Monitoring distributed systems with Google Big Query and R

This talk explores continuous delivery, and how Nomanini monitors daily firmware upgrades of 1000 devices spread across Africa, using Google Big Query and the open source stats package, R.

Presented at GDG Stellenbosch.
Accompanying blog post at http://goo.gl/Cwai02

Transcript

1. GDE
   Monitoring distributed systems
   with Google Big Query and R
   Dale Humby
   CTO, Nomanini
   Google Developer Expert for Cloud Platform


   View Slide

2. View Slide

3. micro-transactions in emerging markets


   View Slide

4. GDE


   View Slide

5. GDE


   View Slide

6. GDE


   View Slide

7. GDE


   View Slide

8. GDE


   View Slide

9. GDE
   Continuous Delivery


   View Slide

10. GDE


    View Slide

11. JSON
    GDE
    Event counters
    {
    "counts": {
    "ERROR": 7,
    "WARNING": 1475,
    "DEBUG": 362754,
    "[E].EventsManager.423": 2,
    "[E].GPSManager.259": 1,
    "[E].SlaveCommsDispatcher.158": 4
    },
    "firmwareVersion": "4264-548923b591c6",
    "startTime": "2014-09-22 00:00:01.152",
    "endTime": "2014-09-23 00:00:06.574"
    }


    View Slide

12. JSON
    GDE
    Event counters
    {
    "counts": {
    "SignalStrength.Percent.20-40": 18,
    "SignalStrength.Percent.40-60": 12,
    "SignalStrength.Percent.60-80": 15,
    "SignalStrength.Percent.80-100": 1,
    ...
    "GPRS.TimeToConnect.Seconds.0-20": 2
    },
    ...
    Histogram and timing


    View Slide

13. GDE
    Upload and stream to Big Query


    View Slide

14. GDE
    Diagnostics saved in Big Query


    View Slide

15. JSON
    GDE
    Event counters
    {
    "counts": {
    "ERROR": 7,
    "WARNING": 1475,
    "DEBUG": 362754,
    "[E].EventsManager.423": 2,
    "[E].GPSManager.259": 1,
    "[E].SlaveCommsDispatcher.158": 4
    },
    "firmwareVersion": "4264-548923b591c6",
    "startTime": "2014-09-22 00:00:01.152",
    "endTime": "2014-09-23 00:00:06.574"
    }


    View Slide

16. SQL
    GDE
    Create View
    SELECT
    JSON_EXTRACT_SCALAR(event_data, '$.firmwareVersion')
    AS firmware_version,
    device_id,
    SUM(INTEGER(JSON_EXTRACT_SCALAR(event_data, '$.counts.ERROR')))
    AS errors,
    SUM(INTEGER(JSON_EXTRACT_SCALAR(event_data, '$.counts.DEBUG')))
    AS debugs,
    1e6 *
    SUM(INTEGER(JSON_EXTRACT_SCALAR(event_data,'$.counts.ERROR'))) /
    SUM(INTEGER(JSON_EXTRACT_SCALAR(event_data,
    '$.counts.DEBUG')))
    AS error_rate
    FROM [nomanini.event_log]
    WHERE event = 'Counters'
    GROUP BY firmware_version, device_id
    ORDER BY firmware_version DESC, device_id DESC;


    View Slide

17. GDE
    SELECT * FROM [nomanini.firmware_error_rates] LIMIT 10;
    Query View


    View Slide

18. GDE
    Stats with R


    View Slide

19. GDE
    Good Beta release


    View Slide

20. GDE
    Log transform data
    to make more ‘Normal’


    View Slide

21. GDE
    Broken Beta release


    View Slide

22. R
    GDE
    Broken Beta release
    > t.test(log10(error_rate.beta),
    log10(error_rate.stable),
    paired=TRUE)
    Paired t-test
    data: log10(error_rate.beta) and log10(error_rate.stable)
    t = 2.8624, df = 28, p-value = 0.007872
    alternative hypothesis: true difference in means is not equal to 0
    95 percent confidence interval:
    0.1131325 0.6825117
    sample estimates:
    mean of the differences
    0.3978221
    Geometric mean of the differences (base 10): 2.499321


    View Slide

23. R
    GDE
    Broken Beta release
    > wilcox.test(error_rate.beta,
    error_rate.stable,
    paired=TRUE, conf.int=TRUE)
    Wilcoxon signed rank test
    data: error_rate.beta and error_rate.stable
    V = 318, p-value = 0.02906
    alternative hypothesis: true location shift is not equal to 0
    95 percent confidence interval:
    7.075123 14546.761849
    sample estimates:
    (pseudo)median
    183.0312


    View Slide

24. GDE
    Broken Beta release


    View Slide

25. JSON
    GDE
    Event counters on broken Beta
    {
    "counts": {
    "ERROR": 1937,
    "WARNING": 1427,
    "DEBUG": 26319,
    "[E].SlaveUpdateManager.442": 1912,
    "[E].HTTPSManager.319": 3,
    "[E].DOTAManager.511": 1,
    ...
    },
    "masterVersion": "3976-aff309f9d073",
    "startTime": "2014-07-09 09:33:57.923",
    "endTime": "2014-07-09 15:02:37.032"
    }


    View Slide

26. GDE
    Fixed Beta release


    View Slide

27. GDE
    The Future


    View Slide

28. GDE


    View Slide

29. GDE
    Thank You
    dale@nomanini.com
    google.com/+DaleHumby
    @dalehumby
    http://goo.gl/Cwai02
