Building a Canary Testing Framework

Originally given at StrangeLoop in 2018, this talk walks through what canary testing and building a simple canary testing framework.

Transcript

1. Building a Canary Testing
   Framework
   Iheanyi Ekechukwu


   View Slide

2. Iheanyi Ekechukwu
   Senior Software Engineer @ GitHub
   @kwuchu
   https://github.com/iheanyi


   View Slide

3. What is a canary?


   View Slide

4. View Slide

5. Canary tests should mimic user
   behavior and test a specific
   feature.


   View Slide

6. Canary tests (normally) should run
   against your production systems.


   View Slide

7. Opinion: Each product in your
   organization should have its own
   canary running.


   View Slide

8. Is this an integration test?


   View Slide

9. Well, yes and no.


   View Slide

10. (\__/)
    (•ź•) Integration Tests
    \>


    View Slide

11. View Slide

12. ⠀ ⠀ ⠀(\__/)
    (•ź•)
    　＿ノ ヽ ノ＼＿
    `/　`/ ⌒Ｙ⌒ Ｙ　ヽ Canaries
    ( 　(三ヽ⼈人　 /　　 |
    |　ﾉ⌒＼ ￣￣ヽ　 ノ
    ヽ＿＿＿＞､＿＿_／
    　　 ｜( 王 ﾉ〈 (\__/)
    　　 /ﾐ`ー―⼺彡\ (•ź•) Integration Tests
    　　/ ╰ ╯ \/ \>


    View Slide

13. You can do more than just CRUD
    operations (ex: SSH, shell
    commands)


    View Slide

14. Allow for more specificity and
    granularity for the execution
    environment


    View Slide

15. Allow for better observability into
    what’s going on within your
    systems


    View Slide

16. So, how do we build a canary
    testing framework?


    View Slide

17. First, what are our necessary
    features?


    View Slide

18. Visualization of Test Output /
    Execution Status


    View Slide

19. Recording and alerting on
    metrics via Prometheus


    View Slide

20. Run all tests simultaneously over
    a set interval with a timeout


    View Slide

21. Ability to write tests in a
    flexible, approachable language


    View Slide

22. Canary Framework
    Architecture Components


    View Slide

23. Go for the Framework


    View Slide

24. JavaScript for the Test VM


    View Slide

25. A database for storing test
    execution results


    View Slide

26. API & Web UI for visualizing test
    execution results from our
    database


    View Slide

27. Why Go for the actual
    framework?


    View Slide

28. Concurrency is our friend


    View Slide

29. Decent support for embedding
    languages


    View Slide

30. Go API Clients


    View Slide

31. Why JavaScript for the
    scripting language?


    View Slide

32. Flexibility


    View Slide

33. Low barrier to entry


    View Slide

34. Embeddable within Go via Otto


    View Slide

35. Canary Daemon Architecture


    View Slide

36. Let’s Break This Down


    View Slide

37. The JavaScript VM


    View Slide

38. Allows us to write and run test
    scripts using JavaScript


    View Slide

39. Extensions to the framework (such
    as logging, http, etc.) are attached
    to the VM


    View Slide

40. View Slide

41. The Test Runner


    View Slide

42. Isolates and configures the
    VM, then runs the tests


    View Slide

43. Returns errors (if any) from
    the test execution


    View Slide

44. The Canary Daemon


    View Slide

45. Executes the config file and
    registers the tests to run


    View Slide

46. Repeatedly runs each test using
    the runner, save results to the
    database


    View Slide

47. Also, records and exports metrics
    such as tests started, running, and
    finished via Prometheus.


    View Slide

48. Serves the API and front-end for
    visualizing test execution results


    View Slide

49. Okay, let’s walk through the
    code for a simple canary.


    View Slide

50. View Slide

51. Loading Test Configurations


    View Slide

52. // internal/js/canary/config.go
    // Load a Javascript config script, returning all the TestConfigs that
    // are defined in it. The given VM is left unchanged, but it's context
    // is available during parsing of the config script.
    func Load(vm *otto.Otto, src io.Reader) (*Config, []*js.TestConfig, error) {
    configVM := vm.Copy() // avoid polluting the global namespace
    ctx := new(ctx)
    configVM.Set("settings", ctx.ottoFuncSettings)
    configVM.Set("file", ctx.ottoFuncFile)
    configVM.Set("register_test", ctx.ottoFuncRegisterTest)
    if err := jsctx.LoadStdLib(context.Background(), configVM, "std"); err != nil {
    return nil, nil, fmt.Errorf("can't load stdlib: %v", err)
    }
    source, err := ioutil.ReadAll(src)
    if err != nil {
    return nil, nil, fmt.Errorf("can't read config file: %v", err)
    }
    if _, err := configVM.Run(source); err != nil {
    return nil, nil, fmt.Errorf("can't apply configuration: %v", err)
    }
    if ctx.cfg == nil {
    ctx.cfg = new(Config)
    }
    return ctx.cfg, ctx.tests, nil
    }


