Killsuit: The Equation Group's Swiss Army Knife for Persistence, Evasion, and Data Exfil

Most researchers have focused on the Equation Group's brilliant exploits but very few researchers have focused on their extremely effective post exploitation capabilities. During this talk, we will dissect the KillSuit framework, the Equation Group's Swiss Army Knife for persistence, information gathering, defense evasion, and data exfiltration. KillSuit is a little-known part of the DanderSpritz post-exploitation toolkit, leaked by the Shadow Brokers in April 2017. KillSuit is a full featured and versatile framework used by a variety of the Equation Group's tools and implants. KillSuit provides the ability to stealthily establish persistence on machines, install keyloggers, packet capture tools, perform WiFi MITM, and other more information gathering tools. Killsuit includes many interesting ways to silently exfiltrate data and intel - including custom written IPSEC-like protocols and misuse of ""disabled"" WIFI cards and near-by open networks.

Transcript

1. KILLSUIT
2. • DEVOPS / SECURITY AT RANDORI • ARCHITECT • SECURITY ENGINEER • CONSULTANT • SECURITY ANALYST
4. • RESEARCHERS FOCUSED ON EXPLOITS • WANTED TO KNOW MORE ABOUT “APT” POST EXPLOITATION • ENCOURAGE OTHERS TO RESEARCH & REVERSE • THIS HAS WORKED (A LITTLE)! • WANTED A TECHNICAL SIDE PROJECT
5. • BRIEF OVERVIEW OF DANDERSPRITZ • QUICK HISTORY OF THE FRAMEWORK(S) • GETTING TO POST-EXPLOITATION • KILLSUIT • PERSISTENCE • EVASION • DATA EXFIL • QUANTUM SHOOTER – MAN ON THE SIDE • DANDERSPRITZ LAB
6. • FREAKING COOL • A FULLY FUNCTIONAL POST-EXPLOITATION FRAMEWORK • WRITTEN IN JAVA L • EXTREMELY MODULAR • “PLUGINS” (FEATURES) WRITTEN IN PYTHON / CUSTOM SCRIPTING J • DESIGNED FOR STEALTH • DESIGNED TO PREVENT DUMB OPERATORS FROM MESSING IT UP
7. Expanding Pully DanderSpritz DanderSpritz script rewrite 2001 2005 2011
8. Expanding Pully DanderSpritz DanderSpritz script rewrite 2001 KillSuit 2008
14. • TARGET = ATTACKED COMPUTER(S) • LP = LISTENING POST (C&C SERVER) • COMMAND = SOMETHING RUNNING ON TARGET • PSP = PERSONAL SECURITY PRODUCT (AV) • SAFETY HANDLER = DON’T MESS IT UP • IMPLANT = MALICIOUS CODE DEPLOYED ON TARGET
15. GETTING TO POST-EXPLOITATION Fuzzbunch Exploit DouplePulsar PeddleCheap DanderSpritz
16. WHAT IS KILLSUIT?
20. • EXTREMELY MODULAR PERSISTENCE FRAMEWORK • MULTIPLE SUPPORTED PERSISTENCE METHODS • CAN LOAD SEVERAL DIFFERENT ”PLUGINS” • ENCRYPTION FOR EVERYTHING
21. • INSTANCE = A SPECIFC INSTANCE OF KILLSUIT (MULTIPLE CAN BE INSTALLED) • TYPE = A SPECIFIC KISU INSTANCE INTENDED TO SUPPORT PERSISTENCE FOR A COMPLEX IMPLANT • LAUNCHER = THE DRIVER EXPLOITED TO RUN KERNEL MODE CODE • MODULE = SPECIFIC IMPLANT / CODE THAT IS INTENDED TO BE PERSISTENT • MODULE STORE = ENCRYPTED VIRTUAL FILE SYSTEM
