Cost versus Performance: Walking the Tightrope

How do you manage cloud costs while maintaining performance and user experience? For many, it’s like walking a tight-rope; lean too far in either direction and you’ll suffer. Analytics can help you find just the right balance by revealing actionable insights about the tradeoffs between performance and cost. This presentation offers (anonymized) case studies that highlight both analytics used and realized cost savings.

Transcript

1. Cost vs Performance: Walking the Tight-Rope Betsy Nichols, Ph.D. Chief Data Scientist June 2016 – DevOpsDays DC @eanTweet
2. www.netuitive.com 2 Abstract •  Abstract: How do you manage cloud costs while maintaining performance and user experience? For many, it’s like walking a tight-rope; lean too far in either direction and you’ll suffer. Analytics can help you find just the right balance by revealing actionable insights about the tradeoffs between performance and cost. This presentation offers (anonymized) case studies that highlight both analytics used and realized cost savings. •  Description This presentation is for members of DevOps teams who have dual responsibilities for delivering industrial strength, responsive services while managing specific budgets and controlling cloud costs. Specific analytics and models will be presented that can provide valuable insights regarding interactions between such factors as capacity and cost, capacity utilization and performance, and reliability and cost. •  It’s easy to make mistakes when you aren’t looking at the complete picture. If you are under provisioned, that can result in cost savings at the expense of customer experience. If you over provisioned, that can lead to better customer experience but also waste resources and incur needless expense. This is the tight rope. If you lean too far in one direction, you’ll suffer undesirable consequences. •  Building on insights from analytics that quantify the interactions between cost and performance, concrete recommendations can be derived that help strike an appropriate balance. This presentation describes such analytics and provides (anonymized) cases from AWS environments where they have been effective.
3. www.netuitive.com 3 Yin and Yang Capacity Cost Capacity Response Time @eanTweet
4. www.netuitive.com 4 Achieving Balance @eanTweet
5. Use Case
6. www.netuitive.com 6 The stories you are about to hear are true. The names have been changed to protect the innocent. @eanTweet
7. The Business: Custom Nails @eanTweet
8. Cast of Characters @eanTweet
9. www.netuitive.com 9 Conceptual Consumer Web Site user Web tier App tier DB tier Capacity Added Only When Needed Current Compute Capacity @eanTweet
10. www.netuitive.com 10 @eanTweet
11. www.netuitive.com 11 AWS Services (more detail) • Route 53 • EC2 • ELB • EBS • S3 • RDS • EMR • CloudFront • CloudWatch • Elasticache • Kinesis • AWS Config • … @eanTweet
12. www.netuitive.com 12 AWS Bill 1x 2x 3x 4x 5x @eanTweet
13. www.netuitive.com 13 Balance is Threatened @eanTweet
14. “Mater artium necessitas” @eanTweet
15. www.netuitive.com 15 One Proven Path Spend Distribution λ µ Capacity Allocation λ µ Under- Utilization λ µ Workload Distribution λ µ Pricing Options Models λ µ @eanTweet
16. Spend Distribution λ µ @eanTweet
17. www.netuitive.com 17 Customnails.com May 2016 Hourly AWS Bill EC2 Costs are 69% of AWS Bill EC2 Costs @eanTweet
18. www.netuitive.com 18 Focus EC2 @eanTweet
19. Capacity Allocation (EC2) λ µ @eanTweet
20. www.netuitive.com 20 EC2 Census Tiers EC2 Count Web 10 Application 120 Database 15 Analytics 10 Other 25 @eanTweet
21. www.netuitive.com 21 Arrival Rate •  Queue Length •  Response Time Completion Rate •  # EC2’s •  Mean CPU Utilization MTTR MTBF Availability Resilience •  # EC2’s •  Mean CPU Utilization Cost @eanTweet EC2 EC2 EC2
22. Under Utilization (ASG) λ µ @eanTweet
23. www.netuitive.com 23 EC2 Costs by Micro Service (ASG) A B C D E F G H I J K L W X Y Z # Nodes = 11; Utilization = 20% @eanTweet Average EC2 CPU Utilization
