1. GPIO Zero
   Ben Nuttall
   Raspberry Pi Foundation
   UK Charity 1129409


   View Slide

2. Ben Nuttall
   ●
   Raspberry Pi Community Manager
   ●
   Based in Cambridge
   ●
   Creator of gpiozero python library
   ●
   Columnist on opensource.com
   ●
   github.com/bennuttall
   ●
   twitter.com/ben_nuttall
   ●
   ben@raspberrypi.org


   View Slide

3. GPIO Pins – General Purpose
   Input/Output


   View Slide

4. GPIO Zero: a friendly API for GPIO devices
   from gpiozero import LED
   led = LED(17)
   led.on()


   View Slide

5. Multi-paradigm: procedural
   from gpiozero import LED, Button
   led = LED(17)
   button = Button(4)
   while True:
   if button.is_pressed:
   led.on()
   else:
   led.off()


   View Slide

6. Multi-paradigm: event-driven
   from gpiozero import LED, Button
   led = LED(17)
   button = Button(4)
   button.when_pressed = led.on
   button.when_released = led.off


   View Slide

7. Multi-paradigm: declarative
   from gpiozero import LED, Button
   led = LED(17)
   button = Button(4)
   led.source = button.values


   View Slide

8. GPIO Zero supports...


   View Slide

9. GPIO Zero Device Hierarchy!


   View Slide

10. .value
    >>> led = PWMLED(17)
    >>> led.value
    0.0
    >>> led.on()
    >>> led.value
    1.0
    >>> led.value = 0


    View Slide

11. .value
    >>> led = PWMLED(17)
    >>> pot = MCP3008()
    >>> led.value = pot.value


    View Slide

12. .value
    >>> led = PWMLED(17)
    >>> pot = MCP3008()
    >>> led.value = pot.value
    >>> while True:
    ... led.value = pot.value


    View Slide

13. Source / Values
    Output Device
    .value
    .values
    .source
    Input Device
    .value
    .values


    View Slide

14. Source / Values
    Output Device
    .value
    .values
    .source
    Input Device
    .value
    .values


    View Slide

15. Source / Values
    from gpiozero import LED, Button
    led = LED(17)
    button = Button(2)
    led.source = button.values


    View Slide

16. Processing values
    Output Device
    .value
    .values
    .source
    Input Device
    .value
    .values
    function


    View Slide

17. Source tools
    from gpiozero import Button, LED
    from gpiozero.tools import negated
    led = LED(4)
    btn = Button(17)
    led.source = negated(btn.values)


    View Slide

18. Combining values
    Output Device
    .value
    .values
    .source
    Input Device
    .value
    .values
    Source tool
    Input Device
    .value
    .values


    View Slide

19. Source tools
    from gpiozero import Button, LED
    from gpiozero.tools import all_values
    button_a = Button(2)
    button_b = Button(3)
    led = LED(17)
    led.source = all_values(button_a.values, button_b.values)


    View Slide

20. Supporting multiple back-ends
    ●
    RPi.GPIO
    ●
    Implemented in C, current default
    ●
    RPIO
    ●
    Implemented in C
    ●
    pigpio
    ●
    Python wrapper for C library, runs as daemon, remote pins
    ●
    Native
    ●
    Pure Python, limited functionality, experimental
    ●
    MockPin & MockPWMPin
    ●
    Pure Python, used in test suite


    View Slide

21. MockPin
    $ GPIOZERO_PIN_FACTORY=mock python3
    >>> from gpiozero import LED
    >>> led = LED(22)
    >>> led.blink()
    >>> led.value
    True
    >>> led.value
    False


    View Slide

22. MockPin
    >>> from gpiozero import LED
    >>> led = LED(22)
    >>> button = Button(23)
    >>> led.source = button.values
    >>> led.value
    False
    >>> button.pin.drive_low()
    >>> led.value
    True


    View Slide

23. pigpio - remote GPIO from Pi or PC


    View Slide

24. pigpio - remote GPIO from Pi or PC
    from gpiozero import LED
    from gpiozero.pins.pigpio import PiGPIOFactory
    factory = PiGPIOFactory('192.168.0.2')
    led = LED(22, pin_factory=factory)
    led.blink()


    View Slide

25. pigpio - remote GPIO from Pi or PC
    $ PIGPIO_ADDR=192.168.0.2 python3 led.py
    from gpiozero import LED
    led = LED(22)
    led.blink()


    View Slide

26. Internal devices
    ●
    TimeOfDay
    ●
    PingServer
    ●
    CPUTemperature
    ●
    More coming soon
    ●
    Make your own!


    View Slide

27. Energenie tortoise lamp
    from gpiozero import Energenie, TimeOfDay
    from datetime import time
    lamp = Energenie(1)
    daytime = TimeOfDay(time(9), time(18))
    lamp.source = daytime.values


    View Slide

28. Is the internet working?
    from gpiozero import LED, PingServer
    from gpiozero.tools import negated
    green = LED(17)
    red = LED(18)
    google = PingServer('google.com')
    green.source = google.values
    green.source_delay = 60
    red.source = negated(green.values)


    View Slide

29. CPU Temperature
    from gpiozero import LEDBarGraph, CPUTemperature
    cpu = CPUTemperature(min_temp=50, max_temp=90)
    leds = LEDBarGraph(2, 3, 4, 5, 6, 7, 8, pwm=True)
    leds.source = cpu.values


    View Slide

30. guizero


    View Slide

31. Raspberry Pi Desktop x86


    View Slide

32. Raspberry Pi Desktop x86 – Remote GPIO


    View Slide

33. GitHub


    View Slide

34. pinout command line tool


    View Slide

35. Read the docs!


    View Slide

36. The MagPi


    View Slide

37. GPIO Zero Book


    View Slide

38. GPIO Zero
    Ben Nuttall
    Raspberry Pi Foundation
    UK Charity 1129409


    View Slide
