Security! The Final Frontier

Practical Kubernetes security for application developers

C588f1fd883c753703d302f8b64fde18?s=128

Cong Nguyen

November 21, 2020
Tweet

Transcript

  1. None
  2. Contents IBM Developer A/NZ / Practical Security for Cloud Native

    Developers / Nov 21, 2020 / © 2020 IBM Corporation 2 Network Security Ingress & Routes Service Mesh Secrets Application Hardening Practices and Tools IBM Garage Cloud Native Toolkit Why security? Risk Management Frameworks Legal Requirements Kubernetes Basics Kubernetes’ Origin and Star Trek references What’s Red Hat OpenShift? Kubernetes Security Kubernetes Architecture Kubernetes Attack Vectors Container Security Identity and Access Management (IAM) Role-Based Access Control (RBAC) OpenShift Projects
  3. IBM Developer A/NZ / Practical Security for Kubernetes Developers /

    Nov 21, 2020 / © 2020 IBM Corporation 3 To help keep you entertained, There will be plenty of Star Trek GIFs! General Martok Captain Sisko Elim Garak
  4. IBM Developer A/NZ / Practical Security for Kubernetes Developers /

    Nov 21, 2020 / © 2020 IBM Corporation #DigitalDefence Hack Presentation link will be available at
  5. Legislative Requirements IBM Developer A/NZ / Practical Security for Kubernetes

    Developers / Nov 21, 2020 / © 2020 IBM Corporation 5 Financial Services Industry Must comply and adhere to APRA standards and guidelines for technology choices Payment and Credit Cards Payment Card Industry (PCI) Data Security Standard (DSS) requirements Healthcare Industry HIPAA (Health Insurance Portability and Accountability Act) that defines security measures to protect electronic protected health information (EPHI) HITECH Act covers data requirements for protected health information (PHI), electronics health records (EHR)
  6. Risk Management Frameworks IBM Developer A/NZ / Practical Security for

    Kubernetes Developers / Nov 21, 2020 / © 2020 IBM Corporation 6 International Risk Management Frameworks • NIST SP 800-53: security and privacy controls • ISO 270001: information security management Australian Risk Management Frameworks • Australian Cyber Security Centre (ACSC)’s Information Security Manual (ISM): another source of risk management guidance • Essential Eight (E8): introduces maturity levels and provide a baseline of mitigation strategies Certification • OpenFAIR Certification: provides a taxonomy of terms, definitions, relationships and describes processes in performing risk analysis Dimensions Confidentiality Means of protecting personal privacy and proprietary information. Integrity Guarding against improper information modification or destruction Availability Ensuring timely and reliable access to and use of information
  7. Why do we (app developers) care? IBM Developer A/NZ /

    Practical Security for Kubernetes Developers / Nov 21, 2020 / © 2020 IBM Corporation 7 Broaden our horizon Understand privacy laws, data management and legislative requirements across industries Help with start-up adoption Prepare for a larger market, or just know which vendor to pick when choosing a deployment platform Commander Riker Data Lieutenant Worf
  8. Star Trek (Voyager) References Seven spokes Whilst still a Borg

    After becoming human Seven of Nine Original code name was Project 7 Heavily inspired by Project Borg IBM Developer A/NZ / Practical Security for Kubernetes Developers / Nov 21, 2020 / © 2020 IBM Corporation
  9. Kubernetes (K8s) Core Concepts IBM Developer A/NZ / Practical Security

    for Cloud Native Developers / Nov 21, 2020 / © 2020 IBM Corporation
  10. Containers A container is the smallest compute unit CONTAINER

  11. Containers are created from container images IMAGE CONTAINER Containers BINARY

    RUNTIME
  12. Container images are stored in an image registry IMAGE CONTAINER

    Containers IMAGE REGISTRY RUNTIME IMAGE IMAGE IMAGE
  13. Containers are wrapped in pods which are units of deployment

    and management POD CONTAINER 10.140.4.44 POD CONTAINER 10.15.6.55 CONTAINER Pods and Services
  14. Labels are simple key-value assignments used as a grouping mechanism

    POD CONTAINER role: backend Pods and Services
  15. Services provide internal load-balancing and service discovery across pods POD