    View Slide

53. ctx := new(ctx)


    View Slide

54. // Config holds the global canary configuration.
    type Config struct {
    Name string
    }
    type ctx struct {
    cfg *Config
    tests []*js.TestConfig
    }


    View Slide

55. // A TestConfig describes how a class of tests must be run.
    type TestConfig struct {
    Name string
    Script *otto.Script
    Frequency time.Duration
    Timeout time.Duration
    }


    View Slide

56. // internal/js/canary/config.go
    // Load a Javascript config script, returning all the TestConfigs that
    // are defined in it. The given VM is left unchanged, but it's context
    // is available during parsing of the config script.
    func Load(vm *otto.Otto, src io.Reader) (*Config, []*js.TestConfig, error) {
    configVM := vm.Copy() // avoid polluting the global namespace
    ctx := new(ctx)
    configVM.Set("settings", ctx.ottoFuncSettings)
    configVM.Set("file", ctx.ottoFuncFile)
    configVM.Set("register_test", ctx.ottoFuncRegisterTest)
    if err := jsctx.LoadStdLib(context.Background(), configVM, "std"); err != nil {
    return nil, nil, fmt.Errorf("can't load stdlib: %v", err)
    }
    source, err := ioutil.ReadAll(src)
    if err != nil {
    return nil, nil, fmt.Errorf("can't read config file: %v", err)
    }
    if _, err := configVM.Run(source); err != nil {
    return nil, nil, fmt.Errorf("can't apply configuration: %v", err)
    }
    if ctx.cfg == nil {
    ctx.cfg = new(Config)
    }
    return ctx.cfg, ctx.tests, nil
    }


    View Slide

57. configVM.Set("file", ctx.ottoFuncFile)
    configVM.Set("register_test", ctx.ottoFuncRegisterTest)


    View Slide

58. // internal/js/canary/config.go
    func (ctx *ctx) ottoFuncFile(call otto.FunctionCall) otto.Value {
    filename := ottoutil.String(call.Otto, call.Argument(0))
    data, err := ioutil.ReadFile(filename)
    if err != nil {
    ottoutil.Throw(call.Otto, err.Error())
    }
    v, err := otto.ToValue(string(data))
    if err != nil {
    ottoutil.Throw(call.Otto, err.Error())
    }
    return v
    }


    View Slide

59. // internal/js/canary/config.go
    func (ctx *ctx) ottoFuncRegisterTest(call otto.FunctionCall) otto.Value {
    cfg := new(testConfig)
    cfg.load(call.Otto, call.Argument(0))
    src := ottoutil.String(call.Otto, call.Argument(1))
    test := &js.TestConfig{
    Name: cfg.Name,
    Frequency: cfg.Frequency,
    Timeout: cfg.Timeout,
    }
    var err error
    test.Script, err = call.Otto.Compile("", src)
    if err != nil {
    ottoutil.Throw(call.Otto, err.Error())
    }
    ctx.tests = append(ctx.tests, test)
    return otto.UndefinedValue()
    }
    type testConfig struct {
    Name string
    Frequency time.Duration
    Timeout time.Duration
    }


    View Slide

60. cfg := new(testConfig)
    cfg.load(call.Otto, call.Argument(0))


    View Slide

61. // internal/js/canary/config.go
    func (cfg *testConfig) load(vm *otto.Otto, config otto.Value) {
    ottoutil.LoadObject(vm, config, map[string]func(otto.Value) error{
    "name": func(v otto.Value) (err error) {
    cfg.Name, err = v.ToString()
    return
    },
    "frequency": func(v otto.Value) error {
    cfg.Frequency = ottoutil.Duration(vm, v)
    return nil
    },
    "timeout": func(v otto.Value) error {
    cfg.Timeout = ottoutil.Duration(vm, v)
    return nil
    },
    })
    }


    View Slide

62. func (ctx *ctx) ottoFuncRegisterTest(call otto.FunctionCall) otto.Value {
    cfg := new(testConfig)
    cfg.load(call.Otto, call.Argument(0))
    src := ottoutil.String(call.Otto, call.Argument(1))
    test := &js.TestConfig{
    Name: cfg.Name,
    Frequency: cfg.Frequency,
    Timeout: cfg.Timeout,
    }
    var err error
    test.Script, err = call.Otto.Compile("", src)
    if err != nil {
    ottoutil.Throw(call.Otto, err.Error())
    }
    ctx.tests = append(ctx.tests, test)
    return otto.UndefinedValue()
    }
    type ctx struct {
    cfg *Config
    tests []*js.TestConfig
    }


