Daten - jetzt! Leichtgewichtige Push-Kommunikation mit ASP.NET SignalR
Ja, es ist cool – aber da ist mehr: Zeitnahes Bereitstellen von aktuellen Daten ist ein wichtiger Erfolgsfaktor in modernen Anwendungen. Benutzer wollen in "Near-Real-Time"-Manier mit Datenupdates in Client-Apps jeglicher Ausprägung versorgt werden. Christian Weyer zeigt anhand des ASP.NET-SignalR-Frameworks, wie man Push Services implementiert und Clients für .NET, Windows 8, iOS, Android und selbstvertständlich für den Browser auf Basis anerkannter Webstandards wie HTTP oder WebSockets anbindet. Es ergeben sich so zahlreiche Möglichkeiten, Ihre Software für den Benutzer "zu verbessern" und für den Entwickler "zu vereinfachen". Push Baby!
Christian Weyer PRO
September 24, 2013
Transcript
30 slides
-
Christian Weyer | thinktecture Daten - jetzt! Leichtgewichtige Push-Kommunikation mit
ASP.NET SignalR think mobile! -
Christian Weyer • Solution architect and principal consultant at thinktecture
• Focus on – distributed applications, service orientation – cloud computing – interoperability, cross-device – pragmatic end-to-end solutions – Windows Server, ASP.NET, Web API, SignalR, WCF, Windows Azure • Microsoft MVP for Windows Azure (Architecture) • ASP.NET Web API Advisory Board Member / ASPInsider • http://blogs.thinktecture.com/cweyer • [email protected] • @christianweyer think mobile! -
Outline Web-based real-time communication Introducing ASP.NET SignalR
Hubs Clients Hosting Summary -
Real time: Problem space It is all about the
users Users want data Now & instant Up-to-date Delivered to any device, over any connection Increasing number of web sites & web applications offer ‚real time‘ data Live searches/updates Stock streamers, auctions Live scores, betting, interactive games Collaborative apps In general: Real-time feedback, real-time notifications -
Real time: Developers’ world Developers look for ways to
provide real time data But not only for web applications What about mobile devices & apps? What about traditional desktop applications? What about server-to-server? Web-based push communication beyond the web is a need We got accustomed to a service-oriented design Think in service facades Facades provide entry points into our logic & data access Think, design & implement Push Services -
Push Services pattern ‘Push Services’ are really not an
official pattern Observer pattern, anyone? Model a service that accepts incoming connections from callers is able to push data down to callers abstracts from communication nitty-gritty details Realize Publish-Subscribe semantics Based on standard web technologies with reach in mind With maximum reach into any device, platform Push Service Consumer Send data External event (Database) External event (Message queue) External event (Other actor) Notify [data] -
HTTP is the protocol When talking about web communication
technologies we talk about HTTP HTTP is warrantor for ubiquity & reach HTTP is inherently request-response, n’est pas? Still we need to realize Push Services with what HTTP gives us -
Technical approaches for push Periodic Polling Long Polling
HTTP Streaming / Comet -
Long polling Poll but don’t respond untill there’s data
Server holds on to the HTTP request until there is data to return (Re-)Poll after data received or after the connection times out Consumes server threads & connection resources Server Client -
Technical approaches for push Periodic Polling Long Polling
HTTP Streaming / Comet Forever Frame Server-Sent Events (SSE) Web Sockets Easy: Web Sockets are the way to go! Only with Windows 8/Server 2012 Network considerations Maybe some time, but not today Alright, let’s just write code for any technology & technique! Erm… really? For any server and any client platform? -
ASP.NET SignalR as a solution SignalR is a
server-side framework to write push services a set of client libraries to make push service communication easy to use on any platform optimized for asynchronous processing Abstracts from the different techniques to implement pushing data Mental model is a persistent connection Volatile, non-durable ‘Signal’, anyone? Sending data to a signal. E.g. represented by a connection ID Part of the ASP.NET brand, but not tied into ASP.NET runtime and APIs -
ASP.NET SignalR development Extensible framework & pipeline Based
on interfaces & DI Two programming models Persistent connections Hubs Hubs offer a pre-defined application-level protocol in an RPC-ish style Easy-to-get-going means for 80/20 situations -
Hubs concept Hubs are classes to implement push services
in SignalR Abstraction on top of persistent connection Convention-over-configuration Hubs provide a higher level RPC framework Perfect for different types of messages to send between server and client Hub conventions Public methods are callable from the outside Send messages to clients by invoking client-side methods Simple steps to get going 1. Write hub class 2. Add route in host process 3. Done -
Programming model Hub name reflected into external API
[HubName] can alias name Return simple type, complex type or Task Complex objects and arrays of objects automatically serialized/deserialized to/from JSON Default is JSON.NET Context holds connection- and request-specific information ConnectionId Request Headers RequestCookies QueryString User -
Hubs protocol Base endpoint is /signalr Optional: get
JS metadata from /signalr/hubs Basically two protocol steps (details vary by transport) /negotiate: which transport do you support? (optional: /ping server) /connect: OK, here is my persistent connection ‘Best’ transport negotiation Web Sockets SSE Forever frame Long polling Pre-defined payload Any data is JSON encoded C: Cursor M: Messages H: Hub name M: Method name A: Method args T: Timeout D: Disconnect -
