NgRx Refactoring Patterns enhanced with ngrx-ducks

In this talk, you will learn about the following mechanisms to improve the maintainability of your Redux Store.

- Property Pattern
- createReducer Factory
- @ngrx/entity
- @ngrx/router-store
- ngrx-data
- ngrx-ducks (sneak peak)

Transcript

1. Redux Refactoring Patterns
   @GregOnNet
   co-IT.eu GmbH
   We Empower Outstanding Business Solutions
   +


   View Slide

2. MY FRIEND OSCAR
   Meet Oscar
   1. My Colleage
   2. He works with
   3. Passionated about Software Development


   View Slide

3. MY FRIEND OSCAR
   Meet Oscar
   1. …He is not an early morning person.


   View Slide

4. Your Code Should
   Always
   Feel
   Like
   Home.


   View Slide

5. @GregOnNet
   Gregor Woiwode
   CTO


   View Slide

6. co-IT.eu GmbH
   We Empower Outstanding Business Solutions
   “ Collect your questions for the Q&A session, please.
   @GregOnNet


   View Slide

7. AGENDA
   Our Review With Oscar
   1. Property Pattern
   2. @ngrx/entity
   3. @ngrx/router-store
   4. selectors
   5. ngrx-data
   6.???


   View Slide

8. REDUX ARCHITECTURE
   Recap
   ACTION
   STATE
   COMPONENT STORE
   Dispatch
   Send To
   Mutate
   Render
   Inspired by @ToddMotto
   REDUCERS


   View Slide

9. export function reducer(state = initialState, action: NotesActions): State {
   switch (action.type) {
   case NotesActionTypes.CreateNoteSuccess: {
   return {
   ...state,
   notes: [...state.notes, action.payload],
   loaded: true,
   loading: false
   }
   }
   case NotesActionTypes.LoadNotesSuccess: {
   return {
   ...state,
   notes: ...action.payload,
   loaded: true,
   loading: false
   }
   /* ... */
   Redundant Code


   View Slide

10. export function reducer(state = initialState, action: NotesActions): State {
    switch (action.type) {
    case NotesActionTypes.CreateNoteSuccess: {
    return {
    ...state,
    notes: [...state.notes, action.payload],
    loaded: true,
    loading: false
    }
    }
    case NotesActionTypes.LoadNotesSuccess: {
    return {
    ...state,
    notes: ...action.payload,
    loaded: true,
    loading: false
    }
    /* ... */
    Redundant Code


    View Slide

11. /* ... */
    case NotesActionTypes.LoadAdditionalNotesSuccess: {
    return {
    ...state,
    notes: [...state.notes, ...action.payload],
    loaded: true,
    loading: false
    }
    }
    case NotesActionTypes.DeleteSingleNoteSuccess: {
    return {
    ...state,
    notes: state.notes.filter(note => note.guid !== action.payload.guid),
    loaded: true,
    loading: false
    }
    }
    /* ... */
    Remove By Filtering


    View Slide

12. OSCAR‘S PROBLEM
    Large Switch-Case-Statements
    1. Lot‘s of list operations we may not need every time
    2. Hard to maintain
    3. Less readable


    View Slide

13. Property Pattern
    SIMPLIFY STATE MUTATIONS


    View Slide

14. PROPERTY PATTERN
    Convert Collections To Dictionaries
    export interface State {
    notes: Note[];
    }
    export interface State {
    notes: { [key: string]: Note };
    }
    List to Object


    View Slide

15. PROPERTY PATTERN
    Delete Single Object
    return {
    ...state,
    notes: state.notes.filter(note =>
    note.guid !== action.payload.guid
    )
    }
    const {
    [action.payload.guid]: deleted,
    ...withoutDeleted
    } = state.notes;
    return {
    ...state,
    notes: withoutDeleted,
    }


    View Slide

16. MY FRIEND OSCAR
    Oscar asks…
    Maybe accessing data is more efficient.
    But the code complexity has increased.
    How can we benefit from this approach?


