Embedding Lua in Composite OS

Chris Anderson and Terry Knowlton

Project for Advanced Operating and Disitributed Systems at George Washington University (CS 6907.83)

http://faculty.cs.gwu.edu/~timwood/wiki/doku.php/teaching:s2013:advos

Transcript

2. Composite and Lua Chris Anderson Terry Knowlton
3. Lua Small scripting language (20K lines, under 275KB) Very fast Embeddable
4. Goal Add Lua support to Composite
5. Why?
6. Configuration files Use a more modern and pleasant programming language For science!
7. Step 1 Statically compile Lua
8. Lua provides different build targets, so we adapted the simplest one that used the fewest dependencies
9. We then checked external dependences with nm. And found some (most notably, the math library).
10. Step 2 Compile Lua in Composite
11. We basically took the Lua source in its entirety and added it to Composite, for completeness and ease of upgrading later on.
12. Composite provides diet libc, so we linked against that to resolve our dependency issue
13. And after some makefile magic, we managed to output a lua_lang.o file that contained the statically compiled Lua libraries, ready to be embedded into C & Composite.
14. Hooray!
15. Step 3 Get Lua code working in Composite
16. Took it slowly to see what we could get working.
17. First, just made a dummy component that included the Lua headers and initialized the Lua stack.
18. Then, we were able to execute Lua code from a string in our component.
19. lua_State *L = luaL_newstate(); printc("Initialized Lua state”); luaL_dostring(L, "return 'Executing Lua inline'"); const char *str = lua_tostring(L, -1); printc("Lua returned value is %s", str); === Initialized Lua state === Lua returned value is ‘Executing Lua inline’
20. We can load values from a configuration file
21. // tests loading configuration from a file // loads the file, then executes it, which converts the variables // in the file to lua parsable data if (luaL_loadfile(L, "config.txt") || lua_pcall(L, 0, 0, 0)){ printc("error %s", lua_tostring(L, -1)); } lua_getglobal(L, "width"); int width = lua_tonumber(L, -1); printc("Width is %d\n", width); // config.txt -- sample config width = 200 height = 500
22. And execute Lua code from a script file
23. -- file 'foo.lua' function fib(n) if n < 2 then return n else return fib(n-1) + fib(n-2) end end
24. if (luaL_loadfile(L, "foo.lua") || lua_pcall(L, 0, 0, 0)){ // if either call fails, will return non-zero error code and print // it out here printc("error %s", lua_tostring(L, -1)); } // loads the fib function lua_getglobal(L, "fib"); // pushes param onto lua stack int fib_num = 20 lua_pushnumber(L,fib_num); // executes function into lua state lua_pcall(L,1,1,0); int result = (int)lua_tonumber(L, -1); printc("Fib of %d is %d", fib_num, result); === Fib of 20 is 6765
25. We did some testing with the Lua garbage collector
26. list = nil function linked_list(n) for i=1,n do list = {next = list, value = 'foobar'} end end function clear_list() list = nil end [ 1068.108374] Create 40000 nodes [ 1068.108374] Loop 1 [ 1068.108379] Garbage 2816kb [ 1068.108383] Loop 2 [ 1068.130174] Garbage 4893kb [ 1068.152191] Loop 3 [ 1068.152196] Garbage 2816kb [ 1068.163271] Loop 4 [ 1068.163275] Garbage 5283kb
27. We then implemented a key/value store based on the Lua stack
28. Powerful and easy to use through the C API. Lua is dynamically typed so a mix of data types can be stored in the same table. These tables exist within the Lua state.
29. // Store a string value in the specified table void luakv_putstring_bytable (char *key, char *value, char *table_name) { lua_getglobal(L, table_name); if(!lua_istable(L, -1)) { create_tablespace(table_name); } lua_pushstring(L, key); lua_pushstring(L, value); lua_settable(L, -3); } // Creates a table on the lua_State object for general use. void create_tablespace (char *table_name) { // Create the new table and assign it to global name *table_name lua_newtable(L); lua_setglobal(L, table_name); // Put the newly created table on top of the stack lua_getglobal(L, table_name); }
30. === Trying out some keyval operations === Starting lua keyvalue storage test. New Lua state has been set. === tablespace didn't exist so try to create === Attempting to create new lua table with table_name=DEFAULT === trying to getString before fields are entered. received (null) === Put string of value1 into the default table at key1 === Retrieved the value at key1, return was: value1 === Put number value of 2 into the default table at key2 === pull from the table key2: 2 === Attempting to create new lua table with table_name=TABLE2 === Placed key3=value3 and key4=4 into TABLE2 === attempting to retrieve TABLE2 values from DEFAULT table === should have no values returned, retrieved key3=(null) and key4=0 === should now have returned values from table 2 key3=value3 and key4=4 === stored key3=default_value3 in default table === Pulled key3 from both tables. DEFAULT=default_value3 and TABLE2=value3 === lua_state has been closed
31. Future work
32. Export Lua as a usable component, using the cbuf or torrent interface to deal with sharing memory Create a framework to load and parse configuration files Continue testing Lua functions and third party libraries for compatibility
33. github.com/gwu-composite-lua/