    SERVICE “backend” CONTAINER 10.110.1.11 role: backend POD CONTAINER 10.120.2.22 role: backend POD CONTAINER 10.140.4.44 role: frontend role: backend Pods and Services
  16. apps can talk to each other via services POD SERVICE

    “backend” CONTAINER 10.110.1.11 role: backend POD CONTAINER 10.120.2.22 role: backend POD CONTAINER 10.140.4.44 role: frontend role: backend Accesses via services Pods and Services
  17. Add new pods to the list of endpoints load- balanced

    by the service POD SERVICE “backend” CONTAINER 10.110.1.11 role: backend POD CONTAINER 10.120.2.22 role: backend POD CONTAINER 10.130.3.33 role: backend POD CONTAINER 10.140.4.44 role: frontend role: backend Pods and Services
  18. Routes make services accessible to clients outside the environment via

    real-world URLs > curl http://app-prod.mycompany.com POD SERVICE “frontend” CONTAINER role: frontend POD CONTAINER role: frontend POD CONTAINER role: frontend role: frontend ROUTE app-prod.mycompany.com Routes
  19. Persistent Volume andClaims My app isstateful. 2Gi PersistentVolumeClaim 2Gi PersistentVolume

    POD CONTAINER 21
  20. Red Hat OpenShift is Kubernetes with batteries included IBM Developer

    A/NZ / Practical Security for Kubernetes Developers / Nov 21, 2020 / © 2020 IBM Corporation 22 OpenShift Service Mesh OpenShift Serverless odo / Dev Catalog Chief of Security from DS9 Sources: ANZ to move all traffic to re-platform internet banking by March 2021 Case Study: OpenShift at Macquarie
  21. Kubernetes Security IBM Developer A/NZ / Practical Security for Kubernetes

    Developers / Nov 21, 2020 / © 2020 IBM Corporation 23
  22. Kubernetes Cluster Worker Node(s) Kubernetes Pod(s) Master Node(s) Kubernetes Control

    Plane Kubernetes Architecture 24 API Server Controller Scheduler etcd Kubelet Containers Applications Attack Vector Attack Vector Risk Mitigation Access to node Compromise entire cluster SSH on secure ports, authn, authz Access to etcd Access secrets, labels and resources, understand system layout Run a private network, within a VPC, employ secure comms channels Access to K8s API server Compromise entire cluster TLS, use certificates, authn Inject control plane traffic Replace authentic K8s modules TLS, rotate credentials, patches, upgrades Access Kubelet Apply malicious actions to workloads Closed to external networks Container runtime Compromising workloads, escalate privileges to host Use hardened container runtimes Escape container to host Compromise entire cluster No root privileges, prevent escalation Intercept app traffic Compromise user data, potentially escape container to host if root is used Limit ports, persisted data are scanned for malware and viruses, good app sec hygiene Platform’s responsibilities Dev’s responsibilities Admin’s responsibilities As a platform, OpenShift handles these for you Source: OpenShift Security Guide
  23. Containers in Linux IBM Developer A/NZ / © 2020 IBM

    Corporation 25 Source: OpenShift Security Guide All containers share the OS kernel layer from host A container runs as a minimal user layer tailored to that specific application.
  24. Container Engine IBM Developer A/NZ / © 2020 IBM Corporation

    26 Source: OpenShift Security Guide A Practical Introduction to Container Terminology CRI-O is a container engine. It implements the Container Runtime Interface (CRI), to use OCI. CRI-O stands for Container Runtime Interface for OpenShift. runc is the container runtime that actually create containers. It’s OCI runtime standard reference implementation.
  25. Container Security IBM Developer A/NZ / © 2020 IBM Corporation

    27 Sources: Configure a Security Context for a Pod or Container Managing Security Context Constraints SecurityContext defines privilege and access control settings for a Pod or Container, including but not limited to: • Permission to access an object based on UID and GID • Running as privileged or unprivileged • Give a process some additional Linux capabilities (privileges) • Filter a process’ system calls with Seccomp • AllowPrivilegeEscalation: control if a process can gain more privileges than its parents These are set with SecurityContextConstraints (SCC) can only be managed by users with cluster-admin Guidelines for application developers: • Don’t use root • Do use Red Hat Universal Base Image (UBI) as the base image – touched in Application Hardening section. Commander Data
  26. Identity and Access Management (IAM) IBM Developer A/NZ / Practical

