Learn how to rip apart UI controls, so that you can rebuild them better, stronger, and faster.

This edition contains a few minor updates in here from my talk in Boston (available here: https://speakerdeck.com/designatednerd/reverse-engineering-ui-for-fun-and-profit-cocoaconf-boston-november-2014) including better links at the end, and mostly just cosmetic updates from the version of this talk I gave in Atlanta (https://speakerdeck.com/designatednerd/reverse-engineering-ui-for-fun-and-profit-cocoaconf-atlanta-december-2014)

Updated useful things that were only in my demos or speaker notes:
- When logging out recursiveDescripton, copy and paste things into TextWrangler documents. Select two documents in the sidebar and then right click to compare them.
- Use the left/right arrow keys to navigate through QuickTime videos: hold the key down to go in slow-mo, tap the key to go frame by frame.
- When looking at a video in QuickTime, Cmd-C to copy the current frame to the clipboard, and then Cmd-N in Preview to open New From Clipboard.
- If you're on Mavericks or below, the two airplay solutions I mentioned are Reflector (http://www.airsquirrels.com/reflector/) and AirServer (http://www.airserver.com/)

C4861b1dfdf3bbb21faec4a1acdf183d?s=128

Ellen Shapiro

March 10, 2015
Tweet

Transcript

  1. REVERSE ENGINEERING USER INTERFACE FOR FUN AND PROFIT BY ELLEN

    SHAPIRO COCOAHEADS CHICAGO SMARCH 2015 @DESIGNATEDNERD | DESIGNATEDNERD.COM | VOKAL.IO | JUSTHUM.COM
  2. PREFACE: WHO AM I?

  3. None
  4. None
  5. None
  6. WHY REVERSE ENGINEER?

  7. YOU WANT A BETTER UNDERSTANDING OF HOW A CONTROL WORKS

  8. YOU WANT TO USE IT YOURSELF

  9. YOU WANT A BETTER UNDERSTANDING OF HOW IOS UI WORKS

    IN GENERAL.
  10. WHEN YOU SEE SOMETHING AWESOME IN AN APP

  11. YOU SAY: "HEY, THAT LOOKS COOL!"

  12. YOU MEAN: "I'M TOTALLY STEALING THAT."

  13. THIS TALK IS YOUR GUIDE TO MORE EFFICIENT AND ACCURATE

    THIEVERY.
  14. TWO SITUATIONS I'LL BE COVERING:

  15. APPLE MAKES SOMETHING THAT LOOKS COOL BUT DOESN'T GIVE YOU

    THE TOOLS TO USE IT YOURSELF.
  16. ANOTHER DEV MAKES SOMETHING COOL BUT DOESN'T OPEN-SOURCE IT.

  17. TOOLS I WILL BE USING ▸ Things that are built

    into OS X Yosemite ▸ Free Text Editors ▸ My Eyeballs ▸ Built-in LLDB and Xcode debugging techniques. ▸ Facebook Chisel
  18. TOOLS I WILL NOT BE USING ▸ Jailbreaking ▸ Reveal

    ▸ Anything else that costs you money.
  19. CASE STUDY #1: DNSSWIPEABLETABLECELL

  20. APPLE MADE SOMETHING AWESOME, AND I WANT TO USE IT.

  21. BUT APPLE'S SDK SAID TOO BAD SO SAD

  22. APPLE INTRODUCED SWIPE-UNDER ACTIONS IN IOS 7.

  23. AS A THIRD PARTY DEVELOPER, YOU COULD EASILY USE SWIPE

    TO DELETE .
  24. iOS 7... !

  25. iOS 8... !

  26. STEP 1: STARE AT YOUR PHONE

  27. WHAT LOOKS LIKE THE VIEW HIERARCHY?

  28. IS THIS GESTURE A SWIPE OR A PAN?

  29. WHAT HAPPENS WHEN YOU CHANGE THE SPEED OF YOUR GESTURE?

  30. STEP 2: POKE AT THE VIEW HIERARCHY FROM INSIDE AN

    APP
  31. CREATE A SAMPLE PROJECT USING THE APPLE CONTROL YOU WANT

    TO USE.
  32. USE LOGGING AND TOOLS TO INSPECT THE VIEW HIERARCHY.

