Crowdsourcing Your Cisco Firewall Administration... WAT

In this presentation, Laura Guay and I talk about a vulnerability we discovered in Cisco ASA (CVE-2014-2127) that allows SSL VPN users to administer Cisco ASAs. We talk about how the vulnerability works, how it was fixed and discuss some offensive and defensive take aways for our fellow security professionals.

If you are interested in the demo that accompanied this presentation you can find that here:

https://vimeo.com/93010946

Transcript

1. Crowdsourcing Your Cisco
   Firewall Administration


   View Slide

2. Jonathan Claudius
   ¤  Trustwave SpiderLabs
   ¤  Lead Security Researcher
   ¤  Vulnerability Assessment Team (VAT)


   View Slide

3. Laura Guay
   ¤  Dell SecureWorks
   ¤  Network Security Senior Advisor
   ¤  (aka: Senior Platform Engineer)
   ¤  SME for Cisco and Imperva
   ¤  Former Penetration Tester


   View Slide

4. We hack together


   View Slide

5. Want to crowdsource your firewall
   administration?


   View Slide

6. Yeah… that makes no sense
   ¤  We tried it briefly (via Twitter)
   ¤  People trolled us…
   ¤  “debug all”
   ¤  “write erase”
   ¤  It’s a terrible idea
   ¤  Ideally, firewall management is limited to a set of trusted
   and experienced staff


   View Slide

7. What this talk is really about
   ¤  A vulnerability we found in Cisco ASA that allows SSL VPN
   users to gain full administrative access to the firewall.
   ¤  We will Cover…
   ¤  Vulnerability Discovery
   ¤  Configuration Review
   ¤  Vulnerability Details
   ¤  Live Demonstration
   ¤  Take Away’s (Offense/Defense)


   View Slide

8. Vulnerability Discovery
   How was this vulnerability discovered?


   View Slide

9. ASDM Brute-forcing is slow…
   ¤  DEFCON 21
   ¤  Had quick conversation with Barrett Weisshaar
   ¤  He said ASDM brute-forcing took forever
   ¤  Basic Process
   ¤  Download the Java client
   ¤  Authenticate like a normal Administrator
   ¤  See if you get lucky before your fingers fall off


   View Slide

10. ASDM Brute-force MSF Module
    ¤  Created a Metasploit Module to make it easier


    View Slide

11. Cisco SSL VPN Portal
    ¤  Cisco SSL VPN Portal
    ¤  Allows remote users access to extranet type website
    ¤  Simple form submission authentication
    ¤  Created a Metasploit Aux Module for this too
    ¤  *Realization*
    ¤  ASDM and SSL VPN authentication schemes use similar
    authentication pattern
    ¤  User-Agent based (ASDM vs. Browser Agent)


    View Slide

12. Session Cookie Reuse Idea


    View Slide

13. Filed this one under
    “Interesting, but not likely”


    View Slide

14. Four months later
    ¤  At the kitchen table at my mom’s house over our
    Thanksgiving vacation.
    ¤  Finally revisited the idea.
    ¤  Set aside 15 minutes.


    View Slide

15. And I was…


    View Slide

16. Configuration Review
    Laura to the rescue!!!


    View Slide

17. SSL VPN Options on ASA
    ¤  Clientless (WebVPN)
    ¤  Web portal that requires no external clients
    ¤  Thin-Client
    ¤  Web portal combined with a small java application
    ¤  AnyConnect
    ¤  Thick-Client VPN Access


    View Slide

18. VPN Group Enforcement
    ¤  Group-policy (group-lock)
    ¤  Force users to connect to a specific tunnel-group
    ¤  Prevents unauthorized access to other VPN groups
    group-policy RemoteAccessVPN_GP attributes!
    vpn-tunnel-protocol ikev1 ssl-clientless!
    group-lock value RemoteAccessVPN_TG!


    View Slide

19. VPN User Attributes
    ¤  Privilege
    ¤  Service-type
    ¤  Group-policy
    username sslvpn_user password encrypted privilege 0!
    username sslvpn_user attributes!
    service-type remote-access!
    group-lock value RemoteAccessVPN_TG!