    View Slide

17. PROPERTY PATTERN
    Review
    Less Collection Operations
    More Performant Operations
    Less Readable Code


    View Slide

18. @ngrx/entity
    SIMPLIFY REDUCERS


    View Slide

19. @ngrx/entity
    Entity State
    export interface State extends EntityState {}
    export interface State {
    ids: string[];
    entities: { [id: string]: T };
    }
    Leverages
    Property
    Pattern


    View Slide

20. @ngrx/entity
    Entity Adapter
    import { createEntityAdapter } from '@ngrx/entity';
    const adapter = createEntityAdapter();
    The mighty helper


    View Slide

21. @ngrx/entity
    Entity Mutators
    Operations
    for single
    objects and
    collections


    View Slide

22. @ngrx/entity
    Simplify Mutations
    return adapter.removeOne(
    action.payload,
    state
    );
    const {
    [action.payload.guid]: deleted,
    ...withoutDeleted
    } = state.notes;
    return {
    ...state,
    notes: withoutDeleted,
    }
    1. Enusres Immutability
    2. Applies State Mutation


    View Slide

23. @ngrx/entity
    Entity Selectors
    const adapter = createEntityAdapter();
    export const {
    selectAll,
    selectEntities,
    selectIds,
    selectTotal
    } = adapter.getSelectors();


    View Slide

24. @ngrx/entity
    Use Entity Selectors
    export class NotesDashboardComponent {
    notes$: Observable;
    constructor(private store: Store) {
    this.notes$ = this.store.pipe(select(fromNotes.selectAll));
    }
    }


    View Slide

25. Demo
    ENTITY ADAPTER


    View Slide

26. PROPERTY PATTERN
    Review
    Less Code Duplication
    Reusable Mutators & Selectors


    View Slide

27. MY FRIEND OSCAR
    Oscar asks…
    @ngrx/entity is nice, thanks.
    Can we tidy up these Switch-Case-Statements now?


    View Slide

28. createReducer
    SIMPLIFY REDUCER INFRASTRUCTURE


    View Slide

29. CREATE REDUCER
    Switch-Case-Anatomy
    Infrastructure UI-Logic
    case: a
    case: b
    case: …


    View Slide

30. CREATE REDUCER
    Factory Pattern To The Rescue
    const mutators: ActionHandlers = {
    [NotesActionTypes.CreateNote]: notes.addOne,
    [NotesActionTypes.LoadNotesSuccessful]: notes.addMany
    };
    export function reducer(state = initialState, action) {
    return createReducer(mutators)(state, action);
    }
    Refer to last slide for the source


    View Slide

31. Demo
    REMOVE SWITCH-CASE-STATEMENTS


    View Slide

32. PROPERTY PATTERN
    Review
    Reduced Infrastructure Code
    Reducers do not need to be
    enhanced as Requirements
    change


    View Slide

33. MY FRIEND OSCAR
    Oscar asks…
    Small things can have a great impact to quality.
    But wait since you are here…


    View Slide

34. OSCAR‘S PROBLEM
    He thinks he breakse the Redux Pattern
    Shouldn’t the store be able to answer every question
    of a Component?


    View Slide

35. SINGLE SOURCE OF TRUTH
    How to deal with location state?
    /* ... */
    export class NoteDetailsComponent {
    note$: Observable;
    constructor(
    private route: ActivatedRoute,
    private store: Store) {
    this.note$ = this.route.params.pipe(
    switchMap(params => this.store.pipe(state =>
    state.notes.entities[params.guid])
    )
    );
    }
    }


    View Slide

36. @ngrx/router-store
    SIMPLIFY LOCATION STATE HANDLING


    View Slide

37. @ngrx/router-store
    Setup
    import { StoreRouterConnectingModule } from '@ngrx/router-store';
    @NgModule({
    imports: [
    /* ... */
    StoreRouterConnectingModule,
    ]
    /* ... */
    })
    export class AppModule {}


    View Slide

38. @ngrx/router-store
    Types & Reducer Come For Free
    import * as fromRouter from '@ngrx/router-store';
    export interface State {
    routerReducer: fromRouter.RouterReducerState;
    }
    export const reducers: ActionReducerMap = {
    routerReducer: fromRouter.routerReducer
    };


    View Slide

39. @ngrx/router-store
    Enhance The State Tree
    Store
    Notes
    Router State provided by
    @ngrx/router-store


    View Slide

40. @ngrx/router-store
    Access The Router State
    import { createFeatureSelector } from '@ngrx/store';
    export const getRouterState = createFeatureSelector('routerReducer');


    View Slide

41. @ngrx/router-store
    Read Router State
    export const currentDetails = createSelector(
    getEntities,
    getRouterState,
    (notes, router) => entities[router.state.params.guid]
    );
    RoutingComponent
    select


    View Slide

42. @ngrx/router-store
    The Reducer‘s Outcome
    Let’s traverse through the
    whole state tree!
    Of Cause Not!


