Improving Genre Annotations for the Million Song Dataset

Improving Genre Annotations for the Million Song Dataset
Hendrik Schreiber 
tagtraum industries incorporated
[email protected] / @h_schreiber
October 27, ISMIR 2015 Málaga

View Slide

TL;DR

View Slide

TL;DR
1. New, high-quality genre annotations for 
part of the Million Song Dataset (MSD)

View Slide

TL;DR
2. Involved in automatic music genre recognition? 
 
Please use them!

View Slide

TL;DR
2. Involved in automatic music genre recognition? 
 
Please use them!
3. http://www.tagtraum.com/msd_genre_datasets.html 
 
Linked to from the MSD site—thanks, Colin!

View Slide

Thank you.

View Slide

Automatic Music Genre Recognition 
is among the most popular MIR tasks. *
Why?
* Zhouyu Fu, Guojun Lu, Kai Ming Ting, and Dengsheng Zhang. A survey of audio-based music classiﬁcation and annotation. Multimedia, IEEE
Transactions on, 13(2):303–319, 2011.

View Slide

Automatic Music Genre Recognition 
is among the most popular MIR tasks. *
Why?
But we don’t use a large, standard dataset.
* Zhouyu Fu, Guojun Lu, Kai Ming Ting, and Dengsheng Zhang. A survey of audio-based music classiﬁcation and annotation. Multimedia, IEEE
Transactions on, 13(2):303–319, 2011.

View Slide

J Intell Inf Syst (2013) 41:371–406 377
Table 2 Datasets used in MGR, the type of data they contain, and the percentage of experimental
work (435 references) in our survey (Sturm 2012a) that use them
Dataset Description %
Private Constructed for research but not made available 58
GTZAN Audio; http://marsyas.info/download/data_sets 23
ISMIR2004 Audio; http://ismir2004.ismir.net/genre_contest 17
Latin (Silla et al. 2008) Features; http://www.ppgia.pucpr.br/∼silla/lmd/ 5
Ballroom Audio; http://mtg.upf.edu/ismir2004/contest/tempoContest/ 3
Homburg Audio; http://www-ai.cs.uni-dortmund.de/audio.html 3
(Homburg et al. 2005)
Bodhidharma Symbolic; http://jmir.sourceforge.net/Codaich.html 3
USPOP2002 Audio; http://labrosa.ee.columbia.edu/projects/musicsim/ 2
(Berenzweig et al. 2004) uspop2002.html
1517-artists Audio; http://www.seyerlehner.info 1
RWC (Goto et al. 2003) Audio; http://staff.aist.go.jp/m.goto/RWC-MDB/ 1
SOMeJB Features; http://www.ifs.tuwien.ac.at/∼andi/somejb/ 1
SLAC Audio & symbols; http://jmir.sourceforge.net/Codaich.html 1
SALAMI (Smith et al. 2011) Features; http://ddmal.music.mcgill.ca/research/salami 0.7
Unique Features; http://www.seyerlehner.info 0.7
Million song Features; http://labrosa.ee.columbia.edu/millionsong/ 0.7
(Bertin-Mahieux et al. 2011)
ISMIS2011 Features; http://tunedit.org/challenge/music-retrieval 0.4
All datasets listed after Private are public
Used Datasets
Sturm, B.L. A survey of evaluation in music genre recognition. In Proc. Adaptive Multimedia Retrieval. 2012.

View Slide

J Intell Inf Syst (2013) 41:371–406 377
Used Datasets
Not
reproducible

View Slide

J Intell Inf Syst (2013) 41:371–406 377
Used Datasets
Not
reproducible
Hardly used

View Slide

J Intell Inf Syst (2013) 41:371–406 377
Used Datasets
Not
reproducible
Has its issues
Hardly used

View Slide

View Slide

Too Much Britney
• Small: 1,000 tracks
• Replicas
• Excerpts from the same recording
• Versions (same music but different recordings)
• Mis-labelings
• Distortions
• Excerpts by the same artists: 35% of Reggae excerpts are by
Bob Marley, 24% of Pop excerpts are by Britney Spears, …
Sturm, B.L. An analysis of the GTZAN music genre dataset. In Proceedings of the second international ACM workshop on Music information retrieval
with user-centered and multimodal strategies, pages 7–12. ACM, 2012.

