DanderSpritz: How the Equation Group's 2013 tools still pwn in 2017

Everyone has focused on the Equation Group's "weapons grade" exploits but no one has focused on their extremely effective post exploitation capabilities.

In this talk I will cover the tools, methods, and capabilities built into the DanderSpritz post exploitation framework. We will review how the Equation Group gained and maintained persistence, bypassed auditing and AV, scan, sampled, subdued, and successfully dominated an entire organization ninja-style.

We'll dig into the technical details of how the framework gains persistence, performs key logging, captures traffic and screenshots, steals credentials, gathers target information, owns AV and WSUS servers, exfiltrates secrets, and causes general mayhem.

Transcript

1. DANDERSPRITZ HOW THE EQUATION GROUP'S 2013 TOOLS PWN IN 2017 DERBYCON 7.0
2. • RUN AN ARCHITECTURE TEAM AT A SWISS SECURITY COMPANY • ARCHITECT • SECURITY ENGINEER • CONSULTANT • SECURITY ANALYST
4. • RESEARCHERS FOCUSED ON EXPLOITS • WANTED TO KNOW MORE ABOUT “APT” POST EXPLOITATION • ENCOURAGE OTHERS TO RESEARCH & REVERSE • WANTED A TECHNICAL SIDE PROJECT
7. • QUICK HISTORY OF THE FRAMEWORK(S) • GETTING TO POST-EXPLOITATION • INTRO TO DANDERSPRITZ • INFO COLLECTED ON CONNECTION • TRADECRAFT • PERSISTENCE • RECON • LATERAL MOVEMENT • DATA EXFIL
8. Expanding Pully DanderSpritz DanderSpritz script rewrite 2001 2005 2011
14. GETTING TO POST-EXPLOITATION Fuzzbunch Exploit DouplePulsar PeddleCheap DanderSpritz
15. • FREAKING COOL • A FULLY FUNCTIONAL POST-EXPLOITATION FRAMEWORK • WRITTEN IN JAVA L • EXTREMELY MODULAR • PLUGINS / FEATURES WRITTEN IN PYTHON / CUSTOM SCRIPTING J • DESIGNED FOR STEALTH • DESIGNED TO PREVENT DUMB OPERATORS FROM MESSING IT UP
16. • OP = OPERATION • TARGET = ATTACKED COMPUTER(S) • LP = LISTENING POST (C&C) • PLUGIN = FUNCTIONALITY • COMMAND = SOMETHING RUNNING ON TARGET • PSP = PERSONAL PROTECTION PRODUCT (AV) • SAFETY HANDLER = DON’T MESS IT UP
18. • REPOSITORY FOR DANDERSPRITZ SESSION DATA ACROSS ALL TARGETS • UNIQUE PRIVATE / PUBLIC KEY PAIR PER OP • DANDERSPRITZ CORRELATES DATA ACROSS TARGETS IN SAME OP • SAFETY HANDLERS CAN BE REGISTERED PER OP (MORE ON THIS LATER) • OPS CAN BE REPLAYED - TRAINING? • PROPERLY FORMATTED OPS NOTES GENERATE “TECH SUMMARIES”
19. • OPERATING SYSTEM INFO • NETWORK INFO • MOUNTED DRIVES • CURRENT PROCS • DRIVERS • INSTALLED SOFTWARE • SERVICES • PSPS • PERSISTENCE • AUDIT CONFIG • SCHEDULED TASKS • RECENTLY MODIFIED FILES • RECENT USB DEVICES • DUMPS PASSWORDS
