  1. A Deep Dive into Service Mesh and Istio 0 ~$

    speaker Shukun SONG ~$ company FUJITSU LIMITED Copyright 2019 FUJITSU LIMITED CLOUDNATIVE DAYS TOKYO 2019 / OPENSTACK DAYS TOKYO 2019 [2C1] 13:20 – 14:00 JULY 23th, 2019
  2. Outline Service mesh and Istio  Architecture  Packet flow

    Performance measurement of Istio Where the problem is Our trial Istio’s next feature Copyright 2019 FUJITSU LIMITED 1
  3. Who am I? Shukun SONG Software engineer for OSS development

    team at Fujitsu. He focuses on improving the performance of Istio and rolling-upgrade for Kubernetes components. Copyright 2019 FUJITSU LIMITED 2
  4. Outline Service mesh and Istio  Architecture  Packet flow

    Performance measurement of Istio Where the problem is Our trial Istio’s next feature Copyright 2019 FUJITSU LIMITED 3
  5. Service Mesh What is service mesh?  Network of microservices

    that make up service-to-service communication on cloud-based applications, containers and microservices with the following key features: Copyright 2019 FUJITSU LIMITED  Traffic management: Service discovery, routing  Observability: Telemetry  Policies and Security: Policy check, Authentication, credential management 4
  6. Overview of Istio What is Istio?  A service mesh

    started by Lyft, Google and IBM. Characteristics Extensibility/pluggable Not CNCF project, run on K8s Copyright 2019 FUJITSU LIMITED 5
  7. Istio’s Architecture Copyright 2019 FUJITSU LIMITED Data Plane Service A

    Service B Galley Citadel Mixer Pilot Control Plane Proxy Proxy 6
  8. Istio’s Architecture Copyright 2019 FUJITSU LIMITED Data Plane Service A

    Service B Proxy Proxy = + (Mixer client) Proxy between applications Istio’s proxy includes envoy which is OSS service proxy for cloud native applications. 7
  9. Istio’s Architecture Copyright 2019 FUJITSU LIMITED Data Plane Service A

    Service B Mixer Control Plane Proxy Proxy Observability and control Mixer policy controls and telemetry collection. 8
  10. Service A Service B Control Plane Istio’s Architecture Copyright 2019

    FUJITSU LIMITED Data Plane Pilot Proxy Proxy Traffic management Pilot configures all proxies to perform load balancing for requests, routing, and provides an API for service discovery. 9
  11. Control Plane Service A Service B Istio’s Architecture Copyright 2019

    FUJITSU LIMITED Data Plane Citadel CA CA Proxy Proxy Certification management Citadel provides key pair and manages certification for mTLS. 10
  12. Istio’s Architecture Copyright 2019 FUJITSU LIMITED Data Plane Service A

    Service B Galley Mixer Pilot Config management Galley can validate Istio configuration with K8s ValidatingWebhook. Proxy Proxy Control Plane 11
  13. Packet flows (except telemetry) Copyright 2019 FUJITSU LIMITED Service A

    Service A Service B ⇔ ⇔ : : Service A Service B Mixer istio-policy LB istio-ingress gateway Proxy Proxy 12
  14. Outline Service mesh and Istio  Architecture  Packet flow

    Performance measurement of Istio Where the problem is Our trial Istio’s next feature Copyright 2019 FUJITSU LIMITED 13
  15. Performance measurement of Istio Purpose  Measure the time of

    one response Test environment  Istio version: 1.0.5  A k8s HA cluster with 3 masters and 5 workers  VM spec: 8×2GHz Cores + 8GB Memory  Use bookinfo sample app with 3 replicas  Send 100 requests with 1RPS(Request per Second) Copyright 2019 FUJITSU LIMITED 14
  16. Result of measurement  Our result  Community result 

    Official report https://istio.io/docs/concepts/performance-and-scalability/  Recent performance assessment https://drive.google.com/drive/folders/1Npndz_yUVXktocg5MUNgwA0lP1tNzrZX Copyright 2019 FUJITSU LIMITED Min[ms] Max[ms] Average[ms] With Istio 33.56 73.07 53 Without Istio 22.9 50.82 36 Mixer adds lots of overhead, both check and report 15
  17. Where the problem is  Data path ① Request ②

    Check send ③ Check response ④ Request ⑤ Report send ⑥ Report response Copyright 2019 FUJITSU LIMITED Service A Proxy Node 1 App pod Service B Proxy Node 2 App pod Node 3 Istio-policy Istio-telemetry ① ② ③ ④ ⑤ ⑥ 16
  18. Mixer architecture  Uniform abstraction of backends  Envoy produces

    common attributes based on requests  Mixer consumes attributes and talks to backends using adapters  Backends provide functionality such as logging, monitoring and checking Copyright 2019 FUJITSU LIMITED Backend Backend Backend Adapter Adapter Adapter Mixer Attribute request.path: xyz/abc request.size: 234 request.time: 12:34:56.789 04/17/2017 source.ip: [192 168 0 1] destination.service.name: example Proxy 17
  19. 1. Check  Data path ① Request ② Check send

    ③ Check response ④ Request ⑤ Report send ⑥ Report response Copyright 2019 FUJITSU LIMITED Service A Proxy Node 1 App pod Service B Proxy Node 2 App pod Node 3 Istio-policy Istio-telemetry ① ② ③ ④ ⑤ ⑥ 18
  20. Block until check is done To reduce traffic  Cache

