Building mostly serverless distributed cloud systems step by step

Transcript

1. Building mostly serverless distributed cloud systems step by step Serverless to servers is like wireless to wires
2. About me Ivan Čuljak from Croatia, Europe .NET freelancer in love with Azure, and Xamarin.Forms over time transitioned to Cloud Solution Architect @ Celeste Maze Developing software and being paid for it for 10+ years Building cloud solutions for 6+ years Leveraging serverless in various SaaS projects for over 2.5 years Tested, and sometimes deployed, a whole lot of scenarios that probably weren’t intended to be ran on serverless J @CuljakIvan ivan@culjak.xyz culjak.xyz
3. We’re gonna use these services today Azure Kubernetes Service (AKS) + Virtual Kubelet Azure Functions & Durable Functions Azure Container Instances Azure Service Bus (Queues & Topics) Azure Event Grid Azure Monitor Azure API Management Azure Logic Apps
4. It would be boring to just talk about that whole list, so let’s build a system using them
5. The system we’re gonna design is heavily over-engineered J
6. A news agency is getting a lot of photos and videos submitted, and they’re categorizing them by hand #Problem
7. What do we have at our disposal? A third-party service that returns a JSON describing the content of a photo or a video sent to it A webhook we need to call when done Azure J
8. Webhook & third-party service
9. What’s the fastest thing to do, and what are the problems? HAVE THE NEWS UPLOAD FORM (WEB APP) PING THE THIRD-PARTY SERVICE A human uploading the data will have to wait a long time In case of the third-party service being offline or timing out the news won’t be submitted DEVELOP A MONOLITH AND HOST IT ON PAAS (AZURE APP SERVICE) Scaling takes time Scalable up to a point We need to implement event-sourcing or another way to handle outages/crashes of our service It costs money J
10. Design a mostly serverless system around a service that categorizes photos and videos #Task
11. Step #1 requirements We need something that will respond to HTTP requests We need to upload the payload to Azure Storage We need to send the „process request” down the line We need to respond with a „request ID” We need to do it all as fast as possible to diminsh the wait time for humans
12. Step #1 implementation Remember => Serverless != FaaS (Functions as a Service) Azure Kubernetes Service (AKS) + Virtual Kubelet The left „part” isn’t serverless, but the right one is We can host „normal” APIs in it, but we can also host Functions in it The most important thing is that we always have something that’s awake to respond to HTTP requests ASAP There are some limitations compared to self-hosted Kubernetes
13. AKS and Azure Storage added
14. Step #2 requirements We need figure out what we have to do We need to do it for each photo or video provided We need to form a response We need to send a response to the webhook provided We need it to be stable handle crashes be able to continue in case of an outage last for as long as needed
15. First let’s talk about Azure Functions
16. Where can we host Azure Functions? Consumption plan (the „serverless way”) Azure AppService On your (virtual) machine directly or inside of a container by using Azure Functions Runtime Premium tier (Preview)
17. How do they scale? Azure AppService scales up to a certain amout of machines, but slowly Your machines scale based on your settings, but probably slower than Azure AppService Premium tier is similar to AKS – you constantly rent a certain amount of cores and RAM, and scale out when needed Consumption plan is challenging The process can last up to 10 minutes You can scale up to 200 instances per Function app You can scale up by 1 instance at most every 10 seconds Your instance will go to sleep after 20 minutes of inactivity But you can preheat them, and keep them alive ;)
18. Step #2 implementation Durable Functions are the solution that we need They enable “long running” functions while maintaining local state Simplify complex Function coordination (chaining, fan- out + fan-in, external events, HTTP async response, etc) Easily call a Function from another Function All of the above using code-only
19. It’s not magic... it’s Durable Task Framework taking care of boilerplate code
20. Function chaining – without Durable F. Problems: • No visualization to show relationship between functions and queues. • Middle queues are an implementation detail – conceptual overhead. • Error handling adds a lot more complexity. F1 F2 F3 F4
21. Function chaining – with Durable F. // calls functions in sequence public static async Task<object> Run(DurableOrchestrationContext ctx) { try { var x = await ctx.CallFunctionAsync("F1"); var y = await ctx.CallFunctionAsync("F2", x); var z = await ctx.CallFunctionAsync("F3", y); return await ctx.CallFunctionAsync("F4", z); } catch (Exception) { // global error handling/compensation goes here } }
