Transcript
David Vávra, Inmite Development for using Android GDK
None
None
None
None
None
None
None
None
None
None
None
None
Hardware
Demo time
4 principles of Glassware design
Design for Glass
Don’t get in the way
Keep it relevant
Avoid the unexpected
User interface: Timeline card • 640x360 px • black background,
given font sizes & colors • bundles
User interface - timeline
Immersions
Menus
None
GDK • Full API level 19 • no touch •
resolution 640x360 • no emulator • same API for Speech, Camera, Navigation, Browser, Location, Sensors
None
<style name="CustomTheme" parent= "@android:style/Theme.DeviceDefault" /> android { compileSdkVersion "Google Inc.:Glass
Development Kit Preview:19" …}
Card card1 = new Card(context); card1.setText("This card has a footer.");
card1.setFootnote("I'm the footer!"); View card1View = card1.getView();
res/xml/my_voice_trigger.xml <?xml version="1.0" encoding="utf-8"?> <trigger keyword="start my app" /> <uses-permission
android:name="com.google.android.glass.permission. DEVELOPMENT"/> <activity | service ...> <intent-filter> <action android:name="com.google.android.glass.action. VOICE_TRIGGER"/> </intent-filter> <meta-data android:name="com.google.android.glass.VoiceTrigger" android:resource="@xml/my_voice_trigger" /> </activity | service> AndroidManifest.xml
None
Menu The same onCreateOptionsMenu from Android SDK public class MainActivity
extends Activity { // ... @Override public boolean onKeyDown(int keyCode, KeyEvent event) { if (keyCode == KeyEvent.KEYCODE_DPAD_CENTER) { openOptionsMenu(); return true; } return super.onKeyDown(keyCode, event); } }
Live card
Creating live cards TimelineManager tm = TimelineManager.from(context); mLiveCard = tm.createLiveCard(LIVE_CARD_TAG);
mLiveCard.setViews(new RemoteViews(context.getPackageName(), R.layout.card_text)); mLiveCard.publish(LiveCard.PublishMode.REVEAL); // or SILENT
Updating live cards mRemoteViews.setTextViewText(R.id.text, "new message"); mLiveCard.setViews(mRemoteViews); Removing live cards
mLiveCard.unpublish();
Let’s dive into Glasquare code http://github.com/destil/glasquare
Distribution • adb install • MyGlass ◦ checklist: https://developers.google.com/glass/distribute/checklist ◦
design ◦ voice commands ◦ assets
None
Documentation • https://developers.google.com/glass • https://github.com/googleglass • http://stackoverflow. com/questions/tagged/google-gdk • https://code.google.com/p/google-glass-
api/issues/list
Q + A Follow me: http://google.com/+DavidVávra http://twitter.com/destil