View Slide

What’s wrong with MSD?

View Slide

What’s wrong with MSD?
No song-level genre annotations.

View Slide

Last.fm MSD Tags
• 522,366 unique tags
• 505,216 tracks with at least one tag, i.e. multiple tags per song
• No explicit relationships between tags
• Many tags are genre related, but not all of them: 
 
rock 101,071 
pop 69,159 
alternative 55,777 
indie 48,175 
electronic 46,270 
female vocalists 42,565 
favorites 39,921 
love 34,901 
dance 33,618 
00s 31,432 
…
http://labrosa.ee.columbia.edu/millionsong/lastfm

View Slide

Last.fm MSD Tags
• 522,366 unique tags
• 505,216 tracks with at least one tag, i.e. multiple tags per song
• No explicit relationships between tags
• Many tags are genre related, but not all of them: 
 
rock 101,071 
pop 69,159 
alternative 55,777 
indie 48,175 
electronic 46,270 
female vocalists 42,565 
favorites 39,921 
love 34,901 
dance 33,618 
00s 31,432 
…
http://labrosa.ee.columbia.edu/millionsong/lastfm
Yes, great data.
But no tag hierarchies/
relationships. 
What’s a genre, what’s not?
What exactly is the ground truth
here that’s usable for MGR?

View Slide

Top-MAGD Annotations
• Album-level annotations scraped from All Music Guide website
• 13 unique tags
• 406,427 labeled tracks: 
 
Pop/Rock 238,786 
Electronic 41,075 
Rap 20,939 
Jazz 17,836 
Latin 17,590 
R&B 14,335 
International 14,242 
Country 11,772 
Reggae 6,946 
Blues 6,836 
Vocal 6,195 
Folk 5,865 
New Age 4,010
Alexander Schindler, Rudolf Mayer, and Andreas Rauber. Facilitating comprehensive benchmarking experiments on the million song dataset. In
Proceedings of the 13th International Conference on Music Information Retrieval (ISMIR), pages 469–474, 2012.

View Slide

• 13 unique tags
 
Pop/Rock 238,786 
Rap 20,939 
Jazz 17,836 
Latin 17,590 
R&B 14,335 
Country 11,772 
Reggae 6,946 
Blues 6,836 
Vocal 6,195 
Folk 5,865 
New Age 4,010
Is this still useful?

View Slide

• 13 unique tags
 
Pop/Rock 238,786 
Rap 20,939 
Jazz 17,836 
Latin 17,590 
R&B 14,335 
Country 11,772 
Reggae 6,946 
Blues 6,836 
Vocal 6,195 
Folk 5,865 
New Age 4,010
Also, great job. 
But the granularity is not really
what we want: 
Metallica just isn’t Britney. 
Has anybody veriﬁed the
annotations? 
Are album-level annotations
good enough?

View Slide

Goal
Intelligently merge several datasets into 
one high-quality genre annotation dataset.