24. Workload Distribution (ASG C) λ µ @eanTweet
25. www.netuitive.com 25 Make It Work Max Workload Time # Nodes = 11 Response Time < 3 sec ASG Nodes Workload Max Requests/sec Requests/sec @eanTweet
26. www.netuitive.com 26 Regular Shapes Actual Requests/sec # Nodes = 11 Response Time < 3 sec @eanTweet
27. Pricing Options λ µ @eanTweet
28. www.netuitive.com 28 EC2 Cost: Factors Location On-Demand $/hour Pricing Option Reserve Spot Instance Type OS @eanTweet
29. www.netuitive.com 29 EC2 On-Demand SKUs1 1As of May 2016: Includes on-demand and reserved pricing only. Includes SKU’s for defunct but still active pricing. Spot pricing does not have SKUs. https://pricing.us-east-1.amazonaws.com/offers/v1.0/aws/AmazonEC2/current/index.csv" @eanTweet
30. • US-East • m3.large • Linux OS • May 2016 @eanTweet
31. www.netuitive.com 31 EC2 Prices: Factors Location On-Demand $/hour Pricing Option Reserve Spot Instance Type OS @eanTweet
32. www.netuitive.com 32 Pricing Options Compared Feature onDemand Reserved Spot Purch Term 1 hour 1, 3 years 1-6 hrs Up Front $$ None 0,50%,100% None Delivery Guaranteed Guaranteed As avail Termination By user By term 1 hr: price Blk: term Risk Low Very Low 1hr: High Blk: Med. Cost High Medium Low Savings over onDemand $0.00 Up to 75%1 Market 1https://aws.amazon.com/ec2/purchasing-options/reserved-instances/ @eanTweet
33. Models λ µ @eanTweet
34. www.netuitive.com 34 Leverage Pricing Options @eanTweet
35. www.netuitive.com 35 The RI bill does not depend on usage. OnDemand and Spot do. Spot @eanTweet
36. www.netuitive.com 36 ASG C: Starting Point Reserve OnDemand Spot Arrival Rate Response Time < 3 sec @eanTweet
37. www.netuitive.com 37 Save $$ with RI’s Reserve OnDemand Spot Response Time < 3 sec Arrival Rate @eanTweet
38. www.netuitive.com 38 Leverage Scaling @eanTweet
39. M/M/c Queuing Model •  λ = Arrival rate with Poisson distribution •  µ = Average service time with exponential distribution •  c = # servers •  Servers serve from the front of the queue (FCFS) •  If there are less than c jobs, some servers will be idle •  If there are greater than c jobs, some will queue in a buffer •  The buffer is of infinite size @eanTweet
40. Equations Response time = The probability that an arriving job is forced to queue is given by Erlange’s C formula: intensity = Ref: https://en.wikipedia.org/wiki/M/M/c_queue @eanTweet
41. M/M/c Model Results 2 4 6 8 10 µ = 1.0s Response Time @eanTweet
42. M/M/c Model Application INPUT: • Service Time (µ) • Arrival rate of requests (λ) • Response Time goal (3s) OUTPUT: • Response Time • Mapping: arrival rate à # nodes with constraint: response time < 3s @eanTweet
43. www.netuitive.com 43 Save $$ with Scaling Model Reserve OnDemand Spot Response Time < 3 sec Arrival Rate @eanTweet
44. www.netuitive.com 44 Leverage Pricing and Scaling @eanTweet
45. www.netuitive.com 45 Save $$ with Scaling Model Reserve OnDemand Spot Response Time < 3 sec Arrival Rate @eanTweet
46. www.netuitive.com 46 Manage Risk @eanTweet
47. www.netuitive.com 47 Risk Mitigation Factors Max scale-in rate: Max scale-out rate: Min instance counts: Zero thresholds: Target response time: Workload metric: Update frequency: 3 sec aws.elb.elb-c.arrivalrate hourly 1% 2 3 unlimited @eanTweet
48. www.netuitive.com 48 Save $$ with Scaling Model Reserve OnDemand Spot Savings: RI + EC2 count + Spots Arrival Rate @eanTweet
49. www.netuitive.com 49 Take Aways @eanTweet
50. www.netuitive.com 50 1. AWS (and others) sell you capacity. 2. How you use it is up to you 3. Know yourself 4. Leverage models to map your context to cost savings strategies 5. You can walk this tightrope! @eanTweet
51. www.netuitive.com 51 @eanTweet “Success consists of going from failure to failure without loss of enthusiasm.” - Winston Churchill @eanTwee
52. www.netuitive.com 52 Contact Info Elizabeth Nichols, Ph.D. Chief Data Scientist bnichols@netuitive.com @eanTweet www.netuitive.com @netuitive (703) 464-1500 @eanTweet
