eBPF disassemblerを作る Drumato
Attention! • 完全準拠ではない • torvalds/linux/samples/bpfのkernel side sourceがそれっぽくなればOKまで をやった
背景
なんとなくeBPFについての記事を読んでた
"基本的に命令長は64bit固定" という記述を見る
素敵! disasm書きたい! (x64を想いつつ)
書く
身につける必要があった知識 • Object file上でeBPF functionがどのように表現されているか • Opcode encoding/immediateの形式を知る
あとは頑張って書く
これはassembler自作と大して変わらない
ELF Header
eBPF object file#ELF Header
eBPF object file#ELF Header
E_machine以外は普通のrelocに見える
Section Header Table
eBPF object file#SHT
eBPF object file#SHT .textはあるけど 中身は空
eBPF object file#SHT SEC("socket1")のように 書いたsymbolが sectionに
eBPF object file#SHT eBPF mapsもsectionに Entry sizeは Programで決まっていて, Shdr.sh_entsizeを読んでも わからない
Key + valueのどちらも可変なので entsizeは使えないか(linkとinfoは?)
eBPF object file#SHT これは単に"GPL\0"という文字列が 入っているだけ
Symbol table
eBPF object file#symtab
ぱっと見特に気になる点はなし
eBPF object file#summary • なんとなく以下を満たすsectionをdisasすれば良さそう ◦ Shdr.sh_type == SHT_PROGBITS ◦
Shdr.sh_flags & (SHF_ALLOC | SHF_EXECINSTR) != 0 ◦ Shdr.sh_size > 0
eBPF instruction architecture
eBPF instruction architecture#overview
eBPF instruction architecture#overview OpcodeEncoding head byteをどう解釈するか
eBPF instruction architecture#overview InstructionClass Opcodeをどう解釈するか Ex1. ic=0x04ならopcode=0x00はAdd ic=0x05ならopcode=0x00はJA
eBPF instruction format ArithOrJump Memory
eBPF instruction format ArithOrJump Memory ADD/SUB/MUL/DIV/MOD/LSH etc.. JA/JEQ/JGT/JSLT/ etc...
eBPF instruction format ArithOrJump Memory Use src field as register
If S bit is up
eBPF instruction format ArithOrJump Memory ALU/ALU64/JMP/JMP64
eBPF instruction format ArithOrJump Memory IMM/MEM/IND/ABS etc
eBPF instruction format ArithOrJump Memory Byte/Half word/Word/Double Word
eBPF instruction format ArithOrJump Memory LD/LDX/ST/STX
わかったら書く!書く!
機械語programmingは手動かす!
disasm#tips • Building block的に作ると良い ◦ Opcode type/InstClass typeを作ってEncoding typeを作る ▪
それぞれのdecoderを書く ◦ それら(とsrc/dst/offset/imm)をまとめてInstruction typeを作る ▪ decoderを次々呼ぶだけ • srcは ooooxxxx のようになっているけど,4bit rshすると使いやすい ◦ Register numberに変換する感覚
disasm#summary
disasm#summary
このくらいのしょぼ完成度なら サクッと数時間で作れる
references • Linux Socket Filtering aka Berkeley Packet Filter (BPF)
- www.kernel.org • Drumato/ebpf-disasm … 実装 ◦ 完全じゃないよ(Memory InstClassは適当)
Thanks!
