1. WebAssembly :
 a new virtual machine for the Web Mozilla Japan N. Shimizu (nshimizu@mozilla-japan.org) Emscripten Night!! @ DRECOM Cafe 2016/10/05
2. IUUQTHJUIVCDPN8FC"TTFNCMZEFTJHOJTTVFT IUUQTHJUIVCDPN'PHBDDJP0QFO%FTJHO
3. Bytes asm.js String AST Parsing Validation Decode Bytes WASM MIR Execut able Validation Emission Compile asm.js is translated as WASM in its compilation pipeline (in SpiderMonkey)
4. N. Shimizu / @chikoski • Mozilla Japan • Developer relation • Localizer: MDN, SUMO, Firefox for iOS • html5j Web platform / html5j Game • Programming language enthusiast • https://speakerdeck.com/chikoski/ • https://html5experts.jp/chikoski/
8. Proudly non-profit, Mozilla makes products like Firefox with a mission to keep the power of the Web in the hands of users everywhere. Mozilla Mission (https://www.mozilla.org/en-US/mission/)
9. Our mission is to promote openness, innovation & opportunity on the Web. Mozilla Mission(https://www.mozilla.org/en-US/mission/)
10. https://www.w3.org/community/webassembly/
12. .P[JMMB .JDSPTPGU (PPHMF "QQMF
13. https://www.w3.org/community/webassembly/
14. +BWB4DSJQU
    7JSUVBM
    .BDIJOF KT 8"4.
    7JSUVBM
    .BDIJOF XBTN
15. Live demo: https://webassembly.github.io/demo/ (Firefox Nightly required)
16. String Executable AST Tokens IR Lexical analysis Parsing Semantic Analysis Optimization code generation Source code compilation (in general)
17. Parsing Download Compile Run WASM Parsing Download Compile Run asm.js Parsing Download Compile Run JS
18. asm.js • An extraordinarily optimizable, "low-level" subset of JavaScript • Numerical operations • Heap access using Array Buffer as linear memory space • Module system (import / export functions) • Type annotation and its formal validation • Foreign function interface (FFI) to JavaScript
19. function Peano(stdlib, ffi, heap){ "use asm"; function zero(){ return 0; } function succ(a){ a = a | 0; return (a + 1) | 0; } return {zero: zero, succ: succ}; } asm.js module
20. function Peano(stdlib, ffi, heap){ "use asm"; function zero(){ return 0; } function succ(a){ a = a | 0; return (a + 1) | 0; } return {zero: zero, succ: succ}; } Type annotations in asm.js
21. function someModule(stdlib, ffi, heap){ var memo = new stdlib.Uint32Array(heap); // snip function f(n){ if(memo[n >> 2] | 0 != 0){ return memo[n >> 2] | 0; } memo[n >> 2] = doSometing(n) | 0; } Heap access in asm.js
22. function Peano(){ use "asm"; // snip return {zero: zero, succ: succ}; } const module = Peano(); const zero = module.zero(); const one = module.succ(zero); asm.js module in JS
24. % emsdk activate latest % source ${where emsdk installed}/emsdk_env.sh % emcc -o helloworld.js helloworld.c % node helloworld.js Hello world! % emcc -o index.html helloworld.c HTML / JS file generation from C / C++ code
25. // call a C function defined as: int add(int a, int b); const add = Module.cwrap("add", "number", ["number, "number"]); const two = add(1, 1); const three = Module.ccall("add", "number", ["number", "number"], [1, 2]); Emscripten translated function call in JS
26. Emscripten bridges the gap between Web and C/C++ • Standard C / C++ libraries • POSIX file system API • MemoryFS / IndexedDB FS / Special file JS emulation • Statically linked libraries • Inline JavaScript • asm.js function export / Object mapping with WebIDL
27. WebAssembly • New web standard discussed in W3C community group • Size and load efficient and portable binary format • Safe and Near-native speed execution • Designed to execute within web browsers as well as non- browser embedding • Text representation (we can "view source" of WASMs)
28. App no compression with gzip compression asm.js WASM asm.js WASM Hello World 301KiB 204KiB 71KiB 26KiB AngryBots 19MiB 6 MiB 4.1 MiB 3.0 MiB StandardAssets 25.7MiB 13.4 MiB 5.5 MiB 4.3 MiB UnityChan-CRS 21.3MiB 11.4 MiB 4.7 MiB 3.7 MiB Size efficiency: asm.js vs WASM
29. WASM's most viable products (MVP) • Module : distributable, loadable and executable unit of code • Behaviors specified in terms of AST (abstract syntax tree) • Linear memory model • Binary format and its equivalent text format • Designed to be implemented both by web browsers and completely difference execution environments
30. (a = (1 + (1 * 2))); a = 1 + 1 * 2;
31. i32.mul i32.add set_local $a 1 i32.const 1 i32.const 2 i32.const AST in WASM
32. i32.mul i32.add set_local $a 1 i32.const 1 i32.const 2 i32.const (set_local $a (i32.add (i32.const 1) (i32.mul (i32.const 1) (i32.const 2)))) WAST: Text representation of WASM (in development)
33. i32.mul i32.add set_local $a 1 i32.const 1 i32.const 2 i32.const Typed stack machine 1 2 3 4 5 6
34. Type name Acceptable values i32 32bit integer i64 64bit integer f32 32bit floating point f64 64bit floating point Types in WASM
35. ptr = malloc(100) 0 address_space_max (< 4GB) 100 byte i32.load i32.store WASM memory model: linear memory
36. Operator Semantics i32.load8_s load 1 byte and extend it to signed i32 i32.load8_u load 1 byte and extend it to unsigned i32 i32.load16_s load 2 bytes and extend it to signed i32 i32.load16_u load 2 bytes and extend it to unsigned i32 i32.load load 4bytes i32 load operators
37. Operator Semantics i32.store8 Store i32 value as i8 i32.store16 Store i32 value as i16 i32.store Store i32 value i32 store operators
38. 0QFSBUPS 4FNBOUJDT grow_memory Grow memory size by given pages current_memory Return current memory size Memory page operators (1page = 64 KiB)
39. Binary encoding • 8bit bytes / byte memory granularity / Little endian • 3 layers of compression: binary encoding / structural compression / compression with generic algorithm (e.g. gzip) • Preamble & sections • Preamble: magic & version number • Section: Import / export declaration, function signature list, set of function bodies, etc
40. fetch("add.wasm").then(response => response.arrayBuffer(); ).then(buffer => { const codeByte = new UInt8Array(buffer); const module = Wasm.instantiateModlue(codeByte); alert(`1 + 2 = ${module.exports.add(1, 2)}`); }); WASM module instantiation
41. Road map Soon after MVP • Threads • Shared memory • Dynamic Linking • zero-cost exceptions • fixed-width SIMDSoon after MVP Future versions • Finer-grained memory control • Large page support • More expressive control flow • GC / DOM integration • Linear memory > 4G • etc
43. IUUQTXXXPQFOXFCHBNFTDPN
