Event Driven Machine Learning

30 minute long presentation given at https://xebicon.fr/.
Presented in French.

Le serving de modèle de Machine Learning pour la prédiction en temps réel présente des défis tant en Data Engineering qu’en Data Science. Comment construire un pipeline moderne qui permet de réaliser des prédictions en continue ? Dans le cas d’un exercice supervisé, comment allier tracing et tracking des performances ?

Transcript

1. A real time ML pipeline proposal
3. Giulia Bianchi Loïc Divad Data Scientist @Xebia France @Giuliabianchl Software Engineer @Xebia France @Loicmdivad 3
4. G.Lo Taxi & Co. 4
5. G.Lo Taxi & Co. 5
6. Data Lover & Community Contributor Giulia Bianchi 6
7. G.Lo App 7 • ◦ ◦ ◦ ◦ • ◦ ◦ ◦ ◦ Given current location and destination estimate trip duration
8. Data Science 101 8
9. Batch inference 9 1 Historical data about taxi trips 2 Train a model to obtain a trained model 3 Use trained model to make batch predictions
10. Trip duration estimation at G.Lo taxi & Co. 10 • ◦ •
11. Continuous inference 11 • ◦ • 3 Use trained model to make 1 prediction Use trained model to make 1 prediction Use trained model to make 1 prediction
12. Streaming is the new batch 12 • • •
13. > println(sommaire) • • • • • • • 13
14. ML powered by Event Stream Apps 14
15. Apache Kafka Lover Loïc Divad 15
16. • • • • • The rise of event stream applications 16 Centralized Event Log
17. • • • • • The rise of event stream applications 17 Centralized Event Log
18. • • • • • The rise of event stream applications 18 Centralized Event Log
19. DISCLAIMER 19
20. The Challenge Constraints • ◦ • • • ◦ ◦ 20
21. 22 • • • • • Kafka Streams application TensorFlow MODEL Kafka TOPICS What if, your model was an event stream app?
22. Working Environment 23
23. Project structure 24 • • • • . ├── build.gradle ├── edml-schema │ ├── build.gradle │ └── src ├── edml-scoring │ ├── build.gradle │ └── src ├── edml-serving │ ├── build │ ├── build.gradle │ └── src ├── edml-trainer │ ├── build.gradle │ └── setup.py └── terraform ├── ... └── ...
24. 25 Working Environment GKE Kafka Streams Apps Kafka as a Service
25. Replay, an integration data stream 26 PICKUPS-2018-11-28 PICKUPS-REPLAY
26. 31 AI Platform BigQuery Gitlab CI GKE Kafka Streams Apps GCE Kafka Connect Instances GCE KSQL Servers Kafka as a Service Control Center Working Environment
27. The model 32
28. Available data 33 Pick-up Location Pick-up Datetime Drop-off Location Drop-off Datetime Trip Duration Passenger Count Trip Distance Total Amount Tips
29. 34 New York City zones
30. Wide features • ◦ day of week ◦ hour of day ◦ pick-up zone ◦ drop-off zone 35
31. Deep features • ◦ day of year ◦ hour of day ◦ pick-up zone ◦ drop-off Zone ◦ passenger count 36
32. Wide and Deep Learning • • ◦ → → ◦ → → • 37
33. Code organisation to run in GCP • • ◦ ◦ ◦ ◦ • 38 $ edml-trainer/ . ├── setup.py └── trainer ├── __init__.py ├── model.py └── task.py
34. Code organisation to run in GCP 39 # task.py [page 1] from . import model if __name__ == '__main__': parser = argparse.ArgumentParser() # Input Arguments for ai-platfrom parser.add_argument( '--bucket', help='GCS path to project bucket', required=True ) .... # Input arguments for modeling parser.add_argument( '--batch-size', type=int, default=512 ) # task.py [page 2] parser.add_argument( '--output-dir', help='GCS location to write checkpoints and export models', required=True ) .... # assign arguments to model variables output_dir = arguments.pop('output_dir') model.BUCKET = arguments.pop('bucket') model.BATCH_SIZE = arguments.pop('batch_size') .... # Run the training job model.train_and_evaluate(output_dir)