    View Slide

63. // internal/js/canary/config.go
    // Load a Javascript config script, returning all the TestConfigs that
    // are defined in it. The given VM is left unchanged, but it's context
    // is available during parsing of the config script.
    func Load(vm *otto.Otto, src io.Reader) (*Config, []*js.TestConfig, error) {
    configVM := vm.Copy() // avoid polluting the global namespace
    ctx := new(ctx)
    configVM.Set("settings", ctx.ottoFuncSettings)
    configVM.Set("file", ctx.ottoFuncFile)
    configVM.Set("register_test", ctx.ottoFuncRegisterTest)
    if err := jsctx.LoadStdLib(context.Background(), configVM, "std"); err != nil {
    return nil, nil, fmt.Errorf("can't load stdlib: %v", err)
    }
    source, err := ioutil.ReadAll(src)
    if err != nil {
    return nil, nil, fmt.Errorf("can't read config file: %v", err)
    }
    if _, err := configVM.Run(source); err != nil {
    return nil, nil, fmt.Errorf("can't apply configuration: %v", err)
    }
    if ctx.cfg == nil {
    ctx.cfg = new(Config)
    }
    return ctx.cfg, ctx.tests, nil
    }


    View Slide

64. Let’s look at an example
    config.js file.


    View Slide

65. settings({
    name: 'Example Canary',
    });
    var frequency = '10m';
    var timeout = '10m';
    register_test(
    {
    name: 'simple example test',
    frequency: frequency,
    timeout: timeout,
    },
    file('simple-example.js')
    );


    View Slide

66. How does config.Load even get
    called?


    View Slide

67. Let's create our daemon and
    call this function.


    View Slide

68. // cmd/canaryd/main.go
    func main() {}


    View Slide

69. // cmd/canaryd/main.go
    func main() {
    log.SetFormatter(&log.JSONFormatter{})
    log.SetOutput(os.Stdout)
    var (
    cfgPath = flag.String("cfg", "config.js", "path to a JS config file")
    workDir = flag.String("work.dir", ".", "directory from which to run, should match expectations about
    relative paths in cfg.file")
    )
    flag.Parse()
    if *workDir != "" {
    if err := os.Chdir(*workDir); err != nil {
    log.WithError(err).WithField("work.dir", *workDir).Fatal("can't change dir")
    }
    }
    var (
    vm = otto.New()
    )
    canaryCfg, testCfgs := mustLoadConfigs(vm, *cfgPath)
    }


    View Slide

70. func mustLoadConfigs(vm *otto.Otto, filename string) (*canary.Config, []*js.TestConfig) {
    cfg, err := os.Open(filename)
    if err != nil {
    log.WithError(err).WithField("filename", filename).Fatal("could not open configuration file")
    }
    defer cfg.Close()
    canaryConfig, testCfgs, err := canary.Load(vm, cfg)
    if err != nil {
    log.WithError(err).Fatal("cannot load canary test configs")
    }
    return canaryConfig, testCfgs
    }


    View Slide

71. The Test Runner


    View Slide

72. // internal/js/runner/runner.go
    func Run(ctx context.Context, vm *otto.Otto, jsctx *js.Context, test *js.Test, id string) error {
    testVM := vm.Copy()
    done := make(chan struct{})
    go func() {
    select {
    case <-ctx.Done():
    testVM.Interrupt <- func() { panic(ctx.Err()) }
    case <-done:
    }
    }()
    _, err := testVM.Run(test.Script)
    if oe, ok := err.(*otto.Error); ok {
    err = errors.New(oe.String())
    }
    close(done)
    return err
    }


    View Slide

73. Extending the VM with logging,
    HTTP, and standard library
    functionality


    View Slide

74. Standard Library Functions


    View Slide

75. // internal/js/context/stdlib.go
    func LoadStdLib(ctx context.Context, vm *otto.Otto, pkgname string) error {
    v, err := vm.Run(`({})`)
    if err != nil {
    return err
    }
    pkg := v.Object()
    for name, subpkg := range map[string]func(*otto.Otto) (otto.Value, error){
    "time": (&timePkg{ctx: ctx}).load,
    "os": (&osPkg{ctx: ctx}).load,
    "do": (newDoPkg(ctx)).load,
    } {
    v, err := subpkg(vm)
    if err != nil {
    return fmt.Errorf("can't load package %q: %v", name, err)
    }
    if err := pkg.Set(name, v); err != nil {
    return fmt.Errorf("can't set package %q: %v", name, err)
    }
    }
    return vm.Set(pkgname, pkg)
    }


