Clouds in Government - Perils of Portability

Clouds in Government - Perils of Portability

Talk from QCon London in March 2013 about the problems inherent in running across multiple IaaS and PaaS providers, why APIs and images are only a small part of the answer and what the future may bring.

98234c645fe8c935edc0fec0186d28b8?s=128

Gareth Rushgrove

March 06, 2013
Tweet

Transcript

  1. http://www.flickr.com/photos/wallyg/299908721/ Clouds in Government Perils of Portability QCon 6th February

    2013 gareth rushgrove | morethanseven.net
  2. Me

  3. Gareth Rushgrove @garethr gareth rushgrove | morethanseven.net

  4. Curate devopsweekly.com gareth rushgrove | morethanseven.net

  5. Blog at morethanseven.net gareth rushgrove | morethanseven.net

  6. Work at UK Government Digital Service Text gareth rushgrove |

    morethanseven.net
  7. http://www.flickr.com/photos/benterrett/6852348725/ I am a Civil Servant gareth rushgrove | morethanseven.net

  8. http://www.flickr.com/photos/iancarroll/5027441664 Perils Clouds and portability

  9. The 2nd definition gareth rushgrove | morethanseven.net per·il /ˈperəl/ Noun

    1. Serious and immediate danger. 2. The dangers or difficulties that arise from a particular situation or activity.
  10. Peril 1 Caring about Image formats http://www.flickr.com/photos/uk_parliament/2700327415

  11. AMI, VMDK, OVF, VHD, VDI, etc. gareth rushgrove | morethanseven.net

  12. http://www.flickr.com/photos/uk_parliament/2700311119/ But I have many machines gareth rushgrove | morethanseven.net

  13. http://www.flickr.com/photos/uk_parliament/2700327415 And my infrastructure is more than just machines gareth

    rushgrove | morethanseven.net
  14. Peril 2 API proliferation http://www.flickr.com/photos/uk_parliament/2700327415

  15. Amazon EC2 gareth rushgrove | morethanseven.net

  16. Big API (Just EC2) gareth rushgrove | morethanseven.net 160+ actions

  17. Lots more APIs gareth rushgrove | morethanseven.net

  18. API compatibility and de facto standards gareth rushgrove | morethanseven.net

    http://www.flickr.com/photos/uk_parliament/2700357007/
  19. Greenqcloud is EC2 compatible gareth rushgrove | morethanseven.net greenqloud.com

  20. Eucalyptus gareth rushgrove | morethanseven.net www.eucalyptus.com

  21. gareth rushgrove | morethanseven.net EUCALYPtUS Funny story

  22. Eucalyptus is an acronym gareth rushgrove | morethanseven.net Elastic Utility

    Computing Architecture for Linking Your Programs to Useful Systems
  23. Ta da gareth rushgrove | morethanseven.net Elastic Utility Computing Architecture

    for Linking Your Programs to Useful Systems
  24. It’s not all about the APIs gareth rushgrove | morethanseven.net

    http://www.flickr.com/photos/uk_parliament/2757120644
  25. Peril 3 Cloud primitives http://www.flickr.com/photos/uk_parliament/2700327415

  26. AWS - All the acronyms! gareth rushgrove | morethanseven.net -

    Instance - Images - Elastic Compute Cloud (EC2) - Elastic IP (EIP) - Elastic Network Interfaces (EIN) - Elastic Block Store (EBS) - Simple Storage Service (S3) - Elastic Load Balancers (ELB)
  27. OpenStack gareth rushgrove | morethanseven.net www.openstack.org

  28. OpenStack gareth rushgrove | morethanseven.net - Compute - Storage -

    Networking - Instance - Security group - Object store - Block store
  29. CloudStack gareth rushgrove | morethanseven.net incubator.apache.org/cloudstack/

  30. CloudStack gareth rushgrove | morethanseven.net - Network - VPC -

    Virtual machine - VPN - Load balancer - Router - Project - Network - ISO - Volume - Template - Security group - User - Snapshot - Firewall - Account - NAT - VM group - Resource tag - Address - Zone - Disk offering - Hypervisor - Guest OS
  31. Abstractions to the rescue? gareth rushgrove | morethanseven.net http://www.flickr.com/photos/uk_parliament/2701192648/

  32. Fog (Ruby) gareth rushgrove | morethanseven.net fog.io

  33. Fog primitives gareth rushgrove | morethanseven.net - Compute - Storage

    - CDN - DNS
  34. libcloud (Python) gareth rushgrove | morethanseven.net libcloud.apache.org

