Event Driven Machine Learning

2d2dbdf5d060b4c1bb238f8f59185cfb?s=47 Giulia
April 28, 2020

Event Driven Machine Learning

2d2dbdf5d060b4c1bb238f8f59185cfb?s=128

Giulia

April 28, 2020
Tweet

Transcript

  1. @Giuliabianchl @Loicmdivad Event-Driven Machine Learning

  2. @Giuliabianchl @Loicmdivad Giulia Bianchi Loïc Divad Data Scientist @PubSapientEng @Giuliabianchl

    Software Engineer @PubSapientEng @Loicmdivad
  3. @Giuliabianchl @Loicmdivad

  4. @Giuliabianchl @Loicmdivad Real time prediction pipeline

  5. @Loicmdivad @Giuliabianchl

  6. @Giuliabianchl @Loicmdivad Data Scientist @PubSapientEng Data Lover & Community Contributor

    Co-Founder and Organizer of @DataXDay Machine Learning with Spark at PS Engineering Training @Giuliabianchl Giulia Bianchi
  7. @Loicmdivad @Giuliabianchl Data science 101

  8. @Giuliabianchl @Loicmdivad Batch inference 1 Historical data about taxi trips

    2 Train a model to obtain a trained model 3 Use trained model to make batch predictions
  9. @Giuliabianchl @Loicmdivad Trip duration estimation Given current location and destination

    estimate trip duration • New data comes in each time someone orders a taxi ◦ NOT IN BATCHES • Continuous predictions
  10. @Giuliabianchl @Loicmdivad Continuous inference Given current location and destination estimate

    trip duration • New data comes in each time someone orders a taxi ◦ NOT IN BATCHES • Continuous predictions 3 Use trained model to make 1 prediction Use trained model to make 1 prediction Use trained model to make 1 prediction
  11. @Giuliabianchl @Loicmdivad Hello data engineer, I could use some help

    • How to build the pipeline? • What is a possible technical solution? • What is the impact on my machine learning routine? Streaming is the new batch
  12. @Loicmdivad @Giuliabianchl ML powered by Event Stream Apps

  13. @Giuliabianchl @Loicmdivad Software Engineer @PubSapientEng Confluent Community Catalyst Scala Developer

    and Apache Kafka Lover Co-Founder and Organizer of @DataXDay Spark and Kafka Streams trainer at PS Engineering Training @Loicmdivad Loïc Divad
  14. @Giuliabianchl @Loicmdivad The rise of event stream applications • Break

    silos • Power faster decisions • Have reactive properties • Reduce point to point connections • Support both batch and stream paradigms Centralized Event Log
  15. @Giuliabianchl @Loicmdivad The rise of event stream applications • Break

    silos • Power faster decisions • Have reactive properties • Reduce point to point connections • Support both batch and stream paradigms Centralized Event Log
  16. @Giuliabianchl @Loicmdivad The rise of event stream applications • Break

    silos • Power faster decisions • Have reactive properties • Reduce point to point connections • Support both batch and stream paradigms Centralized Event Log
  17. What if, your model was an event stream app? •

    First access point to data • No intermediate storage layer • No intermediate processing • Faster feedbacks • Performance over time may trigger other events Kafka Streams application TensorFlow MODEL Kafka TOPICS
  18. What if, your model was an event stream app? •

    First access point to data • No intermediate storage layer • No intermediate processing • Faster feedbacks • Performance over time may trigger other events Kafka Streams application TensorFlow MODEL Kafka TOPICS
  19. Constraints • We have to: ◦ Reduce synchronous calls ◦

    Reduce manual actions ◦ Avoid code duplication • The problem is supervised ◦ and we get the actual durations continuously • Events come from Kafka Topics
  20. @Loicmdivad @Giuliabianchl Working Environment