35. Code organisation to run in GCP 40 # model.py [page 1] import tensorflow as tf BATCH_SIZE = 512 ... CSV_COLUMNS = [...] LABEL_COLUMN = "trip_duration" KEY_COLUMN = "uuid" def read_dataset(...): def _input_fn(): ... return _input_fn() # Feature engineering def get_wide_deep(): ... return wide, deep # model.py [page 2] # Serving input receiver function def serving_input_receiver_fn(): receiver_tensors = { ... } return tf.estimator.export.ServingInputReceiver(features, receiver_tensors) # Model training and evaluation def train_and_evaluate(output_dir): ... estimator = tf.estimator.DNNLinearCombinedRegressor(...) ... tf.estimator.train_and_evaluate(estimator, train_spec, eval_spec)
36. Code organisation to run in GCP #!/usr/bin/env bash BUCKET=edml TRAINER_PACKAGE_PATH=gs://$BUCKET/data/taxi-trips/sources MAIN_TRAINER_MODULE="trainer.task" ... OUTDIR=gs://$BUCKET/ai-platform/models/$VERSION gcloud ai-platform jobs submit training $JOB_NAME \ --job-dir $JOB_DIR \ --package-path $TRAINER_PACKAGE_PATH \ --module-name $MAIN_TRAINER_MODULE \ --region $REGION \ -- \ --batch-size=$BATCH_SIZE \ --output-dir=$OUTDIR \ --pattern="*" \ --train-examples=174000 \ --eval-steps=1 41 gcloud
37. Development Workflow 42
38. Streaming apps deployment 44 • • • • KAFKA STREAMS APPS PODS KUBE MASTER // build.gradle compile group: 'org.tensorflow', name: 'proto', version: '1.15.0' compile group: 'org.tensorflow', name: 'tensorflow', version: '1.15.0' // Processor.scala import org.tensorflow._ val graphDef: GraphDef = GraphDef.parseFrom(Array.empty[Byte]) val graph = new Graph() graph.importGraphDef(graphDef.toByteArray) val session = new Session(graph)
39. 45 The SavedModel Format from TF • • Graph ◦ Not found: Resource … variable was uninitialized • ◦ ◦ Serde $ tree my_model/ . ├── saved_model.pb └── variables ├── variables.data-00000-of-00002 ├── variables.data-00001-of-00002 └── variables.index
40. A model producer… for automation! 46 # ModelPublisher.scala val topic: String = "<model.topic>" val version: String = "<model.version>" val model: String = "gs://.../<model.version>" //… val producer = new KafkaProducer[_, TFSavedModel](... val key = ModelKey("<app.name>") val value = TFSavedModel(… //… producer.send(topic, key, value) producer.flush()
41. 2 input streams 47 APP CI DEPLOY STAGE MoDEL TOPIC NEW RECORDS PREDICTIONS • ◦ ◦ • • ◦ compact •
43. 49 Data Source Model Source Model Storage Current Model Processing Prediction Stream Processor RocksDB Key-Value Store
44. TEST Continuous integration 50 ► ► PACKAGE TRAIN DEPLOY MODEL 0.1.0-<dt>-<sha1> 0.1.0-<dt>-<sha1>-<N> 0.1.0-<dt>-<sha1> {"metadata":"..."} DEPLOY KAFKA STREAMS APP
45. Scoring and Post Prediction 51
46. TensorBoard 53
49. Conclusion • • • • • • • How to face a drop in the performance over time? 56
50. MERCI 57
51. PICTURES 58 Photo by Daniel Jensen on Unsplash Photo by Dimon Blr on Unsplash Photo by Lerone Pieters on Unsplash Photo by Miryam León on Unsplash Photo by Matthew Hamilton on Unsplash Photo by Luke Stackpoole on Unsplash Photo by Gustavo on Unsplash Photo by Negative Space from Pexels Photo by Gerrie van der Walt on Unsplash Photo by Eepeng Cheong on Unsplash Photo by Rock'n Roll Monkey on Unsplash Photo by chuttersnap on Unsplash Photo by Denys Nevozhai on Unsplash Photo by Mike Tsitas on Unsplash
52. ANNEX 59
53. Is this really a 1 month challenge? 60 Total cost: 302.82€
54. 61 Team Work!
55. Training Job Manual Submission 62
57. A world of containers 64
58. Cloud is just someone else's computer 65
59. Data prep before TensorFlow, thank you Big Query 66
60. Schemas Are Service APIs For Event Streaming 67
