Effective Android Development

A presentation of the techniques, tools & process that we employ during our daily work to build high-quality apps for our clients. Not a code-heavy, deep-down into our architecture kinda talk, but a high-level behind the scenes about our process to move from prototyping to design and to production. We want to stay nimble during development, and quickly iterate over features, which we like to accomplish through frequent releases, often paired with A/B testing. At the same time, we are convinced that building robust applications is helped with a Continuous Delivery setup where we highly value an automated test strategy. Working in an agile way while focusing on good architecture, testing and reporting took us some effort, and I’d like to explore how we run our projects trying to be as effective and collaborative as possible...
Presented during the Devoxx conference on Thursday, 10th November 2016.
http://cfp.devoxx.be/2016/talk/VOW-7651/Effective_Android_dev

Transcript

1. Effective Android


   View Slide

2. Effective (Android) development


   View Slide

3. AppFoundry
   appfoundry.be


   View Slide

4. View Slide

5. –H. Alan Stevens
   Building the right thing is always more important than
   building it right.


   View Slide

6. Prototyping


   View Slide

7. Whiteboard


   View Slide

8. Paper prototyping


   View Slide

9. View Slide

10. View Slide

11. View Slide

12. View Slide

13. View Slide

14. View Slide

15. Remote configuration


    View Slide

16. Remote configuration
    - Check flags
    - maintenance
    - upgrade
    - Do specific work (load menu, …)
    - Check and act on feature switches
    Production API Test API
    Load Production config file
    https://xxxxx/2.1.json
    Load Test config file
    https://xxxxx/2.1-test.json


    View Slide

17. –Martin Fowler
    Feature toggles are a powerful technique, allowing teams
    to modify system behavior without changing code.


    View Slide

18. Key / value pairs @ Firebase
    Firebase
    Remote
    Config
    Change behaviour at runtime
    Developer console
    dynamic (no app update required)
    rules & conditions
    hosted, scalable, cross platform


    View Slide

19. View Slide

20. User feedback


    View Slide

21. A/B testing


    View Slide

22. View Slide

23. View Slide

24. Architecture


    View Slide

25. Architecture


    View Slide

26. MODEL
    PRESENTER
    VIEW
    View Presenter
    View
    View
    Presenter
    Presenter
    Data Manager
    Interactors
    Prefs
    API
    API
    DB
    Network
    service
    Network
    service
    Preferences
    Helper
    Observables
    Observables
    Presentation Layer Domain Layer Data Layer
    STREAM
    Architecture


    View Slide

27. Model View Presenter
    Model
    Presenter
    View


    View Slide

28. Model View Presenter
    Model
    Presenter
    View
    Android
    UI


    View Slide

29. MODEL
    PRESENTER
    VIEW
    View Presenter
    View
    View
    Presenter
    Presenter
    Data Manager
    Interactors
    Prefs
    API
    API
    DB
    Network
    service
    Network
    service
    Preferences
    Helper
    Observables
    Observables
    Presentation Layer Domain Layer Data Layer
    STREAM
    Architecture


    View Slide

30. Consistent
    Expressive
    Concise
    Verbose


    View Slide

31. X


    View Slide

32. Jetbrains
    Kotlin
    Good interoperability with Java
    Modern
    Small standard library (±600kb)
    Statically typed, no runtime overhead
    Reduce common errors
    Reduce boilerplate


    View Slide

33. Data class
    public class User {



    private String firstName;

    private String lastName;

    private int age;



    public int getAge() {

    return age;

    }



    public void setAge(int age) {

    this.age = age;

    }



    public String getFirstName() {

    return firstName;

    }



    public void setFirstName(String firstName) {

    this.firstName = firstName;

    }



    public String getLastName() {

    return lastName;

    }



    public void setLastName(String lastName) {

    this.lastName = lastName;

    }



    @Override

    public boolean equals(Object o) {

    if (this == o) return true;

    if (o == null || getClass() != o.getClass()) return false;



    User user = (User) o;



    if (age != user.age) return false;

    if (firstName != null ? !firstName.equals(user.firstName) : user.firstName != null) {

    return false;

