Escaping The Tar Pit at Solidus Conf 2019

Escaping The Tar Pit at Solidus Conf 2019

Presentation about avoiding and escaping the tar pit.

Introduction to the `skunk` gem. Talks a little bit about `flog`; `rubycritic`; `simplecov`; `reek`; and other tools you can use to get metrics related to the codebase.

Ernesto Tagwerker

October 21, 2019
Tweet

More Decks by Ernesto Tagwerker

Other Decks in Programming

Transcript

  1. Escaping The Tar Pit Ernesto Tagwerker (@etagwerker) SolidusConf, October 2019

  2. ! Hi, I’m from Argentina I live in Philadelphia #

    I once forked Spree
  3. Founder & Software Engineer @OmbuLabs

  4. Founder & Software Engineer @fastrubyio

  5. Open Source Contributor & Maintainer database_cleaner; bundler-leak; next_rails

  6. Inspiration

  7. Chapter 1: The Tar Pit

  8. “No scene from prehistory is quite so vivid as that

    of the mortal struggles of great beasts in the tar pits. […] The fiercer the struggle, the more entangling the tar, and no beast is so strong or so skillful but that they ultimately sink.” Fred Brooks
  9. “Large-system programming has over the past decade been such a

    tar pit, and many great and powerful beasts have thrashed violently in it.” Fred Brooks
  10. We are in the tar pit; trying to avoid it;

    or trying to get out.
  11. None
  12. Tar Pit Symptoms > Projects running over budget

  13. Tar Pit Symptoms > Projects running over budget > Taking

    forever to ship small changes
  14. Tar Pit Symptoms > Projects running over budget > Taking

    forever to ship small changes > Sacrificing quality, increasing tech debt
  15. Part 1: How to avoid the tar pit

  16. “THAT’D BE GREAT” BOSS: “IF YOU COULD COME IN ON

    THIS GREAT, LEGACY PROJECT AND MAINTAIN IT FROM NOW ON…”
  17. “THAT’D BE GREAT” CLIENT: “IF YOU COULD COME IN ON

    THIS GREAT, LEGACY PROJECT AND MAINTAIN IT FROM NOW ON…”
  18. “BECAUSE I NEED IT BY END OF DAY TODAY” CLIENT:

    “HOW LONG IS IT GOING TO TAKE?”
  19. How can we quickly assess code quality?

  20. Part 2: How to get out of the tar pit

  21. How can we gradually pay off technical debt?

  22. Part 1: Avoiding the tar pit

  23. None
  24. “It can’t be that hard. It’s a Rails project.”

  25. How can we quickly assess code quality?

  26. Assessing Quality ✅ Paid Services ✅ Open Source Gems

  27. Assessing Quality ✅ Paid Services ➡ Open Source Gems

  28. Open Source Gems ✅ Static code analysis

  29. Open Source Gems ✅ Static code analysis ✅ Code coverage

  30. Open Source Gems ✅ Static code analysis ✅ Code coverage

    ✅ Code smells
  31. What is software quality anyway?

  32. There are hundreds of definitions.

  33. “The degree to which a system, component, or process meets

    implicit and explicit requirements.” IEEE
  34. “It works as expected.”

  35. “It works as expected and it is not a PITA

    to maintain it.”
  36. ISO 9126-1 Software Quality Model ✅ Reliability ✅ Usability ✅

    Efficiency ✅ Maintainability ✅ Portability
  37. ISO 9126-1 Software Quality Model ✅ Reliability ✅ Usability ✅

    Efficiency ➡ Maintainability ✅ Portability
  38. Maintainability

  39. Maintainability 1. Code Coverage

  40. Maintainability 1. Code Coverage 2. Code Quality

  41. Code Coverage SimpleCov (github.com/colszowka/simplecov)

  42. Code Coverage # Gemfile group :test do gem "simplecov", require:

    false end
  43. Code Coverage # spec/spec_helper.rb if ENV["COVERAGE"] == "true" require 'simplecov'

    SimpleCov.start do add_group "Models", "models" add_filter "/spec/" track_files "**/*.rb" end end
  44. Code Coverage # spec/spec_helper.rb if ENV["COVERAGE"] == "true" require 'simplecov'

