on a point-to point basis only • Peers communicate using AMQP/1.0 over TLS • Network map service publishes list of peers • Graph edges represent the potential to communicate, not persistent connections • Think Email and SMTP A Corda Network A Corda network is an authenticated peer-to-peer network of nodes where each node is a Java Virtual Machine run-time environment hosting Corda services and executing applications known as CorDapps Name: Network Map Services: Network map service Address: 192.168.0.2:10005 Public key: t453wv84bvt3cj5w3h Name: Alice Services: Cash Issuer, bond issuer Address: 192.168.0.3:10005 Public key: 5h54h5wv632vhy55 Name: Bob Services: Cash Issuer, bond issuer Address: 192.168.0.4:10005 Public key: 5hw03nnk43jknkj4n NOTARY NODE PERMISSIONING SERVICE CERTIFICATE SIGNING 18 1
  11. What makes a Business Network? We expect that single business

    networks will typically be set up by a consortium of banks and a system delivery partner, and they will include: • A ledger agreement / set ofrules • An operating entity • The specific ledger application for this ledger(CorDapp) • Common network parameters that allow Nodes to transact A network will comprise a number of CordaNodes: • Bank nodes • A Doorman Node • At least one Notary node • Oracles • Messaging Gateways (e.g. SWIFT) Bank A Bank B Bank C Bank D Bank E Doorman Notary Oracle Gateway Peer-to-Peer communications Connectivity to rest of bank Connectivity to external services 19 But of course we want many of these business networks, andour primary objective is for them to be able to interoperate..
  12. p1 5 . AL ICE BOB transaction proposal proposal and

    her signature to Bob 3. Bob inspects the proposal, verifies it and then signs it 4. Bob sendsback the transaction and his signature to Alice 1 . Alice creates a new ce 5.Alice verifies the transaction and checks Bob’s signature Uninvolved peers do not receiveany of Alice’s or Bob’s transactions and sign it. 2.Alice sends the Flows
  13. Single VM Ledger on Microsoft Azure Step-2 Fill all user

    credentials details Single VM Ledger on Microsoft Azure
  14. Single VM Ledger on Microsoft Azure Step-4 Choose notary type

    validating / Nonvalidating notary. Validating Notary will verify all previous transactions.