    }

    return lastName != null ? lastName.equals(user.lastName) : user.lastName == null;

    }



    @Override

    public int hashCode() {

    int result = firstName != null ? firstName.hashCode() : 0;

    result = 31 * result + (lastName != null ? lastName.hashCode() : 0);

    result = 31 * result + age;

    return result;

    }



    @Override

    public String toString() {

    return "User{" +

    "age=" + age +

    ", firstName='" + firstName + '\'' +

    ", lastName='" + lastName + '\'' +

    '}';

    }

    }
    @AutoValue

    public abstract class User {



    public abstract String firstName();



    public abstract String lastName();



    public abstract int age();



    @AutoValue.Builder

    public abstract static class Builder {



    public abstract Builder firstName(String s);



    public abstract Builder lastName(String s);



    public abstract Builder age(int i);

    }



    public static Builder builder() {

    return new AutoParcel_User.Builder();

    }



    public abstract Builder toBuilder();

    }


    View Slide

34. Data class
    public class User {



    private String firstName;

    private String lastName;

    private int age;



    public int getAge() {

    return age;

    }



    public void setAge(int age) {

    this.age = age;

    }



    public String getFirstName() {

    return firstName;

    }



    public void setFirstName(String firstName) {

    this.firstName = firstName;

    }



    public String getLastName() {

    return lastName;

    }



    public void setLastName(String lastName) {

    this.lastName = lastName;

    }



    @Override

    public boolean equals(Object o) {

    if (this == o) return true;

    if (o == null || getClass() != o.getClass()) return false;



    User user = (User) o;



    if (age != user.age) return false;

    if (firstName != null ? !firstName.equals(user.firstName) : user.firstName != null) {

    return false;

    }

    return lastName != null ? lastName.equals(user.lastName) : user.lastName == null;

    }



    @Override

    public int hashCode() {

    int result = firstName != null ? firstName.hashCode() : 0;

    result = 31 * result + (lastName != null ? lastName.hashCode() : 0);

    result = 31 * result + age;

    return result;

    }



    @Override

    public String toString() {

    return "User{" +

    "age=" + age +

    ", firstName='" + firstName + '\'' +

    ", lastName='" + lastName + '\'' +

    '}';

    }

    }
    data class User(val firstName: String, val lastName: String, val age: Int)
    val user = User("Andy", "Rubin", 53)
    println(user)
    // User(firstName=Andy, lastName=Rubin, age=53)
    val usersBirthDay = user.copy(age = 54) // Named parameters

    println(usersBirthDay) // User(firstName=Andy, firstName=Rubin, age=54)


    View Slide

35. View Slide

36. Nullability
    var x: String? = "foo"



    x = null



    x.length // Does not compile




    val y: String = null // Does not compile


    View Slide

37. Nullability
    if (x != null) {

    x.length // Compiles

    }



    // Safe call

    val length = x?.length // Value null



    // Default value

    val length = if (x != null) x.length else -1 // Value -1



    // Elvis operator

    val length = x?.length ?: -1 // Value -1


    View Slide

38. Kotlin
    • Properties
    • Data class
    • Function literal (Lambda)
    • Higher order functions
    • Extension functions
    • …


    View Slide

39. View Slide

40. Layout
    android:layout_width="match_parent"

    android:layout_height="match_parent"

    android:fitsSystemWindows="true">



    android:layout_width="match_parent"

    android:layout_height="wrap_content">



    android:id="@+id/toolbar"

    android:layout_width="match_parent"

    android:layout_height="?attr/actionBarSize"/>







    android:id="@+id/container"

    android:layout_width="match_parent"

    android:layout_height="match_parent"

    app:layout_behavior="@string/appbar_scrolling_view_behavior"/>






    View Slide

41. Layout Anko
    android:layout_width="match_parent"

    android:layout_height="match_parent"

    android:fitsSystemWindows="true">



    android:layout_width="match_parent"

    android:layout_height="wrap_content">



    android:id="@+id/toolbar"

    android:layout_width="match_parent"

    android:layout_height="?attr/actionBarSize"/>







    android:id="@+id/container"

    android:layout_width="match_parent"

    android:layout_height="match_parent"

    app:layout_behavior="@string/appbar_scrolling_view_behavior"/>




    coordinatorLayout {

    fitsSystemWindows = true



    appBarLayout {


    toolBar = toolbar {

    if (SDK_INT >= LOLLIPOP)
    elevation = 4f

    }.lparams(width = matchParent,
    height = actionBarSize())
    }.lparams(width = matchParent)



    changeHandlerFrameLayout()