    SimpleCov.start "rails" end
  45. Code Coverage $ COVERAGE=true rspec

  46. Code Coverage

  47. Code Quality n options

  48. Code Quality n options (flog; flay; reek; churn; RubyCritic; MetricFu;

    attractor; rubocop; fukuzatsu; turbulence; …)
  49. Code Quality RubyCritic (github.com/whitesmith/rubycritic)

  50. Churn

  51. Churn git

  52. Churn $ git log --follow --format=%h default.rb | cat 573c8f5

    2ccc5b8 b447bc3
  53. Churn $ git log --follow --format=%h default.rb | cat 573c8f5

    2ccc5b8 b447bc3 # Churn Count = 3
  54. Complexity

  55. Complexity flog

  56. Complexity $ flog foo.rb 11.2: flog total

  57. Complexity class Foo def yay # 11.2 = a =

    eval "1+1" # 1.2 + 6.0 + if a == 2 then # 1.2 + 1.2 + 0.4 + puts "yay" # 1.2 end end end
  58. Churn Complexity 50 0% 1 100_000

  59. Churn Complexity 100 0% 1 100_000 user.rb (changed: 2 times;

    complexity: 100_000 )
  60. Churn Complexity 100 0% 1 100_000 user.rb user.rb (changed: 27

    times; complexity: 100)
  61. Code Quality $ gem install rubycritic

  62. Code Quality $ rubycritic

  63. None
  64. GPA Pie Graph Complexity (flog) Code Smells (reek)

  65. Churn vs. Complexity Churn (SCM) Complexity (flog)

  66. 100% 0% 1 100_000 Complexity Churn

  67. 100% 0% 1 100_000 Complexity Churn

  68. 100% 0% 1 100_000 “Welcome to the good place.” ❤

    Complexity Churn
  69. solidus/core

  70. 100% 0% 1 100_000 “No one understands these files but

    they work. So don’t change them.” Complexity Churn
  71. 100% 0% 1 100_000 “[…], if the code never changes,

    it's not costing us money.” Sandi Metz Complexity Churn
  72. solidus/core

  73. 100% 0% 1 100_000 “Everybody understands these files but you

    need to change them often because of reasons…” Complexity Churn
  74. solidus/core

  75. 100% 0% 1 100_000 Complexity Churn “Here be dragons. These

    modules are complex and change a lot…” '
  76. 100% 0% 1 100_000 Complexity Churn “Sometimes a class becomes

    so complex that refactoring seems too difficult.” Michael Feathers
  77. solidus/core

  78. Are you getting into a tar pit, is it a

    dumpster fire, or have you found a project which is easy to maintain?
  79. 100% 0% 1 100_000 “Welcome to the tar pit.” Complexity

    Churn
  80. None
  81. Maintainability 1. Code Coverage (SimpleCov) 2. Code Quality (RubyCritic)

  82. Code Coverage Code Smells Complexity

  83. Signal #1 Code Coverage

  84. Signal #2 Complexity

  85. Coverage & Complexity

  86. But what if we could calculate a new signal that

    combines both?
  87. Signal #3 StinkScore

  88. StinkScore = f(code_quality, code_coverage)

  89. StinkScore = f(code_smells, churn, code_complexity, code_coverage)

  90. code_coverage Files which lack tests should be penalized

  91. foo.rb churn: 10 complexity: 10 smells: 10 smell: 1,000 (10*10*10)

  92. bar.rb churn: 10 complexity: 10 smells: 10 smell: 1,000 (10*10*10)

  93. foo.rb churn: 10 complexity: 10 smells: 10 smell: 1,000 (10*10*10)

    bar.rb churn: 10 complexity: 10 smells: 10 smell: 1,000 (10*10*10)
  94. foo.rb is not stinkier than bar.rb

  95. foo.rb churn: 10 complexity: 10 smells: 10 code_coverage: 0 stink_score:

    100,000 (10*10*10)*100
  96. bar.rb churn: 10 complexity: 10 smells: 10 code_coverage: 100 stink_score:

    1,000 (10*10*10)*1
  97. foo.rb churn: 10 complexity: 10 smells: 10 code_coverage: 0 stink_score:

    100,000 (10*10*10)*100 bar.rb churn: 10 complexity: 10 smells: 10 code_coverage: 100 stink_score: 1,000 (10*10*10)*1
  98. foo.rb is considerably stinkier than bar.rb