    Security for Cloud Native Developers / Nov 21, 2020 / © 2020 IBM Corporation 28 Doctor Bashir Colonel Kira Nerys
  27. Role-Based Access Control – Users IBM Developer A/NZ / Practical

    Security for Cloud Native Developers / Nov 21, 2020 / © 2020 IBM Corporation 29 • Regular users: real people, include cluster admins and regular users. • System users: infrastructure services, components that talk to the Kubernetes APIs. kubeadmin is the first user created with Kubernetes and has super privileges. • Service accounts: specialised user objects intended for infrastructure or non-interactive workloads. Service accounts are created with a secret mounted on disk. • Virtual system users: hard-coded with a system prefix, such as system:anonymous. User User User Group Role Role Binding assigned to via Kubernetes Resources Actions defines taken against Cluster-wide Namespace-wide Source: OpenShift Security Guide
  28. RBAC – Authentication Methods IBM Developer A/NZ / Practical Security

    for Cloud Native Developers / Nov 21, 2020 / © 2020 IBM Corporation 30 OOTB, Kubernetes comes with: • Password files for individual authentication • X.509 certification verification • Token files • Requires external integration for protocols (LDAP, Kerberos, SAML and OAuth2, etc.) Red Hat OpenShift comes with an integrated OAuth2 server. User User User Group Role Role Binding assigned to via Kubernetes Resources Actions defines taken against Cluster-wide Namespace-wide Source: Kubernetes Authentication Strategies OpenShift Security Guide
  29. RBAC – Roles, Actions and Role Bindings IBM Developer A/NZ

    / Practical Security for Cloud Native Developers / Nov 21, 2020 / © 2020 IBM Corporation 31 A role is used to define rules for actions – Kubernetes verbs (list, get, edit, etc.) – on Kubernetes resources. • Cluster-wide role: actions affect cluster-wide • Namespace-wide: role and role-binding within the context of a namespace Kubernetes comes with default roles, including: • User facing roles: cluster-admin, admin (for namespaces), edit, view • Core component: control-plane component roles such as system:kube-controller-manager or system:node Role bindings attach a role to a user. User User User Group Role Role Binding assigned to via Kubernetes Resources Actions defines taken against Cluster-wide Namespace-wide Source: Kubernetes Using RBAC Authorisation
  30. Projects isolate apps across environments, teams, groups and departments PAYMENT

    DEV PAYMENT PROD CATALOG INVENTORY ❌ ❌ ❌ POD C POD C POD C POD C POD C POD C POD C POD C POD C POD C POD C POD C Projects and Users
  31. Networking Security IBM Developer A/NZ / Practical Security for Cloud

    Native Developers / Nov 21, 2020 / © 2020 IBM Corporation 33 Commander Burnham Captain Janeway Covering networking security can get very deep very fast So we’ll cover what we need: Ingress, Routes and Service Mesh
  32. Routes make services accessible to clients outside the environment via

    real-world URLs > curl http://app-prod.mycompany.com POD SERVICE “frontend” CONTAINER role: frontend POD CONTAINER role: frontend POD CONTAINER role: frontend role: frontend ROUTE app-prod.mycompany.com Routes Recap
  33. Kubernetes Ingress vs. OpenShift Routes IBM Developer A/NZ / Practical

    Security for Cloud Native Developers / Nov 21, 2020 / © 2020 IBM Corporation 35 Source: OpenShift Security Guide
  34. OpenShift Routes Terminations IBM Developer A/NZ / Practical Security for

    Cloud Native Developers / Nov 21, 2020 / © 2020 IBM Corporation 36 Source: IBM Cloud OpenShift 4 Route Types OpenShift Security Guide Diagram from OpenShift Blog: Self-Service End-to-End Encryption Approaches for Applications Deployed in OpenShift OpenShift Route objects support four TLS termination methods: • None/Simple/Clear for HTTP routes • Edge: your application pod is exposed on a unencrypted endpoint. The router uses a certificate from the OpenShift cluster to encrypt the connection between the client and the router. • Passthrough: router lets traffic pass through as is, this can be used for HTTP/2 and non-HTTP TLS endpoints. • Re-encrypt: the encrypted connection is terminated at the router but then re-encrypted. Red Hat also provides a example with video on how these terminations are used to implement an end-to-end encryption demo.
  35. Control Plane Service Mesh - Istio IBM Developer A/NZ /