    .lparams(width = matchParent,
    height = matchParent) {

    behavior = ScrollingBehavior()

    }


    }


    View Slide

42. Layout


    View Slide

43. Advanced Layout


    View Slide

44. Advanced Layout


    View Slide

45. Anko performance test
    Specs ANKO XML Diff
    ALCATEL

    ONE TOUCH
    Mediatek MT6572

    Dual-core 1.3GHz Cortex-A7

    512MB RAM
    169.33 ms 608.66 ms 359%
    HUAWEI Y300
    Qualcomm MSM8225

    Dual-core 1.0 GHz Cortex-A5
    512 MB RAM
    593.66 ms 3435.33 ms 578%
    HUAWEI Y330
    Mediatek MT6572
    Dual-core 1.3 GHz Cortex-A7
    512MB
    162.33 ms 984 ms 606%
    Samsung
    Galaxy S2
    Exynos 4210 Dual
    Dual-core 1.2 GHz Cortex-A9
    1 GB RAM
    207.33 ms 753.66 ms 363%


    View Slide

46. Testing


    View Slide

47. Testing strategy


    View Slide

48. Confidence
    Refactor possible
    Code handover
    Fix bugs once


    View Slide

49. Automatic
    On every commit / scheduled
    Unit tests
    UI integration tests
    with Espresso


    View Slide

50. Test devices


    View Slide

51. Device testing


    View Slide

52. View Slide

53. View Slide

54. View Slide

55. View Slide

56. View Slide

57. Remote


    View Slide

58. View Slide

59. View Slide

60. Google Cloud Test Lab


    View Slide

61. Google Cloud Test Lab


    View Slide

62. Google Cloud Test Lab


    View Slide

63. Creating software = complex
    Continuous
    integration Ensure quality
    Automate
    high-quality, robust and reliable apps
    tedious / error-prone activities


    View Slide

64. Reduce risk
    Continuous
    integration Reduce overhead
    Quality Assurance


    View Slide

65. Automate all the things


    View Slide

66. Continuous integration
    1
    2
    3
    4
    CODE & COMMIT BUILD & CHECK
    CI PICKUP
    REPORT RESULTS


    View Slide

67. Build pipeline
    Checkout /
    compile
    Unit tests
    Test
    coverage
    Code
    analysis
    Create
    deployable
    artifact
    Deploy for
    automatic
    QA test
    Trigger
    automated
    QA stage


    View Slide

68. Static analysis


    View Slide

69. Auto publish
    Delivery
    Promote APK to production
    Automate
    Google Play alpha / beta
    without additional tools


    View Slide

70. Continuous
    Delivery


    View Slide

71. Continuous delivery / deliverable
    Continuous
    Delivery
    Deliverable Push on demand
    Confidence
    of being deployable


    View Slide

72. Feature-based deployment
    A successful Git branching model
    http://nvie.com/posts/a-successful-git-branching-model/


    View Slide

73. Code review
    Detect problems early.
    Learn from someone else’s code.


    View Slide

74. View Slide

75. View Slide

76. View Slide

77. View Slide

78. View Slide

79. Test app distribution


    View Slide

80. Hockey test app distribution


    View Slide

81. Fabric Beta app distribution


    View Slide

82. Fabric Beta app distribution


    View Slide

83. View Slide

84. Internal QA
    Testing
    Internal alpha testing program
    Beta testing / staged rollout
    of being deployable


    View Slide

85. Metrics


    View Slide

86. Crashlytics


    View Slide

87. Dashboard


    View Slide

88. Dashing


    View Slide

89. Questions?
    Filip Maelbrancke
    Consultant @ AppFoundry
    filip.maelbrancke@appfoundry.be
    @fmaelbrancke


    View Slide

90. Thank you!


    View Slide