    View Slide

43. Demo
    COMPRESS ROUTER STATE


    View Slide

44. PROPERTY PATTERN
    Review
    Store is Single Source of Truth again
    Reduced Complexity of Component
    Component does not rely on ActivatedRoute anymore


    View Slide

45. MY FRIEND OSCAR
    Oscar asks…
    This feels more correct than before, thanks.
    Wait! There is one very last thing…


    View Slide

46. OSCAR‘S PROBLEM
    I Can See A Revenent Pattern….
    We only do CRUD operations.
    Do we need to repeat ourselves for every entity?


    View Slide

47. “ I see reccurring patterns…


    View Slide

48. Looking for the
    right answer…


    View Slide

49. ngrx-data
    SIMPLIFY STORE USING CONVENTIONS


    View Slide

50. Know, Can
    Do…
    Put Your
    Know-How
    Into Action!


    View Slide

51. ngrx-data
    Overview
    Actions
    Reducers
    Effects
    Data Services
    Dynamically sets up…


    View Slide

52. Configure an entity
    export const entityMetadata: EntityMetadataMap = {
    Note: {
    selectId: (note: Note) => note.guid
    }
    };
    export const pluralNames = { Note: 'Notes' };
    ngrx-data


    View Slide

53. Setup Entity Cache
    ngrx-data
    NgrxDataModule.forRoot({
    entityMetadata,
    pluralNames
    }),


    View Slide

54. ngrx-data
    Data Services
    import { Note } from '../../models/note';
    @Injectable()
    export class NotesBoard extends EntityCollectionServiceBase {
    constructor(entityServiceFactory: EntityCollectionServiceFactory) {
    super('Note', entityServiceFactory);
    }
    }


    View Slide

55. Convention Based Data Services
    ngrx-data
    localhost:4200/api/notes/
    root
    entityName
    parameters


    View Slide

56. ngrx-data
    Built-In Functions Of A Data Service
    Mutators &
    Selectors for the
    given entity.


    View Slide

57. Demo
    CONFIGURE NGRX-DATA


    View Slide

58. ngrx-data
    Get Rid Of Unneeded Files
    Delete
    Delete
    Custom
    Configuration


    View Slide

59. PROPERTY PATTERN
    Review
    Less Files to maintain
    Scales good for many entities
    Highly Configurable
    Handles Loading State automatically
    High Learning Curve
    Lot‘s of things happen behind the scenes


    View Slide

60. ngrx-ducks
    Leverage OCP for Redux


    View Slide

61. NGRX
    Criticism
    Touch lots of files
    Boilerplate vs. Explicit Setup
    Distributed Setup
    (Actions, Reducers, Selectors, Effects)
    It is easy to forget parts of the setup
    (ActionType)
    High Learning Curve
    Lot‘s of things happen behind the scenes


    View Slide

62. NGRX
    Redux the bad parts
    REDUCER
    ACTION TYPES
    DISPATCHER
    ACTIONS
    EFFECT
    ACTION REDUCER MAP
    ACTIONS$
    ACTION CREATORS


    View Slide

63. NGRX
    Redux the good parts
    ACTIONS


    View Slide

64. Your Code Should
    Always
    Feel
    Like
    Home.


    View Slide

65. NGRX
    What if…
    1. … we could automate the creation of an action
    2. … an Action knows about it‘s case reducer
    3. … an Acion could dispatch itself
    4. … we have one object strucure providing us every thing we need?


    View Slide

66. NGRX
    Duck, Duck, Ducks, Re-Ducks


    View Slide

67. Demo
    INTRODUCING NGRX-DUCKS


    View Slide

68. PROPERTY PATTERN
    Review
    Consume Redux as a Service
    TypeScript Compiler saves us for
    mistakes
    Serves Open Closed Principle
    Supports AoT
    Supports AoT … `
    Setting up Dynamic Services is hard
    Could improve handling for Effects


    View Slide

69. co-IT.eu GmbH
    We Empower Outstanding Business Solutions
    Thank you!
    @GregOnNet
    e.co-it.eu/dwx18-gift
    e.co-it.eu/dwx18-ng


    View Slide

70. CREDITS
    Icons
    - from www.flaticon.com by Vectors Market
    - from www.flaticon.com by Freepik
    - from www.flaticon.com by Freepik


    View Slide