  35. libcloud primitives gareth rushgrove | morethanseven.net - Compute - Storage

    - Load balancers - DNS
  36. jclouds (Java) gareth rushgrove | morethanseven.net www.jclouds.org

  37. jclouds primitives gareth rushgrove | morethanseven.net - Computeservice - Blob

    store
  38. Naming things is hard gareth rushgrove | morethanseven.net There are

    only two hard things in Computer Science: cache invalidation and naming things. Phil Karlton “ ”
  39. Peril 4 Slippery slope of Platform as a Service http://www.flickr.com/photos/uk_parliament/2700327415

  40. Definitions gareth rushgrove | morethanseven.net ...does not manage or control

    the underlying cloud infrastructure including network, servers, operating systems, or storage... ...does not manage or control the underlying cloud infrastructure but has control over operating systems, storage, and deployed applications; and possibly limited control of select networking components... PaaS IaaS
  41. Platform as a Service gareth rushgrove | morethanseven.net

  42. Not PaaS gareth rushgrove | morethanseven.net

  43. Heroku gareth rushgrove | morethanseven.net

  44. Heroku gareth rushgrove | morethanseven.net

  45. Amazon Elastic Beanstalk gareth rushgrove | morethanseven.net

  46. Amazon Elastic Beanstalk gareth rushgrove | morethanseven.net

  47. Amazon EC2 gareth rushgrove | morethanseven.net

  48. Amazon EC2 gareth rushgrove | morethanseven.net

  49. vCloud Director gareth rushgrove | morethanseven.net

  50. vCloud Director gareth rushgrove | morethanseven.net

  51. Amazon DynamoDB gareth rushgrove | morethanseven.net

  52. Amazon DynamoDB gareth rushgrove | morethanseven.net

  53. Amazon ElastiCache gareth rushgrove | morethanseven.net

  54. Amazon ElastiCache gareth rushgrove | morethanseven.net

  55. Peril 5 Vendor lock-in

  56. Capability lock-in gareth rushgrove | morethanseven.net

  57. Capacity lock-in gareth rushgrove | morethanseven.net

  58. Ecosystem lock-in gareth rushgrove | morethanseven.net http://www.flickr.com/photos/uk_parliament/2700549757/

  59. http://www.flickr.com/photos/iancarroll/5027441664 Interlude The story of GOV.UK

  60. gareth rushgrove | morethanseven.net Government is Big 464,000 55,000 UK

    Civil Service Google 19,995 BBC x8 x23
  61. Martha Lane-Fox Report - October 2010 gareth rushgrove | morethanseven.net

  62. Alpha - June 2011 gareth rushgrove | morethanseven.net

  63. Me - September 2011 gareth rushgrove | morethanseven.net

  64. GDS Government Digital Service - December 2011 gareth rushgrove |

    morethanseven.net
  65. Beta - January 2012 gareth rushgrove | morethanseven.net

  66. Design Principles - April 2012 gareth rushgrove | morethanseven.net

  67. gareth rushgrove | morethanseven.net Why Infrastructure as a Service? digital.cabinetoffice.gov.uk/2012/09/25/why-iaas/

  68. gareth rushgrove | morethanseven.net G-Cloud Procurement Framework gcloud.civilservice.gov.uk

  69. gareth rushgrove | morethanseven.net EC2 to VMWare http://www.flickr.com/photos/uk_parliament/2701203048/

  70. GOV.UK - October 2012 gareth rushgrove | morethanseven.net

  71. Government Digital Strategy - November 2012 gareth rushgrove | morethanseven.net

    publications.cabinetoffice.gov.uk/digital/
  72. 13 of 24 Departments - So far gareth rushgrove |

    morethanseven.net
  73. http://www.flickr.com/photos/iancarroll/5027441664 Solutions? What can we do

  74. Solution 1 Infrastructure as code http://www.flickr.com/photos/uk_parliament/2700327415

  75. gareth rushgrove | morethanseven.net Configuration Management

  76. gareth rushgrove | morethanseven.net Chef opscode.com

  77. gareth rushgrove | morethanseven.net Chef code example cookbook_file "#{home_dir}/.ssh/authorized_keys" do

    source "authorized_keys" mode "0600" owner username group username end group "sysadmin" do members ["garethr"] end
  78. gareth rushgrove | morethanseven.net CFEngine cfengine.com

