Art of Smuggling HTTP Requests

BreachForce
September 29, 2024

Art of Smuggling HTTP Requests

Title: Can Request Encryption Fix Your Web Apps?
Presenter: Saurabh Tiwari
Event: BreachForce CyberSecurity Cohort
Talk Date: 19th-May-2024

Key Takeaways: Techniques behind HTTP request smuggling attacks, exploit vulnerabilities and manipulate HTTP requests, hands-on experience through interactive exercises.

BreachForce

September 29, 2024
Tweet

More Decks by BreachForce

Other Decks in Technology

Transcript

  1. AGENDA  Evolution of HTTP protocol version  HTTP Pipelining

     CL.CL / CL.TE Desync Attack  Impact?  HTTP/2  H2.CL Desync Attack  Websocket  Websocket HRS  Prevention
  2. HTTP/1.0 In early versions of HTTP (version 1.0 and before),

    every request is one TCP connection one that precedes
  3. HTTP/1.1 Uses by default persistent connections to transmit multiples requests

    We can use the header “Connection: close”, if we don’t want persistent connections This version also introduced “Transfer-Encoding” header which is the key to some HRS attacks SOLUTION
  4. HTTP PIPELINING It allows multiple HTTP requests to be sent

    over a single TCP connection without waiting for the correspondin responses
  5. HOW DOES THE SERVER KNOW WHERE A REQUEST ENDS AND

    A NEW REQUEST STARTS? A request is made up of a header section and a body section The headers can have any length and are terminated by \r\n the server can determine the size of the body section using the CL or TE header
  6. HOW DOES THE SERVER KNOW WHERE A REQUEST ENDS AND

    A NEW REQUEST STARTS? A request is made up of a header section and a body section The headers can have any length and are terminated by \r\n the server can determine the size of the body section using the CL or TE header
  7. SO WHERE IS THE CONFUSION? Transfer-Encoding headers are not supported

    by all servers As a result, the confusion appears when the proxy and the backend server do not agree on the size of each request
  8. CONTENT-LENGTH(.)TRANSFER-ENCODING  When both Content-Length and Transfer-Encoding headers are present

    in a message, the server faces a dilemma: which one to prioritize? Fortunately, the HTTP/1.1 RFC provides clear guidance on how to handle this situation.  If a message is received with both a Transfer-Encoding header field and a Content-Length header field, the latter MUST be ignored. Ref: RFC2616 - HTTP/1.1
  9. IMPACT? Leveraging HTTP request smuggling to exploit reflected XSS: 

    When an application is susceptible to both HTTP request smuggling and reflected XSS, a powerful attack vector emerges.  In other words, you can smuggle a request containing the XSS payload, and the next user's request that is processed by the backend server will automatically be affected, allowing you to exploit the XSS vulnerability without any user interaction. Turning an on-site redirect into an open redirect using HTTP request smuggling:  Many applications perform on-site redirects from one URL to another and place the hostname from the request's Host header into the redirect URL  This behavior is normally considered harmless, but it can be exploited in a request smuggling attack to redirect other users to an external domain
  10. HTTP/2 There are only three new concepts that you need

    to understand :-  Pseudo Headers : In HTTP/1, the first line of the request contains the request method and path. HTTP/2 replaces the request line with a series of pseudo-headers. The five pseudo-headers are easy to recognize as they're represented using a colon at the start of the name:
  11. HTTP/2 There are only three new concepts that you need

    to understand :-  Binary Protocol : HTTP/1 is a text-based protocol, so requests are parsed using string operations. HTTP/2 uses a binary protocol, which means that requests and responses are sent as binary data rather than plain text. This binary protocol uses predefined offsets to indicate the start and end of different parts of the request or response, making it much less prone to ambiguity and desync attacks.  Message Length : In HTTP/1, the length of each message body is indicated via the Content-Length or Transfer-Encoding header. In HTTP/2, the message body is composed of data frames, which have a built-in length field. This means that the length of the message body is explicitly specified in the data frames, making it clear and unambiguous.
  12. BUT WAIT, HOW CAN DESYNC ATTACKS STILL HAPPEN IN HTTP/2?

     You might think that with the built-in length field in HTTP/2 data frames, desync attacks would be impossible.  However, the vulnerability lies in HTTP/2 downgrading.  When an HTTP/2 connection is downgraded to HTTP/1, the built-in length field is lost, and the server needs to rely on the Content-Length or Transfer-Encoding header to determine the message length.  This downgrade can create an opportunity for desync attacks to occur. Credit: Portswigger
  13. WEBSOCKET  In traditional HTTP, the client initiates communication by

    sending a request to the server, which then responds with the requested data.  This unidirectional approach can make it challenging to implement certain application features that require real-time, bidirectional communication.  For instance, building a web app that sends instant notifications to users becomes cumbersome, as the client must continuously poll the server for updates, resulting in unnecessary requests and wasted resources.  The WebSocket protocol allows the creation of two-way communication channels between a browser and a server by establishing a long-lasting connection that can be used for full- duplex communications.
  14. WEBSOCKET HANDSHAKE  Client sends GET request (aka Upgrade request)

    to the backend with the set of special HTTP headers: Upgrade, Sec- WebSocket-Version, Sec-WebSocket-Key  Backend should responds with status code 101 and acknowledge nonce sent by client  Backend should compute confirmation value using nonce from client and send it inside Sec-WebSocket-Accept HTTP Header.  After successful handshake client or backend can transfer data using WebSocket frames  If we now add a proxy in the middle, something interesting happens: Instead of fronting the connections themselves, most proxies won't handle the upgrade but will instead relay them to the backend server
  15. PREVENTION  Do not use front-end server.  If used,

    configure them properly to only accept what is acceptable by both the front-end server & backend- server.  Use HTTP/2 end to end and disable HTTP downgrading if possible.  If you can't avoid HTTP downgrading, make sure you validate the rewritten request against the HTTP/1.1 specification.  For example, reject requests that contain newlines in the headers, colons in header names, and spaces in the request method
  16. WHOAMI?  Saurabh Tiwari  23  Working as a

    IT Security Analyst  One of the moderators of BreachForce Cybersecurity Cohort  Also, a student  Life’s motto : Bring on the hardship, it’s preferred in a path of carnage ~ Zoro