    View Slide

76. type osPkg struct {
    ctx context.Context
    }
    func (svc *osPkg) load(vm *otto.Otto) (otto.Value, error) {
    return ottoutil.ToPkg(vm, map[string]func(all otto.FunctionCall) otto.Value{
    "getenv": svc.getenv,
    }), nil
    }
    func (svc *osPkg) getenv(all otto.FunctionCall) otto.Value {
    vm := all.Otto
    key := ottoutil.String(vm, all.Argument(0))
    v, err := otto.ToValue(os.Getenv(key))
    if err != nil {
    ottoutil.Throw(vm, "can't set string value: %v", err)
    }
    return v
    }


    View Slide

77. var secret = std.os.getenv("SOME_SECRET_VARIABLE");


    View Slide

78. HTTP Support


    View Slide

79. // internal/js/context/http.go
    // LoadHTTP loads an HTTP package in the VM that sends HTTP requests using the
    // given client.
    func LoadHTTP(vm *otto.Otto, pkgname string, client *http.Client, cfgReq
    func(*http.Request) *http.Request) error {
    v, err := (&httpPkg{client: client, cfgReq: cfgReq}).load(vm)
    if err != nil {
    return err
    }
    return vm.Set(pkgname, v)
    }


    View Slide

80. type httpPkg struct {
    client *http.Client
    cfgReq func(*http.Request) *http.Request
    }
    func (hpkg *httpPkg) load(vm *otto.Otto) (otto.Value, error) {
    v, err := vm.Run(`({})`)
    if err != nil {
    return q, err
    }
    pkg := v.Object()
    for name, method := range map[string]func(all otto.FunctionCall) otto.Value{
    "do": hpkg.do,
    } {
    if err := pkg.Set(name, method); err != nil {
    return q, fmt.Errorf("can't set method %q, %v", name, err)
    }
    }
    return pkg.Value(), nil
    }


    View Slide

81. func (hpkg *httpPkg) do(all otto.FunctionCall) otto.Value {
    vm := all.Otto
    var (
    method = ottoutil.String(vm, all.Argument(0))
    url = ottoutil.String(vm, all.Argument(1))
    headers = ottoutil.StringMapSlice(vm, all.Argument(2))
    body = ottoutil.String(vm, all.Argument(3))
    )
    req, err := http.NewRequest(method, url, strings.NewReader(body))
    if err != nil {
    ottoutil.Throw(vm, err.Error())
    }
    for k, vals := range headers {
    for _, val := range vals {
    req.Header.Add(k, val)
    }
    }
    resp, err := hpkg.client.Do(hpkg.cfgReq(req))
    if err != nil {
    ottoutil.Throw(vm, err.Error())
    }
    defer resp.Body.Close()
    respBody, err := ioutil.ReadAll(resp.Body)
    if err != nil {
    ottoutil.Throw(vm, err.Error())
    }
    v, err := vm.Run(`({})`)
    if err != nil {
    ottoutil.Throw(vm, err.Error())
    }
    pkg := v.Object()
    for name, value := range map[string]interface{}{
    "code": resp.StatusCode,
    "headers": map[string][]string(resp.Header),
    "body": string(respBody),
    } {
    if err := pkg.Set(name, value); err != nil {
    ottoutil.Throw(vm, err.Error())
    }
    }
    return v
    }


    View Slide

82. var response = http.do('GET', 'https://icanhazip.com', {});


    View Slide

83. Structured Logging


    View Slide

84. // internal/js/context/log.go
    // LoadLog loads a log package in the VM that logs to the given logger
    func LoadLog(vm *otto.Otto, pkgname string, ll log.FieldLogger) error {
    // Setup the logging formatter to be structured as JSON formatted.
    log.SetFormatter(&log.JSONFormatter{})
    // Output the stdout for capturing.
    log.SetOutput(os.Stdout)
    v, err := (&logger{ll: ll}).load(vm)
    if err != nil {
    return err
    }
    return vm.Set(pkgname, v)
    }


    View Slide

85. type logger struct {
    ll log.FieldLogger
    }


    View Slide

86. func (ll *logger) load(vm *otto.Otto) (otto.Value, error) {
    v, err := vm.Run(`({})`)
    if err != nil {
    return q, err
    }
    pkg := v.Object()
    for name, method := range map[string]func(all otto.FunctionCall) otto.Value{
    "kv": ll.kv,
    "info": ll.info,
    "error": ll.error,
    "fail": ll.fail,
    } {
    if err := pkg.Set(name, method); err != nil {
    return q, fmt.Errorf("can't set method %q, %v", name, err)
    }
    }
    return pkg.Value(), nil
    }