  79. gareth rushgrove | morethanseven.net CFEngine code example bundle agent test

    { packages: redhat:: "wget" package_policy => "addupdate", package_method => yum, package_select => ">=", package_version => "1.11.4-2.el5_4.1", package_architectures => { "x86_64" }; }
  80. gareth rushgrove | morethanseven.net Puppet puppetlabs.com

  81. package { 'apache2': ensure => latest, } service { 'apache2':

    ensure => running, provider => upstart, require => Package['apache2'] } gareth rushgrove | morethanseven.net Resources
  82. class govuk::apps::calendars( $port = 3011 ) { govuk::app { 'calendars':

    app_type => 'rack', port => $port, health_check_path => ‘/bank-holidays’, } } gareth rushgrove | morethanseven.net Applications
  83. class govuk::node::s_frontend inherits govuk::n include govuk::node::s_ruby_app_server include govuk::apps::businesssupportfinder include govuk::apps::calendars

    include govuk::apps::canary_frontend include govuk::apps::datainsight_frontend include govuk::apps::designprinciples include govuk::apps::feedback include govuk::apps::frontend include govuk::apps::licencefinder include govuk::apps::smartanswers include govuk::apps::static gareth rushgrove | morethanseven.net Node types
  84. class govuk::node::s_frontend inherits govuk::n include govuk::node::s_ruby_app_server include govuk::apps::businesssupportfinder include govuk::apps::calendars

    include govuk::apps::canary_frontend include govuk::apps::datainsight_frontend include govuk::apps::designprinciples include govuk::apps::feedback include govuk::apps::frontend include govuk::apps::licencefinder include govuk::apps::smartanswers include govuk::apps::static gareth rushgrove | morethanseven.net Include software on nodes
  85. class govuk::node::s_frontend inherits govuk::n include govuk::node::s_ruby_app_server include govuk::apps::businesssupportfinder include govuk::apps::calendars

    include govuk::apps::canary_frontend include govuk::apps::datainsight_frontend include govuk::apps::designprinciples include govuk::apps::feedback include govuk::apps::frontend include govuk::apps::licencefinder include govuk::apps::smartanswers include govuk::apps::static gareth rushgrove | morethanseven.net Include out applications on nodes
  86. gareth rushgrove | morethanseven.net More on Infrastructure as Code speakerdeck.com/garethr

  87. Solution 2 API abstractions http://www.flickr.com/photos/uk_parliament/2700327415

  88. gareth rushgrove | morethanseven.net libcloud

  89. gareth rushgrove | morethanseven.net libcloud OpenStack example from libcloud.compute.types import

    Provider from libcloud.compute.providers import get_driver OpenStack = get_driver(Provider.OPENSTACK) driver = OpenStack('username', 'password', ex_force_auth_url='https://nova-api.trystack.org:5 ex_force_auth_version='2.0_password') nodes = driver.list_nodes() images = driver.list_images()
  90. gareth rushgrove | morethanseven.net libcloud VCloud example from libcloud.compute.types import

    Provider from libcloud.compute.providers import get_driver vcloud = get_driver(Provider.VCLOUD) driver = vcloud('username', 'password', host='vcloud.local', api_version='1.5') nodes = driver.list_nodes() images = driver.list_images()
  91. gareth rushgrove | morethanseven.net But abstractions leak images = driver.list_images()

    sizes = driver.list_sizes() size = [s for s in sizes if s.ram == 512][0] image = [i for i in images if i.name == 'natty-amd64'][0] node = driver.create_node(name='test node', image=image, size=size)
  92. gareth rushgrove | morethanseven.net But abstractions leak images = driver.list_images()

    sizes = driver.list_sizes() size = [s for s in sizes if s.ram == 512][0] image = [i for i in images if i.name == 'natty-amd64'][0] node = driver.create_node(name='test node', image=image, size=size)
  93. gareth rushgrove | morethanseven.net But abstractions leak take two vcloud

    = get_driver(Provider.VCLOUD) driver = vcloud('username', 'password', host='vcloud.local', api_version='1.5') node = driver.create_node(name='test node 4', image=image, ex_vm_network='your vm net name', ex_network='your org net name', ex_vm_fence='bridged', ex_vm_ipmode='DHCP')
  94. gareth rushgrove | morethanseven.net More capabilities, more leaks vcloud =

    get_driver(Provider.VCLOUD) driver = vcloud('username', 'password', host='vcloud.local', api_version='1.5') node = driver.create_node(name='test node 4', image=image, ex_vm_network='your vm net name', ex_network='your org net name', ex_vm_fence='bridged', ex_vm_ipmode='DHCP')
  95. gareth rushgrove | morethanseven.net Fog

