Microservices and Self-contained System to Scale Agile

Architectures like Microservices and Self-contained Systems provide a way to support agile processes and scale them. Held at JUG Saxony Day 2016 in Dresden.

Transcript

1. Microservices & Self- Contained Systems to Scale Agile Eberhard Wolff Fellow, innoQ @ewolff
2. http://continuous-delivery-buch.de/
3. http://microservices-buch.de/ http://microservices-book.com/
4. http://microservices-book.com/primer.html FREE!!!!
5. Microservices
6. Server Server Microservices: Definition > Independent deployment units > E.g. process, VMs, Docker containers > Any technology > Any infrastructure Micro Service Micro Service
7. Components Collaborate Micro Service Micro Service Link Data Replication REST Messaging
8. Layered Microservices iOS Android Web Order Search Catalog Billing Customer Backend Backend Backend
9. Layered Microservices > Reusable Backend Services > Mobile client / Web App as frontend > Backend for frontend (BFF): Custom backend services > ...to implement frontend specific logic
10. Layered: Issues > BFF might contain the same logic – same processes > BFF might contain most relevant logic > Change to a business process means changing many services > Lots of communication
11. Self-contained System
12. Deployment monolith Graphics by Roman Stranghöhner, innoQ http://scs-architecture.org
13. Cut Deployment monolith along domains …
14. … wrap domain in separate web application …
15. Self-contained System (SCS) – individually deployable
16. SCS = user interface+ business logic+ data storage
17. Each SCS contains all layers.
18. Self-contained Systems should be integrated in the web interface
19. Synchronous remote calls inside the business logic should be avoided.
20. Asynchronous Remote calls reduce dependencies and prevent error cascades.
21. Every SCS brings its own data storage with its own (potentially redundant) data
22. Domained scoped SCS enables the development, operation and maintenance of an domain by a single team. Team 1 Team 2 Team 3
23. 1 SCS = 1 Domain = 1 Web App = 1 Team = 1-n Microservices
24. Why create such a complex system?
25. Legacy Apps
26. HTTP New Stuff Links No legacy code Any technology J Small code base
27. Sustainable Development
28. Monoliths > Architecture rot > …not maintainable any more > …and can’t be rewritten / replaced
29. Microservices > Distributed system of small units > Architecture violations harder > Architecture won’t rot > Small units > Easy to replace > Service rotten? Replace!
30. Robust > One failing Microservice doesn’t crash the system > However, Microservices must deal with failing Microservices
31. Continuous Delivery
32. Principles behind the Agile Manifesto Our highest priority is to satisfy the customer through early and continuous delivery of valuable software.
33. Deployment Monolith ECommerce System 3rd party systems Database
34. Continuous Delivery: Build Pipeline ECommerce System Commit Stage Automated Acceptance Testing Automated Capacity Testing Manual Explorative Testing Release
35. Build Pipeline: Problems > Complex infrastructure > Huge database > 3rd party integration > Slow feedback > Test everything for each commit > Huge deployment unit > Deployment slow
36. Microservices ECommerce System 3rd party systems Database
37. Microservices 3rd party systems Database Order Catalog Billing Search
38. Order Billing Customer Commit Stage Automated Acceptance Testing Automated Capacity Testing Manual Explorative Testing Release Commit Stage Automated Acceptance Testing Automated Capacity Testing Manual Explorative Testing Release Commit Stage Automated Acceptance Testing Automated Capacity Testing Manual Explorative Testing Release
39. Build Pipeline for Microservices > Independent deployment > Build pipeline per Microservice > Smaller > Easier to set up > Less features (3rd party systems) > Faster Feedback: Less tests
40. Independent Scaling > Can scale each Microservice indenpendently > Much easier than for a Deployment Monolith
41. Technology Freedom > No meetings for introducing a bug fix in a library! > No big migration away from outdated technology > Easier experiments > Higher motivation
42. Scaling Agility
43. Scaling Agility > Do more > Get more stories implemented > ...and running in production TODO IN PROGRESS DONE
44. Scaling Agility > Add more people > Let the work in parallel > Build more teams
45. What is the problem?
46. Communication > Agile means communication > Instead of written requirements > ...story cards > + direct communication
47. # Persons vs. Potential Links 0 100 200 300 0 10 20 30
48. Communication is great! Need more persons
49. Challenges for Scaling Agile > Dependencies cause delays > Too much communication about functionalities,... > ...releasing software, > ...and technologies
50. Challenges for Scaling Agile > Dependencies cause delays > Too much communication about functionalities... > ...releasing software, > ...and technologies
51. Conway‘s Law Architecture copies communication structures of the organization
52. Logic UI Database Change Order Process!
53. time DB Team Sprint Logic Team Sprint GUI Team Sprint 3 sprints
54. Domained scoped SCS enables the development of a domain by a single team – no coordination Order Team = UI+Logic+Database
55. Challenges for Scaling Agile > Dependencies cause delays > Too much communication about functionalities... > ...releasing software, > ...and technologies
56. Deployment Monolith Stories Technical Coordination Coordinating Releases
57. Self-contained System (SCS) – individually deployable
58. Technical decisions can be made independently from other systems (programming language, frameworks, tooling, platform)
59. SCS Stories Technical Coordination Stories Technical Coordination Stories Technical Coordination Order Billing Search Release Release Release
60. Why Microservices/SCS? Sustainable development speed Continuous Delivery Choose best technology for job! Handle Legacy more efficient Independent Scaling Robustness Scaling Agile
61. Conclusion
62. Conclusion: SCS & Microservices > Microservices have many advantages > SCS are a way to use Microservices > …for large projects > …to scale agile
63. Thank You! @ewolff http://microservices-buch.de/ http://microservices-book.com/primer.html http://scs-architecture.org
64. EMail slidesjugsaxony@ewolff.com to get: Slides + Microservices Primer + Sample Microservices Book + Sample of Continuous Delivery Book Powered by Amazon Lambda & Microservices