    View Slide

87. func (ll *logger) kv(all otto.FunctionCall) otto.Value {
    vm := all.Otto
    var child *log.Entry
    switch {
    case all.Argument(0).IsObject():
    obj := all.Argument(0).Object()
    keys := obj.Keys()
    f := make(log.Fields, len(keys))
    for _, key := range obj.Keys() {
    v, err := obj.Get(key)
    if err != nil {
    ottoutil.Throw(vm, err.Error())
    }
    gov, err := v.Export()
    if err != nil {
    ottoutil.Throw(vm, err.Error())
    }
    f[key] = gov
    }
    child = ll.ll.WithFields(f)
    case len(all.ArgumentList)%2 == 0:
    args := all.ArgumentList
    f := make(log.Fields, len(args)/2)
    for i := 0; i < len(args); i += 2 {
    k := ottoutil.String(vm, args[i])
    v, err := args[i+1].Export()
    if err != nil {
    ottoutil.Throw(vm, err.Error())
    }
    f[k] = v
    }
    child = ll.ll.WithFields(f)
    default:
    ottoutil.Throw(vm, "invalid call to log.kv")
    }
    v, err := (&logger{ll: child}).load(vm)
    if err != nil {
    ottoutil.Throw(vm, err.Error())
    }
    return v
    }


    View Slide

88. var q = otto.UndefinedValue()
    func (ll *logger) info(all otto.FunctionCall) otto.Value {
    vm := all.Otto
    msg := ottoutil.String(vm, all.Argument(0))
    ll.ll.Info(msg)
    return q
    }


    View Slide

89. func (ll *logger) fail(all otto.FunctionCall) otto.Value {
    vm := all.Otto
    msg := ottoutil.String(vm, all.Argument(0))
    ll.ll.Error(msg)
    ottoutil.Throw(all.Otto, msg)
    return q
    }


    View Slide

90. log.kv('foo', 'bar').info('this is an example message');


    View Slide

91. Let’s add them to the VM in
    the runner


    View Slide

92. func Run(ctx context.Context, vm *otto.Otto, jsctx *js.Context, test *js.Test, id string) error {
    testVM := vm.Copy()
    reqConfig := func(req *http.Request) *http.Request {
    return req.WithContext(ctx)
    }
    if err := jscontext.LoadStdLib(ctx, testVM, "std"); err != nil {
    return fmt.Errorf("can't setup std package in VM: %v", err)
    }
    if err := jscontext.LoadHTTP(testVM, "http", jsctx.HTTPClient, reqConfig); err != nil {
    return fmt.Errorf("can't setup HTTP package in VM: %v", err)
    }
    if err := jscontext.LoadLog(testVM, "log", jsctx.Log); err != nil {
    return fmt.Errorf("can't setup LOG package in VM: %v", err)
    }
    …
    }


    View Slide

93. Let's add the runner to the
    daemon.


    View Slide

94. func main() {
    log.SetFormatter(&log.JSONFormatter{})
    // Output the stdout for capturing.
    log.SetOutput(os.Stdout)
    var (
    cfgPath = flag.String("cfg", "config.js", "path to a JS config file")
    workDir = flag.String("work.dir", ".", "directory from which to run, should match expectations about
    relative paths in cfg.file")
    )
    flag.Parse()
    if *workDir != "" {
    if err := os.Chdir(*workDir); err != nil {
    log.WithError(err).WithField("work.dir", *workDir).Fatal("can't change dir")
    }
    }
    var (
    ctx = context.Background()
    vm = otto.New()
    )
    canaryCfg, testCfgs := mustLoadConfigs(vm, *cfgPath)
    launchTests(vm, canaryCfg, testCfgs)
    // Block forever because we want the tests to run forever.
    select {}
    }


    View Slide

95. func launchTests(vm *otto.Otto, config *canary.Config, configs
    []*js.TestConfig) {
    for _, cfg := range configs {
    go runTestForever(db, met, vm, cfg, cfg.Test())
    }
    }


    View Slide

96. func runTestForever(db dbpkg.CanaryStore, met *metrics.Node, vm *otto.Otto, cfg *js.TestConfig, test *js.Test) {
    ll := log.WithFields(log.Fields{
    "test.name": test.Name,
    })
    for {
    go func(vm *otto.Otto) {
    testID := uuid.New()
    ll = ll.WithField("test.id", testID)
    testCtx := &js.Context{
    Log: ll,
    HTTPClient: &http.Client{
    Transport: http.DefaultTransport,
    },
    }
    ctx, cancel := context.WithTimeout(context.Background(), cfg.Timeout)
    defer cancel()
    terr := runner.Run(ctx, vm, testCtx, test, testID)
    if terr != nil {
    ll.WithError(terr).Error("test failed")
    }
    }(vm.Copy()) // copy VM to avoid polluting global namespace
    // We'll run the test again after the duration we defined.
    time.Sleep(cfg.Frequency)
    }
    }