  96. gareth rushgrove | morethanseven.net jclouds

  97. Solution 3 Config managent plus APIs http://www.flickr.com/photos/uk_parliament/2700327415

  98. gareth rushgrove | morethanseven.net Pallet github.com/pallet/pallet

  99. gareth rushgrove | morethanseven.net Pallet code example (use 'pallet.crate.java) (defnode

    webserver {} :configure (phase (java :openjdk))) (converge {webserver 10} :compute service)
  100. gareth rushgrove | morethanseven.net Ironfan github.com/infochimps-labs/ironfan

  101. gareth rushgrove | morethanseven.net Ironfan example Ironfan.cluster 'web_demo' do cloud(:ec2)

    do flavor 't1.micro' end role :base_role facet :dbnode do instances 2 role :mysql_server end end
  102. gareth rushgrove | morethanseven.net puppet-iaas github.com/garethr/garethr-iaas

  103. gareth rushgrove | morethanseven.net Cloud instances as resources server {

    'web-server': ensure => present, count => 5, provider => brightbox, image => 'img-q6gc8', # ubuntu 12.04 }
  104. gareth rushgrove | morethanseven.net Switch the provider server { 'web-server':

    ensure => present, count => 5, provider => rackspace, image => 'img-q6gc8', # ubuntu 12.04 }
  105. gareth rushgrove | morethanseven.net Leaky interface server { 'web-server': ensure

    => present, count => 5, provider => rackspace, image => '5cebb13a-f783-4f8c-8058 c4182c7 flavor => 2, # 512 MB }
  106. gareth rushgrove | morethanseven.net Vagrant 1.1 vagrantup.com

  107. gareth rushgrove | morethanseven.net Define our instance Vagrant::Config.run do |config|

    config.vm.box = "precise64" config.vm.forward_port 5555, 5555 config.vm.forward_port 5556, 5556 config.vm.forward_port 4567, 4567 config.vm.provision :puppet do |puppet| puppet.manifests_path = "manifests" puppet.module_path = "modules" puppet.manifest_file = "site.pp" end end
  108. gareth rushgrove | morethanseven.net Configure different providers Vagrant.configure("2") do |config|

    config.vm.box = "precise64" config.vm.provider :vmware_fusion do |v| v.vmx["memsize"] = "1024" end config.vm.provider :aws do |aws| aws.instance_type = "m1.small" end end
  109. gareth rushgrove | morethanseven.net Choose your own provider $ vagrant

    up --provider=virtualbox
  110. gareth rushgrove | morethanseven.net Switch your provider $ vagrant up

    --provider=ec2
  111. Solution 4 Software defined networks http://www.flickr.com/photos/uk_parliament/2700327415

  112. gareth rushgrove | morethanseven.net Ruby DSL require 'rubygems' require 'nat'

    nat do snat :interface => "Client Data", :original => { :ip => "10.0.0.0/xx" }, :translated => { :ip => "xx.xx.xx.xx" }, :desc => "Outbound internet traffic" dnat :interface => "Client Data", :original => { :ip => "xx.xx.xx.xx", :port => 22 }, :translated => { :ip => "10.0.0.xx", :port => 22 }, :desc => "jumpbox-1 SSH" dnat :interface => "Client Data", :original => { :ip => "xx.xx.xx.xx", :port => 80 },, :translated => { :ip => "10.0.0.xx", :port => 80 }, :desc => "jenkins, logging, monitoring HTTP"
  113. require 'rubygems' require 'firewall' firewall do # internal rules rule

    "ssh access to jumpbox1" do source :ip => "Any" destination :ip => "xx.xx.xx.xx", :port => 22 end rule "http to backend applications" do source :ip => "Any" destination :ip => "xx.xx.xx.xx", :port => 80 end rule "https to backend applications" do gareth rushgrove | morethanseven.net Including Firewall and Loadbalancer
  114. http://www.flickr.com/photos/iancarroll/5027441664 Conclusions if all you remember is

  115. http://www.flickr.com/photos/kevharb/5314268567 gareth rushgrove | morethanseven.net Solve the problem for the

    complex case
  116. gareth rushgrove | morethanseven.net Focus on capabilities over APIs http://www.flickr.com/photos/sprengben/5136170057

  117. The End

  118. gareth rushgrove | morethanseven.net Thanks for the photos

  119. Questions? gareth rushgrove | morethanseven.net http://flickr.com/photos/psd/102332391/

  120. QCon session code gareth rushgrove | morethanseven.net 4172
