Cloud Genius
December 26, 2013

Best practices for cloud performance in real world networks

Cloud Genius

December 26, 2013

Transcript

15 slides
  1. Network Conditions Vary Wildly 2 ¨  Best to plan cloud

    assuming bad things will happen ¨  We will discuss best practices for cloud architecture LAN Dial up Satellite / WAN Internet and VPN LOW HIGH LOW HIGH Bandwidth RTT
  2. Best Practices for Cloud Performance 3 ¨  Have network applications

    initialize quickly ¤  The user interface should not have to wait for network responses. ¤  Some tasks can be performed before the network is available, or without the network. ¤  If the network is not responding, the user may need the user interface for simple operations, such as closing the application.
  3. Best Practices for Cloud Performance 4 ¨  Do not wait

    for the network for shutdown ¤  Properly designed architectures handle abortive disconnects gracefully. ¤  Do not initiate a potentially lengthy operation, such as synchronizing files or folders with a server, that cannot be interrupted on shutdown. ¤  Networks are not consistently responsive, so even small operations could prove time consuming. ¤  Provide positive feedback for users, including indications of progress and estimated completion times.
  4. Best Practices for Cloud Performance 5 ¨  Ensure a responsive

    user interface ¤  Application responsiveness helps eliminate unnecessary helpdesk calls. ¤  A good guideline for interactive response is 500 milliseconds. ¤  Users perceive pauses longer than 500 milliseconds as a lag in performance. ¤  Applications should be responsive enough to provide the user with confidence about the application.
  5. Best Practices for Cloud Performance 6 ¨  Test in an

    environment with a large RTT to reveal problems ¤  Testing can be performed in several environments, including n  a wireless LAN network, n  a link-delay simulator, or n  a satellite network RTT = Round Trip Time = Time it takes a packet to go from A to B and back.
  6. Best Practices for Cloud Performance 7 ¨  Scrutinize network errors

    ¤  Not all network errors are critical. ¤  For example, an application that has received or posted all of its data can likely ignore errors when closing the connection. ¤  Do not assume the network or the user is available; either handle errors without user intervention, or ignore them if errors are noncritical
  7. Best Practices for Cloud Performance 8 ¨  An application should

    define its own reasonable time outs ¤  For example, a sockets connect request may block under some conditions for as much as 21 seconds. ¤  Introduce your own time outs as appropriate for users
  8. Best Practices for Cloud Performance 9 ¨  Minimize protocol overhead

    ¤  Conserve network bandwidth - minimize the protocol overhead incurred ¤  Eliminate unnecessary network traffic. ¤  Use protocols with a lower header overhead to transfer data. n  For example, when sending smaller amounts of noncritical or repeatable data, use UDP as opposed to TCP to reduce the overhead associated with connection establishment and maintenance. ¤  If the same data must be sent to multiple recipients, consider multicast. ¤  Be aware that UDP traffic is not flow-controlled—pushing beyond the available bandwidth can cause catastrophic network failure.
  9. Best Practices for Cloud Performance 10 ¨  Conserve system resources

    ¤  System resources can be consumed quickly if proper restraint is not used. n  For example, sockets and TCP connections consume resources. ¤  Do not use several TCP connections per client where one will serve the application's purpose.
  10. Best Practices for Cloud Performance 11 ¨  For transactional applications,

    good user experience and low network utilization are not conflicting goals. ¨  Network-intensive applications spend more time waiting ¤  Well designed network applications minimize unnecessary wait time, both n  for the user interface and n  for network transmissions.
  11. Best Practices for Interactive Apps 12 ¨  Make the data

    stream as much as possible, rather than going in chunks. ¨  Use a few large transactions rather than many small ones. Large transactions can also be efficiently streamed. ¨  Minimize reliance on the network - recognize that the network is a slow, unreliable resource. ¨  Use a well-architected representation of the data on the network. The data representation should be computer-architecture agnostic, contain no fat, and possibly be compressed. ¨  During initialization and shutdown, do not make the user wait for the network to start up or shut down. Network related initialization could take a relatively long time. Separate the noncritical network code. ¨  Handle errors as appropriate to their impact. Not all errors are critical. Implement recovery mechanisms and provide nonintrusive user feedback. ¨  Use remote procedure calls (RPC) only when necessary (may result in chatty, fat protocols when used with small data.
  12. Some useful network stats 13 ¨  A healthy cloud instance

    can service about 200,000 simultaneous TCP connections ¨  A webserver can service about 25,000 HTTP requests per second ¨  Cloud instances can transmit about 750Mbps on a transcontinental gigabit network with 10 hops