23. • MODIFIES VBR TO LOAD KERNEL DRIVER • USES AN ENCRYPTED TRUETYPE FONT FILES AS “CONTAINERS” FOR KERNEL DRIVER • PATCHES WINLOAD.EXE & THE FIRST DRIVER LOADED DURING BOOT TIME
25. • LAUNCHES A “KERNEL MODE ORCHESTRATOR” BY EXPLOITING A “LAUNCHER” DRIVER • PROVIDES ABILITY TO RUN *UNSIGNED* KERNEL MODE AND USER MODE CODE • BEGINS LAUNCHING IMPLANTS • INJECTS MALICIOUS USER MODE CODE INTO PROCESSES
27. DEFENSE EVASION
28. • EVERYTHING ENCRYPTED WITH UNIQUE KEY PER TARGET • VIRTUAL FILE SYSTEM STORED IN REGISTRY • PROCESS INJECTION FOR USER MODE CODE • TEMPORARILY CREATE FILES • TIME STOMPING
30. • PROVIDES COVERT (NON-WINSOCK) NETWORK ACCESS FOR TOOLS • FLEWAVENUE = IPV4 DRIVER • DOORMANGAUZE = IPV6 DRIVER
33. DATA GATHERING
34. • STEALTHY KEYLOGGERS • PERSISTENCE USING KILLSUIT USING THE “STLA” INSTANCE TYPE • STORES ENCRYPTED DATA IN VBNARM.DLL (CONFIGURABLE)
35. • FULLY FEATURED PACKET CAPTURE TOOL • USES BERKLEY PACKET FILTER (BPF) FILTER FORMAT • INSTALLED ONTO AN EXISTING KILLSUIT INSTANCE • CAPTURED DATA STORED TO AN ENCRYPTED CONTAINER
37. • DANDERSPRITZ INCLUDES DRIVERS TO INTERACT WITH SEVERAL DATABASES • CAN BE INSTALLED PERSISTENTLY WITH KISU • MSSQL, MYSQL, SQLITE, ORACLE
39. • WIFI MAN IN THE MIDDLE (MITM) • USES A SEPARATE KILLSUIT INSTANCE WITH IT’S OWN TYPE (MABE) • INSTALLS DRIVER WITH PACKET INJECTION CAPABILITIES
40. STEALTHY EXFIL
41. STRAITBIZARRE FRIEZERAMP
42. • STRAITBIZARRE = IMPLANT DESIGNED FOR STEALTHY DATA EXFIL • FRIEZERAMP = CUSTOM NETWORK PROTOCOL • PROVIDES COVERT & ENCRYPTED NETWORKING CAPABILITIES • USES ”ADAPTERS” TO INSERT PACKETS INTO RELEVANT TRANSPORT LAYER • SIMILAR TO IPSEC
44. • DATA EXFIL VIA UN-USED / DISABLED WIFI CARDS • USED WHEN THE TARGET IS AIR GAPPED • CAN USE STOLEN CREDENTIALS OR SEND VIA OPEN NETWORKS • USES A SEPARATE KILLSUIT INSTANCE WITH IT’S OWN TYPE (SOKN)
45. QUANTUM SHOOTER
51. • STRAITBIZARRE SHOOTER REDIRECTS TO FOXACID EXPLOIT SERVER • EXPLOIT SERVER DEPLOYS “VALIDATOR” • VALIDATOR CONFIRMS IF TARGET IS INTERESTING • UPGRADE TO UNITED RAKE
52. STORY TIME
55. v 0x7a43e1fa in hex
60. • • • • • • • • • • • • • • • • •
61. DANDERSPRITZ LAB
62. • FULLY FUNCTIONAL DANDERSPRITZ LAB IN 2 COMMANDS • PACKER BUILD DANDERSPRITZ_LAB.JSON • VAGRANT UP
63. • BRIEF OVERVIEW OF DANDERSPRITZ • FRAMEWORK HISTORY & OVERVIEW • GETTING TO POST-EXPLOITATION • SOLARTIME • KILLSUIT MODULES • QUANTUM SHOOTER – MAN ON THE SIDE • DANDERSPRITZ LAB
64. DANDERSPRITZ.COM @FRANCISCKRS DANDERSPRITZ_DOCS DANDERSPRITZ_LAB