Pushing data: Clients Clients property as dispatching point to
send messages to clients Holds dynamic properties and methods Target method with parameters is dynamically ‘injected’ into code path, serialized, and embedded into protocol response public void SendMessage(string message) { var msg = string.Format("{0}: {1}", Context.ConnectionId, message); Clients.All.newMessage(msg); } -
Pushing data: Groups Groups Typical base pattern in
push scenarios Can add connections to groups and send messages to particular groups Groups are not persisted on the server We need to keep track of what connections are in what groups No automatic group count public void JoinRoom(string room) { Groups.Add(Context.ConnectionId, room); } public void SendMessageForRoom(string room, string message) { var msg = string.Format("{0}: {1}", Context.ConnectionId, message); Clients.Group(room).newMessage(msg); }4 -
Hub lifecycle Hub connections have a lifecycle Override
async pipeline event handlers Sending data from outside a hub Retrieve hub context (via dependency resolver) private void SendMonitorData(string eventType, string connection) { var context = GlobalHost.ConnectionManager.GetHubContext<MonitorHub>(); context.Clients.All.newEvent(eventType, connection); } public override Task OnConnected() { … } public override Task OnDisconnected() { … } public override Task OnReconnected() { … } -
Hub consumers Consumers can be classic client applications or
other services/hubs SignalR provides a variety of client libraries Microsoft SignalR team .NET 4.0+ WinRT Windows Phone 8 Silverlight 5 jQuery C++ Community iOS native iOS via Mono Android via Mono -
jQuery client HTML5-based applications often use jQuery JSON-based
wire protocol makes it easy to integrate with JavaScript SignalR jQuery plugin offers two approaches Proxy-based with generated proxy Without proxy but ‘late binding’ -
jQuery with proxy Automatic proxy code via /signalr/hubs
Script generated based on hubs declaration in .NET ‘Contract’ if you will Optionally: create static proxy file via signalr.exe tool Simple steps to get going 1. Get reference to hub 2. Wire up events 3. Start hub connection 4. Call method 5. Done Hubs become properties on $.connection E.g. $.connection.chatHub Hub name camel cased -
jQuery with proxy - II $.connection.hub.start can take transport
configuration Auto, or any of the supported persistent connection transports [hub].server.abc Call methods on the server hub [hub].client.xyz Define client-side methods to be invoked by server hub var chat; chat = $.connection.chat; chat.client.newMessage = onNewMessage; var chat; chat = $.connection.chat; $.connection.hub.start({ transport: 'longPolling'}); chat.server.joinRoom('private'); -
jQuery without proxy file We can also use a
late binding approach Simple steps to get going 1. Create hubConnection Derived from $.connection 2. Get dynamic proxy 3. Wire up events based on method/event handler name via on 4. Start & invoke methods based on method name via invoke Same connection-related event handlers Cross-domain support same as with static proxy var connection = $.hubConnection(); var proxy = connection.createHubProxy('chat'); proxy.on('newMessage', onNewMessage); connection.start(); proxy.invoke('sendMessage', $('#message').val()); -
.NET client Client NuGet package contains binaries for all
supported .NET flavors .NET 4.x, SL5 WP8, WinRT Mental model resembles proxy-less JavaScript approach Simple steps to get going 1. Create HubConnection 2. Create hub proxy via CreateHubProxy 3. Wire up event handlers via On 4. Start connection with Start 5. Call methods via Invoke var hubConnection = new HubConnection("http://localhost/services"); var chat = hubConnection.CreateHubProxy("chat"); chat.On<string>("newMessage", …); hubConnection.Start().Wait(); … -
ASP.NET hosting SignalR ASP.NET hosting integrates with RouteTable
Create routes for hubs Referenced assemblies are scanned for Hub implementations In v2 hosting sits on top of OWIN public class Global : System.Web.HttpApplication { protected void Application_Start(object sender, EventArgs e) { // Register the default hubs route: ~/signalr RouteTable.Routes.MapHubs(); } } -
Self hosting Self hosting sits on top of OWIN
IAppBuilder API Simple steps to get going 1. Define startup class with IAppBuilder method signature 2. Map hubs onto IAppBuilder (route) 3. No automatic scanning of referenced assemblies Startup class used in WebApplication.Start to spin up server HTTP or HTTPS base URL jQuery client needs to explicilty set connection URL -
SignalR & Web API Web API == “incoming API”
SignalR == “outgoing API” Can easily leverage same pipeline extensions public abstract class HubApiController<THub> : ApiController where THub : IHub { private Lazy<IHubContext> hub = new Lazy<IHubContext>( () => GlobalHost.ConnectionManager.GetHubContext<THub>()); protected string ConnectionId { get { var connectionId = new FormDataCollection(Request.RequestUri). Get("connectionId"); return connectionId; } } protected IHubContext Hub { get { return hub.Value; } } } -
Summary Deliver data to your users & consumers –
everywhere Building push services with an easy-to-use programming model SignalR hubs Consume push services on nearly any platform Various clients libs for a plethora of programming languages SignalR can be hosted side-by-side or be combined with Web APIs Watch-out for scaling out SignalR server side -
Resources • [email protected] • http://www.thinktecture.com • thinktecture’s GitHub Repositories –
https://github.com/thinktecture • Christian Weyer’s GitHub Repositories – https://github.com/ChristianWeyer • ASP.NET SignalR – http://www.asp.net/signalr 30