    View Slide

97. Saving Test Execution Results
    to a Database


    View Slide

98. View Slide

99. // internal/db/db.go
    type CanaryStore interface {
    StartTest(id string, testName string, startTime time.Time) (*TestInstance, error)
    EndTest(test *TestInstance, failure error, endAt time.Time) error
    ListTests() ([]TestInstance, error)
    ListOngoingTests() ([]TestInstance, error)
    FindTestByID(id string) (*TestInstance, error)
    Close() error
    }


    View Slide

100. // internal/db/models.go
     // TestInstance collects details about the instance of a unique
     // test execution.
     type TestInstance struct {
     TestID string `json:"id,omitempty"`
     TestName string `json:"name,omitempty"`
     StartAt time.Time `json:"start_at,omitempty"`
     EndAt time.Time `json:"end_at,omitempty"`
     Pass bool `json:"pass,omitempty"`
     FailCause string `json:"fail_cause,omitempty"`
     }
     // BoltTestInstance is what gets serialized and saved to the Bolt database. Only
     // difference is that we're going to be using strings for StartAt and EndAt
     type BoltTestInstance struct {
     TestID string `json:"id,omitempty"`
     TestName string `json:"name,omitempty"`
     StartAt string `json:"start_at,omitempty"`
     EndAt string `json:"end_at,omitempty"`
     Pass bool `json:"pass,omitempty"`
     FailCause string `json:"fail_cause,omitempty"`
     }


     View Slide

101. var _ CanaryStore = (*boltStore)(nil)
     type boltStore struct {
     db *bolt.DB
     ongoingMu sync.RWMutex
     ongoing map[string]TestInstance
     cancel context.CancelFunc
     }


     View Slide

102. // internal/db/db.go
     func (db *boltStore) StartTest(id string, testName string, startTime
     time.Time) (*TestInstance, error) {
     test := &TestInstance{
     TestID: id,
     TestName: testName,
     StartAt: startTime.UTC(),
     }
     // keep in memory until its finished
     db.ongoingMu.Lock()
     db.ongoing[id] = *test
     db.ongoingMu.Unlock()
     return test, nil
     }


     View Slide

103. func (db *boltStore) EndTest(test *TestInstance, failure error, endAt time.Time) error {
     db.ongoingMu.Lock()
     defer db.ongoingMu.Unlock()
     t, ok := db.ongoing[test.TestID]
     if !ok {
     return fmt.Errorf("test with ID does not exist: %q", test.TestID)
     }
     delete(db.ongoing, test.TestID)
     t.Pass = failure == nil
     if failure != nil {
     t.FailCause = failure.Error()
     }
     t.EndAt = endAt
     return insertTest(db.db, &t)
     }


     View Slide

104. func insertTest(db *bolt.DB, test *TestInstance) error {
     return db.Update(func(tx *bolt.Tx) error {
     b := tx.Bucket(testsBucket)
     // Make this something that is saveable by the database.
     dbTest := &BoltTestInstance{
     TestID: test.TestID,
     TestName: test.TestName,
     StartAt: test.StartAt.UTC().Format(time.RFC3339),
     EndAt: test.StartAt.UTC().Format(time.RFC3339),
     Pass: test.Pass,
     FailCause: test.FailCause,
     }
     // Marshal and save the encoded test.
     if buf, err := json.Marshal(dbTest); err != nil {
     return err
     } else if err := b.Put([]byte(dbTest.TestID), buf); err != nil {
     return err
     }
     return nil
     })
     }


     View Slide

105. Let’s add it to the daemon.


     View Slide

106. // cmd/canaryd/main.go
     func main() {
     log.SetFormatter(&log.JSONFormatter{})
     // Output the stdout for capturing.
     log.SetOutput(os.Stdout)
     var (
     cfgPath = flag.String("cfg", "config.js", "path to a JS config file")
     workDir = flag.String("work.dir", ".", "directory from which to run, should match expectations about relative paths in
     cfg.file")
     dbPath = flag.String("db.file", "canary.db", "file for the canary database")
     )
     flag.Parse()
     var (
     ctx = context.Background()
     vm = otto.New()
     )
     db := mustOpenBolt(*dbPath)
     defer db.Close()
     canaryCfg, testCfgs := mustLoadConfigs(vm, *cfgPath)
     launchTests(db, vm, canaryCfg, testCfgs)
     // Block forever because we want the tests to run forever.
     select {}
     }


     View Slide

107. func mustOpenBolt(path string) dbpkg.CanaryStore {
     db, err := dbpkg.NewBoltStore(path)
     if err != nil {
     log.WithError(err).Fatal("can't open database")
     }
     return db
     }


