Containers from Scratch: what are they made from?

Talk from Docker meetup Jakarta on June 2018. Presented and demonstrated various Linux kernel features that enable container runtime, i.e. chroot, namespaces, cgroups, capabilities.

Transcript

1. Containers from Scratch: what are they made from? GIRI KUNCORO
2. Giri Kuncoro Senior System Engineer @GO-PAY Core Infrastructure github.com/girikuncoro
3. Build Your Own Smartphone http://www.instructables.com/id/Build-Your-Own-Smartphone
4. Raspberry Pi A+ 256 MB Adafruit FONA - Mini GSM Breakout GSM Antenna Electret Microphone 1200 mAh Lithium Ion Battery Ingredients
5. Today Build a container without a container runtime, i.e. Docker, lxc, rkt
6. Ingredient #1: Container Image TL;DR: nothing but tarball • Application metadata • Filesystem
7. Ingredient #1: Container Image Container filesystem: looks like an OS; but no kernel, no init system
8. Ingredient #1: Container Image Build root: http://www.buildroot.org/ Debootstrap: https://wiki.debian.org/Debootstrap YUM / DNF Gentoo: https://www.gentoo.org/downloads/ Buildah: https://github.com/projectatomic/buildah
9. $ mkdir rootfs $ sudo dnf -y \ --installroot=$PWD/rootfs \ --releasever=24 install \ @development-tools \ procps-ng \ python3 \ which \ iproute \ net-tools $ ls rootfs
10. Ingredient #2: chroot Execute a process in our container filesystem chroot(2): http://man7.org/linux/man-pages/man2/chroot.2.html
11. $ sudo chroot rootfs /bin/bash
12. Ingredient #3: namespaces Limit the “view” of a container: Process namespace (pid) Network namespace (net) Mount namespace (mnt) https://en.wikipedia.org/wiki/Linux_namespaces
13. Ingredient #3: namespaces chroot of other systems: clone(2): http://man7.org/linux/man-pages/man2/clone.2.html unshare(2): http://man7.org/linux/man-pages/man2/unshare.2.html Process trees Network interfaces Mount volumes
14. $ sudo unshare -p -f \ --mount-proc=$PWD/rootfs/proc \ chroot rootfs /bin/bash
15. Ingredient #4: enter namespaces Namespaces are composable Example: Kubernetes pod setns(2): http://man7.org/linux/man-pages/man2/setns.2.html k8s pod di r p o s , di r c o t sa t o k, sa un
16. # PID=321 # ls /proc/$PID/ns cgroup ipc mnt net pid user uts # nsenter \ --pid=/proc/$PID/ns/pid \ --mnt=/proc/$PID/ns/mnt \ chroot $PWD/rootfs /bin/bash
17. Ingredient #5: volume mounts Inject files into our chroot $ docker run -d \ --name=nginxtest \ -v nginx-vol:/usr/share/nginx/html \ nginx:latest
18. apiVersion: v1 kind: Pod metadata: name: test-pd spec: containers: - image: k8s.gcr.io/test-webserver name: test-container volumeMounts: - mountPath: /test-pd name: test-volume volumes: - name: test-volume hostPath: path: /data
19. # nsenter --mount=/proc/$PID/ns/mnt \ mount --bind -o ro \ $PWD/readonlyfiles \ $PWD/rootfs/var/readonlyfiles
20. Ingredient #6: cgroups Restrict resources for processes
21. # ls /sys/fs/cgroup # mkdir /sys/fs/cgroup/memory/demo # echo $$ > /sys/fs/cgroup/memory/demo/tasks # cat /proc/self/cgroup
22. # CGROUP=/sys/fs/cgroup/memory/demo # echo “100000000” > $CGROUP/memory.limit_in_bytes # echo “0” > $CGROUP/memory.swappiness # python3 hungry.py
23. Ingredient #7: cgroup namespace Q: How do you restrict a process from reassigning cgroup? A: More namespaces!
24. # unshare -C # cat /proc/self/cgroup
25. # (how to remove cgroups: reassign) # echo $$ > /sys/fs/cgroup/memory/tasks # rmdir /sys/fs/cgroup/memory/demo
26. Ingredient #8: capabilities “Docker is about running random code downloaded from Internet and running it as root” - Dan Walsh (Red Hat)
27. Ingredient #8: capabilities SELinux, seccomp, AppArmor should’ve been covered Show Linux capabilities instead http://man7.org/linux/man-pages/man7/capabilities.7.html
28. $ go build -o /tmp/listen listen.go $ sudo setcap cap_net_bind_service=+ep \ /tmp/listen $ getcap /tmp/listen
29. $ sudo capsh --print $ sudo capsh --drop=cap_chown --
30. Ingredient #9: network namespace Huge topic, will do simple demo for now For the impatient, probably next talk: https://github.com/girikuncoro/netns-demo
31. $ sudo unshare -n chroot rootfs # ip addr # ip link set dev lo up
32. $ sudo ip link add veth0 type veth peer name veth1 $ sudo ip link set veth1 netns $PID $ sudo ip address add 10.1.1.2/24 dev veth0 $ sudo ip link set dev veth0 up # (inside namespace) # ip address add 10.1.1.3/24 dev veth1 # ip link set dev veth1 up
33. Conclusion Containers are a combination between Linux kernel features Docker, rkt, lxc (container runtime) are just opinionated wrapper around these
34. References Containers from scratch, Eric Chiang https://ericchiang.github.io/post/containers-from-scratch/ Building minimal containers, Brian Redbeard https://github.com/brianredbeard/minimal_containers Namespaces in operation, Michael Kerrisk https://lwn.net/Articles/531114/ cgroups v1, Paul Menage https://www.kernel.org/doc/Documentation/cgroup-v1/cgroups.txt Bocker, Docker implemented in 100 lines of bash https://github.com/p8952/bocker
35. Thanks! giri.kuncoro@go-jek.com twitter.com/girikuncoro github.com/girikuncoro Our team is hiring, come talk to us or open www.go-jek.com/careers