  21. @Giuliabianchl @Loicmdivad Project structure • Unified maven project • Separate

    submodules for each Kafka Streams application • Plugin and virtual env are used to create python modules for the ml part • The Infrastructure is specified in separate projects . ├── pom.xml │ ├── edml-scoring │ └── src │ ├── edml-serving │ └── src │ └── edml-trainer ├── requirements.txt └── setup.py . └── tf-aiplatform-edml . └── tf-apps-edml
  22. @Giuliabianchl @Loicmdivad Kafka as a Service Kafka Streams GKE Working

    Environment
  23. @Giuliabianchl @Loicmdivad Replay, an integration data stream PICKUPS-2018-11-28 PICKUPS-REPLAY

  24. @Giuliabianchl @Loicmdivad Replay, an integration data stream PICKUPS-2019-11-28 PICKUPS-REPLAY KSQL

    Queries on Confluent Cloud
  25. @Giuliabianchl @Loicmdivad Kafka as a Service Kafka Streams GKE Working

    Environment
  26. @Giuliabianchl @Loicmdivad Kafka as a Service Kafka Streams GKE Kafka

    Connect GCE Google BigQuery Working Environment
  27. @Giuliabianchl @Loicmdivad Kafka as a Service Control Center Kafka Streams

    GKE Google BigQuery KSQL Servers GCE Kafka Connect GCE Working Environment
  28. @Giuliabianchl @Loicmdivad Kafka as a Service Kafka Streams GKE Google

    BigQuery Kafka Connect KSQL Server Working Environment
  29. @Giuliabianchl @Loicmdivad Kafka as a Service Kafka Streams GKE Google

    BigQuery Gitlab CI ✔ Kafka Connect KSQL Server Working Environment
  30. @Giuliabianchl @Loicmdivad Kafka as a Service Kafka Streams GKE Google

    BigQuery Gitlab CI ✔ AI Platform Kafka Connect KSQL Server Working Environment
  31. @Loicmdivad @Giuliabianchl The model

  32. @Giuliabianchl @Loicmdivad Available data NYC opendata 2017, 2018, 2019 Pick-up

    Location Pick-up Datetime Drop-off Location Drop-off Datetime Trip Duration Passenger Count Trip Distance (approx.)
  33. @Giuliabianchl @Loicmdivad New York City Geography - Distance estimation NYC

    Open data Taxi Zones • Geography type • Manipulation via Big Query GIS • Simple geography functions SELECT ST_DISTANCE( ST_CENTROID(pickup_zone_geom), ST_CENTROID(dropoff_zone_geom) ) AS distance FROM <table>;
  34. @Giuliabianchl @Loicmdivad Wide features Sparse features for linear model •

    One hot encoded features ◦ pick-up day of week ◦ pick-up hour of day ◦ pick-up day of year ✖pick-up hour of day ◦ pick-up zone ◦ drop-off zone ◦ pick-up zone ✖drop-off zone Pick-up Location Pick-up Datetime Drop-off Location Passenger Count Trip distance Approximation
  35. @Giuliabianchl @Loicmdivad Deep features Dense features for deep neural network

    • Embedded Features ◦ pick-up day of year ◦ pick-up hour of day ◦ pick-up zone ◦ drop-off zone ◦ passenger count ◦ approximated distance Pick-up Location Pick-up Datetime Drop-off Location Passenger Count Trip distance approximation
  36. @Giuliabianchl @Loicmdivad Wide & Deep learning Categorical variables with many

    distinct values • Two strategies combined ◦ one hot encoding → sparse features → linear model ◦ embedding → dense features → deep neural network • TensorFlow Estimator API
  37. @Loicmdivad @Giuliabianchl Job Submission

  38. @Giuliabianchl @Loicmdivad Code organisation to run in GCP • 217M

    data points • AI Platform ◦ notebooks for exploring, building and testing the solution locally ◦ remote training and prediction ◦ hyperparameter tuning ◦ model deployment • Code must be organised and packaged properly $ tree edml-trainer/ . ├── setup.py └── trainer ├── __init__.py ├── model.py ├── task.py └── util.py
  39. @Giuliabianchl @Loicmdivad Code organization to run in GCP # task.py