  99. Stink Score Calculator Skunk (github.com/fastruby/skunk)

  100. Skunk $ gem install skunk

  101. Skunk $ skunk

  102. None
  103. None
  104. Skunk $ skunk ... StinkScore Total: 13220.859999999997 Modules Analysed: 71

    StinkScore Average: 0.1862092957746 Worst StinkScore: 2401.75 (lib/rubycritic/source_control_systems/git.rb)
  105. RubyCritic module RubyCritic class AnalysedModule def cost smells.map(&:cost).inject(0.0, :+) +

    # From Reek (complexity / COMPLEXITY_FACTOR) # From Flog end end end
  106. Skunk module RubyCritic class AnalysedModule def stink_score return churn_times_cost if

    perfect_coverage? (churn_times_cost * (PERFECT_COVERAGE - coverage.to_i)) end def churn_times_cost safe_churn = churn > 0 ? churn : 1 safe_churn * cost end end end
  107. Skunk module RubyCritic class AnalysedModule def stink_score return churn_times_cost if

    perfect_coverage? (churn_times_cost * (PERFECT_COVERAGE - coverage.to_i)) end def churn_times_cost safe_churn = churn > 0 ? churn : 1 safe_churn * cost end end end
  108. Skunk Warning > skunk-v0.2.0 > feedback wanted

  109. Maintainability 1. Code Coverage (SimpleCov) 2. Code Quality (RubyCritic) 3.

    StinkScore (Skunk)
  110. You are here:

  111. Part 2: Getting out of the tar pit

  112. So, where do we begin?

  113. removing files will decrease our stink_score

  114. Find Dead Code Coverband (github.com/danmayer/coverband)

  115. None
  116. refactoring complex files will decrease our stink_score

  117. 100% 0% 1 100_000 Complexity Churn “Here be dragons. These

    modules are complex and change a lot…” '
  118. 100% 0% 1 100_000 Complexity Churn “Great candidates for refactoring

    (paying technical debt!)” #
  119. Churn vs. Complexity is not enough to prioritize

  120. Stink Score Table

  121. Refactor These Files:

  122. Refactor These Files:

  123. 100% 0% 1 100_000 Complexity Churn git.rb

  124. 100% 0% 1 100_000 Complexity Churn git_calculator.rb git_fetcher.rb refactor! git.rb

  125. 100% 0% 1 100_000 Complexity Churn git_calculator.rb git_fetcher.rb

  126. Skunk $ skunk ... StinkScore Total: 13220.859999999997 11220 Modules Analysed:

    71 StinkScore Average: 0.1862092957746 0.157
  127. writing tests for our app will decrease our stink_score

  128. Stink Score Table

  129. Write Tests Here:

  130. Skunk $ skunk ... StinkScore Total: 13220.859999999997 11220 Modules Analysed:

    71 StinkScore Average: 0.1862092957746 0.157
  131. stink_score your compass to get out of the tar pit

  132. stink_score Code Coverage; Complexity; and Smells

  133. Thank you! @etagwerker 133

  134. Resources 1. https://github.com/whitesmith/rubycritic 2.https://github.com/colszowka/simplecov 3.https://github.com/metricfu/metric_fu 4.https://github.com/julianrubisch/attractor 5.https://www.fastruby.io/blog/ruby/quality/code-quality-ruby-gems.html 6.https://www.reddit.com/r/ruby/comments/2bq092/rubycritic/ 7.http://jakescruggs.blogspot.com/2008/08/whats-good-flog-score.html 8.http://ruby.sadi.st/Flog.html

    9.http://ruby.sadi.st/Flay.html 10.https://github.com/makaroni4/sandi_meter
  135. Resources 1.https://codeclimate.com/blog/deciphering-ruby-code-metrics/ 2.https://www.stickyminds.com/article/getting-empirical-about-refactoring 3.https://www.sandimetz.com/blog/2017/9/13/breaking-up-the-behemoth 4.https://github.com/troessner/reek 5.https://github.com/seattlerb/flay 6.https://github.com/seattlerb/flog 7.http://www.sqa.net/iso9126.html 8.https://www.slideshare.net/mscottford/important-metrics-for-measuring- code-health

    9.https://dilbert.com/strip/2006-12-08
  136. Questions?
