Erstellung hochverfügbarer Dienste mit Consul

Consul ist ein verteiltes Service Discovery Tool. Das in Go geschriebene Programm ist für viele Plattformen verfügbar, unter anderem für Solaris 11 bzw. Illumos. In diesem Vortrag will ich aufzeigen, wie Consul bei der Erstellung von hochverfügbaren Diensten verwendet werden kann. Das Ziel ist es Gateways, Loadbalancer und auch Datenbanken hochverfügbar zu halten.

Transcript

1. © 2017 stefan.husch@qutic.com
   Erstellung hochverfügbarer
   Dienste mit Consul


   View Slide

2. Stefan Husch
   @qutic
   ‣ Inhaber ‚qutic development‘
   ‣ Beratung, Entwicklung und Hosting von Webapplikationen
   ‣ Rechenzentrums-Dienstleistungen


   View Slide

3. Was ist das Ziel?


   View Slide

4. Hochverfügbarkeit von
   Gateways,
   Loadbalancer,
   Datenbankserver,
   DNS-Auth-Server,
   etc.


   View Slide

5. Was ist Consul?


   View Slide

6. ‣Service Discovery
   ‣Automatic Leader Election
   ‣HA Key/Value Store
   ‣Multi Datacenter


   View Slide

7. Service Discovery


   View Slide

8. ‣Health Check
   ‣DNS und HTTP JSON API
   ‣command-line interface


   View Slide

9. Service bekanntgeben


   View Slide

10. Health Check


    View Slide

11. DNS-API
    $ dig @127.0.0.1 \
    -p 8600 \
    database.service.dc1.consul \
    +short
    10.10.10.30
    10.10.10.31


    View Slide

12. HTTP-API
    $ curl \
    127.0.0.1:8500/v1/status/leader
    "10.10.10.11:8300"
    $ curl \
    127.0.0.1:8500/v1/health/state/critical
    []


    View Slide

13. Leader Election


    View Slide

14. ‣ Intern und Extern
    ‣ Raft Protocol
    ‣ Extern: HTTP JSON API


    View Slide

15. HA Key/Value Store


    View Slide

16. View Slide

17. Multi Datacenter


    View Slide

18. Hochverfügbarkeit


    View Slide

19. Consul


    View Slide

20. View Slide

21. View Slide

22. DNS-Auth-Server


    View Slide

23. View Slide

24. Loadbalancer


    View Slide

25. View Slide

26. View Slide

27. 1. Consul client check health of service by executing check_lb script
    1. check if loadbalancer is online
    2. store ip addresses of all virtual interfaces as key-value in Consul
    2. If check succceeds marks as healthy, if not mark as unhealthy,
    communicate result with Consul leader
    3. If service is unhealthy, Consul will execute watch-script check_lb
    on the fallback loadbalancer
    1. Get virtual interfaces and their ip out of consul key-value store
    2. Create virtual interfaces with their ip
    3. Update arp-table by sending out a gratuitous arp for all
    4. Add route
    5. Start failover loadbalancer service


    View Slide

28. Watcher Skript bekanntgeben


    View Slide

29. Gateway


    View Slide

30. ... wie beim Loadbalancer,
    nur mit interner IP-Adresse


    View Slide

31. MySQL Client Access


    View Slide

32. View Slide

33. View Slide

34. 1. Consul client check health of service by executing check_mysql script
    1. check if mysql is online
    2. If check succceeds marks as healthy, if not mark as unhealthy,
    communicate result with Consul leader
    3. If service is unhealthy, Consul will execute watch-script check_mysql
    on all mysql-proxy instances
    1. Rewrite mysql-proxy configuration (or use consul-template !)
    2. Restart mysql-proxy Service


    View Slide

35. ?


    View Slide

36. Quellen
    ‣ https://www.consul.io
    ‣ https://github.com/hashicorp/consul
    ‣ https://www.youtube.com/watch?v=rA4hyJ-pccU
    ‣ http://www.thekelleys.org.uk/dnsmasq/doc.html
    ‣ https://unbound.net
    ‣ https://www.consul.io/docs/internals/consensus.html
    ‣ https://www.consul.io/docs/guides/leader-election.html
    ‣ https://stripe.com/blog/service-discovery-at-stripe
    ‣ https://github.com/eBay/fabio
    ‣ https://github.com/hashicorp/consul-template
    ‣ https://github.com/darkcrux/consul-skipper