    View Slide

20. Authentication & Authorization
    ¤  AAA authentication (Local or External)
    ¤  Authorization
    aaa authentication ssh console LOCAL !
    aaa authentication http console LOCAL!
    !
    aaa authentication ssh console LDAP_SERVER LOCAL !
    aaa authentication http console LDAP_SERVER LOCAL !
    aaa authorization command LOCAL !
    aaa authorization exec LOCAL!


    View Slide

21. CVE-2014-2127
    ¤  Cisco ASA SSL VPN Privilege Escalation Vulnerability
    ¤  Bug ID: CSCul70099
    ¤  Security Advisory: cisco-sa-20140409-asa
    ¤  Coordinated disclosure on April 9th
    ¤  2 days after OpenSSL Heartbleed release
    ¤  1 day after Windows XP EOL


    View Slide

22. Technical Details
    How the vulnerability works


    View Slide

23. WebVPN – Post Auth


    View Slide

24. How to learn the ASDM paths…
    ¤  Using a custom proxy listener in Burp with Redirection and
    Invisible Proxying to inspect the ASDM HTTPS transport
    layer traffic.
    ¤  Redirection – Bind local ports to remote ports
    ¤  Invisible Proxying – A transparent proxy in Burp
    ¤  “Reversing” Non-Proxy Aware HTTPS Thick Clients w/ Burp
    ¤  http://blog.spiderlabs.com/2014/02/reversing-non-proxy-
    aware-https-thick-clients-w-burp.htm


    View Slide

25. Show Version


    View Slide

26. Dump Config


    View Slide

27. Make Changes


    View Slide

28. Demonstration
    Show and tell


    View Slide

29. Demonstration Context (Live)
    ¤  Malicious Service Provider w/ VPN Access
    ¤  User rights limited, Grouplock, Remote Service Type, AAA
    enabled, LDAP Auth, etc. (aka: best practice)
    ¤  We will show how this user can take full control of the
    firewall in seconds by exploiting this vulnerability
    ¤  Wrote a Metasploit Module for stability reasons
    ¤  Browsers are too flakey (Cookie Mgmt Problems)


    View Slide

30. Takeaways
    Where do we go from here?


    View Slide

31. Defensive Takeaways
    ¤  Patch to the latest version(s)
    ¤  All the settings I mentioned earlier
    ¤  If you don’t you will still be “vulnerable”!!!
    8.2(5.48) 8.4(7.15) 9.0(4.1)
    8.3(2.40) 8.6(1.13) 9.1(4.5)


    View Slide

32. Workarounds
    ¤  Cisco says there are none…
    ¤  Host your SSL VPN / ASDM on different interfaces/port
    ¤  Implement ACLs for ASDM access


    View Slide

33. Detection Logic
    ¤  Monitor for these log message IDs:
    %ASA-7-111009: User '' executed cmd: show version!
    %ASA-3-113021: Attempted console login failed user 'thinclient'
    did NOT have appropriate Admin Rights.!


    View Slide

34. Offensive Takeaways Part 1
    ¤  Social Engineering and MiTM
    ¤  LDAP – Attacking Active Directory
    aaa-server LDAP protocol ldap!
    aaa-server LDAP (inside) host 192.168.101.150!
    ldap-base-dn CN=Users,DC=cisco,DC=local!
    ldap-scope subtree!
    ldap-login-password MyADPassword!!!
    ldap-login-dn CN=Administrator,CN=Users,DC=cisco,DC=local!
    server-type auto-detect!
    ldap-attribute-map LDAP-Example!


    View Slide

35. Offensive Takeaways Part 2
    ¤  Attack ASA modules
    ¤  Denial of service
    ¤  Drop firewall rules
    ¤  Capture all traffic


    View Slide

36. Parting Thoughts
    ¤  Understand the actual risk
    ¤  Patch your ASAs
    ¤  Review your ASA config


    View Slide

37. Thank You!
    ¤  Jonathan Claudius
    ¤  Twitter: @claudijd
    ¤  Email: jclaudius@trustwave.com
    ¤  Laura Guay
    ¤  Twitter: @L_ORA
    ¤  Email: lguay@secureworks.com


    View Slide