    [page 1] from . import model def parse_arguments(): parser = argparse.ArgumentParser() # Input Arguments for ai-platfrom parser.add_argument( '--bucket', help='GCS path to project bucket', required=True )... # Input arguments for modeling parser.add_argument( '--batch-size', type=int, default=128 )... return args() # task.py [page 2] def train_and_evaluate(args): estimator, train_spec, eval_spec = model.my_estimator(...) tf.estimator.train_and_evaluate(...) if __name__ == '__main__': args = parse_arguments() train_and_evaluate(args)
  40. @Giuliabianchl @Loicmdivad Code organization to run in GCP # util.py

    [page 1] import tensorflow as tf from tensorflow_io.bigquery import BigQueryClient # Read input data def read_dataset(...): def _input_fn(): client = BigQueryClient() ... return _input_fn() # Feature engineering def get_wide_deep(...): ... wide = [ # Sparse columns fc_dayofweek, fc_hourofday, fc_weekofyear, fc_pickuploc, fc_dropoffloc] ... # util.py [page 2] deep = [ # Dense columns fn_passenger_count, fn_distance, fc_embed_dayofweek, fc_embed_hourofday, fc_embed_weekofyear, fc_embed_pickuploc, fc_embed_dropoffloc] return wide, deep # Serving input receiver function def serving_input_receiver_fn(): receiver_tensors = { ... } return tf.estimator.export.ServingInputReceiver(features, receiver_tensors)
  41. @Giuliabianchl @Loicmdivad Code organization to run in GCP # model.py

    [page 1] import tensorflow as tf from . import util def my_estimator(...): ... # Feature engineering wide, deep = util.get_wide_deep(...) # Estimator definition estimator = tf.estimator.DNNLinearCombinedRegressor( model_dir=output_dir, linear_feature_columns=wide, dnn_feature_columns=deep, dnn_hidden_units=nnsize, batch_norm=True, dnn_dropout=0.1, config=run_config) # model.py [page 2] train_spec = tf.estimator.TrainSpec( input_fn=util.read_dataset(...), ...) exporter = tf.estimator.LatestExporter('exporter', serving_input_receiver_fn=util.serving_input_receiv er_fn) eval_spec = tf.estimator.EvalSpec( input_fn=util.read_dataset(...), ..., exporter=exporter) return estimator, train_spec, eval_spec
  42. @Giuliabianchl @Loicmdivad #!/usr/bin/env bash BUCKET=edml TRAINER_PACKAGE_PATH=gs://$BUCKET/data/taxi-trips/sources MAIN_TRAINER_MODULE="trainer.task" ... OUTDIR=gs://$BUCKET/ai-platform/models/$VERSION gcloud

    ai-platform jobs submit training $JOB_NAME \ --job-dir $JOB_DIR \ --package-path $TRAINER_PACKAGE_PATH \ --module-name $MAIN_TRAINER_MODULE \ --region $REGION \ -- \ --batch-size=$BATCH_SIZE \ --output-dir=$OUTDIR \ --train-steps=2800000 \ --eval-steps=3 Code organization to run in GCP Variable definition gcloud specific flags user arguments for specific application
  43. @Giuliabianchl @Loicmdivad AI Platform job interface

  44. @Loicmdivad @Giuliabianchl Development Workflow

  45. @Giuliabianchl @Loicmdivad KAFKA STREAMS APPS PODS KUBE MASTER Streaming apps

    deployment • Kafka Streams apps are containerized • They use GKE StatefulSets • No rolling upgrades • No embedded model
  46. @Giuliabianchl @Loicmdivad • Kafka Streams apps are containerized • They

    use GKE StatefulSets • No rolling upgrades • No embedded model Streaming apps deployment // pom.xml <groupId>com.spotify</groupId> <artifactId>zoltar-api (+ zoltar-tensorflow)</artifactId> // Processor.scala import org.tensorflow._ val model: TensorFlowModel = TensorFlowLoader .create("gs://edml/path/to/model/...", ???) .get(10 seconds) model.instance().session() // org.tensorflow.Session KAFKA STREAMS APPS PODS KUBE MASTER
  47. The SavedModel Format from TF • Both graph and variables

