RIBs Architecture - why Uber invented their own wheel

Originally posted here: https://speakerdeck.com/dimaosa/ribs-architecture-why-uber-invented-their-own-wheel

RIBs Architecture was presented by UBER in 2017, since than it become an architecture which gain attention all around the globe.

How UBER solved this problems?
Why did they develop their own solution?
Who should consider this architecture?
How to use it?
Where to start?

This talk was made for CocoaHeads Kyiv #14 which took place Oct 6 2018.

Transcript

1. RIBs Architecture.
   Why UBER invented their own wheel?


   View Slide

2. Let’s recall the situation when you open
   someones/yours ViewController and you have
   no clue, What the f*ck is going on here?
   • We know what is going on here

   • We don’t ask other person to explain us what is going on here

   • We write code that is possible to support and extend

   • Easy to add New features

   • Easy to reuse Views


   View Slide

3. Inputs Outputs
   Imagine that every part is a
   component


   View Slide

4. Beer opener
   Bottle of beer
   Electricity
   Bottle
   is opened !
   Unable to
   open a beer
   Beer was
   opened
   Inputs Outputs


   View Slide

5. Things to consider before
   creating new "Part"
   What are your inputs. (Without inputs your part will not work)

   What are your outputs. (What are you trying to achieve by
   implementing it)

   If we attach Part

   (child) to Part

   (parent),

   must satisfy all

   inputs and outputs


   View Slide

6. More examples:


   View Slide

7. Our body is a perfect example of a
   set of reasonably connected parts
   System Parts


   View Slide

8. Our body is a perfect example of a
   set of reasonably connected parts


   View Slide

9. RIBs
   Router Ineractor
   Builder


   View Slide

10. Massive View Controller


    View Slide

11. Massive View Controller


    View Slide

12. State
    Management


    View Slide

13. State Management


    View Slide

14. State Management


    View Slide

15. Search Station RIB


    View Slide

16. Ticket Search RIB ⚙


    View Slide

17. RIB parts
    Interactor
    Router ViewController
    Builder
    Component
    Manage RIBs
    Dependency


    View Slide

18. Communication


    View Slide

19. Communication : Upwards


    View Slide

20. Communication
    Upwards Question from
    GitHub.com
    Question: The issue I'm having is finding a good way of passing data from children
    components (D, E, F) to component in another "subtree" (G).
    Currently, I'm passing this data through every parent component (for example D -> C -
    > B -> A -> Root) using Listeners and then I'm using Rx stream to pass data from Root
    to G.
    This creates a lots of boilerplate and I wonder if there's a better way of doing it.
    https://github.com/uber/RIBs/issues/232
    Answer: You could pass Mutable Rx stream from Root to children (D, E, F), and make changes in D, E, F,
    after that pass NonMutable Rx Stream to G (if you need only listen). So in that way you don't need to use
    Listeners in A, B, C


    View Slide

21. Action
    Action
    Action
    Present here


    View Slide

22. Communication : Downwards


    View Slide

23. Streams
    - LocationManagerStream
    - ProfileManager
    - TrainColorPalette
    - TrainService
    - SearchLocationsStream
    ⚙ - PreferencesStream
    - TicketsStream
    Typically, we store state inside streams of immutable
    models that re-emit values when the details change.


    View Slide

24. Streams


    View Slide

25. Streams
    • MutableStream and Stream


    View Slide

26. Streams


    View Slide

27. Streams


    View Slide

28. Streams


    View Slide

29. No architecture
    View Controller vision
    Day 1 Day 30


    View Slide

30. RIBs vision
    Day 1 Day 30


    View Slide

31. Why UBER invented their
    own wheel?
    • Isolation and Testability. Classes must be easy to unit test and reason about in isolation.
    Individual RIB classes have distinct responsibilities like: routing, business, view logic, creation. Plus, most RIB logic
    is decoupled from child RIB logic. This makes RIB classes easy to test and reason about independently.

    • Tooling for developer productivity. RIBs come with IDE tooling around code
    generation, memory leak detection, static analysis and runtime integrations - all which improve developer
    productivity for large teams or small.

    • An architecture that scales. This architecture has proven to scale to hundreds of
    engineers working on the same codebase and apps with hundreds of RIBs.

    • Shared architecture across iOS and Android. Build cross-platform apps
    that have similar architecture, enabling iOS and Android teams to cross-review business logic code.

    • Open-Closed Principle. Whenever possible, developers should be able to add new features
    without modifying existing code. This can be seen in a few places when using RIBs. For example, you can attach or
    build a complex child RIB that requires dependencies from its parent with almost no changes to the parent RIB.


    View Slide

32. How to add 50 screens feature, spent 8 months, and
    remain linear speed for adding new features… in feature


    View Slide

33. For whom?
    •More than 2 people

    •Feature, feature and one more feature

    •Don’t want to write bad code

    •Never stop scaling

    •Invest your time to learn new
    •Proactive


    View Slide

34. How to start?
    Installation for iOS
    CocoaPods
    To integrate RIBs into your project add the following to your
    Podfile:

    pod 'RIBs', '~> 0.9'
    Carthage
    To integrate RIBs into your project using Carthage add the
    following to your Cartfile:

    github "uber/RIBs" ~> 0.9


    View Slide

35. Where to go next?
    RIBs engineer talk about architecture
    https://www.youtube.com/watch?v=FfwZSk6VRVY
    RIBs Github
    https://github.com/uber/RIBs
    RIBs Slack channel, talk with creators one-to-one
    uber-ribs.slack.com
    Engineering Scalable, Isolated Mobile Features with
    Plugins at Uber
    https://eng.uber.com/plugins/


    View Slide

36. Wanna talk more?
    facebook
    https://www.facebook.com/dima.osadchy
    email
    dima.osadchy@gmail.com


    View Slide

37. The End
    ?
    Or just the beginning


    View Slide