View Slide

How
1. Make sure all datasets use the same 
labels (via taxonomies)
2. Use datasets to evaluate each other
3. Generate new & improved dataset
5. Hip-Hop Hip-Hop Jazz Reggae Latin Soundtrack
6. Hip-Hop/Rap R&B Alternative R&B Dance Jazz
7. Soundtrack Soundtrack Dance Soundtrack House Electronica/Dance
8. R&B Jazz R&B Blues Otros M#✏(Rock)
9. Electronic Country Rock/Pop Electronic Blues Altern. & Punk
10. Country Altern. & Punk Soundtrack Rap Electronica Hip-Hop/Rap
Table 1. Top ten genres used by beaTunes users with different languages. N denotes the number of submissions in millions.
Co-Occurrence Rank 1. 2. 3. 4.
Rock Rock (0.609) Pop (0.057) Alternative (0.026) Rock/Pop (0.016)
Pop Pop (0.593) Rock (0.077) Rock/Pop (0.014) R&B (0.013)
Alternative Alternative (0.394) Rock (0.156) Pop (0.052) Alternative/Punk (0.036)
R&B R&B (0.566) Pop (0.061) Soul (0.036) R&B/Soul (0.033)
Soundtrack Soundtrack (0.754) Rock (0.024) Pop (0.022) Game (0.011)
... ... ... ... ...
Table 2. Genre labels in the beaTunes database and their top four co-occurring labels ordered by relative strength given in
parenthesis. The underlying values from the co-occurrence matrix C were computed taking only submissions by English
speakers and the 1,000 most-used labels into account.
(2) Because this rule allows a genre to be a sub-genre of
multiple genres, we add:
a is a
direct
sub-genre of b, iff
a is a sub-genre of b
^ C
a,b
> C
a,c
with c 6= a ^ c 6= b; a, b, c 2 G
(4)
By finding all direct sub-genres and their parents, we
can now create a set of trees. The number of created trees
depends on the threshold ⌧. We found, that to properly dis-
tinguish between genres like Pop, Rock, Dance, R&B,
Folk, and Other, ⌧ := 0.085 proved to be useful, re-
sulting in 141 trees. The roots of these trees are typi-
cally the names of seed-genres like Jazz, Pop, Rock,
etc. (see Figure 1).
Not all generated trees have children. For example, the
tree with the seed-genre Groove consists of just the root.
Although Groove co-occurs with R&B, Rock, Funk, and
Soul, the co-occurrence rates with genres other than itself
are all below ⌧. Even the co-occurrence with itself is low
(0.157). This suggests, that Groove is not really a genre,
but more a property of a genre. Another example for a root-
only tree is Calypso. Here the co-occurrence with itself
is much higher (0.606) and indeed Calypso qualifies as
stand-alone genre that simply does not have any sub-genres
in this database.
Naturally, the generated taxonomies are only simplified
mappings of the more complex relationship graph repre-
sented by C. In reality, genres aren’t necessarily exclusive
members of one tree or another (e.g. fusion genres). An
ontology is the much better construct. But, as we will see,
for the purpose of mapping most sub-genres to their seed-
genre, trees are useful.
Rock
Metal Alternative Punk ...
Pop
Folk Pop Acoustic Pop Top 40 ...
Hip-Hop
East Coast Rap Turntablism ...
RnB
Motown Funk Soul Urban ...
Figure 1. Partial, generated trees for the seed-genres
Rock, Pop, Hip-Hop, and R&B.
2.4 Matching with Million Song Dataset
To create song-level genre annotations for the MSD, we
queried the beaTunes database for songs with artist/title
pairs contained in the MSD and were able to match
677,038 songs. In order to ease the comparison with the
HO and Top-MAGD datasets, we associated each matched
song with the seed-genre of its most often occurring
genre label, taking advantage of the taxonomies created in
Section 2.3. Motown, for example, is represented by its
seed-genre RnB. In many cases, the found seed-genres are

View Slide

But ﬁrst, a little…

View Slide

beaTunes
• Consumer application for Windows and Mac
• Encourages users to correct metadata
• Collects anonymized, user-submitted metadata in
central database
https://www.beatunes.com/

View Slide

beaTunes Database
• 870 million song submissions by 200 thousand users
• 772 million submissions are labeled with a genre
• Mapped to more than 85 million distinct songs 
(one song, many genre labels)
• 677,038 songs have been 
matched to MSD
https://www.beatunes.com/

View Slide

Mapping User Genre Labels
to a Genre Taxonomy
1. Normalization (lowercase, smart subs, etc.)
2. Inferring hierarchical relationships via co-occurrence

View Slide

Co-Occurrence Matrix
2. Pop Pop Rock Pop Pop Pop
3. Alternative Alternative Electronic Jazz Jazz J-Pop
4. Jazz Hip-Hop/Rap Hip-Hop Hip-Hop Soundtrack R&B
... ... ... ... ...
a is a
direct
sub-genre of b, iff
^ C
a,b
> C
a,c
with c 6= a ^ c 6= b; a, b, c 2 G
(4)
Rock
Pop
Genre labels and their top four co-occurring labels
ordered by relative strength given in parenthesis.

View Slide

Co-Occurrence Matrix
2. Pop Pop Rock Pop Pop Pop
3. Alternative Alternative Electronic Jazz Jazz J-Pop
4. Jazz Hip-Hop/Rap Hip-Hop Hip-Hop Soundtrack R&B
... ... ... ... ...
a is a
direct
sub-genre of b, iff
^ C
a,b
> C
a,c
with c 6= a ^ c 6= b; a, b, c 2 G
(4)
Rock
Pop
Genre labels and their top four co-occurring labels
ordered by relative strength given in parenthesis.
Co-occurrence rates
aren’t symmetric!