    are needed to rebuild the model at prediction time • Graph serialization is not enough and will resolve in: ◦ Not found: Resource … variable was uninitialized • Proposal: ◦ The model metadata (e.g. inputs, GCS path) can be sent in a topic $ tree my_model/ . ├── saved_model.pb └── variables ├── variables.data-00000-of-00002 ├── variables.data-00001-of-00002 └── variables.index
  48. @Giuliabianchl @Loicmdivad A model producer… for automation! # ModelPublisher.scala val

    topic: String = "<model.topic>" val version: String = "<model.version>" val model: String = "gs://.../<model.version>" val producer = new KafkaProducer[_, TFSavedModel](... val key = ModelKey("<app.name>") val value = // … producer.send(topic, key, value) producer.flush()
  49. @Giuliabianchl @Loicmdivad A model producer… for automation! # ModelPublisher.scala val

    topic: String = "<model.topic>" val version: String = "<model.version>" val model: String = "gs://.../<model.version>" val producer = new KafkaProducer[_, TFSavedModel](... val key = ModelKey("<app.name>") val value = /* { version: … output: { name:…, type:… } features: [ input1: { name:…, type:… }, input2: { name:…, type:… } ] } */ producer.send(topic, key, value) producer.flush()
  50. @Giuliabianchl @Loicmdivad 2 input streams • We consider 2 data

    streams ◦ Input records to predict ◦ Model updates • The model description gets broadcasted on every instances of the same app ◦ they all separately load the model graph from GCS • Deserialized model Graph lives in memory • Input record gets skipped if no model is present APP CI DEPLOY STAGE MoDEL TOPIC NEW RECORDS PREDICTIONS
  51. @Giuliabianchl @Loicmdivad Model serving architecture by Boris Lublinsky - from

    Serving Machine Learning Models
  52. @Giuliabianchl @Loicmdivad Model serving architecture … our implementation Data Source

    Model Source Model Storage Current Model Processing Prediction Stream Processor RocksDB Key-Value Store
  53. @Giuliabianchl @Loicmdivad Continuous integration TEST ► ► PACKAGE TRAIN DEPLOY

    MODEL 0.1.0-<dt>-<sha1> 0.1.0-<dt>-<sha1>-<N> 0.1.0-<dt>-<sha1> {"metadata":"..."} DEPLOY KAFKA STREAMS APP
  54. @Giuliabianchl @Loicmdivad Continuous integration TEST ► ► PACKAGE TRAIN 0.1.0-<dt>-<sha1>

    0.1.0-<dt>-<sha1> {"metadata":"..."} DEPLOY KAFKA STREAMS APP Click to deploy
  55. @Loicmdivad @Giuliabianchl Model performance

  56. @Giuliabianchl @Loicmdivad TensorBoard AI Platform

  57. @Giuliabianchl @Loicmdivad TensorBoard AI Platform

  58. @Giuliabianchl @Loicmdivad Kafka Connect

  59. @Giuliabianchl @Loicmdivad Real time cost function PICKUP REPLAY SERVING SCORING

    DROPOFF REPLAY
  60. @Loicmdivad @Giuliabianchl Conclusion

  61. @Giuliabianchl @Loicmdivad Conclusion From exploration to packaged code fairly easy

    The TF graph is the interface between data scientist and data engineer Standardisation of the Model serialisation and event production "Success of Model training" is an event Model size can be an issue Transition to TF 2.0 & Java compatibility Preprocessing and dataprep is not covered
  62. @Giuliabianchl @Loicmdivad MERCI

  63. @Giuliabianchl @Loicmdivad QUESTIONS?

  64. @Giuliabianchl @Loicmdivad PICTURES • Photo by Dimon Blr on Unsplash

    • Photo by Miryam León on Unsplash • Photo by Negative Space from Pexels • Photo by Gerrie van der Walt on Unsplash • Photo by Todd DeSantis on Unsplash • Photo by Rock'n Roll Monkey on Unsplash • Photo by Denys Nevozhai on Unsplash • Photo by Denys Nevozhai on Unsplash
