Seattle NodeJS Intro to RackHD

Introducing RackHD - a hardware management and orchestration service layer written in NodeJS

Transcript

1. 1
   © Copyright 2016 EMC Corporation. All rights reserved.
   RACKHD
   INTRODUCTION – JAN 2016


   View Slide

2. 2
   © Copyright 2016 EMC Corporation. All rights reserved.
   Limited mechanisms to
   automate interactions with
   hardware
   •  PXE
   •  IPMI
   Existing software focused
   solely on provisioning
   HARDWARE MANAGEMENT
   Razor/Hanlon
   xCat
   DHCP TFTP HTTP
   …some software…


   View Slide

3. 3
   © Copyright 2016 EMC Corporation. All rights reserved.
   •  Software “tap roots”: some
   software very specific to
   firmware versions
   •  Upgrading some firmware
   requires rebooting in the
   process
   •  Want to be API driven, not
   another mandatory human
   touch-point
   PROBLEMS TO OVERCOME
   DHCP TFTP HTTP
   …some software…
   REST API
   Want to extend
   with vendor
   specific tooling
   Different tasks or goals
   mean different logic –
   embedding “know how”


   View Slide

4. 4
   © Copyright 2016 EMC Corporation. All rights reserved.
   •  Asynchronous; many things happening at once
   •  Possible to common remote failure or intermittent
   failure
   •  Multiple network protocols
   COMMON DISTRIBUTED SYSTEM PROBLEMS


   View Slide

5. 5
   © Copyright 2016 EMC Corporation. All rights reserved.
   •  Some background with javascript, none with Go
   •  Proved to ourselves we could get stuff done fast
   •  Prototypes worked fast and well
   But…
   WHY


   View Slide

6. 6
   © Copyright 2016 EMC Corporation. All rights reserved.
   •  We didn’t really grok how asynchronous JS was
   •  Inadvertent bloat
   –  Memory
   –  CPU
   •  Finding solid libraries
   •  Building and packaging
   •  “Dynamic ecosystem” and tooling change
   NOT WITHOUT CHALLENGES


   View Slide

7. 7
   © Copyright 2016 EMC Corporation. All rights reserved.
   •  Hardware Management and Orchestration
   •  Open Sourced by EMC Dec 2015
   •  Screencast Overview
   –  https://www.youtube.com/watch?v=cCiXtROSt8U
   HTTPS://GITHUB.COM/RACKHD/RACKHD
   HTTP://RACKHD.READTHEDOCS.ORG/


   View Slide

8. 8
   © Copyright 2016 EMC Corporation. All rights reserved.
   •  Vendor Agnostic
   •  Discovery, Cataloging, Telemetry
   •  Component in Larger Stack
   •  Hardware Configuration capabilities
   •  Automation of the lowest layer most stacks
   –  Provisioning
   –  Configuration
   –  Metrics and Events
   VISION


   View Slide

9. 9
   © Copyright 2016 EMC Corporation. All rights reserved.
   •  Stepping beyond
   existing provisioning
   systems
   –  Declarative Workflow
   engine
   –  Working closely with PXE
   capabilities
   –  Built to be a component
   in a larger stack up
   •  REST API
   •  Telemetry/Data Feeds
   •  It’s not a scheduler or
   reactive system
   •  Minimal “knowledge”
   layers above hardware
   WHAT IT IS AND ISN’T


   View Slide

10. 10
    © Copyright 2016 EMC Corporation. All rights reserved.
    •  iPXE oriented bootloader
    •  SKU identification based on rules
    •  PXE based compute server discovery
    process
    •  Free-format data catalogs
    •  Integral monitoring/telemetry with
    Out of band management
    •  Multiple Out-of-band management
    capabilities (via plugin)
    •  Remote discovery and telemetry
    support for PDU and switches
    •  Compute server telemetry available
    via IPMI and SNMP
    •  Live structured data feeds with
    Websockets or AMQP
    •  Declarative Workflows
    •  Composed of tasks – in serial or
    parallel – acyclic graphs
    •  Custom images easily included and
    used in workflows
    •  Leverage templates and profiles
    (dynamic file & ipxe scripts based on
    workflow data)
    CURRENT CAPABILITIES


    View Slide

11. 11
    © Copyright 2016 EMC Corporation. All rights reserved.
    •  SKU packs
    –  Load templates, profiles,
    microkernels, and sku
    definitions for specific hardware
    or OS personalities
    •  V2 API
    –  More solid schema definition,
    swagger based
    •  Fault tolerant workflow
    processing
    •  Hardware connection
    topology
    •  Additional south-bound
    discovery protocols
    –  Adding Redfish 1.0 support to
    IPMI and SNMP
    •  Additional workflow
    capabilities
    –  Secure Erase
    –  In-band management tasks
    –  Enhanced workflow
    programmability
    UPCOMING CAPABILITIES


    View Slide

12. 12
    © Copyright 2016 EMC Corporation. All rights reserved.
    Roadmaps/Specs
    •  https://github.com/RackHD/specs
    Cross Team Dashboard
    •  http://heckj.github.io/ptclientside/
    Public Forums/Mailing List
    •  https://groups.google.com/d/forum/rackhd
    •  rackhd+subscribe@googlegroups.com
    Dedicated Dev Teams
    •  Gripen
    –  https://www.pivotaltracker.com/n/
    projects/1492890
    •  Maglev
    –  https://www.pivotaltracker.com/n/
    projects/1492892
    •  Monorail
    –  https://www.pivotaltracker.com/n/
    projects/1492888
    •  Stryker
    –  https://www.pivotaltracker.com/n/
    projects/1496834
    PUBLIC DEVELOPMENT


    View Slide

13. 13
    © Copyright 2016 EMC Corporation. All rights reserved.
    Instructions
    •  https://github.com/RackHD/RackHD/
    tree/master/example
    Pre-requisites
    •  Install vagrant & virtualbox
    git clone https://github.com/RackHD/RackHD
    cd RackHD/example
    cp config/monorail_rack.cfg.example config/
    monorail_rack.cfg
    bin/monorail_rack
    …
    open http://localhost:9090/docs
    SANDBOX DEMO / HANDS ON


    View Slide

14. View Slide
