Swift Package Manager 3.1

Overview of Swift Package Manager (3.1)

Transcript

1. 3.1
   SWIFT PACKAGE MANAGER


   View Slide

2. SWIFTPM
   PACKAGE MANAGER GOALS
   The Swift Package Manager is a tool for managing the
   distribution of Swift code. It’s integrated with the Swift build
   system to automate the process of downloading, compiling,
   and linking dependencies.
   The Package Manager is included in Swift 3.0 and above.
   The Big Vision:
   ‣ https://github.com/apple/swift-package-manager/blob/master/Documentation/
   PackageManagerCommunityProposal.md
   2


   View Slide

3. SWIFTPM
   WHAT IT DOES TODAY
   ‣ Collect dependencies based on a manifest
   ‣ Resolve dependencies
   ‣ Suggest how to install related dependencies with brew
   or apt
   ‣ swift build, test, and package commands
   ‣ Build & link C and Swift code
   ‣ Generate xcode project file
   ‣ Pass through CLI flags to llbuild/clang layers
   3


   View Slide

4. SWIFTPM
   CONSTRAINTS AND LIMITS (SWIFT 3.1)
   ‣ Only git for source control
   ‣ minimal fork support
   ‣ Limited ability to have configurable “C” builds
   ‣ c++ support starting in dev
   ‣ Minimal integration with Xcode
   ‣ project generation only
   ‣ No integration with Objective-C/IOS
   ‣ external package support coming in swift 4
   4


   View Slide

5. SWIFTPM
   INFLUENCES
   Cocoapods
   Carthage
   Javascript’s NPM
   Rust’s Cargo
   … and really quite a number of others - PyPi, CPAN, etc.
   5


   View Slide

6. SWIFTPM
   GETTING STARTED
   ▸ swift package init --type=executable
   ▸ .gitignore
   ▸ Package.swift
   ▸ Sources/main.swift
   ▸ Tests
   6


   View Slide

7. SWIFTPM
   DEMO & EXAMPLES
   ▸ (more complex)
   ▸ Vapor
   ▸ https://github.com/vapor/vapor
   ▸ (simpler)
   ▸ Guaka
   ▸ https://github.com/oarrabi/Guaka
   7


   View Slide

8. SWIFTPM
   C LIBRARY EXAMPLES
   ▸ YAMS https://github.com/jpsim/Yams
   ▸ Sources/CYaml
   ▸ Sources/Yams
   ▸ Kitura's CCurl https://github.com/IBM-Swift/CCurl
   ▸ Brew/apt of underlying library
   ▸ module.modulemap
   8


   View Slide

9. TEXT
   GUAKA
   heckj ~ $ git clone https://github.com/oarrabi/Guaka
   Cloning into 'Guaka'...
   remote: Counting objects: 1095, done.
   remote: Compressing objects: 100% (22/22), done.
   remote: Total 1095 (delta 5), reused 0 (delta 0), pack-reused 1072
   Receiving objects: 100% (1095/1095), 223.01 KiB | 0 bytes/s, done.
   Resolving deltas: 100% (621/621), done.
   heckj ~ Guaka master $ swift build --enable-prefetching
   Fetching https://github.com/oarrabi/StringScanner
   Cloning https://github.com/oarrabi/StringScanner
   Resolving https://github.com/oarrabi/StringScanner at 0.2.0
   Compile Swift Module 'StringScanner' (5 sources)
   Compile Swift Module 'Guaka' (24 sources)
   heckj ~ Guaka master + $ swift package show-dependencies
   .
   !"" StringScanner


   View Slide

10. TEXT
    PACKAGE.SWIFT
    import PackageDescription
    let package = Package(
    name: "Guaka",
    targets: [
    Target(name: "Guaka")
    ],
    dependencies: [.Package(url: "https://github.com/oarrabi/StringScanner", majorVersion: 0)]
    )


    View Slide

11. TEXT
    VAPOR
    heckj ~ $ git clone https://github.com/vapor/vapor
    Cloning into 'vapor'...
    remote: Counting objects: 20053, done.
    remote: Compressing objects: 100% (26/26), done.
    remote: Total 20053 (delta 7), reused 0 (delta 0), pack-reused 20027
    Receiving objects: 100% (20053/20053), 8.56 MiB | 3.45 MiB/s, done.
    Resolving deltas: 100% (13118/13118), done.
    heckj ~ vapor master $ swift build --enable-prefetching
    Fetching https://github.com/vapor/crypto.git
    Fetching https://github.com/vapor/engine.git
    Fetching https://github.com/vapor/fluent.git
    Fetching https://github.com/vapor/console.git
    Fetching https://github.com/vapor/json.git
    Fetching https://github.com/stormpath/Turnstile.git
    …
    Cloning https://github.com/vapor/core.git
    Resolving https://github.com/vapor/core.git at 1.1.1
    Cloning https://github.com/stormpath/Turnstile.git
    Resolving https://github.com/stormpath/Turnstile.git at 1.0.3
    …


    View Slide

12. TEXT
    VAPOR DEPENDENCIES
    .
    #"" Crypto
    $ #"" Core
    $ !"" CLibreSSL
    #"" Fluent
    $ !"" Node
    $ #"" PathIndexable
    $ !"" Polymorphic
    #"" Engine
    $ #"" Crypto
    $ $ #"" Core
    $ $ !"" CLibreSSL
    $ #"" TLS
    $ $ #"" CLibreSSL
    $ $ #"" Core
    $ $ !"" Socks
    $ !"" Core
    #"" Console
    $ #"" Polymorphic
    $ !"" Core
    #"" JSON
    $ #"" Core
    $ #"" Node
    $ $ #"" PathIndexable
    $ $ !"" Polymorphic
    $ !"" Jay
    #"" Turnstile
    …


