LegoSDN HotNets 2014

Tolerating SDN Application Failures with LegoSDN, HotNets 2014.

A redesign of the SDN controller architecture centering around a set of abstractions to eliminate the fate-sharing relationships between SDN applications & the controller, and between the SDN applications themselves.

Transcript

1. Tolerating Application Failures with LegoSDN Balakrishnan Chandrasekaran Theophilus Benson Duke University
2. Quality of Code “In C, I never learned to use the debugger, so I used to never make mistakes …” “I went millions and millions of hours with no problems—probably tens of millions of hours with no problems.” — Arthur Whitney, creator of A, K and Q. ACM Queue, Feb 2009. October 28, 2014 HotNets 2014 | LegoSDN 2
3. Bugs are endemic in software! § Bugs can be deterministic or non- deterministic § [STS] Pox Premature PacketIn – l2_multi routing module failed unexpectedly with a KeyError. October 28, 2014 HotNets 2014 | LegoSDN 3
4. Cascading Crashes October 28, 2014 HotNets 2014 | LegoSDN 4 Controller A App1 A App2 A … in out
5. Cascading Crashes October 28, 2014 HotNets 2014 | LegoSDN 5 Controller A App1 A App2 A … in out
6. Cascading Crashes October 28, 2014 HotNets 2014 | LegoSDN 6 Controller A App1 A App2 A … in out
7. LegoSDN § Availability is of utmost importance – Second only to security October 28, 2014 7 HotNets 2014 | LegoSDN
8. Fate-sharing § Fate-sharing relationships between – the SDN controller and the SDN application(s) (also between SDN applications) – the SDN application and the network § Failure in any one SDN application brings down the other applications, and the SDN controller. October 28, 2014 8 HotNets 2014 | LegoSDN
9. Three-pronged approach Controller A App1 A App2 A … in out 1 October 28, 2014 HotNets 2014 | LegoSDN 9 Contain crash
10. Three-pronged approach Controller A App1 A App2 A … in out 2 October 28, 2014 HotNets 2014 | LegoSDN 10 Undo changes
11. Three-pronged approach Controller A App1 A App2 A … in out 3 October 28, 2014 HotNets 2014 | LegoSDN 11 Handle message
12. Controller architecture must support two new abstractions October 28, 2014 HotNets 2014 | LegoSDN 12
13. Current architecture Controller A App1 A App2 October 28, 2014 HotNets 2014 | LegoSDN 13
14. Isolate SDN-Apps from the controller Sandbox A App1 Sandbox A App2 Controller October 28, 2014 HotNets 2014 | LegoSDN 14
15. Isolate SDN-Apps from the controller Sandbox A App1 Sandbox A App2 Controller October 28, 2014 HotNets 2014 | LegoSDN 15
16. Isolate SDN-Apps from the controller Sandbox A App1 Sandbox A App2 Controller October 28, 2014 HotNets 2014 | LegoSDN 16
17. Isolate SDN-Apps from the network Sandbox A App1 Controller a October 28, 2014 HotNets 2014 | LegoSDN 17
18. Isolate SDN-Apps from the network Sandbox A App1 Controller a October 28, 2014 HotNets 2014 | LegoSDN 18
19. LegoSDN AppVisor Stub Lightweight wrapper AppVisor Proxy Message dispatcher SDN-App is treated as a black-box. Stub and proxy allow SDN-Apps to talk to controller. NetLog Transactional support Sandbox A App1 Controller a AppVisor Stub AppVisor Proxy NetLog October 28, 2014 HotNets 2014 | LegoSDN 19
20. LegoSDN Built on top of FloodLight Ported three applications bundled with FloodLight to LegoSDN Sandbox A App1 Controller a AppVisor Stub AppVisor Proxy NetLog October 28, 2014 HotNets 2014 | LegoSDN 20
21. Three-pronged approach Controller A App1 A App2 A … in out 3 October 28, 2014 HotNets 2014 | LegoSDN 21 Handle message
22. How do you handle the crash inducing message? October 28, 2014 HotNets 2014 | LegoSDN 22
23. 1. Crash and burn § Halt the application – SDN-App cannot continue processing – Other SDN-Apps can continue unaffected § No Compromise – Think of security related SDN-Apps Correctness: SDN-App’s ability to implement its functionality without change, according to the specification. October 28, 2014 HotNets 2014 | LegoSDN 23
24. 2. Induce amnesia § Ignore or drop the crash inducing message – SDN-App will not see the message again § Complete Compromise October 28, 2014 HotNets 2014 | LegoSDN 24
25. 3. Apply transformations § Transform the offending message into another one that the application can handle – application will continue with a modified input § Equivalence Compromise October 28, 2014 HotNets 2014 | LegoSDN 25
26. Course of action? No Compromise Apply Transformation(s) Complete Compromise Operator October 28, 2014 HotNets 2014 | LegoSDN 26
27. Related work § Fault tolerance – via reboots – applying Paxos for leader selection § Debugging SDN-Apps or the controller October 28, 2014 HotNets 2014 | LegoSDN 27
28. Message equivalence § How do you determine two messages are equivalent? October 28, 2014 HotNets 2014 | LegoSDN 28
29. Rollbacks are non-trivial § Rollback of one or more rules installed changes controller’s view of the state of network – Might induce crashes of other SDN applications that rely on a consistent view of network state October 28, 2014 HotNets 2014 | LegoSDN 29
30. Error propagation § Last message received by the SDN-App prior to the crash need not be the culprit! – How far along should we go back in history to find the root cause of the crash? – Recovery from an earlier checkpoint; How many checkpoints should we maintain? October 28, 2014 HotNets 2014 | LegoSDN 30
31. Road ahead § Rethink controller architecture – LegoSDN is only the tip of the iceberg. § Resilient controllers can catalyze adoption § Failures need to be a first-class citizen October 28, 2014 HotNets 2014 | LegoSDN 31
32. October 28, 2014 HotNets 2014 | LegoSDN 32 [https://twitter.com/tech_faq/status/450276248854355968]