  33. 2A: BUILT-IN TOOLS po [view recursiveDescription] Xcode's View Hierarchy debugger

  34. [DEMO: XCODE FUNTIMES]

  35. 2B: FACEBOOK CHISEL Make things happen when you're paused at

    a breakpoint without rerunning
  36. [DEMO: CHISEL IN ACTION]

  37. !: CHISEL ONLY WORKS IN OBJ-C CODE (FOR NOW).

  38. STEP 3: START BUILDING

  39. [DEMO: DNS SWIPEABLE TABLE CELL]

  40. [WE'LL COME BACK TO BUILDING IN A BIT]

  41. CASE STUDY #2: DNSCASTROSEGMENTEDCONTROL

  42. SOMEONE ELSE MADE AN AWESOME THING AND I WANT TO

    USE IT.
  43. DID THEY OPEN SOURCE IT? NOPE.

  44. WHAT AM I STEALING REVERSE ENGINEERING?

  45. None
  46. None
  47. ONE MINOR PROBLEM: NON-STOCK CONTROLS CAN'T BE EXAMINED INTERNALLY WITHOUT

    JAILBREAKING.
  48. YOU HAVE TO GET A BIT MORE CREATIVE TO FIGURE

    OUT HOW THINGS WORK.
  49. BLAME CREDIT THIS GUY

  50. None
  51. STEP 1: RECORD SOME VIDEO FROM YOUR DEVICE

  52. MAVERICKS AND BELOW: IT'LL COST YA Use Reflector ($12.99) or

    AirServer (14.99) to AirPlay to your Mac
  53. YOSEMITE: FREE Record directly from your device with QuickTime

  54. [DEMO: RECORDING VIDEO WITH QUICKTIME]

  55. STEP 2: OPEN THAT VIDEO WITH QUICKTIME When you hit

    the info button, you'll get some useful...information!
  56. [DEMO: QUICKTIME SCRUBBING]

  57. SIDEBAR: EASING

  58. EASING IS ABOUT THE CURVE OF THE ANIMATION

  59. UNDERSTANDING EASING MAKES GETTING THE DETAILS OF A CONTROL RIGHT

    A LOT SIMPLER.
  60. [DEMO: EASE IN, EASE OUT]

  61. STEP 3: OPEN INDIVIDUAL FRAMES IN PREVIEW

  62. MEASURE IMAGES PIXEL BY PIXEL

  63. ZOOM WAAAAAAAY IN ON YOUR IMAGES

  64. [DEMO: PREVIEW MEASURING]

  65. STEP 4: START BUILDING AGAIN!

  66. [DEMO: DNS CASTRO SEGMENTED CONTROL]

  67. PUTTING IT TOGETHER: BUILDING BASED ON YOUR FINDINGS

  68. BUILD YOUR SAMPLE PROJECT IN ISOLATION.

  69. KEEP THE FILES FOR THE CONTROL ITSELF IN A SINGLE

    FOLDER.
  70. KEEP DISPLAY LOGIC INDEPENDENT

  71. TEST TEST TEST TEST TEST TEST TEST TEST TEST TEST

    (DID I MENTION TEST?)
  72. COMPARE THE FEEL OF YOUR SAMPLE APP TO THE ORIGINAL

    APP
  73. NEXT STEPS: MAKE IT SHAREABLE

  74. Create a repo for your sample code.

  75. Make a CocoaPod!

  76. Submit it to CocoaControls

  77. OFFICIAL SUMMARY SLIDE™ ▸ View hierarchy debugging with built-in tools

    ▸ How to use Facebook Chisel to make that even faster ▸ How to use video to examine the contents of a control ▸ How to go tear apart a control so you can rebuild it yourself
  78. QUESTIONS?

  79. STUFF I MENTIONED! ▸ https://github.com/facebook/chisel ▸ http://www.barebones.com/products/textwrangler ▸ http://guides.cocoapods.org/making/making-a-cocoapod.html ▸

    http://castro.fm/ ▸ http://petersteinberger.com/blog/2013/how-to-inspect-the-view- hierarchy-of-3rd-party-apps/
  80. TEH CODEZ! ▸ https://github.com/designatednerd/DNSSwipeableTableCell ▸ https://github.com/designatednerd/DNSCastroSegmentedControl (both of the above

    also available via CocoaPods) ▸ https://github.com/designatednerd/EasingExample
  81. PLUGS! ▸ http://justhum.com ▸ http://www.mobilemakers.co/ ▸ http://vokalinteractive.com/