    View Slide

13. // Console protocol and implementation for powering command
    line interface.
    .Package(url: "https://github.com/vapor/console.git",
    majorVersion: 1),
    // JSON enum wrapper around Foundation JSON
    .Package(url: "https://github.com/vapor/json.git",
    majorVersion: 1),
    // A security framework for Swift.
    .Package(url: "https://github.com/stormpath/Turnstile.git",
    majorVersion: 1),
    // An extensible templating language built for Vapor.
    .Package(url: "https://github.com/vapor/leaf.git",
    majorVersion: 1),
    // A type safe routing package including HTTP and TypeSafe
    routers.
    .Package(url: "https://github.com/vapor/routing.git",
    majorVersion: 1),
    // Parses `Content-Type: multipart` as defined in RFC 2046.
    .Package(url: "https://github.com/vapor/multipart.git",
    majorVersion: 1),
    ],
    exclude: [
    "Sources/Development",
    "Sources/Performance",
    "Sources/TypeSafeGenerator"
    ]
    import PackageDescription
    let package = Package(
    name: "Vapor",
    targets: [
    // Framework
    Target(name: "Vapor", dependencies: [
    "Auth",
    "Cache",
    "Cookies",
    "Sessions",
    "Settings"
    ]),
    // Misc
    Target(name: "Auth", dependencies: ["Cookies", "Cache"]),
    Target(name: "Cache"),
    Target(name: "Cookies"),
    Target(name: "Sessions", dependencies: ["Cookies"]),
    Target(name: "Settings"),
    // Development and Testing
    // Target(name: "Development", dependencies: ["Vapor"]),
    // Target(name: "Performance", dependencies: ["Vapor"]),
    ],
    dependencies: [
    // SHA2 + HMAC hashing. Used by the core to create session
    identifiers.
    .Package(url: "https://github.com/vapor/crypto.git",
    majorVersion: 1),
    // ORM for interacting with databases
    .Package(url: "https://github.com/vapor/fluent.git",
    majorVersion: 1),
    // Core vapor transport layer
    .Package(url: "https://github.com/vapor/engine.git",
    majorVersion: 1),


    View Slide

14. SWIFTPM
    REFERENCE
    ▸ swift.org
    ▸ https://github.com/apple/swift-package-manager/blob/master/Documentation/Usage.md
    ▸ https://github.com/apple/swift-package-manager/blob/master/Documentation/Reference.md
    ▸ blogs/articles
    ▸ https://www.cocoawithlove.com/blog/package-manager-fetch.html
    ▸ https://www.raywenderlich.com/148832/introduction-swift-package-manager
    ▸ http://ankit.im/swift/2016/02/17/swift-package-manager-testing-preview/
    ▸ https://oleb.net/blog/2017/03/testing-swift-packages-on-linux/
    ▸ https://oleb.net/blog/2017/03/keeping-xctest-in-sync/
    ▸ https://oleb.net/blog/2017/04/swift-3-1-package-manager-deployment-target/
    14


    View Slide

15. SWIFTPM
    WHAT’S BEEN DONE
    ‣Swift 3
    ‣swift test integration
    ‣https://github.com/apple/swift-evolution/blob/master/proposals/0019-package-manager-testing.md
    ‣package manager support for C languages
    ‣https://github.com/apple/swift-evolution/blob/master/proposals/0038-swiftpm-c-language-targets.md
    ‣system module search paths (Apt, Brew)
    ‣https://github.com/apple/swift-evolution/blob/master/proposals/0063-swiftpm-system-module-search-
    paths.md
    ‣test naming conventions
    ‣https://github.com/apple/swift-evolution/blob/master/proposals/0129-package-manager-test-naming-
    conventions.md
    ‣package versioning
    ‣https://github.com/apple/swift-evolution/blob/master/proposals/0135-package-manager-support-for-
    differentiating-packages-by-swift-version.md
    ‣Swift 3.1
    ‣package edit
    ‣ https://github.com/apple/swift-evolution/blob/master/proposals/0082-swiftpm-package-edit.md
    ‣package manager version pinning
    ‣https://github.com/apple/swift-evolution/blob/master/proposals/0145-package-manager-version-pinning.md
    15


    View Slide

16. SWIFTPM
    WHAT’S COMING
    ‣ product definitions (mult deliverables per repo)
    ‣ https://github.com/apple/swift-evolution/blob/master/proposals/0146-package-manager-product-
    definitions.md
    ‣ top of tree development
    ‣ https://github.com/apple/swift-evolution/blob/master/proposals/0149-package-manager-top-of-tree.md
    ‣ packages following branches
    ‣ https://github.com/apple/swift-evolution/blob/master/proposals/0150-package-manager-branch-support.md
    ‣ package manifest API/language compatibility
    ‣ https://github.com/apple/swift-evolution/blob/master/proposals/0151-package-manager-swift-language-
    compatibility-version.md
    ‣ package/manifest version
    ‣ https://github.com/apple/swift-evolution/blob/master/proposals/0152-package-manager-tools-version.md
    ‣ package/manifest update
    ‣ https://github.com/apple/swift-evolution/blob/master/proposals/0158-package-manager-manifest-api-
    redesign.md
    ‣ package/manifest custom targets update
    ‣ https://github.com/apple/swift-evolution/blob/master/proposals/0162-package-manager-custom-target-
    layouts.md
    16


    View Slide

17. JOE HECK
    https://github.com/heckj/
    @heckj


    View Slide