View Slide

Rules

View Slide

Rules
1. If a genre a co-occurs with another genre b more
than a minimum threshold τ, and a co-occurs with b
more than the other way around, then we assume
that a is a sub-genre of b.

View Slide

Rules
1. If a genre a co-occurs with another genre b more
than a minimum threshold τ, and a co-occurs with b
more than the other way around, then we assume
that a is a sub-genre of b.
2. a is a direct sub-genre of b, iff a is a sub-genre of b
and Ca,b > Ca,c with c≠a und c≠b. 
 
a,b,c ∈ G and Ca,b being the co-occurrence rate
between a and b.

View Slide

Generated Taxonomies
Rock (0.077) Rock/Pop (0.014) R&B (0.013)
Rock (0.156) Pop (0.052) Alternative/Punk (0.036)
Pop (0.061) Soul (0.036) R&B/Soul (0.033)
Rock (0.024) Pop (0.022) Game (0.011)
... ... ...
d their top four co-occurring labels ordered by relative strength given in
ccurrence matrix C were computed taking only submissions by English
unt.
genre of
(4)
ents, we
ed trees
properly
roved to
se trees
z, Pop,
mple, the
he root.
nk, and
an itself
f is low
a genre,
r a root-
Rock
Pop
Hip-Hop
RnB
a is a
direct
sub-genre of b, iff
^ C
a,b
> C
a,c
with c 6= a ^ c 6= b; a, b, c 2 G
(4)
depends on the threshold ⌧. We found, that to properly
distinguish between Pop and Rock, ⌧ := 0.085 proved to
be useful, resulting in 141 trees. The roots of these trees
are typically the names of seed-genres like Jazz, Pop,
Rock, etc. (see Figure 1).
in this database.
Rock
Pop
Hip-Hop
RnB

View Slide

Generated Taxonomies
Rock (0.077) Rock/Pop (0.014) R&B (0.013)
Rock (0.156) Pop (0.052) Alternative/Punk (0.036)
Pop (0.061) Soul (0.036) R&B/Soul (0.033)
Rock (0.024) Pop (0.022) Game (0.011)
... ... ...
d their top four co-occurring labels ordered by relative strength given in
ccurrence matrix C were computed taking only submissions by English
unt.
genre of
(4)
ents, we
ed trees
properly
roved to
se trees
z, Pop,
mple, the
he root.
nk, and
an itself
f is low
a genre,
r a root-
Rock
Pop
Hip-Hop
RnB
a is a
direct
sub-genre of b, iff
^ C
a,b
> C
a,c
with c 6= a ^ c 6= b; a, b, c 2 G
(4)
depends on the threshold ⌧. We found, that to properly
distinguish between Pop and Rock, ⌧ := 0.085 proved to
be useful, resulting in 141 trees. The roots of these trees
are typically the names of seed-genres like Jazz, Pop,
Rock, etc. (see Figure 1).
in this database.
Rock
Pop
Hip-Hop
RnB
No parent 
= seed genre
Seed genres can easily be found and 
mapped to Top-MAGD labels. 
(Pop/Rock, Electronic, Rap, Jazz, Latin, R&B, International, 
Country, Reggae, Blues, Vocal, Folk, New Age)

View Slide

Building Genre Taxonomies
with Last.fm Tags
• Last.fm tags come with a relative strength (0-100)
• Same procedure can be applied
• Many more different tags -> minimum threshold τ has
to be adjusted
• Allows us to ﬁnd seed genres (top-level)

View Slide

Comparing Annotations
• beaTunes and Last.fm labels can now be matched to
Top-MAGD labels using the generated taxonomies
• Let’s compare!

View Slide

Last.fm beaTunes
Top-MAGD 75.7% 84.0%
Last.fm - 80.9%
Pairwise Comparison

View Slide

Last.fm beaTunes
Top-MAGD 75.7% 84.0%
Last.fm - 80.9%
Pairwise Comparison
High agreement rates,
especially between beaTunes
and Top-MAGD

View Slide

Last.fm beaTunes
Top-MAGD 75.7% 84.0%
Last.fm - 80.9%
Pairwise Comparison
Glass-ceiling for ground truth
with just one value/song?