     View Slide

108. func runTestForever(db dbpkg.CanaryStore, met *metrics.Node, vm *otto.Otto, cfg *js.TestConfig, test *js.Test) {
     …
     for {
     go func(vm *otto.Otto) {
     testID := uuid.New()
     ll = ll.WithField("test.id", testID)
     testCtx := &js.Context{
     Log: ll,
     HTTPClient: &http.Client{
     Transport: http.DefaultTransport,
     },
     }
     dbtest, err := db.StartTest(
     testID,
     test.Name,
     time.Now(),
     )
     if err != nil {
     ll.WithError(err).Error("could not start the test")
     }
     ctx, cancel := context.WithTimeout(context.Background(), cfg.Timeout)
     defer cancel()
     terr := runner.Run(ctx, vm, testCtx, test, testID)
     if terr != nil {
     ll.WithError(terr).Error("test failed")
     }
     if err := db.EndTest(dbtest, terr, time.Now()); err != nil {
     ll.WithError(err).Error("couldn't mark test as being ended")
     }
     }(vm.Copy()) // copy VM to avoid polluting global namespace
     // We'll run the test again after the duration we defined.
     time.Sleep(cfg.Frequency)
     }
     }


     View Slide

109. Front-End for Viewing Test
     Execution Results


     View Slide

110. View Slide

111. // internal/app/serve.go
     import (
     "github.com/99designs/gqlgen/handler"
     "github.com/gorilla/mux"
     "github.com/iheanyi/simple-canary/internal/db"
     "github.com/sirupsen/logrus"
     )
     // App is an instance of the dashboard for the canary.
     type App struct {
     l logrus.FieldLogger
     db db.CanaryStore
     }
     func New(db db.CanaryStore, r *mux.Router) *App {
     app := &App{
     l: logrus.WithField("component", "app"),
     db: db,
     }
     r.Handle("/", handler.Playground("GraphQL Playground", "/query"))
     r.Handle("/query", handler.GraphQL(NewExecutableSchema(Config{Resolvers: &Resolver{
     db: db,
     }})))
     return app
     }


     View Slide

112. type TestInstance {
     id: ID!
     name: String!
     start_at: Time!
     end_at: Time
     pass: Boolean
     fail_cause: String
     }
     type Query {
     tests: [TestInstance!]!
     test(id: String!): TestInstance
     ongoingTests: [TestInstance!]!
     }
     scalar Time


     View Slide

113. type Resolver struct {
     db dbpkg.CanaryStore
     }
     func (r *Resolver) Query() QueryResolver {
     return &queryResolver{r}
     }
     func (r *Resolver) TestInstance() TestInstanceResolver {
     return &testInstanceResolver{r}
     }
     type queryResolver struct{ *Resolver }
     func (r *queryResolver) Tests(ctx context.Context) ([]dbpkg.TestInstance, error) {
     tests, err := r.db.ListTests()
     return tests, err
     }
     func (r *queryResolver) Test(ctx context.Context, id string) (*dbpkg.TestInstance, error) {
     test, err := r.db.FindTestByID(id)
     return test, err
     }
     func (r *queryResolver) OngoingTests(ctx context.Context) ([]dbpkg.TestInstance, error) {
     tests, err := r.db.ListOngoingTests()
     return tests, err
     }
     type testInstanceResolver struct{ *Resolver }
     func (r *testInstanceResolver) ID(ctx context.Context, obj *dbpkg.TestInstance) (string, error) {
     return obj.TestID, nil
     }
     func (r *testInstanceResolver) Name(ctx context.Context, obj *dbpkg.TestInstance) (string, error) {
     return obj.TestName, nil
     }
     func (r *testInstanceResolver) StartAt(ctx context.Context, obj *dbpkg.TestInstance) (time.Time, error) {
     return obj.StartAt, nil
     }
     func (r *testInstanceResolver) EndAt(ctx context.Context, obj *dbpkg.TestInstance) (*time.Time, error) {
     return &obj.EndAt, nil
     }
     func (r *testInstanceResolver) FailCause(ctx context.Context, obj *dbpkg.TestInstance) (*string, error) {
     return &obj.FailCause, nil
     }


     View Slide

114. Back to the daemon.


     View Slide

115. func main() {
     log.SetFormatter(&log.JSONFormatter{})
     // Output the stdout for capturing.
     log.SetOutput(os.Stdout)
     var (
     …
     listenHost = flag.String("listen.host", "", "interface on which to listen")
     listenPort = flag.String("listen.port", "8080", "port on which to listen")
     )
     …
     l := mustListen(*listenHost, *listenPort)
     db := mustOpenBolt(*dbPath)
     defer db.Close()
     if err := launchHTTP(ctx, l, db); err != nil {
     log.WithError(err).Fatal("can't launch http server")
     }
     …
     }