22. Fan-out/Fan-in – without Durable F Problems: Fanning-out is easy, but fanning-in is significantly more complicated Functions offers no help with this scenario today All the same problems of the previous pattern F1 F2 F3
23. Fan-out/Fan-in – with Durable F. public static async Task Run(DurableOrchestrationContext ctx) { var parallelTasks = new List<Task<int>>(); // get a list of N work items to process in parallel object[] workBatch = await ctx.CallFunctionAsync<object[]>("F1"); for (int i = 0; i < workBatch.Length; i++) { Task<int> task = ctx.CallFunctionAsync<int>("F2", workBatch[i]); parallelTasks.Add(task); } await Task.WhenAll(parallelTasks); // aggregate all N outputs and send result to F3 int sum = parallelTasks.Sum(t => t.Result); await ctx.CallFunctionAsync("F3", sum); }
24. Azure (Durable) Functions added
25. Step #3 requirements We need something that will call the third-party service, wait for a response, and send back the result We need something as cheap as possible, but also scalable We need something that can run/wait for a response „for ages”
26. Step #3 implementation Azure Container Instances We can spin them up on demand We can group them and set up a mutual file share We can set their Environment Variables & execute commands Containers with GPU resources are also available
27. ACI added
28. Step #4 requirements The ACI from step #3 needs to ping back the Durable Functions from step #2
29. public static async Task Run(DurableOrchestrationContext ctx) { await ctx.CallFunctionAsync<object[]>(„ProcessData"); using (var timeoutCts = new CancellationTokenSource()) { DateTime dueTime = ctx.CurrentUtcDateTime.AddMinutes(36); Task durableTimeout = ctx.CreateTimer(dueTime, 0, cts.Token); Task<bool> dataProcessedEvent = ctx.WaitForExternalEvent<bool>(„DataProcessed"); if (dataProcessedEvent == await Task.WhenAny(dataProcessedEvent, durableTimeout)) { timeoutCts.Cancel(); await ctx.CallFunctionAsync(„CallWebhook", approvalEvent.Result); } else { await ctx.CallFunctionAsync("Escalate"); } } } Step #4 implementation External Event with Timeout
30. ACI calling External Event URL
31. But we’ve left something out... those parts aren’t connected
32. Why are we mixing events and messages? (because of different concepts and features) AZURE EVENT GRID low latency capable of receiving and processing millions of events per second at least once delivery AZURE SERVICE BUS reliable asynchronous message delivery (enterprise messaging as a service) that requires polling advanced messaging features like FIFO, batching/sessions, transactions, dead- lettering, temporal control, routing and filtering, and duplicate detection at least once delivery optional in-order delivery
33. Service Bus Topics added
34. Event Grid added
35. Service Bus Queue added
36. When something crashes or degrades Years ago we’ve got Azure Application Insights Then we’ve got Azure Log Analytics which united our logs from multiple Application Insights, various on- prem/VM sources, etc and allowed us to perform easy queries Now we have Azure Monitor and basically the whole cloud is sending data there + your software can as well by using SDKs
37. Congrats, we now have a working system... without security
38. Solution #1 Handle it in a „normal” API There’s a bunch of libraries available for your language/framework of choice that can handle: Authentication Authorization Perhaps throttling The only thing you need to do is to develop your API as you would normally do
39. Solution #2 Handle it in Functions Remember how you can host Functions inside of containers and run them in AKS? That’s why we have this problem J Functions have a few levels of API keys (per function, per function app), but that’s not a solution If we were hosting them on Azure how they were intended to be hosted, we could leverage EasyAuth from Azure AppService, and use social media provides, but our system is more of a B2B API So... enjoy handling the „raw” HTTP request message, and all of its headers
40. Solution #3 Use Azure API Management This is an enterprise-grade service recently „gone serverless” – you can now pay for it per-usage The beauty of it is that you can create various types of subscriptions that allow only a certain portion of the API available, and give an API key to each customer You can also throttle the number of parallel connections per key in order to create „entry level” and „premium” charged subscriptions There’s so much more here, but that’s a topic for another talk
41. Azure API Management added
42. How do Logic Apps fit in here? Well... they usually don’t J But... the news agency is getting a huge portion of news submissions in form of e-mails The easiest thing to do is to leverage this IFTTT on steroids to keep a watch on our inbox, and submit everything to our newly built system It can’t get simpler than that
43. Thank you for listening, and ping me if you’ll need me Ivan Čuljak @CuljakIvan ivan@culjak.xyz culjak.xyz