View Slide

Combined Dataset 1

View Slide

Combined Dataset 1
• Find songs occurring in all datasets

View Slide

Combined Dataset 1
• For which at least two of the datasets agree 
(majority voting)

View Slide

Combined Dataset 1
(majority voting)
• Take note of minority vote, if existent 
(i.e. allow ambiguity)

View Slide

Combined Dataset 1
(majority voting)
• Take note of minority vote, if existent 
(i.e. allow ambiguity)
• => Combined Dataset 1 (CD1): 
133,676 tracks 
98,149 (73.4%) found by unanimous consent

View Slide

CD1 Genre Distribution
CD1
0 20 40 60
Blues
Country
Electronic
Folk
Intern.
Jazz
Latin
New Age
Pop Rock
Rap
Reggae
RnB
Vocal
2.2
3.9
11.4
2.2
1.1
5.8
2.1
1
59.8
4.6
2.7
2.9
0.2
Tracks per Genre [%]
Figure 2. Majority genre distribution of tracks in CD1.
As
gen
BG
suit

View Slide

Metallica is not Britney
≠

View Slide

Combined Dataset 2

View Slide

Combined Dataset 2
• Just beaTunes and Last.fm tracks, because Top-MAGD
can’t distinguish between Pop and Rock

View Slide

Combined Dataset 2
• Split Pop and Rock

View Slide

Combined Dataset 2
• Add Metal and Punk

View Slide

Combined Dataset 2
• Remove Vocal

View Slide

Combined Dataset 2
• Remove Vocal
• Combine R&B and Soul

View Slide

Combined Dataset 2
• Remove Vocal
• Combine R&B and Soul
• Rename International to World

View Slide

Combined Dataset 2
• Find songs in both beaTunes and Last.fm datasets
• => Combined Dataset 2 (CD2): 
280,831 tracks 
191,401 (68.2%) have the same genre label
• Combined Dataset 2 Consensus (CD2C): 
Convenience dataset with only the songs that have the
same genre label

View Slide

0 20 40 60
Blues
Country
Electronic
Folk
Intern.
Jazz
Latin
New Age
Pop Rock
Rap
Reggae
RnB
Vocal
2.2
3.9
11.4
2.2
1.1
5.8
2.1
1
59.8
4.6
2.7
2.9
0.2
CD2C Genre Distribution
CD1
CD2C
0 20 40 60
RnB
Vocal
2.7
2.9
0.2
0 20 40 60
Blues
Country
Electronic
Folk
Jazz
Latin
Metal
New Age
Pop
Punk
Rap
Reggae
RnB
Rock
World
3.2
4.7
11.4
2.2
7.7
1.6
4.8
0.6
6.8
1.7
5.7
4.2
5.1
39.2
1
Figure 3. Genre distribution of tracks in CD2C.
As CD2 songs are
genre, we used the ﬁ
6. A
BGD and LFMGD
suitable for compar
Top-MAGD. They b
the genre labels them
ﬁcations are problem
datasets presented in
bels where feasible.
is actually much mo
basis. We are publis
it proves useful for
cludes:
• Multiple genr
relative streng
judge reliabili
• Co-occurrenc
in Section 2.3
• Derived genre
All data can be fo
com/msd_genre_

View Slide

Benchmarking Partitions
• Main “feature” of Schindler et al. paper
• Increase reproducibility
• Traditional training/test splits (90%, 80%, …)
• Training/test splits with genre stratiﬁcation
• Splits with ﬁxed number per genre (1,000, 2,000, 3,000)

View Slide

Summary

View Slide

Summary
• Multiple large ground truth datasets for the MSD

View Slide

Summary
• Despite large size, reasonable quality

View Slide

Summary
• Allow for ambiguity

View Slide

Summary
• Allow for ambiguity
• Benchmark partitions to promote experimentation and
comparability

View Slide

Thank you.
http://www.tagtraum.com/msd_genre_datasets.html

View Slide

Thank you.
Questions?
http://www.tagtraum.com/msd_genre_datasets.html

View Slide

Improving Genre Annotations for the Million Song Dataset

Improving Genre Annotations for the Million Song Dataset

Hendrik Schreiber

More Decks by Hendrik Schreiber

Other Decks in Science

Featured

Transcript