    Cannot really help as there are too many attributes, too many values, just make local proxy bigger and bigger.  Turn off Check really do not matter, most purposes can be achieved by RBAC Default from v1.1 1. Check Copyright 2019 FUJITSU LIMITED Adapter B Adapter C Adapter A Mixer A : xxx B : xx C : xx Attributes Proxy cache request.path: xyz/abc request.size: 234 request.time: 12:34:56.789 04/17/2017 source.ip: [192 168 0 1] destination.service.name: example request.path: xyz/abc request.size: 234 request.time: 12:34:56.789 04/17/2017 source.ip: [192 168 0 1] destination.service.name: example request.path: xyz/abc request.size: 234 request.time: 12:34:56.789 04/17/2017 source.ip: [192 168 0 1] destination.service.name: example cache cache cache 19
  21. 2. Report  Data path ① Request ② Check send

    ③ Check response ④ Request ⑤ Report send ⑥ Report response Copyright 2019 FUJITSU LIMITED Service A Proxy Node 1 App pod Service B Proxy Node 2 App pod Node 3 Istio-policy Istio-telemetry ① ② ③ ④ ⑤ ⑥ Mixer 20
  22. 2. Report Happens after request done Batched, not happens every

    request. Not always affect performance but do harm it when report Currently, the default batch number has been reduced from 1000 to 100. Copyright 2019 FUJITSU LIMITED 21
  23. Our trial Copyright 2019 FUJITSU LIMITED 22

  24. Current structure Copyright 2019 FUJITSU LIMITED Service A Proxy Node

    1 App pod Service B Proxy Node 2 App pod Node 3 Istio-policy Istio-telemetry ① ② ③ ④ ⑤ ⑥ Reduce this traffic Mixer 23
  25. Our idea  Reduce traffic between nodes Copyright 2019 FUJITSU

    LIMITED Service A Proxy Node 1 App pod Istio-policy Istio-telemetry ① ② ③ ④ ⑤ ⑥ Service B Proxy Node 2 App pod Istio-policy Istio-telemetry Mixer Mixer 24
  26. Reference (IBM)  Measurement  Environment - Node A: 1

    CPU(2.2GHz) / 4GB RAM - Node B: 2 CPUs(2.2GHz) / 4GB RAM - Node C: 4 CPUs(2.2GHz) / 8GB RAM  Run mixc on a node, access to istio-telemetry through service and send 100k requests  Result  Average report time 3.9ms Copyright 2019 FUJITSU LIMITED Node B Istio-telemetry Node A Istio-telemetry mixc Node C Istio-telemetry istio-telemetry.istio-system.svc.cluster.local:15004 25
  27. Reference (IBM)  Measurement  Not use mixc, but write

    a client call report function directly and serially  Result  Compare to the result of 3.9ms, report to local mixer can reduce 1.1~2.4ms latency Copyright 2019 FUJITSU LIMITED Node B Istio-telemetry Node A Istio-telemetry Client Node C Istio-telemetry Client Client 26
  28. Distributed Mixer Points ① Create a mixer on each node

    ② Ensure proxies communicate with the mixer on the same node Our trial Copyright 2019 FUJITSU LIMITED Node Mixer Proxy App Container Proxy App Container Proxy App Container … Node Mixer Proxy App Container Proxy App Container Proxy App Container ① ① ② ② ② ② ② ② 27
  29. Ensure proxies communicate with the mixer on the same node

    Copyright 2019 FUJITSU LIMITED Mixer Mixer Service … Mixer Mixer … Access to Mixer via service (Load balanced) Access to Mixer directly 28
  30. Ensure proxies communicate with the mixer on the same node

    Copyright 2019 FUJITSU LIMITED Mixer Mixer Service … Mixer Mixer … Access to Mixer directly Sidecar deployment Envoy has to be deployed with configuration which specifying Mixer directly. Pilot-agent Template --- ----- JSON --- ----- Mixer 29
  31. Ensure proxies communicate with the mixer on the same node

    Copyright 2019 FUJITSU LIMITED Mixer Mixer Service … Mixer Mixer … Access to Mixer directly Sidecar deployment Envoy has to be deployed with configuration which specifying Mixer directly. Pilot-agent Template --- ----- Mixer JSON --- ----- …, “dynamic_resources”: { // Ask Pilot }, “static_resources”: { // Pilot information, // Add mixer’s information },…, 30
  32. Our trial Configure Envoy  Add static resource The procedure

    about creating configuration from template is written in the file istio.io/istio/pkg/bootstrap/bootstrap_config.go whose name is WriteBootstrap Copyright 2019 FUJITSU LIMITED // WriteBootstrap generates an envoy config based on config and epoch, and returns the filename. // TODO: in v2 some of the LDS ports (port, http_port) should be configured in the bootstrap. func WriteBootstrap(config *meshconfig.ProxyConfig, node string, epoch int, pilotSAN []string, opts map[string]interface{}, localEnv []string, nodeIPs []string, dnsRefreshRate string) (string, error){ Add a little change to this function to enable pilot-agent recognize HOST_IP 31
  33. Our trial Configure Envoy  Figure out the process of

    check (In progress..) • Dump the config of a running Envoy sidecar • Envoy config is hard!  Cluster, listener, router, filter, … So many new concepts over 7000 lines. • Istio creates a custom filter named mixer  This filter is a mixer client responsible to interact with mixer server through gRPC  Have no idea about how to write the config about this filter correctly Copyright 2019 FUJITSU LIMITED 32
  34. Outline Service mesh and Istio  Architecture  Packet flow

    Performance measurement of Istio Where the problem is Our trial Istio’s next feature Copyright 2019 FUJITSU LIMITED 33
  35. Istio’s next feature Extensibility v2 (formerly known as Mixer v2)

     Envoy communicates with backend directly to reduce overhead b/w Envoy and Mixer. Copyright 2019 FUJITSU LIMITED Mixer Backend Backend Backend Backend Backend Backend No change to Envoy No restart Envoy https://www.youtube.com/watch?v=XdWmm_mtVXI 34