    Practical Security for Cloud Native Developers / © 2020 IBM Corporation 37 Istio provides: • Traffic encryption to defend against MITM attacks • Mutual TLS and Fine- grained access control policies to provide service access controls • Auditing tools to determine who did what and when Certificate Authority Authentication Policies Network Configurations Authorisation Policies istiod Pod Service A Proxy Pod Service B Proxy Ingress Egress API Server JWT + TLS JWT + TLS HTTP, gRPC, TCP Data Plane Data plane traffic, encrypted with mTLS Control plane traffic Types of transport protocol supported Source: Istio Security Concepts Introducing OpenShift Service Mesh 2.0 Service Mesh 2.0 vs Istio Adding External CA for Service Mesh 2.0
  36. Secrets IBM Developer A/NZ / Practical Security for Cloud Native

    Developers / Nov 21, 2020 / © 2020 IBM Corporation 38 Odo Chief O’Brien Doctor Bashir
  37. Secrets Management IBM Developer A/NZ / Practical Security for Cloud

    Native Developers / Nov 21, 2020 / © 2020 IBM Corporation 39 Etcd Datastore Encryption • By default, etcd stores secrets with base64 encoding – cluster admins can decode application secrets. • Additional protection can be enabled by encrypting the etcd datastore. • In OpenShift, keys are automatically created and rotated by the Kubernetes Operators. • Keys are still available as secrets via the kube API to a cluster administrator. • Use an external Key Management Services to encrypt your secrets Passing Secrets to Containers Secrets should be protect in-transit and at-rest. For applications, there are three ways of passing secrets to containers: • Build secrets into images • Use environment variables • Mount a volume into a container that contains a file with secrets It is recommended to use secret data volumes.
  38. Application Hardening IBM Developer A/NZ / Practical Security for Cloud

    Native Developers / Nov 21, 2020 / © 2020 IBM Corporation 40
  39. Red Hat Universal Base Image IBM Developer A/NZ / Practical

    Security for Cloud Native Developers / Nov 21, 2020 / © 2020 IBM Corporation 41 • A trusted supply chain attempt to resolve untrusted base image issue, by enforcing more stringent requirements, such as: • Image comes from a trusted source • Every time it’s extended, the supply chain keeps track of how it was done and scans for potential vulnerabilities or non-compliance Red Hat provides Universal Base Image (UBI) • UBIs are based on RHEL and follows RHEL’s release cycle • Freely shared and deployed on any Kubernetes platform • Language images available in Python, Node, Ruby, PHP, .NET Core, .NET 5.0, NGINX https://catalog.redhat.com/software/containers/search
  40. Golden Images IBM Developer A/NZ / Practical Security for Cloud

    Native Developers / Nov 21, 2020 / © 2020 IBM Corporation 42 Example CI/CD Base Image Hardening Pipeline using UBI on the right →
  41. IBM Assets IBM Developer A/NZ / Practical Security for Cloud

    Native Developers / Nov 21, 2020 / © 2020 IBM Corporation 43 The Cloud Native Toolkit is an open-source asset created by IBM Garage. It helps unify the developer experience for both managed Red Hat OpenShift and Kubernetes environments on IBM Cloud. • Offers production-ready code patterns • Enable delivery of production-ready solutions using a robust SDLC • Built upon key CNCF open-source technologies and tools • Enables code change, continuous integration, testing, continuous delivery, tracing and monitoring in a unified experience • Help teams get started quickly • https://cloudnativetoolkit.dev Spock IBM has a Container Software Certification Program that discusses over 150 certification requirements, best practices and standards.
  42. 44 Continuous Integration Deploy Observe Code Test and Coverage Build

    and Package DEV TEST STAGE Toolkit Components
  43. IBM Developer A/NZ / Practical Security for Cloud Native Developers

    / Nov 21, 2020 / © 2020 IBM Corporation 45 Q&A Uhura