23. • GREATERDOCTOR • CAN SCAN MEMORY & PROCESSES • CAN PARSE FILES • CAN GRAB MEMORY FOR FORENSICS LATER • GANGSTERTHIEF • READS RAW MFT FOR ANALYSIS
27. BYPASS AV & LOGGING LIKE A PRO
33. • PREVENT OPERATOR OR AUTOMATED SCRIPTS FROM PERFORMING CERTAIN ACTIONS • MEANT TO REDUCE POSSIBILITY OF DETECTION • LOTS OF DIFFERENT TYPES OF SAFETY HANDLERS
34. • AUDIT • REGISTRYADD & QUERY • PROCESS INJECTION • MEMORY • NETWORK TRAFFIC • PREVENT DROPPING OF EXES • PREVENT DLL LOADS • …MORE
39. OH YOU GOT LOGGING? THAT’S CUTE
43. “ ” DON’T BE AN IDIOT NATION STATE HACKING 101
44. • DON’T SLOW DOWN THE MACHINE • DON’T SEND OUT A TON OF NETWORK TRAFFIC • HAVE THINGS CHANGED SINCE YOU LAST VISITED • DID THEY GET SUSPICIOUS FOR SOME REASON? • TRY NOT TO DROP EXES • MAKE SURE THEY LOOK LEGIT • MATCH FILE TIMES WITH LEGIT EXES • ENCRYPT EVERYTHING • STAY ON A TARGET FOR AS LITTLE TIME AS POSSIBLE
53. • CAN LISTEN • AT SPECIFIC TIMES • CAN REQUIRE PORT KNOCKING (YES REALLY...) • CAN CALL BACK • AT SPECIFIC TIMES • WORKS WITH A PROXY
55. • EXTREMELY MODULAR • CAN LOAD SEVERAL DIFFERENT ”PLUGINS” • USED BY OTHER SYSTEMS SUCH AS KEYLOGGERS • EVERYTHING ENCRYPTED WITH UNIQUE KEY PER TARGET
58. • MODIFIES MBR TO LOAD KERNEL DRIVER • USES TRUETYPE FONT FILES AS “CONTAINERS” FOR DRIVER • DOESN’T WORK WITH BITLOCKER OR EFI
61. • BROWSER DATA (IE, FF, CHROME) • RECENTLY PLAYED MEDIA • USB DEVICES • RECENTLY RUN COMMANDS • DNS CACHE • RECENT RDP SESSIONS • RECENTLY ACCESSED FILES • PUTTY / WINSCP CREDS • PERIODIC SCREENSHOTS • SHARES • PCAPS • KEYLOGGER DATA
64. • LIST DBS • VIEW SCHEMAS • TOP 10 ROWS FROM TABLES • QUERY PLANS
68. THANKS FOR THE HELP!
74. 1. USE CREDENTIALS GATHERED FROM RECON PHASE 2. MOUNT ADMIN SHARE & PUSH CONFIGURED PEDDLECHEAP EXE 3. SCHEDULE TASK TO RUN EXE 4. PROFIT
75. 1. MOUNT ADMIN SHARE & PUSH CONFIGURED PEDDLECHEAP EXE 2. USE WMI REMOTE EXEC TO RUN EXE 3. PROFIT
76. 1. GENERATE A PEDDLECHEAP IMPLANT TRIGGERED VIA WINSOCKHELPER 2. REBOOT MACHINE 3. PROFIT
77. 1. USE “PACKETREDIRECT” COMMAND 2. CONFIGURE FUZZBUNCH WITH IMPLANTED TARGET AS A REDIRECTOR 3. SMB / NAMEPIPED TOUCH (TELLS YOU WHICH EXPLOIT TO USE) 4. EXPLOIT 5. DOUBLEPULSAR LOADS PEDDLECHEAP 6. PROFIT
79. FRAMEWORK INCLUDES DRIVERS TO INTERACT WITH SEVERAL DATABASES
80. • IDENTIFY INTERESTING DOCUMENTS / SHAREPOINT SITES • USE “SHAREPOINT” COMMAND TO RECURSIVELY PULL FILES
84. • INTRO TO DANDERSPRITZ & A LOOKED AT WHY IT’S SO DAMN COOL • BRIEF LOOK AT EQUATION GROUP TRADECRAFT • BRIEF LOOK AT PERSISTENCE METHODS • LOOK AT RECON CAPABILITIES • DATA EXFIL
85. DANDERSPRITZ.COM @FRANCISCKRS DANDERSPRITZ_DOCS