     View Slide

116. func launchHTTP(
     ctx context.Context,
     l net.Listener,
     db dbpkg.CanaryStore,
     ) error {
     addr := l.Addr().(*net.TCPAddr)
     host, err := os.Hostname()
     if err != nil {
     return fmt.Errorf("can't get hostname: %v", err)
     }
     host = net.JoinHostPort(host, strconv.Itoa(addr.Port))
     r := mux.NewRouter().Host(host).Subrouter()
     _ = app.New(db, r)
     log.WithField("host", host).Info("API starting")
     go http.Serve(l, r)
     return nil
     }


     View Slide

117. View Slide

118. Last, but not least, metrics.


     View Slide

119. // internal/metrics/metrics.go
     package metrics
     import (
     "net/http"
     "github.com/prometheus/client_golang/prometheus"
     "github.com/prometheus/client_golang/prometheus/promhttp"
     )
     // Node is a wrapper around Prometheus's registerer interface
     type Node struct {
     registry prometheus.Registerer
     }
     // Prometheus returns an instance of the metrics node and the prometheus
     // handler.
     func Prometheus() (*Node, http.Handler) {
     registry := prometheus.NewRegistry()
     handler := promhttp.HandlerFor(registry, promhttp.HandlerOpts{})
     registry.MustRegister(prometheus.NewProcessCollector(prometheus.ProcessCollectorOpts{}))
     registry.MustRegister(prometheus.NewGoCollector())
     return &Node{
     registry: registry,
     }, handler
     }


     View Slide

120. // cmd/canaryd/main.go
     func main() {
     …
     met, hdl := metrics.Prometheus()
     …
     if err := launchHTTP(ctx, l, hdl, db); err != nil {
     log.WithError(err).Fatal("can't launch http server")
     }
     canaryCfg, testCfgs := mustLoadConfigs(vm, *cfgPath)
     launchTests(db, met, vm, canaryCfg, testCfgs)
     // Block forever because we want the tests to run forever.
     select {}
     }


     View Slide

121. func launchHTTP(
     ctx context.Context,
     l net.Listener,
     promhdl http.Handler,
     db dbpkg.CanaryStore,
     ) error {
     addr := l.Addr().(*net.TCPAddr)
     host, err := os.Hostname()
     if err != nil {
     return fmt.Errorf("can't get hostname: %v", err)
     }
     host = net.JoinHostPort(host, strconv.Itoa(addr.Port))
     r := mux.NewRouter().Host(host).Subrouter()
     _ = app.New(db, r)
     r.PathPrefix("/metrics").Handler(promhdl)
     log.WithField("host", host).Info("API starting")
     go http.Serve(l, r)
     return nil
     }


     View Slide

122. func runTestForever(db dbpkg.CanaryStore, met *metrics.Node, vm *otto.Otto, cfg *js.TestConfig, test *js.Test) {
     ll := log.WithFields(log.Fields{
     "test.name": test.Name,
     })
     tmet := met.Labels(map[string]string{
     "test_name": test.Name,
     })
     var (
     started = tmet.Counter("test_started_count", "Number of tests that were started")
     finished = tmet.Counter("test_finished_count", "Number of tests that have finished", "result")
     running = tmet.Gauge("test_running_total", "Tests that are currently running")
     _ = tmet.Summary("test_duration_seconds", "Duration of tests", []float64{0.5, 0.75, 0.9, 0.99, 1.0}, "result")
     )
     …
     }


     View Slide

123. func runTestForever(db dbpkg.CanaryStore, met *metrics.Node, vm *otto.Otto, cfg *js.TestConfig, test *js.Test) {
     …
     for {
     go func(vm *otto.Otto) {
     …
     started.WithLabelValues().Add(1)
     running.Add(1)
     defer running.Add(-1)
     ctx, cancel := context.WithTimeout(context.Background(), cfg.Timeout)
     defer cancel()
     terr := runner.Run(ctx, vm, testCtx, test, testID)
     if terr != nil {
     finished.With(prometheus.Labels{"result": "fail"}).Add(1)
     ll.WithError(terr).Error("test failed")
     } else {
     finished.With(prometheus.Labels{"result": "pass"}).Add(1)
     }
     if err := db.EndTest(dbtest, terr, time.Now()); err != nil {
     ll.WithError(err).Error("couldn't mark test as being ended")
     }
     }(vm.Copy()) // copy VM to avoid polluting global namespace
     // We'll run the test again after the duration we defined.
     time.Sleep(cfg.Frequency)
     }
     }


     View Slide

124. View Slide

125. We're done! Let's see a demo?


     View Slide

126. https://github.com/iheanyi/
     simple-canary


     View Slide

127. Special thanks to Antoine Grondin


     View Slide

128. Questions?


     View Slide

129. Thank you!
     @kwuchu


     View Slide
